Kvaser USBcan Professional User manual

Kvaser USBcan Professional
User's Guide
Copyright 2001-2011 Kvaser AB, Mölndal, Sweden
http://www.kvaser.com
Last updated Thursday, 28 April 2011
We believe that the information contained herein was accurate in all respects at the time of printing. Kvaser AB cannot, however, assume
any responsibility for errors or omissions in this text. Also note that the information in this document is subject to change without notice and
should not be construed as a commitment by Kvaser AB.

Kvaser USBcan Professional User's Guide 2(23)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
(This page is intentionally left blank.)

Kvaser USBcan Professional User's Guide 3(23)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
1 Table of Contents
Kvaser USBcan Professional User's Guide...........................................................................1
1Table of Contents..............................................................................................................3
2About this manual .............................................................................................................4
3Introduction........................................................................................................................5
3.1 Welcome to Kvaser USBcan Professional...................................................................5
3.2 Major features of Kvaser USBcan Professional...........................................................6
3.3 Additional software and documentation.......................................................................6
4Kvaser USBcan Professional hardware..........................................................................7
4.1 Hardware installation....................................................................................................7
4.2 USB connector.............................................................................................................7
4.3 CAN channels ..............................................................................................................7
4.4 LED indicators..............................................................................................................9
5How to use the Kvaser USBcan Professional ............................................................. 11
5.1 Troubleshooting ........................................................................................................ 11
6Appendices ..................................................................................................................... 12
6.1 System requirements ................................................................................................ 12
6.2 Technical data........................................................................................................... 12
6.3 Performance.............................................................................................................. 13
6.4 CAN connectors........................................................................................................ 13
6.5 Updating the firmware............................................................................................... 17
6.6 Required driver version............................................................................................. 18
6.7 CAN bus termination................................................................................................. 18
7Frequently Asked Questions......................................................................................... 20
8Legal acknowledgements.............................................................................................. 21
8.1 Usage warning .......................................................................................................... 21
8.2 EMC compliance statement...................................................................................... 22
8.3 WEEE compliance statement.................................................................................... 22
8.4 RoHS compliance statement..................................................................................... 22
8.5 Patents, copyrights and trademarks ......................................................................... 22
9Document revision history............................................................................................ 23

Kvaser USBcan Professional User's Guide 4(23)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
2 About this manual
This manual is intended for the Kvaser USBcan Professional users. This manual contains a
description of the properties of the hardware and general instructions for connecting the
device to a computer.

Kvaser USBcan Professional User's Guide 5(23)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
3 Introduction
This section will describe the functions and features of the Kvaser USBcan Professional.
3.1 Welcome to Kvaser USBcan Professional
Figure 1. Kvaser USBcan Professional.
Kvaser USBcan Professional is a powerful two channel real time CAN to USB interface.
The Kvaser USBcan Professional supports Kvaser's MagiSync™ technology to synchronize
time stamps across multiple units without extra wires providing flexibility for multi-channel
applications. With quick reaction times and high data throughput, the Kvaser USBcan
Professional is perfect for rapid ECU re-flashing, advanced bus analyzers, and efficient
development work.
This guide is applicable to the Kvaser USBcan Professional devices listed in Table 1.
Table 1: The Kvaser USBcan Professional device and its EAN number.
Device
Product Number
Kvaser USBcan Professional HS/HS
733-0130-00357-6

