KYLAND SICOM3000S Assembly instructions

SICOM3000S Industrial Ethernet Switch
Hardware Installation Manual
Publication Date: May. 2021
Version: V1.1
No.: 112020193

SICOM3000S Industrial Ethernet Switch
Hardware Installation Manual
Disclaimer: Kyland Technology Co., Ltd. tries to keep the content of this manual as accurate
and as updated as possible.This document is not guaranteed to beerror-free, and we reserve
the right to amend it without notice to users.
All rights reserved.
No part of this documentation may be excerpted, reproduced, translated, annotated or
duplicated, in any form or by any means without the prior written permission of KYLAND
Corporation.
Copyright © 2021 Kyland Technology Co., Ltd.

Notice for Safety Operation
The product performs reliably as long as it is used according to the guidance. Artificial
damage or destruction of the device should be avoided. Before using the device, read this
notice carefully for personal and equipment safety. Please keep the manual for further
reference. Kyland is not liable to any personal or equipment damage caused by violation of
this notice.
Do not place the device near water sources or damp areas. Keep the ambient relative
humidity within the range from 5% to 95% (non-condensing).
Do not place the device in an environment with high magnetic field, strong shock, or high
temperature. Keep the working and storage temperatures within the allowed range.
Install and place the device securely and firmly.
Please keep the device clean; if necessary, wipe it with a soft cotton cloth.
Do not place any irrelevant materials on the device or cables. Ensure adequate heat
dissipation and tidy cable layout without knots.
Wear antistatic gloves or take other protective measures when operating the device.
Avoid any exposed metal wires because they may be oxidized or electrified.
Install the device in accordance with related national and local regulations.
Before power-on, make sure the power supply is within the allowed range of the device.
High voltage may damage the device.
Power connectors and other connectors should be firmly interconnected.
Do not plug in or out the power supply with wet hands. When the device is powered on,
do not touch the device or any parts with wet hands.
Before operating a device connected to a power cable, remove all jewelry (such as rings,
bracelets, watches, and necklaces) or any other metal objects, because they may cause
electric shock or burns.
Do not operate the device or connect or disconnect cables during an electrical storm.
Use compatible connectors and cables. If you are not sure, contact our sales or technical
support personnel for confirmation.

Do not disassemble the device by yourself. When an anomaly occurs, contact our sales
or technical support personnel.
If any part is lost, contact our sales or technical support personnel to purchase the
substitute. Do not purchase parts from other channels.
Dispose of the device in accordance with relevant national provisions, preventing
environmental pollution.
In the following cases, please immediately shut down the power supply and contact
Kyland:
Water gets into the device.
Device damage or shell damage.
Device operation or performance has abnormally changed.
The device emits odor, smoke or abnormal noise.

Contents
1 Product Overview...............................................................................................................6
2 Structure and Interface.......................................................................................................7
2.1 Front Panel ................................................................................................................. 7
2.2 Top Panel.................................................................................................................... 8
3 Mounting.............................................................................................................................9
3.1 Dimension................................................................................................................... 9
3.2 Mounting Modes and Steps ........................................................................................ 9
3.3 DIN Mounting.............................................................................................................10
4 Connection .......................................................................................................................12
4.1 10/100/1000Base-T(X) ethernet port..........................................................................12
4.2 POE Function.............................................................................................................13
4.3 1000Base-X, 10/100/1000Base-T(X)SFP interface....................................................14
4.3.1 SFP optical module .............................................................................................15
4.4 Console Port ..............................................................................................................16
4.4.1 RJ45 Console Port ..............................................................................................16
4.5 Grounding..................................................................................................................17
4.6 Power Terminal Block................................................................................................18
4.7 Alarm Terminal Block.................................................................................................20
4.8 DI/DO Interface..........................................................................................................21
5 Reset................................................................................................................................22
6 LED Status .......................................................................................................................23
7 Access..............................................................................................................................25
7.1 Access through Console Port.....................................................................................25
7.2 Access through Telnet ...............................................................................................27
7.3 Access through Web..................................................................................................27

8 Basic Features and Specifications....................................................................................29

