Kyocera ECOSYS FS-C5350DN User manual

Installation Guide
Clearance
• Temperature: 10 to 32.5 °C (50 to 90.5 °F) The humidity should be 70 % or less when the
temperature is 32.5 °C (90.5 °F)
• Humidity: 15 to 80 %RH The temperature should be 30 °C (86 °F) or less when the humidity
is 80 %
• Power Supply: 120 V AC, 60 Hz, 9.2 A / 220 to 240 V AC, 50/60 Hz, 4.7 A
FS-C5350DN
Environment
CAUTION: Be sure to provide enough space around printer. Prolonged use
without sufficient clearance may cause overheating.
400 mm (15-3/4") 250 mm (9-13/16") 200 mm (7-7/8") 600 mm (23-5/8")
Unpacking
CD-ROM Manuals and Other
Printed Materials
Printer Power Cord
Toner Containers (4)
Waste Toner Box
Installing the Toner Container and Waste Toner Box
Open the top cover until it stops. Before installing the toner container, open the slide lever (yellow-colored) on the
developer unit. The toner container cannot be installed until the slide lever is open.
Proceed as follows:
To open the slide lever, squeeze and hold the lever (1), and slide the lever all the way
toward the direction of the arrow indicated (2) on the lever. When the slide lever is
open, install the toner container.
Push down on the container until it
clicks firmly into place.
Follow the procedure above to install
the other color toner containers.
Note: Ensure the toner container is in the
correct location for that color.
Close the top cover.
2
1
12
564Place the new toner container in the
printer with the markings facing
upward.
400 mm
(15-3/4")
Open the cap of the waste toner box.
87 Open the left cover.
Unpack the printer and all its included components.
Important: The printer must be carried by two persons.
Check the parts and components.
12
Magenta (M)
Cyan (C)
Yellow (Y)
Black (K)
Cap
Toner Supply Opening
Position the bottom of the waste toner
box in the receptacle and push the box
down until it snaps firmly into place.
9
Hold the toner container with the
upside down markings (caution notes,
etc.) facing downward and shake it 5 or
6 times as shown.
3
Close the left cover.
10
(1) (2)
FS-C5300DN_IG_EN.fm 1 ページ ２００９年５月１５日 金曜日 午後５時２５分

Pull the paper cassette all the way out
of the printer.
Paper Width Guides
Loading Paper
Adjust the paper length guide to fit the
paper size.
Adjust the paper width guides to fit the
paper size.
Turn the paper size dial so that the size
of the paper to use appears in the
paper size window.
Paper Length Guide
Fan the paper, then tap it on a level
surface to avoid media jams or skewed
printing.
Load paper in the cassette, with the
side to be printed upward. Important: Do not exceed the upper limit
of the cassette. Otherwise, it may cause
paper jams.
Insert the paper cassette into the slot in
the printer. Push it straight in as far as
it will go.
Limit Mark
3
2
5
3
6
1
7
4
Connect the power cord to the printer
and the other end into a power outlet.
Turn the power switch off (O). Connect the printer to the PC or your
network device. Use shielded interface
cables. These cables are sold
separately.
Connecting Cables
4
132
Selecting the Message Language
Turn the power switch on (|).
Important: The printer will begin
cleaning the LSU; this will take
approximately 70 seconds.
5
1
© 2009 by KYOCERA MITA Corporation All rights reserved. 2-28, 1-Chome, Tamatsukuri, Chuo-ku, Osaka 540-8585, Japan Printed in China 302K856020 First edition 2009.5
Refer to the Operation Guide to install the printer driver and to set network parameters.
2Wait until the message display
indicates MSG Language. The default
message language is English.
Remove the cap, when using the
network interface.
USB Interface
Network Interface
Paper Size Dial Paper Size Window
To change the language, press [U]or
[V]repeatedly until the message
display shows the desired language.
Press [OK]. The message language
will be changed.
3
4
FS-C5300DN_IG_EN.fm 2 ページ ２００９年５月１５日 金曜日 午後５時２５分
