FS-C5400DN - colour laser printer
FS-C5400DN - colour laser printer
SAVINGS RELIABILITY ENVIRONMENT
®
The FS-C5400DN delivers an astounding 35 pages per minute in
vibrant colour output and fulfils the highest user-demands with the
option for a total of 6 paper trays, for flexible paper handling. Add
this to its compact design, Kyocera reliability, and long-life components:
the FS-C5400DN is perfect for office use or in-house production.
• Up to 35 pages per minute A4 in colour and b/w
• Up to 9,600 x 600 dpi printing quality with Multi-Bit Technology
• Standard duplex unit for double-sided printing
• Standard USB and Network Connectivity
• Amazing 300,000 page drum life
• 150-sheet multi-purpose tray
• 500-sheet universal cassette
• Exceptionally low printing costs in its class
THE TOP-SPEED PROFESSIONAL FOR
COLOUR IN A4.

The FS-C5400DN includes:
PRESCRIBE IIc
With the Kyocera page design and control language PRESCRIBE IIc, even complex graphics, logos and forms (multipart forms) can be
created independently on the system and saved and updated in the printer. Consequently, integration into print files no longer
applies. They are only accessed as required and therefore relieve the load on the network.
The KM NetViewer
The KM NetViewer enables complete monitoring and control of all ECOSYS printers and digital KYOCERA multifunction units from
any Windows© PC and thus provides ideal network administration. It also supports the standardised SNMP protocol.
Status Monitor and Command Center
The Status Monitor shows the current printers condition and gives direct access to the Command Center for the modification of
settings that are not contained in the drivers (e.g. network settings, adjustment of sleep mode or blocking of the control panel).
USB Host Interface for USB Flash Memory
PDF files can be printed directly from a USB Flash Memory (e.g. USB stick) via the USB host interface. Documents are selected directly
via the printer’s control panel. No computer is required.
FS-C5400DN
COLOUR PRINTER FOR A4 FORMATS
General
Technology
Kyocera ECOSYS Colour Laser Printer
Engine speed
Up to 35 pages per minute in A4 in colour and b/w
Resolution
600 x 600 dpi
Multi-Bit Technology for print quality of up to
9,600 x 600dpi
Duty cycle
Max. 150,000 pages per month (A4)
Warm-up time
Approx. 45 seconds from sleep mode
Time to first page
Approx. 8.0 seconds or less in b/w
Approx. 9.0 seconds or less in colour
Dimensions (W x D x H)
345 mm x 518 mm x 510 mm
Weight
Approx. 35 kg (basic unit ready for operation)
Power source
220/240 V, 50/60 Hz
Power consumption
Printing: 608 W
Stand-by: 91 W
Power-Saving: 10 W
Safety standards
GS, TÜV, CE
This unit is manufactured according to ISO 9001 quality
standard and ISO 14001 environmental standard.
Paper handling
All paper capacities quoted are based on 80gsm paper,
thickness of max 0.11mm. Please use paper recommended
by KYOCERA under normal environmental conditions.
Input capacity
150-sheet multi-purpose tray; 60–220 g/m2;
A4, A5, A6, B5, B6, Letter, Legal, Custom
(70 x 138 mm – 216 x 356 mm)
500-sheet universal cassette; 60–120 g/m2;
A4, A5, A6, B5, B6, Letter, Legal, Custom
(105 x 148 – 216 x 356 mm)
Max. paper capacity incl. options: 2,650 sheets
Duplex unit
Double-side printing: 60–120 g/m2; A4, A5, B5, Letter,
Legal, Custom (140 x 210 mm – 216 x 356 mm)
Output capacity
500-sheet-face-down with paper full sensor
Controller
CPU
PowerPC 750/733 MHz
Memory
256MB RAM, can be increased to 1,280MB RAM
(single DIMM slot) as an option
Standard interface
USB 2.0 (Hi-Speed), USB Host Interface
Fast Ethernet (10/100 Base-TX for IPv4/IPv6)
Controller language
Prescribe IIc
Emulations
PCL6, PCL5c, PostScript* 3 (KPDL 3), XPS (Windows Vista),
PDF Direct Print, with automatic emulation sensing
Operating systems
All current Windows operating systems,
Mac OS X Version 10.2 or higher,
UNIX, LINUX as well as other operating systems
Fonts/barcodes
93 scalable fonts for PCL, 136 scalable fonts for PostScript*,
8 fonts for Windows Vista*, 1 Bitmap font, 45 barcodes
(e. g. EAN8, EAN13, EAN128) with automatic generation of
checksums as well as support of two-dimensional barcodes
PDF-417 under PRESCRIBE (PCL and other barcodes available
as an option)
Integrated accounting
100 department codes
Consumables
TK-574K Toner-kit
Micro-Particle toner black for 16,000 pages A4 in
accordance with ISO/IEC 19798
TK-574C, TK-574M, TK-574Y Toner-kits
Micro-Particle toner cyan, magenta, yellow for 12,000
pages A4 in accordance with ISO/IEC 19798
Capacity of starter toner is black 8,000 pages, and cyan,
magenta, yellow is 6,000 pages each in accordance with
ISO/IEC 19798
Maintenance Kit: MK-570 Installed every 300,000 pages
Options
PF-500 Paper feeder
Max. 500 sheets; 60–120 g/m2; A4, A5, B5, Letter, Legal,
Custom (148 x 210 mm – 216 x 356 mm)
PF-510 Multi-Media Feeder
Max. 500 sheets; 60–220 g/m2; A4, A5, B5, Letter, Legal,
Custom (148 x 210 mm – 216 x 356 mm)
Max. 4 x PF-500 or PF-510 feeders in any combination for a
total of 2,650 sheet input
CA-500 Caster Kit
If the FS-C5400DN is placed on the floor with 1 paper
feeder or more, then the CA-500 must be installed
Memory upgrade
DIMM-512P: 512MB extension
Or DIMM-1GBP: 1GB extension
1 slot available for memory upgrade
CompactFlash*-Card
1 slot (up to 4 GB) for printing forms, fonts, logos, macro
storage
USB Flash Memory
Supports direct printing of PDF, XPS, TIFF, JPEG files via
USB Host Interface
HD-5A Hard Disk
40GB for forms, fonts, virtual mailbox and more
Warranty
2-year warranty as standard. KYOCERA guarantees the drums
and developers for 2 years or maximum 300,000 pages
(whichever occurs sooner), provided the printer is used and
cleaned in accordance with the service instructions.
10/2010
KYOCERA MITA Australia
Ph: 13 KYOCERA
www.kyoceramita.com.au
KYOCERA MITA New Zealand
Ph: 0508 KYOCERA
www.kyoceramita.co.nz
KYOCERA MITA Australia Pty Ltd ABN 77 003 852 444
Our Unique Printing Technology
ECOSYS stands for ECOlogy,
ECOnomy and SYStem-printing.
With their long-life components, ECOSYS devices
are designed to maximise durability and minimise
the total cost of ownership with regard to
maintenance, administration and consumables.
The cartridge-free system means that only the toner
has to be replaced regularly, and the drum unit
every 300,000 prints. The modular design concept
allows you to add workflow enhancing functions as
required. Integrated system software provides long-
term cross-network compatibility. KYOCERA’s long-life
components cost you and the environment less.
