Kyocera ECOSYS P7240cdn Reference manual

(Page.1/11)
Service Bulletin Ref. No. 2TV-0015 (J130)
(Service information) <Date> July 19, 2019
KYOCERA Document Solutions Inc.
For authorized KYOCERA engineers only.
Do not distribute to non-authorized parties.
A
B
C
CONFIDENTIAL
Subject:
서비스 호출 오류 C4600 에대한 조치 (서비스 부품으로 먼지
필터, LSU 구동 장치 등설정)
Model: l:
P7240cdn, P6235cdn, P6230cdn, P7040cdn, P6035cdn,
P6130cdn,
M6635cidn, M6630cidn, M6235cidn, M6230cidn, TASKalfa 351ci,
M6535cidn, M6530cdn, M6035cidn, M6030cdn, TASKalfa 350ci
Classification:
Field measures
timing:
At Set Up Next Periodic Maintenance
Next Visit/Service Call Information only
Phenomenon:
SC/Error Paper Feeding/Conveying Other
Image Machine operation
Type of change:
Hardware Firmware and Software Information
Depending on installation environment, dust gets into the main unit through the louver at the left side of the main
unit and adheres to the LSU drive part. The LSU cleaning motor rotation torque increases and servcie call error
C4600 (LSU cleaning motor error) might occur at the LSU slit glass cleaning (executed in a specified interval)
Follow the procedures 1-4 below when the above phenomenon occurs.
[Field measure] (Refer to page 3-5 for procedure 1,2,4 and 6 and after or procedure 3)）
1. Clean around the louver of the middle left covr and lower left cover (2 points).
2. Attach the filter mounting holder (No2)to the above louver and set the dust filter (No1).
3. Check the condition of LSU drive unit (No4 or No5) and replace it if necessary.
(It is difficult to remove dust inside the LSU drive unit and it is recommended to replace the unit but not
mandatory.)
4. (Maintenance afterward) Clean the dust filter or replace it when visiting the customer. (Standard interval
to replace: 1 year) At the same time, check the condition of the the filter mounting holder secured and if
coming off, use the double sided tape set of 6 pcs. (No3) to replace the double sided tape.
[Service parts set for the field measure]
To implement the above, parts for field measure are set for service.
Parts for field measure
No. in part table
Remarks
Set of 2 pcs. dust filters
No1
Used at the 1st attachment and filter
replacement afterward
Set of 2 pcs. filter mounting holders + 6
pcs. double sided tape
No2
Used at the 1st attachment only
Set of 6 pcs. double sided tape
No3
Used at the maintenance after implementing
this field measure
LSU drive unit (No4, 5)
No4, 5
Used to replace if difficult to remove dust

(Page.2/11)
Service Bulletin Ref. No. 2TV-0015 (J130)
(Service information) <Date> July 19, 2019
KYOCERA Document Solutions Inc.
For authorized KYOCERA engineers only.
Do not distribute to non-authorized parties.
A
B
C
CONFIDENTIAL
N00107707; N00107682; N00107726; N00107948; N00107576; Q1904003
Field Measure: No particular problems are expected.
First implemented timing at factory: After using up the old stock.
Parts Table
No.
Old Part
No.
New Part
No.
Description
Q’
ty
Com
bi
pati
lity
Remarks
Old
New
Old
New
1
----------
302NR94350
PARTS FILTER FAN SET SP
-
1
-
O
Set of 2 pcs. dust
filter
2
----------
302TX94090
PARTS HOLDER FILTER SET SP
-
1
-
O
Set of 2 pcs. filter
mounting holders + 6
pcs. double sided
tape
3
----------
302TX94100
+PARTS TAPE FILTER FAN SET
SP
-
1
-
O
Set of 6 pcs. double
sided tape
4
----------
302TV94100
PARTS LSU DRIVE ASSY SP
-
1
-
O
LSU drive unit for
30/35ppm model
5
----------
302TX94080
PARTS LSU DRIVE ASSY SP
-
1
-
O
LSU drive unit for
40ppm model
"+" mark at the beginning of the part name means it is a component parts.
[Attachment condition of the dust filter
and filter mounting holder]
(Left side of the main unit)
[Positional relationship of parts]
A: Middle left cover
B: Lower left cover
C: LSU
D: LSU drive unit
E: LSU cleaning motor
X
A
B
C
[Machine rear side of
LSU drive unit (D)]
(Arrow view X)
E
Louver
Filter mounting holder
(with double sided
tape)
Dust filter
D

