KT&C 120-E230-001 User manual

HIGH PERFORMANCE BULLET CAMERA
OPERATION MANUAL
Thank you for choosing our high quality camera.
Before attempting to connect operate this unit, please read and follow these instructions.
ACCESSORIES FURNISHED
Bullet Camera Screw 3ea
Mounting Bracket Operation Manual
SPECIFICATIONS
M120-E230-001
Signal Format NTSC PAL
Image Device 1/3" 960H SONY EXview HAD CCD II
Scanning System 2 : 1 Interlace
H.Resolution 700TV Lines
Scanning Frequency 15.734KHz(H), 59.94Hz(V) 15.625KHz(H), 50Hz(V)
Total Pixels 1020(H) X 508(V) 1020(H) X 596(V)
Effective Pixels 976(H) X 494(V) 976(H) X 582(V)
Electronic Shutter 1/60 ~ 1/100,000 sec 1/50 ~ 1/100,000 sec
S/N Ratio More than 50dB(AGC OFF)
Gamma r =0.45
Min. Illumination 0.1Lux
Sync System Internal
Video Output 1.0 Vp-p Composite 75(Ω)
White Balance PUSH
2DNR ON
Power Consumption DC 12V (±10%), Max 83mA
Temperature Operating 14F ~ 122F(-10℃~ +50℃)
Storage -4F ~ 140F(-20℃~ +60℃)
Humidity Less than 80%
Lens Board Lens, Pinhole Lens
Specications and designs are subject to change for improving the functionality of this product without notice.
DIMENSIONS
Unit : mm
50
Ф40
28.6
24.8
1/4"-20 UNC
3-Ф3.2
INSTALLATION
When you install the camera, please glue up the end of cable to keep it stable.
This is for protecting the camera from the humidity problems.
DC12V
BNC FEMALE
DC12V POWER SUPPLY
VIDEO IN
TV MONITOR
• MONITOR CONNECTION• MOUNTING POSITION
75.8

This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions;
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
Note
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.”
WARNING
This is a class A product. In a domestic environment this product may cause radio interference in which
case the user may be required to take adequate measures.
Caution
Any changes or modifications in construction of this device which are not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
These servicing instructions are for use by qualified service personnel only.
To reduce the risk of electric shock do not perform any servicing other than that contained in the
operating instructions unless you are qualified to do so.
In USA and Canada, Use Class 2 Power Supply Only.
CAUTION
IMPORTANT SAFETY INSTRUCTION
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat
registers,stoves, or other apparatus (including ampliers) that produce heat.
9) Do not defeat the safety purpose of the polarized or
grounding- type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has
two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the
provided plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specied by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specied by
the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for
long periods of time.
14) Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
This symbol is intended to alert the user to the presence of uninsulated "dangerous voltage" within the
product's enclosure that may be of sufcient mangnitude to constitute a risk of electric shock to persons.
This symbol is intended to alert the user to the presence of important operating and
maintenance(servicing) instruction in the literature accompanying the appliance.
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems)
This marking shown on the product or its literature, indicate that it should not be disposed with
other household wastes at the end of its working life. To prevent possible harm to the environment
or human health from uncontrolled waste disposal, please separate this from other types of
wastes and recycle it responsibly to promote the sustainable reuse of material resources.
This product should not be mixed with other commercial wastes purchased this product, or their
local government ofce, for details of where and how they can take item for environmentally safe
recycling. Business users should contact their supplier and check the terms and conditions of the
purchase contract. Household users should contact either the retailer where they for disposal.
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER(OR BACK). NO USER.
SERVICING TO QUALIFED SERVICE PERSONNEL.
CAUTION
1. A regulated DC12V 300mA power supply is recommended for use with this camera for the best picture and the
most stable operation.
An unregulated power supply can cause damage to the camera. When unregulated power supply is applied,
product warranty will be out of subject.
2. It is recommended that the camera is used with a monitor that has a CCTV quality 75 video impedance level. If
your monitor is switched to high impedance then please adjust accordingly.
3. Do not attempt to disassemble the camera to gain access to the internal componets. Refer servicing to your
dealer.
4. Never face the camera towards the sun or any bright or reective light, which may cause smear on the picture and
possible damage to the CCD.
5. Do not remove the serial sticker for the warranty service.