Kvaser USBcan Professional User's Guide 6(23)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
3.2 Major features of Kvaser USBcan Professional
Quick and easy plug-and-play installation.
Supports both 11-bit (CAN 2.0A) and 29-bit (CAN 2.0B active) identifiers.
CAN messages are time-stamped with 2 microseconds accuracy.
Large on-board RAM buffer for CAN messages.
Supports silent (listen-only) mode for analyzing tools and data logging.
100% compatible with applications written for Kvaser hardware such as LAPcan,
PCIcan, and USBcan with Kvaser CANLIB.
Two high-speed CAN connections (compliant with ISO 11898-2), 5 kbit/s up to 1
Mbit/s.
Fully compatible with J1939, CANopen, NMEA 2000® and DeviceNet.
One USB 2.0 HiSpeed connection with data rates up to 480 Mbit/s. The device can
also be used in USB 1.1 slots (with up to 12 Mbit/s).
Power is taken from the USB bus.
Small, light plastic housing with dimensions (W x L x H) approximately 46 x 115 x 22
mm (1.8 x 4.5 x 0.9 inch) –easy to tuck away (e.g. in a vehicle during a test drive)
Supports extreme data throughput, quick reaction times and precise time stamping –
removing any bottlenecks. Handles up to 40 000 messages per second.
Kvaser MagiSync- automatic time synchronization between all Kvaser products
that uses the Kvaser MagiSyncfeature.
Simultaneous operation of multiple devices.
3.3 Additional software and documentation
Kvaser CANLIB SDK, which includes everything you need to develop software for the
Kvaser CAN hardware. Includes full documentation and many sample programs,
written in C, C++, C#, Delphi, and Visual Basic. All Kvaser CAN interface hardware
shares a common software API. Programs written for one board type will run without
modifications on the other board types!
On-line documentation in Windows® HTML Help and Adobe Acrobat format.
Documentation, software and drivers can be downloaded for free at www.kvaser.com
or purchased separately on CD if preferred.

Kvaser USBcan Professional User's Guide 7(23)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
4 Kvaser USBcan Professional hardware
In this section you can read more about the CAN channels, power supply, LED indicators,
and external triggers.
4.1 Hardware installation
The Kvaser USBcan Professional may be inserted in any free USB socket on the host
computer. You do not need to switch the power off before inserting or removing the device.
For the Kvaser USBcan Professional to communicate with the host computer, the correct
version of the Kvaser driver and firmware must be installed. The firmware is downloaded and
installed directly on the Kvaser USBcan Professional and the driver is installed on the host
computer. For additional information on how to upgrade the firmware, read section 6.5,
Updating the firmware.
The delivery package of Kvaser USBcan Professional contains:
Kvaser USBcan Professional.
Software and Driver CD, containing drivers for Windows; Kvaser CANKing, an easy to
use CAN bus monitor; Drivers for RP1210A, LabView and DIAdem; and Kvaser
CANlib Software Development Kit.
Kvaser USBcan Professional User's Guide (also on the CD.)
A USB cable.
For driver installation information, see the driver and hardware installation guide which can be
found at http://www.kvaser.com.
4.2 USB connector
The Kvaser USBcan Professional has a standard USB type ―B‖ receptacle connector.
Connect it to your PC using any high quality, USB 2.0 certified cable. The maximum USB
cable length is 5 meters (approx. 16.5 ft.). If you need a longer cable, you can use USB hubs
or USB extension cables with a built-in hub. By chaining up to 5 hubs, you can achieve a
cable length of up to 25 meters (approx. 83 ft.)
4.3 CAN channels
The standard Kvaser USBcan Professional has two independent CAN channels that are seen
in Figure 2. The first CAN channel is marked on the housing with the symbol ‗1‘, where as the
second channel (number 2) is not marked. See Figure 3. The CAN connectors are also
labeled for easy identification.

Kvaser USBcan Professional User's Guide 8(23)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
CAN channel
connectors
USB device
connector
Figure 2: Connections on the Kvaser USBcan Professional. The two CAN channels are
on top of the picture and the USB device connector is on the bottom of the picture.
Figure 3: The CAN channels on Kvaser USBcan Professional.

Kvaser USBcan Professional User's Guide 9(23)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
4.4 LED indicators
Table 2: LED indicators overview.
Lamp
General meaning
PWR (Green)
Power and general status.
CAN 1 (Yellow)
Status for CAN channel 1.
CAN 2 (Yellow)
Status for CAN channel 2.
ERR (Red)
Indicates different types of errors.
Figure 4. LEDs on the Kvaser USBcan Professional.

Kvaser USBcan Professional User's Guide 10(23)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
Table 3: LED indicators, detailed meaning.
PWR
(Green)
CAN 1
(Yellow)
CAN 2
(Yellow)
ERR
(Red)
Meaning
Slow flash
Waiting for USB connection with the PC.
Steady
Power ON (The device is connected to
the computer).
Short flash
CAN traffic on channel 1.
Short flash
CAN traffic on channel 2.
Short
flash
Error frame on either channel.
Steady
Self-test failed, wrong bit rate, CAN bus
transceiver failure.
Fast flash
Firmware configuration error (should not
normally happen, so please contact the
support).

