KUNK 1601 User manual

www.kunk.kr
THE BEST SMART MULTI-MIST
KUNK MANUALBOOK

USER MANUAL ENGLISH
KUNK MANUALBOOK

MANUAL
KUNK Smart Multi-Mist 18
TEL [phone]
HOMEPAGE www.kunk.kr
MANUFACTURER KUNK Co., Ltd.
COUNTRY OF MANUFACTURE South Korea
MODEL NO KUNK1601
·For your own safety, please read the cautions below properly
before using and during use of the device.
·This manual contains a warranty. Please read the manual and
keep it in case needed for a warranty claim.
This purchase warranty lasts 1 year after purchase.
·Be sure to install the APP provided by KUNK Co., Ltd. on your
smartphone and use it accordingly to the contents of this manual.

1 Device
2 Cartridge
Check before using
Cautions before using
1 Device
2 Cartridge
Cleaning
1 Product use order
2 Package Contents
3 Charging
4 Button
5 Connect APP
6 APP Functions
Using Device
20p
21p
30p
23p
Warranty 31p
Q&A 34p
INDEX
KUNK Smart Multi-Mist 19

Check before using
1 Product specification and color
COLOR White, Mint, Rose Pink, Gray
SIZE 75inch x 2.36inch x 1.18inch (70mm x 60mm x 30mm)
2 Device and parts
Device, 2 empty cartridges, Gel pad, USB charging cable, Pouch, Manual
3 LED, Button, Charging socket
4 Mist header, Cartridge
Button Mist
Cartridge Mist header
USB
Charging socket LED
Sticker
KUNK Smart Multi-Mist 20
Check before using

Cautions before using 1
Careless use may cause personal injury or property damage.
Please be sure to know the following points before using.
1 Device
Please use the device only for personal humidifier, diffuser and mist.
Do not connect USB plug with wet hands. This would carry a risk of
electric shock which could lead to serious injury.
An external shock may cause a breakdown of PRINTED CIRCUIT BOARD
inside the device. If a strong chemical solution comes into contact with
the surface of the device case, it may cause deformation of the device case.
Please contact us for case replacement of the device.
If the stickers (films) attached to the product are damaged or removed,
it cannot be exchanged / refunded because of product disassembly and
arbitrary operation.
Please note that it is not a waterproof product. A breakdown or
malfunction due to user’s careless, exchange / refund is not possible.
Continuously spraying the solution for more than 60 minutes
may cause a breakdown of ultrasonic vibrator.
·
·
·
·
·
·
This product is an electronic device operating via a battery as power resource.
To prevent electronic shock, please keep out of reach of preschool children
and infants. This could also be a choking hazard.
·
KUNK Smart Multi-Mist 21
Cautions before using

Careless use may cause personal injury or property damage.
Please be sure to know the following points before using.
2 Cartridge
If you press to the ultrasonic vibrator with your nails or sharp objects,
there is a risk of damage.
Cartridge (included mist header) is consumable. If the ultrasonic vibrator
has broken down over time due to usage, you have to purchase it again,
it shall not be exchanged.
Also, there is a possibility of bacterial growth in the solution, please wash
the used cartridge for a certain period of time with alcohol or replace with
a new cartridge.
Do not attach the cartridge to the device with wet hands.
There is a risk of electric shock.
In case of fragrance, please use the solution recommended by KUNK Co., Ltd.
If you use the solution not recommended by KUNK Co., Ltd, if the oil content
exceeds 20%, the ultrasonic vibrator may cause a breakdown or malfunction.
·
·
·
·
·
KUNK Smart Multi-Mist 22
Cautions before using 2
Cautions before using

Using Device 1
1 Product use order
Check how to use before using the device.
KUNK Smart Multi-Mist 23
Using Device
Put a solution and fit the mist
header to the cartridge
Insert the cartridge
on the device.
Press the top groove to open the
case and separate the cartridge.
Turn the mist header and
separate it from the cartridge.
1 2
3 4

Using Device 1
KUNK Smart Multi-Mist 24
Using Device
If the power is not on,
please charging it.
If the power is on, press the
button to operate the device.
Close the case. Press the button for long
periods to turn on the power.
5 6
7 8
1 Product use order
Check how to use before using the device.

Using Device 1
KUNK Smart Multi-Mist 25
Using Device
While working device, press
the button to stop the device.
Press the button for long
periods to turn off the power.
910
It may not be sprayed by foam of solution. Gently shake the device.
If the solution is fully filled, the operation may not be smooth.
1 Product use order
Check how to use before using the device.