Product Overview
1 Product Overview
SICOM3000S series switch is a two-layer network management PoE industrial Ethernet
switch developed by Kyland for petroleum and petrochemical, factory automation, intelligent
transportation, rail transit and other industries.
This series of switches supports DIN rail mounting, provides RJ45 management port,
supports Console、Telnet、Web management; Reset button hasone-click recovery function.
This switch can be configured with up to 4 1000Base-X, 10/100/1000Base-T(X) SFP
ethernet interfaces and 8 100/1000Base-T(X) POE ethernet interfaces. 100/1000Base-T(X)
ethernet interface supports IEEE802.3at (Compatible IEEE802.3af), The switch can provide
a maximum of 240W (L16) power. The specific configuration is as follows.
Table 1 SICOM3000S Configuration Table
Model
number
SICOM3000S-4GX8GP-L16-L16 SICOM3000S-4GX8P-L16-L16
SICOM3000S-2GX4GP-L16-L16 SICOM3000S-2GX4P-L16-L16
Code definition
Code Selection
Ports
4GX8GP、4GX8P、2GX4GP、2GX4P
Description:
4GX8GP:41000Base-X ， 10/100/1000Base-T(X)SFPinterface;810/100/1000Base-
T(X) POE electrical interface;
4GX8P: 4 1000Base-X ， 10/100/1000Base-T(X) SFP interface; 8 10/100 Base-T(X)
POE electrical interface;
2GX4GP ： 21000Base-X ， 10/100/1000Base-T(X)SFPinterface;4 10/100/1000Base-
T(X) POE electrical interface;
2GX4P ： 2 1000Base-X ， 10/100/1000Base-T(X) SFP interface; 410/100 Base-T(X)
POE electrical interface;
PS1-PS2:
power input
L16-16: 45V-49V (dual redundancy), support 802.3af;
L16-16: 50V-57V (dual redundancy), support 802.3at.

Structure and Interface
2 Structure and Interface
Caution:
It is recommended to purchase the portdustproof shield (optional) to keep portsclean and ensure
switch performance.
2.1 Front Panel
Figure 1 Front panel
(1) PWR 1 LED
(2) PWR 2 LED
(3) Run LED
(4) Ring status LED
(5) Reset button
(6) Alarm LED
(7) 1000M SFP interface
(8) 1000M SFP interface speed LED (yellow)
(9) 1000M SFP interface link status LED (green)
(10) 1000M SFP interface speed LED (yellow)
(11) 1000M SFP interface link status LED (green)
(12) 10/100/1000Base-T(X) ethernet interface
(13) 10/100/1000Base-T(X) ethernet interface speed
LED (yellow)
(14) 10/100/1000Base-T(X) ethernet link status LED
(green)

Structure and Interface
(15) output signal LED
(16) input signal LED
(17) POE output LED
(18) output signal
interface
(19) output GND
(20) input signal interface
(21) input GND
2.2 Top Panel
Figure 2 Top panel

Mounting
3 Mounting
3.1 Dimension
Figure 3 DIN-rail mounting dimension (mm)
Caution:
As part of the heat dissipation system, the switch housing becomes hot during
operation. Please do not cover the switch housing when the switch is running.
The figures in this manual are only for reference.
3.2 Mounting Modes and Steps
The switch supports DIN-rail mounting. Before installation, make sure that the following
requirements are met.
1) Environment: temperature (-40℃to 85℃), ambient relative humidity (5% to 95%,
non-condensing).
2) Power requirements: Verify that the operating voltage matches the voltage range
identified on the switch.
3) Grounding resistance: <5。
4) Avoid direct sunlight, away from heating sources or areas with strong electromagnetic

Mounting
interference.
5) The installation environment should meet the requirements of the authority, do not
touch the equipment directly by hand, avoid causing personal injury.
6) Only professionals or trained and qualified personnel can perform installation,
replacement and maintenance operations for this switch.
3.3 DIN Mounting
DIN-rail mounting
Step 1: Select the mounting position for the switch and ensure enough space and smooth
heat dissipation.
Step 2: Clamp the top of the rail seat on the DIN rail, slightly force up the bottom of the
device, rotate the device follow arrow 2 as below figure, ensure the DIN rail reliably fits in the
connecting seat.
Figure 4 DIN-rail mounting
DIN-rail dismounting
Step 1: As shown in the following figure, press the device downward and move the device
in direction 1 until the bottom of the device is detached from the DIN rail.
Step 2: Pull the device upward and move the device in direction 2 until the device is
removed from the DIN rail completely.

