Ledgerware 13 GPU Mining Rig Case User manual

LEDGERWARE
13 GPU Mining Rig Case
Assembly Instructions

LEDGERWARE
Assembly Instructions
13 GPU Mining Rig Case
2
Components Included in Kit
•13 x Riser Kits (In the case + riser configurations only)
o1 x Riser PCB
o1 x USB 3.0 Cable
o1 x SATA or Molex Power Cable
o1 x PCI to USB Adapter
•1 x Accessories Kit
o6-32 Screws
o6-32 Standoffs
oPower Supply Screws
oDual PSU Adapter
•1 x GPU Safety Bar
•1 x GPU Support Bar
•1 x Riser Mount Bar
•1 x Chassis Body
•1 x Chassis Top
•1 x Front Panel PCB
•1 x Hard Drive Mounting Bracket
•12 x Case Fans
Components NOT Included
These components are referenced in the instructions but are not included with
the mining kit.
•ATX Power Supply
•2.5” Hard Drive (optional if booting from an external source)
•ATX Mother Board
•ATX Mother Board Pass-Through Plate
•Graphics Cards

LEDGERWARE
Assembly Instructions
13 GPU Mining Rig Case
3
General Case Layout
SAFETY
DO NOT ASSEMBLY THE CASE OR ANY CASE COMPONENTS
THAT ARE POWERED. GROUND YOURSELF BEFORE
HANDLING ELETRONIC COMPONENTS TO MINIMIZE THE
POTETIAL FOR STATIC DISCHARGE DURING ASSEMBLY.

LEDGERWARE
Assembly Instructions
13 GPU Mining Rig Case
4
Step 1: Unboxing
•Open the box and remove the case from the shipping foam and
plastic cover.
•Remove the accessories kit (bag or box) from the box.
•Remove the risers and riser components from the box (if the case
+ riser package was purchased).
Step 2: Open the Case
Remove the two screws from the back of the case that keep chassis
top from sliding backwards with a Phillips head screwdriver.
Slide the chassis top backwards and set the chassis top aside.
Remove the GPU Safety, GPU Support & Riser Support Bars from the
case.

LEDGERWARE
Assembly Instructions
13 GPU Mining Rig Case
5
Step 3: Add ATX Mother Board
Add the ATX mother board pass-through plate (usually included with
your ATX mother board).
Reference the hole-pattern on your ATX mother board and add the
brass 6-32 standoffs that are included in the accessories kit.
Place your ATX mother board on the standoffs that were just
added to the case.
Attach the ATX mother board to the standoffs using the 6-32
screws included in the accessories kit.
Attach the Power/Reset Buttons & Power/Status LEDs to the ATX
main board. Consult your ATX mother board instructions for the
attachment locations.

LEDGERWARE
Assembly Instructions
13 GPU Mining Rig Case
6
Step 4: Add ATX Power Supply
Attach ATX power supply to the back panel of the case using the four
screw holes highlighted with green circles.
Note: If you are using two power supplies, repeat this step in the second
power supply location. After both power supplies are installed attach
the Dual PSU Adapter (from the accessories box).

LEDGERWARE
Assembly Instructions
13 GPU Mining Rig Case
7
Attach the Dual PSU Adapter to each PSU. Make sure that any
additional Mother Board Power comes from PSU1 so that it shares the
same ground connection as the ATX Mother Board Power Connector.
Step 5: Attach Fans to Power Supply
Daisy-chain the six molex fans connectors together and then attach one
of the molex fan cables to the power supply.
Repeat this step for the six fans in the back of the case.

LEDGERWARE
Assembly Instructions
13 GPU Mining Rig Case
8
Step 6: Add Hard Drive
Remove the hard drive mounting bracket by removing the 4 screws
holding it in place (with a Phillips head screwdriver).
Attach your hard drive to the mounting bracket by screwing the base of
the hard drive to the bracket. Your bracket may look different than the
one in the example below.

LEDGERWARE
Assembly Instructions
13 GPU Mining Rig Case
9
Step 7: Attach the Risers to the Riser Support Bar
Start by attaching the PCI to USB adapters and USB Cords into the
motherboard. This will save the hassle of attaching these components
once space becomes an issue.
Punch a hole through the foam covering the bottom of mounting holes
on the risers. This will allow you to use the mounting screws on the
Riser Support Bar.
Attach the risers using the two standoffs that are on the Riser Support
Bar using the screws provided in the accessories kit.
Once all the risers are attached to the Riser Support Bar, attached the
Riser Support Bar to the inside of the chassis.

LEDGERWARE
Assembly Instructions
13 GPU Mining Rig Case
10
Attach the USB Cords and power from the PSU to the risers.

LEDGERWARE
Assembly Instructions
13 GPU Mining Rig Case
11
Step 8: Add GPU Support Bar & GPU Flange Mount Bar
Attach the GPUs to the risers
Then attach the GPUs to the GPU Support Bar

LEDGERWARE
Assembly Instructions
13 GPU Mining Rig Case
12
Step 9: Attach GPU Safety Bar
This step is optional, but highly suggested to ensure the safety
of your GPUs during movement of the case.
Place the GPU Safety Bar across the top of the GPUs and align it with
the holes in the side of the case. Attach the GPU Safety Bar to the sides
of the case using the bar attachment screws that are included in the
accessories kit.

LEDGERWARE
Assembly Instructions
13 GPU Mining Rig Case
13
It is suggested that the GPUs are removed during
transportation of the case to minimize damage that may be
due to vibrations or movement of the GPUs.
