Nibe SMO 05 User manual

User manual
LEK
LEK
NIBE™ SMO 05
Accessories
UHB GB 1146-1
431200

4XLFN JXLGH
1DYLJDWLRQ 2N EXWWRQ FRQILUPVHOHFW
%DFN EXWWRQ EDFNXQGRH[LW
8SGRZQ EXWWRQV
PRYHLQFUHDVHUHGXFH
A detailed explanation of the button functions can be found on page 10.
How to scroll through menus and make different settings is described on
page 12.
6HW WKH LQGRRU FOLPDWH
LQGRRU FOLPDWH
KRW ZDWHU
LQIR
P\ V\VWHP ;
The mode for setting the indoor temperature is reached, when in the start
mode in the main menu, by pressing the OK button twice. Read more
about the settings on page 19.
,QFUHDVH KRW ZDWHU YROXPH
7(0325$5< /8; 
RII
;
;
To temporarily increase the amount of hot water (if a hot water heater is
installed to your SMO 05), first push the down button once to mark menu
2 (water droplet) and then press the OK button twice. Read more about
the settings on page 31.
In event of disturbances in comfort
If a disturbance in comfort of any type occurs there are some measures
that can be taken before you need to contact your installer. See page 44
for instructions.

Table of Contents
1 Important information 2
Installation data 2
Safety information 3
Serial number 4
Country specific information 4
SMO 05 – An excellent choice 7
2 The control module – the heart of the house 8
Control module's function 8
Contact with SMO 05 9
Maintenance of SMO 05 15
3 SMO 05 – at your service 18
Set the indoor climate 18
Set the hot water capacity 30
Get information 34
Adjust the heat pump 35
4 Disturbances in comfort 43
Manage alarm 43
Troubleshooting 44
Add. heat only 46
5 Technical data 47
6 Glossary 48
Item register 52
1NIBE™ SMO 05Table of Contents |

1Important information
Installation data
SMO 05Product
Serial number
Installation date
Installer
Type of docking
Accumulator/hot water heater
Heat pump/output size
Add. heat type/power
SetDe-
fault
set-
tings
NameNo.
0/7heating curve (offset/curve slope)1.9.1
Serial number must always be given
Certification that the installation is carried out according to instructions in
NIBE's installer manual and applicable regulations.
_________________________Signed__________________Date
NIBE™ SMO 05Chapter 1 | Important information2

Safety information
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appli-
ance.
Rights to make any design or technical modifications are reserved.
©NIBE 2011.
Symbols
NOTE
This symbol indicates danger to machine or person.
Caution
This symbol indicates important information about what you should observe
when maintaining your installation.
TIP
This symbol indicates tips on how to facilitate using the product.
Marking
This accessory is CE marked and fulfils IP20 (room unit) and IP21 (unit box).
The CE marking means that NIBE ensures that the product meets all regula-
tions that are placed on it based on relevant EU directives. The CE mark is
obligatory for most products sold in the EU, regardless where they are made.
IP20 means that the product can be touched by hand, that objects with a
diameter larger than or equivalent to12.5 mm cannot penetrate and cause
damage.
3NIBE™ SMO 05Chapter 1 | Important information

Serial number
The serial number can be found on one long side of the cover on the unit
box.
LEK
6HULDO QXPEHU
Caution
Always give the product's serial number when reporting a fault.
Country specific information
Great Britain
This installation is subject to building regulation approval, notify the local
Authority of intention to install.
Use only manufacturer’s recommended replacement parts.
Nibe is a licensed member of the Benchmark Scheme which aims to improve
the standards of installation and commissioning of domestic heating and hot
water systems in the UK and to encourage regular servicing to optimise safety,
efficiency and performance.
Benchmark is managed and promoted by the Heating and Hotwater Industry
Council. For more information visit www.centralheating.co.uk
NIBE™ SMO 05Chapter 1 | Important information4

Warranty information
Thank you for installing a new NIBE heat pump in your home.
NIBE heat pumps are manufactured in Sweden to the very highest standard
so we are pleased to offer our customers a comprehensive guarantee.
The product is guaranteed for 24 months for parts and labour from the date
of installation or 33 months from the date of manufacture, whichever is the
shorter.
The NIBE guarantee is based on the unit being installed and commissioned
by a NIBE accredited installer, serviced every year and the Benchmark docu-
ments completed. Where this condition is not met, any chargeable spare
parts or components issued within the applicable guarantee period still benefit
from a 12 month warranty from the date of issue by the manufacturer.
We recommend the installer completes and returns as soon as possible, your
guarantee registration card or completes the guarantee form on the NIBE
website www.nibe.co.uk.
Please ensure that the installer has fully completed the Benchmark Checklist
in the end of the Installation Instructions supplied with the product and that
you have signed to say that you have received a full and clear explanation of
its operation. The installer is legally required to complete a commissioning
checklist as a means of complying with the appropriate Building Regulations
(England and Wales).
All installations must be notified to Local Area Building Control either directly
or through a Competent Persons Scheme. A Building Regulations Compliance
Certificate will then be issued to the customer who should, on receipt, write
the Notification Number on the Benchmark Checklist.
This product should be serviced regularly to optimise its safety, efficiency and
performance. The service engineer should complete the relevant Service Record
on the Benchmark Checklist after each service.
The Benchmark Checklist may be required in the event of any warranty work
and as supporting documentation relating to home improvements in the
optional documents section of the Home Information Pack.
5NIBE™ SMO 05Chapter 1 | Important information