Mounting
Figure 5 DIN-rail dismounting

Connection
4 Connection
4.1 10/100/1000Base-T(X) ethernet port
10/100/1000Base-T(X) Ethernet port uses standard RJ45 connector. The port supports
self-adaptive and it can be automatically configured to 10M/100M/1000M, full or half duplex
mode. The port can also support auto MDI/MDI-X, that is connect the port to a terminal or
network device with a straight-through or cross-over cable.
Pin Definition
Figure 6 RJ45 PIN number
Table 2 10/100Base-T(X) Ethernet Port PIN Definition
PIN
MDI-X signal name
MDI signal name
1
Receive Data+ (RD0+)
Transmit Data+ (TD0+)
2
Receive Data- (RD0-)
Transmit Data- (TD0-)
3
Transmit Data+ (TD1+)
Receive Data+ (RD1+)
4
Receive Data+ (RD2+)
Transmit Data+ (TD2+)
5
Receive Data- (RD2-)
Transmit Data- (TD2-)
6
Transmit Data- (TD1-)
Receive Data- (RD1-)
7
Transmit Data+ (TD3+)
Receive Data+ (RD3+)
8
Transmit Data- (TD3-)
Receive Data- (RD3-)
Note:
"+" and "-" indicate level polarities.

Connection
Wiring Sequence
Figure 7 10/100Base-T(X) RJ45 Connection Using Straight-through/Cross-over Cable
Note:
The color of the cable for RJ45 connector follow standard 568B (1-orange and white，2-orange,
3-green and white, 4-blue, 5-blue and white, 6-green, 7-brown and white, and 8-brown.)
4.2 POE Function
This device power the external PD (Power Device) through 10/100 Base-T (X) or
10/100/1000 Base-T(X) ethernet interface as PSE (Power Sourcing Equipment).
10/100Base-T(X) and 10/100/1000Base-T(X) ethernet port support IEEE802.3at (compatible
IEEE802.3af), each POE port supplies up 30W power, L16-L16 supply up 240W powe.
1、POE definition
POE (Power over Ethernet) means that a device uses twisted-pair wires to power an
external PD (power device) through an ethernet interface. A maximum power supply distance
is 100 m.
2、POE power supply mode
This device supports to power supply to PD over data signal wire.
Table 3 RJ45 PIN definition
PIN
MDI-X signal name
MDI signal name
POE power supply

Connection
RJ45 interface
1
Transmit/Receive Data
(TRD1+)
Transmit/Receive Data
(TRD0+)
V-
2
Transmit/Receive Data
(TRD1-)
Transmit/Receive Data
(TRD0-)
V-
3
Transmit/Receive Data
(TRD0+)
Transmit/Receive Data
(TRD1+)
V+
4
Transmit/Receive Data
(TRD3+)
Transmit/Receive Data
(TRD2+)
--
5
Transmit/Receive Data
(TRD3-)
Transmit/Receive Data
(TRD2-)
--
6
Transmit/Receive Data
(TRD0-)
Transmit/Receive Data
(TRD1-)
V+
7
Transmit/Receive Data
(TRD2+)
Transmit/Receive Data
(TRD3+)
--
8
Transmit/Receive Data
(TRD2-)
Transmit/Receive Data
(TRD3-)
--
Note:
"+" and "-" indicate level polarities.
4.3 1000Base-X, 10/100/1000Base-T(X)SFP interface
1000Base-X,10/100/1000Base-T(X)SFP interface (gigabit SFP interface) requires an
SFP optical/electrical module to enable data transmission. The following table lists the
gigabit SFP optical/electrical modules (optional) supported by the series switches.
Table 4 SFP optical/electrical modules
Model number
Interface
MM/SM
Connector
Wavelength
Distance

Connection
IGSFP-M-SX-LC-850-0.55
1000Base-X
MM
LC
850nm
0.55km
IGSFP-S-LX-LC-1310-10
1000Base-X
SM
LC
1310nm
10km
IGSFP-S-LH-LC-1310-40
1000Base-X
SM
LC
1310nm
40km
IGSFP-S-ZX-LC-1550-80
1000Base-X
SM
LC
1550nm
80km
Note:
The switch support optical power detection of SFP port, this function needs SFP module with
DDM, if you want to get more detailed information, please contact market or technical engineer.
4.3.1 SFP optical module
Figure 8 SFP optical module
SFP optical module interface adopts standard LC fiber connector, each interface is
divided into transmit port (TX port) and receive port (RX port). To enable communication
between DeviceA and Device B, connect the TX port of Device A to the RX port of Device B,
and the RX port of Device A to the TX port of Device B, as shown in the below figure.
Figure 9 SFP optical module connection
How to Connect the SFP Optical Module
Insert the SFP optical module into the SFP slot in the switch, and then insert the fibers
into the TX port and RX port of the SFP module.

