For inquires or orders :
Safety Warnings : Please read the "Safety Warnings" in the instruction manual supplied with the instrument thoroughly and completely
for correct use. Failure to follow the safety rules can cause fire, trouble, electrical shock, etc. Therefore, make sure
to operate the instrument on a correct power supply and voltage rating marked on each instrument.
The contents of this leaflet are subject to change without notice.
In consideration of the environment, soy ink and recycled paper were used in this publication.
KEW 2200R/2200-1E Sep. 14 AD
2-5-20, Nakane, Meguro-ku, Tokyo, 152-0031 Japan
Phone:+81-3-3723-0131
Fax:+81-3-3723-0152
8008
For measurements up to 3000A
Conductor size: φ100mm
Input to output: 10:1
Cable length: 1,100mm
91607107A
Press the trigger to open the current sensor
and clamp the one conductor under test.
Connect the test
leads to the circuit
under test.
IncorrectCorrect
KEW 2200R KEW 2200
Detection method RMS Averaging value
AC A 40.00/400.0/1000A(Auto-ranging)
±1.5%rdg±5dgt(45~65Hz)
±2.0%rdg±5dgt(40Hz~1kHz)
40.00/400.0/1000A(Auto-ranging)
±1.4%rdg±6dgt(50/60Hz)
±1.6%rdg±6dgt(45~65Hz)
AC V 4.000/40.00/400.0/600V(Auto-ranging)
±1.8%rdg±7d gt(45~65Hz)
±2.3%rdg±8dgt(65~500Hz)
DC V 400.0mV/4.000/40.00/400.0/600V(Auto-ranging)
±1.0%rdg±3dgt* *400mV range is excluded
Ω400.0Ω/4.000/40.00/400.0kΩ/4.000/40.00MΩ(Auto-ranging)
±2.0%rdg±4dgt(0~400kΩ)
±4.0%rdg±4dgt(4MΩ)
±8.0%rdg±4dgt(40MΩ)
Continuity buzzer buzzer sounds below 50±30Ω
Conductor size φ33mm max.
Applicable standards IEC61010-1 CATⅣ300V*, CATⅢ600V Pollution degree2(AC A) *2200R only
CATⅢ300V, CATⅡ600V Pollution degree2(AC/DC V)
IEC61010-031, IEC61010-2-032, IEC61326(EMC), EN50581(RoHS)
Power source R03/LR03(AAA)(1.5V)×2
Continuous measuring
time
Approx.120 hours Approx.350 hours
Auto power off : approx.10 minutes
Dimensions/Weight 190(L)x68(W)x20(D)mm / Approx.120g(including batteries)
Accessories 7107A (Test leads), 9160 (Carrying case), R03(AAA)×2, Instruction manual
Optional 8008 (Multi-tran)
●KEW 2200R / 2200 Specifications
●Accessories ●Optional
Teardrop shaped jaw for easy use
in crowded cable areas
Reliable result can be obtained even
from distorted wave form generated by
nowadays electronic loads
Slim and compact that fits right
into your pocket
Current Measurement Voltage
Measurement
Resistance
Measurement
Waveform
True RMS type Averaging
value type
✓
correct
reading
✓
correct
reading
✓
correct
reading
higher
reading
✓
correct
reading
lower
reading
✓
correct
reading
lower
reading