NIBE™ SMO 05Chapter 1 | Important information6

SMO 05 – An excellent choice
SMO 05 is a control module, which has been introduced to supply your home
with inexpensive and environmentally friendly heating. Heat production is
reliable and economical with a NIBE air/water heat pump and accumulator/wa-
ter heater.
An additional heater (for example electric/oil/gas boiler) can engage automat-
ically if something unexpected should occur or as reserve operation.
Excellent properties for SMO 05:
႑Easy to read display
The room unit has an easy to read display with easy-to-understand menus
that facilitate setting a comfortable indoor climate.
႑Easy to install
SMO 05 is easy to install together with NIBE
F2015/F2025/F2016/F2026/F2300. When installing together with these,
the control module is connected to the heat pump, which enables you to
see any heat pump alarms in SMO 05.
႑Two part design
SMO 05 consists of a room unit and a unit box. The room unit can be
positioned in a convenient place for the user and the unit box can be
positioned in another location together with other equipment in your
system.
7NIBE™ SMO 05Chapter 1 | Important information

2The control module – the heart
of the house
Control module's function
SMO 05 is a simple control module, which, together with NIBE air/water heat
pump, accumulator/water heater and additional heater (e.g. electric/oil/gas
boiler), creates a complete installation.
NIBE™ SMO 05Chapter 2 | The control module – the heart of the house8

Contact with SMO 05
Room unit
$
% & ' (
There is a room unit for SMO 05 that is used to control your installation. Here
you:
႑sets the indoor climate and hot water as well as adjusts the heat pump
to your needs.
႑receive information about settings, status and events.
႑see different types of alarms and receive instructions about how they are
to be rectified.
Display
Instructions, settings and operational information are shown on the
display.
A
Stand-by button
The room unit can be switched to stand-by mode using the stand-by
button. Heat pump operation is not affected by pressing the button.
B
Back button
The back button is used to:
႑go back to the previous menu.
႑change a setting that has not been confirmed.
C
9NIBE™ SMO 05Chapter 2 | The control module – the heart of the house

OK button
The OK button is used to:
႑confirm selections of sub menus/options/set values.
D
Up and down buttons
With the up and down buttons you can:
႑scroll in menus and between options.
႑increase and decrease the values.
႑change page in multiple page instructions
E
Menu system
When the room unit starts up you come to the information menu. Basic in-
formation about your system status is shown here.
2XWGRRU WHPSHUDWXUH
,QGRRU WHPSHUDWXUH
7HPS OX[ DFWLYDWHG
+RW ZDWHU WHPS
Press any button to go to the main menu.
NIBE™ SMO 05Chapter 2 | The control module – the heart of the house10

LQGRRU FOLPDWH
KRW ZDWHU
LQIR
P\ V\VWHP
,QGRRU WHPSHUDWXUH
LI URRP VHQVRUV DUH
LQVWDOOHG
+RW ZDWHU WHPS
,QIRUPDWLRQ DERXW
RSHUDWLRQ
,QIRUPDWLRQ DERXW WKH
KHDWLQJ V\VWHP
The information menu shows:
႑on starting
႑when the back button in the main menu is pressed
႑after 15 minutes of inactivity.
In the event of an alarm a symbol is shown in the display together with the
alarm's number. See page 44 for instructions.
In the other menus the alarm symbol is shown in the bottom right hand
corner.
11NIBE™ SMO 05Chapter 2 | The control module – the heart of the house

INDOOR CLIMATE
Setting the indoor climate. See page 18.
Menu 1
HOT WATER
Setting the hot water production. See page 30.
Menu 2
This menu only appears if a water heater is activated in the menu system.
INFO
Display of temperature and other operating information. See page 34.
Menu 3
MY INSTALLATION
Setting operating mode etc. See page 35.
Menu 4
Operation
To move the cursor, press the up or down button. The marked position is
brighter and/or has a turned up tab.
Selecting menu
To advance in the menu system select a sub-menu by marking it by using the
up and down buttons and then pressing the OK button.
NIBE™ SMO 05Chapter 2 | The control module – the heart of the house12