Connection
Figure 10 Connecting the SFP Optical Module
Confirm the RX port and TX port of an SFP optical module:
1. Insert the two connectors at one end of fibers into the two interfaces of SFP module, and
then insert the two connectors at the other end of fibers into the two interfaces at the
corresponding end.
2. View the corresponding connection status LED: If the LED is on, the connection is
correct. If the LED is off, the link is not connected. This may be caused by incorrect
connection of the TX and RX ports. In this case, swap the two connectors at one end of the
fibers.
Caution:
The device uses laser to transmit signals over fiber. The laser meets the requirements of level
1 laser products. Do not look directlyat the fiber portto avoid to harm to your eyes when device
is powered on.
For SFP module which transmission distance is longer than 60km, do not use a short fiber
(<20km) to connect to avoid the SFP module is brunt since the optical power is saturation.
4.4 Console Port
4.4.1 RJ45 Console Port
Connect the 9-pin serial port of a PC to the console port of the switch with a DB9-RJ45
console cable. Then you can configure, maintain, and manage the switch by running Hyper
Terminal in Windows OS.

Connection
Figure 11 Console port
DB9-RJ45 Console Cable
One end of a DB9-RJ45 console cable is crimped RJ45 connector to be inserted into the
console port of the switch, and the other end is the DB9 connector to be inserted into the 9-
pin serial port of a PC.
Figure 12 Wiring Sequence of DB9-RJ45 Console Cable
Table 5 Pin Definitions of DB9 Port (9-Pin Serial Port) and RJ45 Port (Console Port)
DB9 Port (9-Pin Serial Port)
RJ45 Port (Console Port)
Pin
Signal
Pin
Signal
2
RXD (Receive Data)
2
TXD (Transmit Data)
3
TXD (Transmit Data)
3
RXD (Receive Data)
5
GND (Grounding)
5
GND (Grounding)
4.5 Grounding
Normal grounding of device is important for lightning protection and anti-interference, so
the user must connect the ground wire correctly. and ground before power on, and then
disconnect the ground wire after power off.

Connection
The switch provides a grounding screw on the top panel for chassis grounding. After
crimping one end of the grounding cable to a cold pressed terminal, fix the grounding screw
and connect the other end to the earth firmly.
Note:
Cross-sectional area of the chassis grounding cable>2.5 mm2; grounding resistance<5Ω.
4.6 Power Terminal Block
The power terminal is located on the cover plate of the device, and the power cord is
connected to the terminal blockto supply power to the device.This device supports redundant
power input and adopts 5 core 5.08 mm spacing plug-in terminal block. when any one of the
power supply failure, the device can run normally without interruption, improve the reliability
of network operation.
说明：
Power cord cross-sectional area should be above 0.75mm2(max cross-sectional is 2.5mm2)；
grounding resistance<5。
Copper conductor must be used for field wiring and the temperature should
meet 75℃.
5-Pin 5.08mm-Spacing Plug-in Terminal Block
Figure 13 5-Pin 5.08mm-Spacing Plug-in Terminal Block (socket)
Table 6 Pin Definitions of 5-Pin 5.08mm-Spacing Plug-in Terminal Block
No.
Signal
DC Definition
AC Definition
1
+/L
PWR1：+
PWR1：L
2
-/N
PWR1：-
PWR1：N

Connection
3
PGND
PGND
4
-/N
PWR2：-
PWR2：N
5
+/L
PWR2：+
PWR2：L
Wiring and Mounting
Step 1: Ground the device properly according to section 4.5.
Step 2: Remove the power terminal block from the device.
Step 3: Insert the power wires into the power terminal block according to Table 6 and fix
the wires.
Step 4: Insert the terminal block with the connected wires into the terminal block socket
on the device.
Step 5: Connect the other end of the power wires to the external power supply system
according to the power supply requirements of the device. View the status of the power
LEDs on the front panel. If the LEDs are on, the power is connected correctly.
Wiring and mounting should meet the following specifications
Table 7 Wiring and Mounting Specifications
Terminal Block type
Torque requirements
Cross-sectional area (AWG)
Plug-in Terminal Block
4.5-5.0 lb-in
12-24
Caution:
Before connecting the device to powersupply, make surethatthe power input meets the power
requirement.
To meet the UL requirements, the power supply of the device should conform the Class 2.
Warning:
Do not touch anyexposed conducting wire, terminal or component with a voltage warning sign,
it may cause damage to humans.
Do not remove any part or plug in or out any connector when the device is powered on.
