Kyocera C4700 User manual

C4700 User Guide
Touchscreen Mobile Phone

1
Table of Contents
Introduction ..........................................................2
For Your Safety ...................................................3
Getting Started ....................................................4
Call Functions ....................................................12
Contacts ............................................................ 14
Call Log ............................................................. 17
Calendar ............................................................ 17
Multimedia ......................................................... 18
Messaging ......................................................... 22
Games ............................................................... 24
Internet .............................................................. 24
Profiles ............................................................... 26
Tools ..................................................................26
Camera .............................................................. 26
My files .............................................................. 28
Settings .............................................................. 28
Care and Maintenance ......................................32

© 2010 by Compal Communications Inc. All rights reserved
No part of this publication may be reproduced, stored in a retrieval system or
transmitted in any form or by any means(electronic, mechanical, photocopying,
recording or otherwise) without prior written permission from Compal Communi-
cations Inc.
2
Introduction
Thank you for choosing the product. The C4700 is a
touchscreen mobile phone features a 2.8 inch screen with
240*320 resolution, a 2-megapixel camera/camcorder, and
Bluetooth for handsfree devices. This is also a quad-phone
supporting the four global standard GSM frequencies of 850/
2100 MHz, so you do not worry about that whether or not
your phone will work in a different country.
As you explore your C4700 mobile phone, use this guide to
find out more useful information.
Now get your SIM card and enjoy your new C4700 mobile
phone!

3
For Your Safety
Read and understand all the following guidelines before
using the product. Breaking the rules may be dangerous or
illegal.
• Use only approved battery and charger. Do not connect
incompatible products. Using other types of batteries or
chargers may damage the phone and void the
warranty.
• Turn off the phone before inserting or removing the
battery and memory card.
• Keep the battery and the phone dry and away from
water or any other liquids as it may cause a short
circuit.
• Keep the battery out of the reach of children.
• Do not dispose of the battery by fire or with hazardous
or flammable materials.
• Do not use a hand-held phone while driving, except in
the case of emergency.
• Do not use the phone in areas where its use is
prohibited. Switch the phone OFF near medical
equipment, in aircraft, and at the refueling point.
• Do not take apart or attempt to service the phone
yourself.

4
Getting Started
Phone at a glance
1 Earphone jack 8 Speaker
2 Earpiece 9 Camera lens
3 Touch screen 10 Volume keys
4 Menu key 11 USB charge/sync
connector
5 Call key 10 Volume keys
6 Power/End key 12 Back cover
7 Microphone 13 Camera key
2
3
1
9
10
11
13
12
5
4
8
6
7

5
SIM card
The SIM (Subscriber Identity Module) card, which contains
your subscription details, is provided by your network
operator.
Install the SIM card, battery and memory
card
Always turn off your phone and disconnect the charger
before installing or replacing the SIM card, battery, and
memory card.
1. Slide the back cover downward to
release and remove the cover.
Important!
Keep your SIM card in a safe place when you are not using
it. The SIM card can be easily damaged by scratching,
bending, or exposing it to static electricity, water, or dirt.

6
2. Locate the SIM card slot and
insert the SIM card with its gold
contacts facing down and its cut-
off corner facing out the card slot.
Make sure the card is securely
inserted.
3. If necessary, locate the memory
card slot and insert the memory
card with its gold contacts facing
down as shown. Make sure the
card is securely inserted.
4. Insert the battery with the correct
polarity. Then gently press down
to secure the battery.
5. Slide the back cover into place.
To remove the SIM card, memory
card, and battery,
1. Make sure the phone is turned off.
2. Remove the back cover.
3. Lift out the battery from the notches
at the bottom of the battery
compartment as shown.

7
4. Gently press on the SIM card and
slide it out of its slot.
5. Gently press on the memory card
and slide it out of its slot.
Charge the battery
1. Make sure the battery is installed properly in your
phone.
2. Connect the AC charger and the phone using the
supplied USB sync cable.
3. Plug in the AC charger to an electrical outlet to start
charging the battery.
An icon in the upper-right corner of the Main screen shows
battery charging status. When charging is complete, a full
battery icon ()appears on the screen. Disconnect the
phone and the charger from the electrical outlet.
Important!
The rechargeable Lithium-ion battery is not charged when
shipped. Before you start using your phone, it is
recommended that you install and fully charge the battery.