(Page.3/11)
Service Bulletin Ref. No. 2TV-0015 (J130)
(Service information) <Date> July 19, 2019
KYOCERA Document Solutions Inc.
For authorized KYOCERA engineers only.
Do not distribute to non-authorized parties.
A
B
C
CONFIDENTIAL
[Set of 2 pcs. dust filter (No1)]
[Set of 2 pcs. filter mounting holders + 6 pcs. double sided tape (No2]]
[Set of 6 pcs. double sided tape (No3)]
[LSU drive unit (No4, 5)]
(Extract from FIG.13 of P7240cdnparts list)
*Ref No.500s are not for supply to field
*1: Wire only, listed in Wire Section in other than FIG.13
Ref No.10：
PARTS PWB ASSY DRUM
CONNECT SP
(for 40ppm printer: 302NT9402_
for the other:302NR9412_)
Ref No.9：
PARTS DC MOTOR ASSY SP
（302NG9443_）
*1：
CONN.CORD ASSY S03959
ENGINE-LSU CL
（302NR4629_）

(Page.4/11)
Service Bulletin Ref. No. 2TV-0015 (J130)
(Service information) <Date> July 19, 2019
KYOCERA Document Solutions Inc.
For authorized KYOCERA engineers only.
Do not distribute to non-authorized parties.
A
B
C
CONFIDENTIAL
Procedures to attch the dust filter and filter mounting holder
(Estimate work time: 10min. or less)
No
Procedure
Detail
1
Detach the middle left cover (a) and lower left
cover (b), and clean around the louver (c) of
inner and outer side of the machine. (Refer to
each model service manual Chapter4
[Detaching/reattaching the lower left cover] for
the procedures to detach the above cover.)
Reattach the middle left cover (a) and lower left
cover (b) after cleaning.
2
Clean around the louver (d) at the outer side of
the main unit with alcohol.
3
Affix 3 pcs. double sided tape (f) to the filter
mounting holder (e).
Note:
The double sided tape (f) should not run over
the sticking area of the filter mounting holder (e)
(Figure for 40ppm printer)
c
a
b
(Example)
c
d
e
f

(Page.5/11)
Service Bulletin Ref. No. 2TV-0015 (J130)
(Service information) <Date> July 19, 2019
KYOCERA Document Solutions Inc.
For authorized KYOCERA engineers only.
Do not distribute to non-authorized parties.
A
B
C
CONFIDENTIAL
No
Procedure
Detail
4
Peel of the carrier sheet of the double sided
tape (f) and affix 2 pcs. filter mounting holders
(e) to the louver (c) on the middle left cover and
lower left cover with the alignment below.
Press there firmly after affixing.
[Alignment]
[Front side louver (Y: right side in the top
figure)]
・Vertical: g above 20mm from h
g…Edge of the filter mounting holder
h…Bottom edge of the middle left cover (white)
・Horizontal: Edge (i) of the front side of the
main unit of the middle left cover
[Rear side louver (Z: left side in the figure)]
・Vertical: Upper edge (l) of the lower left
cover (black)
・Horizontal: The louver (c) located in the
center of circle (k) of the filter
mounting holder (e)
(Refer to the right figure)
(Refer to Procedure 1 for (c) and Procedure 3
for (f))
5
Insert the filter mounting holder (e) from the
upper side while pressing the left and right
edge of the dust filter (m)
Note:
・Attach the dust filter (m) in the direction in the
right figure.
・Clean the dust filter (m) using a vacuum
cleaner, etc. Standard interval to replace is 1
year and the timing depends on the installed
environment.
20mm
h
g
i
e
Y
Z
k
l
e
e
m

(Page.6/11)
Service Bulletin Ref. No. 2TV-0015 (J130)
(Service information) <Date> July 19, 2019
KYOCERA Document Solutions Inc.
For authorized KYOCERA engineers only.
Do not distribute to non-authorized parties.
A
B
C
CONFIDENTIAL
Replace the LSU drive unit
(Estimate worktime: 30 min.)
No
Procedure
Detail
1
Detach the external covers and units below.
・Upper right cover
・Middle right cover
・Upper left cover
・Middle left cover
・2 LSUs
・Primary transfer unit
・4 drum units
・4 developer units
(Refer to each model service manual Chapter 4 for
the detaching procedures for each part)
2
Release hook (o) of 3 pcs. parts (n) securing
FFC and detach them.
3
Disconnect the connecter (q) of the LSU cleaning
motor wire (red) connecting to YC26 connector of
the engine relay PWB (p).
(Condition inside the main unit after
detaching the parts to the left)
n
o
YC26
p
q