Kvaser USBcan Professional User's Guide 11(23)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
5 How to use the Kvaser USBcan Professional
To use the Kvaser USBcan Professional as a CAN interface; connect the unit to a free USB
socket on your PC or USB hub.
When used as a CAN interface, the green lamp will be illuminated and the yellow
lamps will emit short flashes when CAN messages are transmitted and received.
5.1 Troubleshooting
Use ―Kvaser Hardware‖ in the Control Panel to verify that the computer really
can talk to the Kvaser USBcan Professional. Read out the firmware version. If
it‘s all zeroes, there are communication problems.
If the LEDs are flashing or glowing, compare the pattern with the specified LED
indicators in Table 2 and Table 3.
If the LEDs are not flashing or glowing at all, check the power supply.

Kvaser USBcan Professional User's Guide 12(23)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
6 Appendices
In this section you will find technical information about Kvaser USBcan Professional and its
connectors.
6.1 System requirements
A USB interface. Use USB 2.0 HiSpeed for optimum results, although the device will
work with a USB 1.1 interface too.
6.2 Technical data
In Table 4 below you will find the Kvaser USBcan Professional‘s technical specifications.
Table 4: Kvaser USBcan Professional Technical specifications.
CAN Channels
2 (CAN 2.0A and 2.0B active).
CAN Transceivers
SN 65251 (Compliant with ISO 11898-2)
CAN Controller
Built into the M32C
Microcontroller
Renesas M32C
CAN Bit Rate
5 kbit/s to 1 Mbit/s
Timestamp accuracy
2 μs
Error Frame Detection
Yes, both channels.
Error Frame Generation
Yes, when used as a USB-CAN interface.
PC interface
USB 2.0. Supports HiSpeed (HS) at 480 Mbit/s.Compatible with USB
1.1 at 12 Mbit/s.
Power consumption
~ 5V and 130mA when powered from the USB.
Software requirements
Windows XP or later. (For other operating systems, see Kvaser web or
contact Kvaser support.)
Hardware configuration
Done by software (Plug & Play).
Dimensions (W x L x H)
46 x 115 x 22 mm (1.8 x 4.5 x 0.9 inch)
Operating temperature
-40 ºC ... +85 ºC
Weight
142 g including cables and connectors.

Kvaser USBcan Professional User's Guide 13(23)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
Storage temperature
-40 ºC ... +85 ºC
Relative Humidity
0% ... 85% (non-condensing.)
6.3 Performance
In Table 5 below some approximate performance numbers of the Kvaser USBcan
Professional are listed.
Table 5: Performance.
Kvaser USBcan Professional
RX performance per
channel.
20000 messages/s
TX performance per
channel
20000 messages/s
Time stamp accuracy.
2 s
Galvanic isolation.
Yes
6.4 CAN connectors
The Kvaser USBcan Professional has two high-speed CAN channels which are equipped with
either D-SUB connectors or RJ45 connectors.
6.4.1 D-SUB
Both CAN channels have 9-pin D-SUB connectors (see Figure 5) with the pinning described
below (see Table 6 and Table 7).
Figure 5: The D-SUB connector pin numbers on a CAN channel.

Kvaser USBcan Professional User's Guide 14(23)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
Table 6: D-SUB pin configuration of the CAN channel 1.
The CAN channel 1 has the following pin configuration.
(Auto-reset fuses protect Pins 2, 3, 4, 7 and 9.)
D-SUB pin number
Color code
Function
1
N/A
Not connected.
2
Green
CAN_L
3
Brown
GND
4
Orange
Reserved; do not connect
5
Black
Shield
6
N/A
Not connected.
7
Red
CAN_H
8
N/A
Not connected.
9
Yellow
Not connected.
Table 7: D-SUB pin configuration of the CAN channel 2.
The CAN 2 channel has the following pin configuration.
(Auto-reset fuses protect Pins 2, 3, 4, 7 and 9.)
D-SUB pin number
Color code
Function
1
N/A
Not connected.
2
Green
CAN_L
3
Brown
GND
4
Orange
Reserved; do not connect
5
Black
Shield
6
N/A
Not connected.
7
Red
CAN_H
8
N/A
Not connected.
9
Yellow
Not connected.
Note: Always connect the ground pin on the D-SUB to the ground of your CAN
bus.
6.4.2 RJ45
Both CAN channels have 8-pin RJ45 connectors (see Figure 6) with the pinning described
below (see Table 8 and Table 9).

