KTI Networks Gigabit Ethernet PCI Adapter KG-502T User manual

10/100/1000Base-T
Gigabit Ethernet PCI Adapter
KG-502T Ver.B
FCC Part 15'Class B
CISPR 22 Class B
Katron Technologies Inc.
15F-7, No. 79, Sec. 1, Hsin Tai Wu Rd.,Hsi-
chih, Taipei Hsien, Taiwan.
Te l :886-2-2698-3878
Fax:[phone]
E-mail:[email protected]
URL:http://www.ktinet.com.tw
KTI Networks Inc.
7400 Harwin Dr., Suite 120 Houston, Texas
77036 U.S.A.
Te l :713-266-3891
Fax:[phone]
E-mail:[email protected]
URL:http://www.ktinet.com
Trademarks: All brand names are trademarks or registered
trademarks of their respective holders.
This information is subject to change without prior notice.
Specifications:
Standards IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T
Ports 1 x 10/100/1000Mbps, RJ45
Supports Auto MDI/MDI-X
Host Interface 32-bit 33/66Mhz PCI Rev.2.1/2.2/2.3
Cables 10Base-T: Cat.3, 4, 5 or higher ( 100 meters max. )
100Base-TX: Cat.5, 5e or higher ( 100 meters max. )
1000Base-T: Cat.5e or higher ( 100 meters max. )
Network Data Ethernet: 10Mbps (Half-duplex) 20Mbps (Full-duplex)
Transfer Rate Fast Ethernet: 100Mbps (Half-duplex) 200Mbps (Full-duplex)
Gigabit Ethernet: 2000Mbps (Full-duplex)
LEDs Link
Act
Environment Operation Temperature: 0OC ~ 40OC
Relative Humidity: 5% ~ 90% non-condensing
Dimension 59 x 120 x 15 mm (WxDxH)
Power 5V
Approval FCC Class B, CE Mark Class B, VCCI-B
070309
Key Features:
 Supports 32-bit 33/66Mhz PCI Local Bus Master high-speed operation of Rev.2.1/2.2/2.3
specification
 Complies with 10/100/1000 Mbps full/half-duplex triple-speed operation
 Fully complies with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
 Supports IEEE 802.3x full duplex flow control
 Supports crossover detection and auto-correction
 Supports IEEE 802.1Q VLAN tagging
 8K bytes for transmit buffer, 64K bytes for receive buffer