(Page.7/11)
Service Bulletin Ref. No. 2TV-0015 (J130)
(Service information) <Date> July 19, 2019
KYOCERA Document Solutions Inc.
For authorized KYOCERA engineers only.
Do not distribute to non-authorized parties.
A
B
C
CONFIDENTIAL
No
Procedure
Detail
4
Release 4 hooks (t) at the lower sider of the LSU
drive unit (s) in the order of 1 to 4 in the figure and
detach it from the metal plate.
5
Release the upper side hooks (u) in the order of 1
to 4 in the figure while the lower hooks (t) are
released as in Procedure 4.
1
h
2
h
3
h
4
h
s
t
t
(Rear side of the main unit)
(Front side of the main unit)
1
h
2
h
u
3
h
4
h
u

(Page.8/11)
Service Bulletin Ref. No. 2TV-0015 (J130)
(Service information) <Date> July 19, 2019
KYOCERA Document Solutions Inc.
For authorized KYOCERA engineers only.
Do not distribute to non-authorized parties.
A
B
C
CONFIDENTIAL
No
Procedure
Detail
6
Pull the LSU drive unit (s) to the center of the main
unit and pull out the LSU cleaning motor wire (q)
through the hole (v) on the left frame of the main
unit.
Note:
The LSU drive unit (s) cannot be take out since
the FFC is connected at this procedure.
7
Release 4 hooks (x) of COVER DUCT LEFT (w) at
the rear side of the main unit (LSU cleaning motor
side) in the order of 1 to 4 in the figureCOVER and
detach COVER DUCT LEFT (w).
8
Disconnect the FFC terminal (z) from the FFC
connector on the drum relay PWB (y).
9
Detach COVER DUCT LEFT(w) of the new LSU
drive unit (s) (35/35ppm printer/MFP: No4, 40ppm
printer: No5) at the rear side of the main unit (LSU
cleaning motor side) (Refer to Procedure 7)
s
v
q
w
1
3
2
4
x
y
z

(Page.9/11)
Service Bulletin Ref. No. 2TV-0015 (J130)
(Service information) <Date> July 19, 2019
KYOCERA Document Solutions Inc.
For authorized KYOCERA engineers only.
Do not distribute to non-authorized parties.
A
B
C
CONFIDENTIAL
No
Procedure
Detail
10
Pass through the FFC terminal (z) disconnected at
Procedure 8 in between DUCT COVER INNER of
the new LSU drive unit (s) and the edge of the
drum relay PWB (y).
Connect the FFC terminal (z) to the FFC
connector of the drum relay PWB (y).
11
Reattch COVER DUCT LEFT (w).
12
Pass the LSU cleaning motor wire (q) through the
hole (v) on the left frame of the main unit (Refer to
Procedure 6)
w
z
s
y
DUCT COVER INNER
z
y

(Page.10/11)
Service Bulletin Ref. No. 2TV-0015 (J130)
(Service information) <Date> July 19, 2019
KYOCERA Document Solutions Inc.
For authorized KYOCERA engineers only.
Do not distribute to non-authorized parties.
A
B
C
CONFIDENTIAL
No
Procedure
Detail
13
Insert 2 positioning bosses (F) on the LSU drive
unit into2 positioning holes (G) on the left frame of
the main unit.
14
Insert 4 upper hooks (u) in the order of 1 to 4 in
the figure.
G
G
F
F
(Front side of the main unit)
(Rear side of the main unit)
u
u
1
2
3
4

(Page.11/11)
Service Bulletin Ref. No. 2TV-0015 (J130)
(Service information) <Date> July 19, 2019
KYOCERA Document Solutions Inc.
For authorized KYOCERA engineers only.
Do not distribute to non-authorized parties.
A
B
C
CONFIDENTIAL
No
Procedure
Detail
15
Insert 4 lowe hooks (t) in the order of 1 to 4 in the
figure.
Note: The hook (t) breaks easily and so press the
root of the hook (Yin the figure) to insert it into the
hole on the metal plate.
16
Connect the wire connector (q) of the LSU
cleaning motor to YC26 connector of th engine
relay PWB (p) (Refer to Procedure 3 in page 6)
17
Reattach 3 pcs. parts (n) to to secure FFC.
(Refer to Procedure 2 in page 6)
18
Reattachthe external covers and units detached
(Refer to Procedure 1 in page 6)
(Rear side of the main unit)
(Front side of the main unit)
1
2
3
4
t
t
t
Y