8
Low battery indicator
When the battery power is low, you will find a blinking empty
battery icon ()at the top of the Main screen. The phone
will sound an alert and display a low-battery warning
message. In this condition, you should immediately charge
the battery, otherwise the phone may be turned off
automatically.
Turn your phone on and off
To turn the phone on, press and hold the Power/End key
until the display lights up. If you have set up phone and SIM
card password, the phone may prompt you to enter your
password to unlock your phone or SIM card.
To turn off the phone, press and hold the Power/End key for
a few seconds.
NOTE
Your phone can be charged via a computer’s USB port. To
do so, connect your phone directly to a computer’s USB
port using the supplied USB cable. Make sure the
computer used for charging is turned on.

9
Status indicators
Your device status indicators are located at the top of the
Main screen. Here’s some common indicators:
Lock the keys and touchscreen
To avoid accidental dialling, the touchscreen and keys may
be locked automatically after a period of inactivity. You can
also lock the touchscreen and keys manually by pressing
the Menu key.
To unlock, press and hold the icon on the Main screen.
: The current signal strength of the cellular network.
: You have selected the Normal profile mode.
: You have one or more unread messages.
: Alarm has been set.
: Bluetooth function is activated.
: Bluetooth device is connected.
: The battery charging level.
: Available 3G network connection.
: Available Edge network connection.

10
Adjust the volume
The volume keys on the side of the phone allows you to
quickly adjust ring tone, music player and earpiece volumes.
Access the Main menu and shortcut menus
• To start using the touchscreen, first press the Menu key
on the phone to enter the Main menu.
• Tap a menu item you want to use. Each menu item may
have a shortcut menu. To access, touch a menu item
and tap at the top left-hand corner of the screen.
There may be more options available under a shortcut
menu. Touch and hold a shortcut menu to bring up its
option menu. Touch and slide your finger up or down
the screen to scroll through the shortcut menu and
option menu.
• To go back to the previous screen, tap at the top
right-hand corner of the screen.
NOTE
Earpiece volume can be only adjusted during a call.

11
Widget
Widgets are placed at the bottom of the Main screen, which
is called Widget section. These widgets can be shortcuts to
an application or program so that you can easily access
them from the Main screen. You can drag widgets left and
right to reorder them. To open a widget, do the following:
1. Press the widget you want to use until the icon turns
green.
2. Drag it out of the Widget section and onto the desktop.
To close a widget, press the widget until the icon turns green
and drag it back to the widget section.
Text input modes
When you store names in the Contacts or write a message,
you can enter text by using the on-screen keypad. Tap
to bring up the text input menu.

12
Call Functions
Make a call
There are two ways you can make a call,
• From the Dialer -- From any screen, press the Call key
to bring up the Dialer. Use the on-screen keypad to
enter the phone number, then touch to call the
number.
•FromContacts -- Tap the desired contact in the contact
list, and tap the phone number that you want to call.
Answer or reject a call
When a call comes in, the screen displays the phone
number or a caller’s name (if stored in Contacts).
• To answer the call, press the Call key on the phone or
tap the green Answer button on the screen.
• To reject a call, press the Power/End key on the phone
or tap the red End/Reject button on the screen.
End a call
When you are finished talking, tap the End/Reject button on
the Dialer screen to hang up.

13
During a call
Your phone provides a number of options that you can use
during a call.
• : Mute/Unmute the microphone.
• : Activate/Deactivate the speakerphone.
• : Place the current call on hold, allowing you to
alternate between two calls.
• : Place another call. To make a three-party
conversation, tap .
• : Search for a number in Contacts.
Speed dial
Speed dialling allows you to make a call with a single tap on
the Dialer screen. Before you can use this function, you will
need to assign different phone numbers to the speed dial
numbers.
How to set up speed dial?
See "Speed dial" on page 13.

