KTI Networks KE-PCI/T User manual

KE-PCI/T, KE-PCI
PCI Ethernet Card
10Mbps
Full Duplex
Plug and Play
User’s Guide

FCC Warning
This equipment has been tested and found
to comply with the regulations for a Class B
digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated
in a commercial environment. This
equipment generates, uses, and can radiate
radio frequency energy and, if not installed
and used in accordance with this user’s
guide, may cause harmful interference to
radio communications. Operation of this
equipment in a residential area is likely to
cause harmful interference, in which case
the user will be required to correct the
interference at his own expense.
CE Mark Warning
This is a Class B product. In a domestic
environment, this product may cause radio
interference, in which case the user may be
required to take adequate measures.
P/N: 6012-1050101

iii
Table of Contents
INTRODUCTION..................................................1
PCI ETHERNET CARD.......................................1
PRODUCT FEATURES .........................................2
PACKING LIST.....................................................3
INSTALLATION....................................................3
HARDWARE INSTALLATION..............................3
CONFIGURATION ................................................4
DRIVER INSTALLATION.....................................4
BOOT ROM INSTALLATION ............................4
PRODUCT SPECIFICATIONS.........................5

1
Introduction
Congratulations on your purchase of a PCI
10Mbps Ethernet adapter. This adapter was
designed and manufactured to give you
years of trouble-free and reliable service.
PCI Ethernet Card
The PCI Ethernet adapter is high
performance adapter compatible with version
2.0 of the PCI local bus specification and
support Plug and Play (PnP) function,
making it fully auto-configuration.
The adapter supports full-duplex mode. Full
duplex mode can be used to obtain
throughput up to 20Mbps when the twisted-
pair port connecting through an Ethernet
switching hub. This feature not only
increases the channel bandwidth from
10Mbps to 20Mbps but also avoids the
performance-degrading problem due to the
characteristic of the Ethernet CSMA/CD
protocol.
The Ethernet adapter includes a complete
set of drivers for popular Network Operating
System. The optional BOOT ROM device
allows the diskless workstation to be
connected to the network.

2
Product Features
lMeets PCI Local Bus specification,
Rev.2.0
lPCI 32-bit architecture
lCompliant to IEEE 802.3 10BASE-2 and
10BASE-T standards.
lSupports PCI Plug and Play configuration.
lSupports Full-Duplex Ethernet function to
double channel bandwidth.
lAutomatic port selection between
10BASE-2 interface(BNC) and 10BASE-T
interface(RJ-45)
lSupport 100ohm STP/UTP cables using
Category 3, 4 or 5
lOn-board socket for remote Boot ROM.
lLED Indicators
One LED on the bracket provides LINK
indicators.
State Description
On Normal data packet are received
or Link integrity pulse is detected
Off * When no twisted-pair connected
* No power source into hub
* Twisted-pair is faulty
* Non-10BASE-T device
connected at the other end of the
twisted pair
* A twisted-pair wire that exceeds
recommended length

3
Packing List
The adapter package should contain the
following items:
lOne 32-bit PCI Ethernet adapter
lThis User’s guide
lOne 3.5”driver diskette
lOne T-connector (for BNC port only)
If any of these items are missing contact your
reseller.
Installation
Hardware Installation
1. Turn OFF the computer, unplug the
power cord and open the computer
case.
2. Pick a free PCI expansion slot and
remove the expansion slot cover. Insert
the adapter into the slot until it is fully
seated. Secure the adapter.
3. Replace the computer cover and
connect the network adapter.
Reconnect the computer’s power cord
and plug it into the power outlet.

4
Configuration
This Ethernet adapter is automatically
configured when you power-on computer. In
certain computer, however, you must modify
BIOS by entering CMOS SETUP utility to
enable “PCI Device”and map INTA to an
appropriate address. Please refer to the
system documentation for details on
configuration the PCI SYSTEM BIOS.
Driver Installation
Before you connect adapter to the network,
you have to install the network driver first.
The driver for each Networking Operating
System is under a separate directory. A
HELPME.EXE file under root directory lists
the information and detailed installation
procedure of all the available driver.
Boot ROM Installation
The optional Boot ROM device allows you to
connect a diskless workstation to the
network. Perform the following steps to
install your Boot ROM device:
1. Insert the Boot ROM into the socket on
the adapter.
2. Refer to the installation procedure
provided by Networking Operating
System.

5
Product Specifications
Standards
Wiring connector
Bus Interface
I/O address
IRQ Line
Operating
Temperature
Humidity
Emissions
IEEE 10BASE-2,
10BASE-T
PCI Local Bus
specification Rev.2.1
BNC and RJ-45
32-bit PCI bus
Automatically determined
by configuration space
INTA, being assigned by
the BIOS to free I/O
address
0 °C –40 °C
(32 °F –104 °F)
10% to 90%
non-condensing
FCC Class B
CE Mark
