Kuppersbusch IKD 9380.0 GE Operation manual

BED ENUNGSANWE SUNG
mit Montageanweisungen
Instrucciones de Uso y de Montaje
Instructions for use and installation
Instructions d΄utilisation e avis de montage
Instruηυes de uso com indicaηυes para montagem
Istruzioni di uso e di montaggio
Bruks- och monteringsanvisningar
Gebruiksaanwijzing en montagehandleiding
Εγχειριδίου µε τις Οδηγίεσ Χρήσεωσ
KD 9380,0 GE
(Rev. 0)

14
ENG
Dear client:
Congratulations on your choice. We are sure
that this modern, functional and practical
appliance, made with top quality materials,
will fully satisfy your needs.
Please read every section of this
INSTRUCTIONS MANUA before using your
kitchen hood for the first time, to ensure
maximum performance from the appliance
and to avoid breakdowns, which may be
caused by incorrect use, as well as to allow
any minor problems to be solved.
Store this manual, as it will provide useful
information about your kitchen hood at all
times and will also help other people to use it.
• Please be aware of current local
regulations with reference to domestic
electrical fittings and gas eduction.
• Verify that the tension and frequency of the
network match those indicated on the label
located inside the kitchen hood.
• For disconnection from the supply mains
must be incorporated in the fixed wiring in
accordance with the wiring rules. THE NET
CAB E MUST NOT BE SUBSTITUTED,
EXCEPT BY AN AUTHORIZED
TECHNICA SERVICE.
• Once the kitchen hood has been installed,
ensure that the mains cable to the network
is not in contact with any live metal edges.
• Avoid connecting the appliance to
conductors used as exits for fumes
produced by a non-electric energy source,
e.g.: boilers, chimneys, etc.
• If the extractor fan is going to be used
simultaneously with equipment powered by
a non-electric energy source, e.g.: gas
cookers, then the room must have
sufficient ventilation.
• Excessive fat accumulation in the kitchen
hood and metal filters is a fire risk and may
also cause dripping, therefore the inside of
the kitchen hood and the metal filters must
be cleaned at least once a month.
• The lower part of the kitchen hood must be
fitted at least 50 cm. over electric hobs and
65 cm. over gas or mixed hobs. FO OW
THE HOBS´ MANUFACTURER'S
MINIMUM RECOMMENDATIONS.
• Never leave gas hobs lit if not covered by a
container. The fat accumulated in the filters
may drip or catch fire when the
temperature increases.
• Avoid cooking under the kitchen hood if the
metal filters are not fitted, e.g.: while they
are being cleaned in the dishwasher.
• You must not produce flames under the
kitchen hood.
• Disconnect the appliance before any
interior manipulation, e.g. during cleaning
or maintenance.
• We recommend the use of gloves and to
be extremely careful when cleaning the
kitchen hood's interior.
• Your kitchen hood is designed for domestic
use and only for extraction and purification
of fumes produced during food
preparation. It will be your responsibility if it
is used for other purposes, which may be
dangerous. The manufacturer cannot
accept responsibility for damage caused
by improper use of the appliance.
• For repairs please contact the nearest
KÜPPERSBUSCH Technical Assistance
Service, and always use genuine spare
parts. Repairs or modifications carried out
by unqualified personnel can cause
malfunctions or may damage the
appliance, putting your safety in danger.
• This appliance is marked according to the
European directive 2002/96/EC on “Waste
Electrical and Electronic Equipment”
(WEEE). This guideline is the frame of a
European-wide validity of return and
recycling on Waste Electrical and
Electronic Equipment, .
• When the cooker hood is run at the same
time as other than electrical appliance or
equipment with different energy source,
the air extraction (underpressure) must no
be higher than 4Pa (4 x 10-5 bar).
• The appliance is not intended for use by
young children or infirm persons without
supervision. Young children should be
supervised to ensure they do not play with
the appliance.
Sa ety Instructions

15
ENG
ndex
Page
Description of the appliance 15
Instructions for use 15
Programming timer 15
Cleaning and maintenance 16
Problem solving 16
Sizes and specifications 17
Accessories supplied 18
Installation 18
Active charcoal filters 19
AOn/ Off Push button, speed selector,
light and working pilot.
BMetal filters.
CLamp with bulbs - 9W (E-14).
D, E Vertically adjustable tubecovers.
FDecorative part.
Switch on the extractor fan a few minutes
before you start to cook in order to ensure that
a steady air flow has been established before
fumes appear.
Allow the extractor fan to run for several
minutes after you have finished cooking
(between 3 to 5 minutes) in order to expel all
the grease from the outlet duct. This prevents
the return of grease, smoke and smells.
Description of the appliance
Instructions for use
2
3
1
321
You may control the kitchen hood by
operating the controls as shown in the
diagram.