14
Contacts
Contacts lists all entries on your phone and on the SIM
card. You can use this feature to create, edit, and manage
all contact information. Touch and slide your finger up or
down the screen to scroll through Contacts directory.
Add a new contact
1. Press the Menu key to enter the Main menu.
2. Tap Contacts > > Add.
3. Touch each field and use the on-screen keypad to enter
the necessary information.
4. You can also assign a picture or a specific ring tone to a
new contact.
5. To add more fields, tap > Add.
6. When finishing editing, tap > Save.
Caller groups
The phone provides five default groups as follows,
Business, Family, Friends, Others, and VIP. You can also
create new groups or delete existing groups from Main
menu > Contacts > > Group.

15
To assign a contact to a group:
1. Press the Menu key to enter the Main menu.
2. Tap Contacts > > Groups.
3. Touch a group type, tap , and select a contact from
the list.
Speed dial
Speed dials can only be assigned to numbers stored in
Contacts only. To create a speed dial entry from Contacts,
do the following:
1. Press the Menu key > tap Contacts > > Speed dial.
2. Tap a key to use as the speed dial key.
3. Tap a desired contact to assign to that key.
Personal details
From the Main menu, tap Contacts > > My details or
Owner numbers to enter your personal details.

16
Service dial number
From the Main menu, tap Contacts > > Service dial
number to view the SDN (Service Dialing Numbers) list
assigned by your service provider in your SIM card.
SOS number
From the Main menu, tap Contacts > > SOS number.
The worldwide emergency number for mobile is 112.
Manage contacts
This feature allows you to copy and move contacts to
different databases (from phone memory to SIM card or vice
versa), and clear all contacts from both your phone memory
and SIM card. To use this function, enter the Main menu,
and tap Contacts > > Manage contacts.
Settings
From the Main menu, tap Contacts > > Settings to
display the following advanced configuration.
•Sort contacts by: Choose from First name or Last
name.

17
•Save new contacts to: Choose from Ask each time,
Phone memory, or SIM memory.
•View contacts from: Choose from Phone memory,
SIM memory, or Both phone and SIM.
Call Log
Call Log allows you to view all recent history including all
received, dialed, and missed calls. Enter the Main menu,
and tap Call Log > to clear call history, and check call
time or cost.
Calendar
You can use this application to schedule appointments or a
repeating event such as a birthday, anniversary, or meeting.
Create a new calendar entry
1. Open the Main menu and tap Calendar.
NOTE
The most recent calls are listed first. The phone will list
recent calls in 30 days and store call logs for 30 days by
default. You can change the settings via Main menu > Call
Log > > Settings.

18
2. Touch a specific date. Tap > New.
3. Choose the new event type from Appointment,
Anniversary, Birthday, and Vacation. Then enter the
event information. The reminder and event recurrence
can be set for appointments only.
View and delete an event
• To open an event, touch a specific date, and then tap
> View day.
• To delete an event, touch a specific date, and then tap
> Delete.
• To move to the current date, tap > Go to today.
You can configure the starting day of the calendar and the
default reminder time for appointments via > Settings.
Multimedia
Multimedia works as an entertainment center, which is well
equipped with image gallery, music player, video player,
voice recorder, and FM radio.

19
View images
Open the Main menu and tap Multimedia > Gallery to view
all the images stored in your device. Tap on the desired
thumbnail to view the image in the fullscreen mode. Double-
tapping the fullscreen image to bring up the zoom function.
• To view images as a slideshow, tap > Slideshow.
• To take a new picture, tap > Take picture.
• To delete all images, tap > Delete all.
Music player
This allows you to play the media files stored on your phone
or memory card. To open the music player, go to Main
menu > Multimedia > Music player. You can easily control
the music player by tapping the control buttons on the
screen.
Media libraries
Go to Main menu > Multimedia, touch Music, Playlist, or
Video library to locate the songs, playlists, or videos you
want to play. In each library, touch and hold a track, playlist,
or video to bring up the shortcut menu.