Using Device 2
2 Package Contents
Check how to use before using the package Contents.
KUNK Smart Multi-Mist 26
Cable
Connect to USB port for charging the device.
Pouch
Put your device in the pouch for the device protection and carrying easily.
Funnel
Insert the funnel into the cartridge for putting solution safely.
Gel
Stick the device to the gel pad for fixing the device such as inside a car.
Using Device

Using Device 3
3 Charging
Must be charged before using the device.
4 Button
You can press the button for a short or long periods.
Require Charging You need charging the device.
While Charging When the USB cable is connected,
a red LED light flashes every 3 seconds
if it is Charging in a normal manner
Complete Charging If the amount of battery is more than 90%
during charging, the light changes to
green color and it is automatically turned off
when the cable is disconnected.
Turn-On When the power is turned on, a Green LED light flashes once.
Play Start
Play Stop
Turn-Off When the power is turned off, a Red LED light flashes once.
KUNK Smart Multi-Mist 27
Using Device

Using Device 3
3 Charging
Must be charged before using the device.
4 Button
You can press the button for a short or long periods.
Require Charging You need charging the device.
While Charging When the USB cable is connected,
a red LED light flashes every 3 seconds
if it is Charging in a normal manner
Complete Charging If the amount of battery is more than 90%
during charging, the light changes to
green color and it is automatically turned off
when the cable is disconnected.
Turn-On When the power is turned on, a Green LED light flashes once.
Play Start
Play Stop
Turn-Off When the power is turned off, a Red LED light flashes once.
KUNK Smart Multi-Mist 27
Using Device

Me Time
Diffuse aroma with soothing lights for an hour.
Aromatherapy mode that can be used in everyday life.
Drive Time
Diffuse aroma through GPS data analysis if driving at a constant speed.
Mist Time
Diffuse aroma according to humidity.
Mist mode protects yourself from an external drying.
Alarm
Diffuse aroma according to schedule.
It is an alarm mode in which the fragrance is diffused at a desired time.
Using Device 5
6 APP Functions
KUNK Smart Multi-Mist 29
Using Device

Cleaning
1 Device
The material of the device is PC(polycarbonate).
Be sure to turn off the power of the device and wipe it with wet tissue or tissue.
2 Cartridge
Put the vegetable ethanol into the cartridge and spray it about 5 minutes in
combination with the mist header. After spraying, wipe the ultrasonic
vibrator of the mist header with dry tissue or cotton swab and rinse the
cartridge with clean water.
KUNK Smart Multi-Mist 30
Cleaning

Warranty 1
This document certifies that this product has passed the quality inspection
by the head office.
·
Also, this document specifies the terms of free A/S and does not limit user’s legal right.·
Please contact the place of purchase if you have any problem with the product
after the warranty period has expired.
·
We will use the personal information provided in this warranty when accepting A/S.·
Except in special circumstances, we will not disclose or transfer your information to
third parties without your permission.
·
In case of a malfunction or breakdown even though user has used it properly,
we provide free A/S for 1 year according to the regulations of this document.
·
Product name
Date of purchase yy mm dd
Place of purchase
Name
Phone number
Price
KUNK Smart Multi-Mist 31
Warranty

Case Compensation
Deformation or quality defects in normal condition within
10 days from the date of purchase
Deformation or quality defects in normal condition within
1 year from the date of purchase
Deformation or quality defects in normal condition after
1 year from the date of purchase
Scratches caused by manufacturing or delivery of new product
within 15 days from the date of purchase
Same defects occur more than 3 times within the warranty period
Product exchange or refund
Product exchange or free A/S
Parts exchange or A/S at a cost
Product exchange
Product exchange or refund
If repair is
not possible.
Within the warranty period In normal condition
In user’s fault
Product exchange or refund
Product exchange at a cost
Product exchange at a cost
After the warranty period
Warranty 2
KUNK Smart Multi-Mist 32
If a problem occurs within the warranty period, go to the place of purchase
with your product and this warranty.
·
Warranty

KUNK Smart Multi-Mist 33
If there is any content below, we will not provide A/S
(Included when the warranty period has not expired)
1 A malfunction or breakdown after 1 year from the date of purchase
2 If it does not meet the warranty terms of this document or if you do not have a
document proving the date of purchase, such as the place of purchase, receipt, etc.
3 If you change contents such as the date of purchase, the place of purchase
4 A malfunction or breakdown due to external factors such as natural disasters
(fire, earthquake, etc.), other disasters and war
5 A malfunction or breakdown due to improper use such as dropping or using in water
6 Appearance defects after use such as damages, pollution
7 A malfunction or breakdown due to disassembly, modification,
or improper maintenance
8 Used cartridges and ultrasonic vibrators(It is consumable)
9 A malfunction or breakdown occurs if user did not comply with
“Cautions before using”
·
Warranty
Warranty 3

Q&A
KUNK Smart Multi-Mist 34
Please refer to KUNK Homepage or APP Q&A board
for contents other than this manual.

www.kunk.kr