Selecting options
7(0325$5< /8; 
RII
6HOHFWDEOH RSWLRQV
In an options menu the current selected option is indicated by a green
tick.
To select another option:
Mark the applicable option using the up or down button. One of
the options is pre-selected (white).
1.
Press the OK button to confirm the selected option. The selected
option has a green tick.
2.
13NIBE™ SMO 05Chapter 2 | The control module – the heart of the house

Setting a value
7(03(5$785( 
$GMXVWDEOH YDOXH
To set a value:
Mark the value you want to set using the up or down button.1.
Press the OK button. The background of the value becomes
green, which means that you have accessed the setting mode.
2.
Press the up button to increase the value or the down button
to reduce the value.
3.
Press the OK button to confirm the value you have set. To undo
and return to the original value, press the back button.
4.
NIBE™ SMO 05Chapter 2 | The control module – the heart of the house14

Maintenance of SMO 05
Regular checks
All servicing must be carried out by a person competent for the job.
Your heat pump requires minimal maintenance after commissioning. On the
other hand, it is recommended that you check your installation regularly. For
more information regarding the maintenance of heat pumps and/or accumu-
lator tanks/water heaters, refer to the relevant manual.
If something unusual occurs, messages about the malfunction appear in the
display in the form of different alarm texts. See alarm management on page
43.
Saving tips
Your heat pump installation produces heat and hot water. This occurs via the
control settings you made.
Factors that affect the energy consumption are, for example, indoor temper-
ature, hot water consumption, the insulation level of the house and whether
the house has many large window surfaces. The position of the house, e.g.
wind exposure is also an affecting factor.
If you activate "Hot water Economy", less energy is used.
Power consumption
Increasing the indoor temperature one degree increases power consumption
by approx. 5%.
Domestic electricity
In the past it has been calculated that an average Swedish household has an
approximate annual consumption of 5000 kWh domestic electricity/year. In
today's society it is usually between 6000-12.000 kWh/year.
Approx-
imate
annual
con-
sump-
tion
(kWh)
Normal Output (W)Equipment
StandbyOperation
15NIBE™ SMO 05Chapter 2 | The control module – the heart of the house

Approx-
imate
annual
con-
sump-
tion
(kWh)
Normal Output (W)Equipment
3802200Flat-screen (Operation: 5 h/day, Standby: 19
h/day)
901011Digital box (Operation: 5 h/day, Standby: 19
h/day)
45515DVD (Operation: 2 h/week)
672160TV games console (Operation: 6 h/week)
50140Radio/stereo (Operation: 3 h/day)
1202100Computer incl. screen (Operation: 3 h/day,
standby 21 h/day)
175-60Bulb (Operation 8 h/day)
55-20Spot light, Halogen (Operation 8 h/day)
165-100Cooler (Operation: 24 h/day)
380-120Freezer (Operation: 24 h/day)
365-1500Oven, hob (Operation: 40 min/day)
310-3000Oven (Operation: 2 h/week)
730-2000Dishwasher, cold water connection (Operation
1 time/day)
730-2000Washing machine (Operation: 1 time/day)
730-2000Tumble drier (Operation: 1 time/day)
100-1000Vacuum cleaner (Operation: 2 h/week)
50-400Engine block heater (Operation: 1 h/day, 4
months a year)
100-800Passenger compartment heater (Operation: 1
h/day, 4 months a year)
These values are approximate example values.
Example: A family with 2 children live in a house with 1 flat-screen TV, 1 di-
gital box, 1 DVD player, 1 TV games console, 2 computers, 3 stereos, 2 bulbs
in the WC, 2 bulbs in the bathroom, 4 bulbs in the kitchen, 3 bulbs outside,
a washing machine, tumble drier, fridge, freezer, oven, vacuum cleaner, en-
gine block heater = 6240 kWh domestic electricity/year.
NIBE™ SMO 05Chapter 2 | The control module – the heart of the house16

Energy meter
Check the accommodation's energy meter regularly, preferably once a month.
This will indicate any changes in power consumption.
17NIBE™ SMO 05Chapter 2 | The control module – the heart of the house

3SMO 05 – at your service
Set the indoor climate
Overview
,1'225 &/,0$7( 
WHPSHUDWXUH
DGYDQFHG
Sub-menus
For the menu INDOOR CLIMATE there are several sub-menus. Status inform-
ation for the relevant menu can be found on the display to the right of the
menus.
temperature Setting the temperature for the climate system. The status in-
formation shows the set values for the climate system.
advanced Setting of heat curve, adjusting with external contact, minimum
value for supply temperature and room sensor.
NIBE™ SMO 05Chapter 3 | SMO 05 – at your service18