Kvaser USBcan Professional User's Guide 15(23)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
Figure 6: The RJ45 connector pin numbers on a CAN channel.

Kvaser USBcan Professional User's Guide 16(23)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
Table 8: RJ45 pin configuration of the CAN channel 1.
The CAN channel 1 has the following pin configuration.
(Auto-reset fuses protect Pins 1, 2, 3, 4 and 8.)
RJ45 pin number
Function
1
CAN_H
2
CAN_L
3
GND
4
Reserved; do not connect.
5
Not connected.
6
Shield.
7
GND
8
Not connected.
Table 9: RJ45 pin configuration of the CAN channel 2.
The CAN 2 channel has the following pin configuration.
(Auto-reset fuses protect Pins 1, 2, 3, 4 and 8.)
RJ45 pin number
Function
1
CAN_H
2
CAN_L
3
GND
4
Reserved; do not connect.
5
Not connected.
6
Shield.
7
GND
8
Not connected.
Note: Always connect at least one of the ground pins on the RJ45 to the ground of
your CAN bus. Preferably use ground on pin 3.

Kvaser USBcan Professional User's Guide 17(23)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
6.5 Updating the firmware
Connect the Kvaser USBcan Professional to your PC with the USB cable. Double-click on the
file ―update.exe‖. A small application opens where you should see the device listed if correctly
connected to your PC (see Figure 7). Select the device to program and click the Next button.
Figure 7: Firmware update, select device.
Click on the Start Upgrade button to start programming (see Figure 8). The programming
takes approximately 20 seconds. The progress is printed on the screen, and typically looks
like this:

Kvaser USBcan Professional User's Guide 18(23)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
Figure 8: Firmware update, start upgrade.
No error messages should appear. If you see error messages, try to disconnect
and reconnect the device, and then perform the operation again.
To verify that the firmware is updated,
Double-click on ―Kvaser Hardware‖ in the Control Panel. Select ―Kvaser USBcan
Professional‖ in the tree view to the left, and click on either channel. The firmware
revision information appears in the right half of the window.
6.6 Required driver version
You need at least driver (CANLIB) version 3.9 to use your Kvaser USBcan Professional.
6.7 CAN bus termination
Every CAN bus must be terminated with a 120 Ohm resistor at each end of the bus. The
Kvaser USBcan Professional does not contain any CAN bus terminators, because their
inclusion could cause severe disturbance in a system which is already correctly terminated.
For laboratory or testing use, the exact value of the termination resistors is not always critical.
Sometimes a single terminator is sufficient. For production, proper termination is essential. If
you see error frames on the bus, you should check the termination.

Kvaser USBcan Professional User's Guide 19(23)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
To save yourself a lot of trouble, always terminate the CAN bus properly.

Kvaser USBcan Professional User's Guide 20(23)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
7 Frequently Asked Questions
Q: I want to read the messages sent on the CAN bus without interfering with the
system, how can I do that?
A: You should put the Kvaser USBcan Professional in Silent mode; that is, it doesn't send
anything, not even ACK bits, on the bus. Reception works as usual.
Q: I am trying to send CAN messages but I can’t se any messages on the bus.
A: Make sure the CAN channel isn‘t in Silent mode.
Q: Could I use several Kvaser USBcan Professional?
A: Yes, no problem. For MagiSyncTM to work make sure you connect them to the same root
hub.
Q: If I reboot my computer, will the Kvaser USBcan Professional and other products
have the same channel numbers as before?
A: Yes, they will try to reuse the old channel numbers.
Q: How can I identify which Kvaser USBcan Professional has a certain channel
number?
A: Use ―Kvaser Hardware‖ to flash the LEDs on the Kvaser USBcan Professional.
Q: How do I know which Kvaser USBcan Professionals are synchronized?
A: Use ―Kvaser Hardware‖ to flash the LEDs on an entire MagiSyncTM group.
Q: Do I have to use an external hub to keep the USBcan Professionals synchronized?
A: No, you don‘t. Just make sure they are on the same root hub.