16
ENG
During cleaning and maintenance work,
make sure the safety instructions set out
on page 14 are complied with.
• f your kitchen hood is made from stainless
steel, use proprietary cleaners mentioned
in the product instructions.
• Never use metallic scourers, nor abrasive
or corrosive products.
• Dry the kitchen hood using a cloth that
does not produce fibres.
• The use of vapour cleaners is not
recommended.
To remove the filters from their fittings, press
lightly on the locks and then pull them off.
The metal filters can be cleaned by soaking
them in hot water with neutral detergent until
the fat dissolves and then rinsing them under
the tap or using special anti-grease products.
They can also be washed in a dishwasher. n
this case, it is advisable to stack them
vertically to avoid food residues to stick to
them.
Cleaning in a dishwasher may damage the
metallic surface (blackening it), although this
will not affect its fat retention capacity.
Once clean, leave them to dry off and then fit
them onto the kitchen hood.
Fig. 1 (Page 19)
Proceed as follows:
• Remove the metal filters.
• oosen the screws (J) to dismount the
cover top (U).
• Change the broken/ burnt out lamp.
Maximum lamp power is 9W (E-14).
• Mount the cover top again (U).
• Fit the metal filters.
Cleaning and maintenance
_________________________________________________________
Problem solving
Proceed with the following checks before calling the Technical Service:
Cleaning the hood body
Cleaning the metal filters
Changing light bulbs

17
ENG
Sizes and specifications
KÜPPERSBUSCH reserves the right to make changes and corrections to its products as
it deems necessary, without altering their basic characteristics.
* Check Characteristics label inside the hood.
E EC: AC 220-240V ~ 50/60Hz M* W
Código Técnico:************** F.Nr.**********
F-PTX

18
ENG
1 150/ 120 mm reduction.
1 Anti-recoil valve.
4 Screws (Ø4 x 12).
4 Screws (Ø4 x 10).
6 Lock screws (M8 x 45).
Fig. 1 (Page 19)
n installing the kitchen hood make sure
that the Safety Instructions set out on page
14 are complied with.
To obtain optimum performance, the external
conduct must not be more than FOUR
METRES long, have no more than two 90°
angles and its diameter must be at least Ø120.
1) Using the support (O) trace and drill the
where the screw-fittings will sit onto the roof (S)
(Ø8 x 45).
2) Screw the support (O) into the roof with the
screw-fittings (S) (Ø8 x 45).
3) Mount the upper chassis (A6) onto the
support (O) using the screws (Q) (M6 x 16).
4) Connect the upper part of the inner tube (not
supplied) to the exit.
5) Mount the upper cover (A8) and attach it to
the upper chassis (A6) with the screws (G) (M4
x 12).
6) Fit the part (A) if the inner tube (not supplied)
is Ø150 or (A) + (B) if it is Ø120.
7) Mount the whole lower unit to the upper
section, attaching it to the roof using the
screws (A10) (M4 x 12) at the required height.
8) Attach the inner tube with a clamp (not
supplied) to (A) or (B) as the case may be.
9) Mount the lower part (A9a) of the cover to
the lower chassis (A7) with the screws ( ) (M4
x 12).
10) Adjust the lower part (A9b) of the cover
(A9a) as shown in the diagrams.
When exterior gas extraction is not possible,
then the kitchen hood may be set to purify the
air by recycling it through active charcoal
filters.
The active charcoal filters have an active life of
between three to six months, depending on
the individual conditions of use. These filters
cannot be washed nor regenerated. They must
be replaced once their useful life comes to an
end.
Fig. 1 (Page 19)
1) Mount the diffuser support (A13) onto the
upper chassis (A6) with the screws (A4) (M4 x
12).
2) Adjust the diffuser (A5) over the support
(A13).
3) Connect the upper part of the inner tube (not
supplied) to the circular support exit (A13).
4) Using the support (O) trace and drill the
where the screw-fittings will sit onto the roof (S)
(Ø8 x 45).
5) Screw the support (O) into the roof with the
screw-fittings (S) (Ø8 x 45).
6) Mount the upper chassis (A6) onto the
support (O) using the screws (Q) (M6 x 16).
7) Mount the upper cover (A8) and attach it to
the upper chassis (A6) with the screws (G) (M4
x 12).
8) Fit the part (A) if the inner tube (not supplied)
is Ø150 or (A) + (B) if it is Ø120.
9) Mount the whole lower unit to the upper
section, attaching it to the roof using the
screws (A10) (M4 x 12) at the required height.
10) Attach the inner tube with a clamp (not
supplied) to (A) or (B) as the case may be.
11) Mount the lower part (A9a) of the cover to
the lower chassis (A7) with the screws ( )
(M4x12).
12) Adjust the lower part (A9b) of the cover
(A9a) as shown in the diagrams.
13) Put the filters into the lateral draught
section of the motor making the holes in the
filters match up (A11) with the pivots (A12) of
the motor carcass.
14) Fit the metal filters again.
Active charcoal filters ( ptional)
Installation
Accesories supplied

19
ENG
FIG. 1
