La Hacienda 69514 User manual

User instructions - please keep for future reference
Standing Halogen Electric Heater 69514
69536
V2.0
Tools list
Tools required (not included)
Technical information
Power Supply: 220 - 240V ~ 50Hz
Wattage: 2100W
Element Type: Halogen
Life of Lamp: Approximate 5000 hours
Ingress Protection Rating: IP44
Net Weight: 10.5Kg
Dimensions: H 207 x Diam 50cm
All measurements are approximate
Insulation Class: I
IMPORTANT! – Carefully remove any packaging before use, but retain the safety instructions.
These instructions form part of the product.
Please take note of all of the safety warnings listed in these instructions.
Please read these instructions in their entirety and retain them for future reference.
These instructions should be stored with the product.
Failure to adhere to these instructions could result in property damage, personal injury or death.
Produced in PRC for La Hacienda Ltd
Hangar 27, Site C, Aston Down Airfield, Nr Stroud, Glos, GL6 8HR, UK
www.lahacienda.co.uk

2
Care and safe use guidelines
IMPORTANT! KEEP FOR FUTURE REFERENCE.
Thank you for choosing our outdoor Electric Heater. This manual will provide you with
information necessary for the proper assembly, care and maintenance of your new product.
Please take a few moments to thoroughly read the instructions and familiarise yourself with all
the operational aspects of your new heater.
When using this electric unit, please follow the safety precautions detailed below. This should
reduce the risk of fire, electric shock and injury to persons.
WARNING – CAUTION!
READ ALL INSTRUCTIONS BEFORE ATTEMPTING TO OPERATE THIS UNIT.
KEEP THE ASSEMBLY INSTRUCTIONS FOR FUTURE REFERENCE. KEEP THE ORIGINAL
PACKAGING FOR USE WHEN STORING THE HEATER DURING EXTENDED PERIODS OF
NON-USE.
•Read ALL instructions before using this unit.
•DO NOT leave this unit unattended when in use.
•This heater will get hot when in use. DO NOT touch hot surfaces.
• CAUTION! Some parts of this product can become very hot and cause burns. Particular
attention has to be given when children and vulnerable people are present.
•DO NOT move the unit when in use. Wait until the heater is completely cool before moving
and check that it has been unplugged from the power supply.
•Position the unit at least 1m away from highly combustible materials such as furniture, trees,
leaves, dry grass and bushes.
•The heater MUST be a minimum of 0.5m away from the ceiling of a building or
overhanging items.
•The heater MUST NOT face with the heating element pointing upwards towards a ceiling.
The heater element MUST be facing the area it is to heat.
• WARNING! In order to avoid overheating DO NOT cover the heater. It is not for drying clothes.
•Keep children and pets at a safe distance from the unit.
•Children of less than 3 years should be kept away unless continuously supervised.
•This appliance can be used by children from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children without supervision.
•Ensure any person operating the heater has the capability to do so without risking injury to
themselves or others.
• Children aged from 3 years and less than 8 years shall only switch on/off the appliance
provided that it has been placed or installed in its intended normal operating position and they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
•DO NOT operate the heater if ANY signs of damage or malfunction manifest themselves.
•DO NOT attempt to repair or adjust any electrical or mechanical functions on this unit. The
unit DOES NOT contain any user serviceable parts. ONLY a qualified electrician should
perform servicing or repairs. Attempting to repair the unit yourself will void your warranty.
•If the power cable is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
• DO NOT handle the element with bare hands. If it is inadvertently touched, remove finger
marks with a soft cloth and methylated spirits or alcohol, otherwise the marks will burn into
the element causing premature heater failure.
•DO NOT replace or attempt to replace the element in this product.
•DO NOT use this heater in the immediate surroundings of a bath, shower, swimming pool
or hot tub.
• This product must NOT be left outdoors exposed to the elements for long periods of time.
•DO NOT touch the plug with wet or damp hands.
•DO NOT run the power cable under carpeting. DO NOT cover the power cable with rugs,
runners, or similar coverings. Arrange the power cable away from foot traffic and where it will
not be tripped over.
•DO NOT wind the power cable around the unit.
• This product is NOT suitable for indoor use.

Care and safe use guidelines
3
•DO NOT insert or allow foreign objects to enter any ventilation or opening on the heater, as
this may result in electric shock, fire, or damage to the heater.
•To prevent a possible fire, DO NOT block the air vents.
•A heater has hot and arcing or sparking parts inside. DO NOT use in areas where petrol,
paint, explosive and/or flammable liquids are used or stored. Keep unit away from heated
surfaces and open flames.
•Where possible, avoid the use of an extension cable as this may overheat and cause a fire.
However, if you have to use an extension cable, ensure it is suitable for the purpose, has
been tested for outdoor use and preferably has an RCD device fitted or attached.
•ALWAYS ensure the heater is plugged into a suitable socket, one that is tested for outdoor use.
•To disconnect heater, turn controls toOFF, then remove plug from socket. DO NOT unplug by
pulling on the power cable.
•ALWAYS unplug the unit and ensure the unit is completely cold before moving, cleaning
or storing.
•The use of attachments on the heater is NOT recommended.
•DO NOT use this heater with a programmer, timer, separate remote control system or any
other device that switches the heater on automatically, since a fire risk exists if the heater is
covered or positioned incorrectly.
•WARNING! This heater is not equipped with a device to control the room temperature.
•DO NOT use this heater in small rooms when occupied by persons not capable of leaving
a room on their own, unless constant supervision is provided.
•ALWAYS use on a dry, suitably strong, stable, flat and level surface.
•This unit is NOT suitable to be modified for hardwiring to the mains electric supply. Please
contact a fully qualified electrician to install a suitable outdoor plug socket for this unit,
if necessary.
OPERATING THE UNIT:
• Ensure the unit is plugged into the correct power supply.
• To turn the unit ON push the switch below the head on the ‘I’ symbol.
• To turn the unit OFF push the switch on the ‘O’ symbol.
MAINTENANCE:
•Before performing ANY maintenance, unplug the unit and let it cool completely.
•To keep the heater clean, the outer casing may be cleaned with a soft, damp cloth. You may
use a mild detergent if necessary. After cleaning, dry the unit with a soft cloth.
•DO NOT use alcohol, petrol, abrasive powders, furniture polish, or rough brushes to clean
the heater. This may cause damage or deterioration to the surface of the heater.
•DO NOT immerse the heater in water to clean.
•Wait until the unit is completely dry before use.
STORAGE:
•Ensure the unit is completely cold before storing in a cool, dry location.
•To prevent dust and dirt build-up, use the original packaging to repack the unit.
•CHOKING HAZARD: Store out of the reach of children and pets. Contains small parts.
TROUBLE SHOOTING:
If the heater will not operate, please check the following before seeking help:
•Check the power cable is correctly plugged into the electrical socket, check the socket switch
is in the ON position and check if electricity to the main fuse is working.
• If tipped or on uneven ground this unit may not operate due to an anti-tip cut out system.
If the unit will not switch on, check the unit is upright and on level ground.
DISPOSAL:
•DO NOT dispose of via your weekly household waste collection service. ONLY dispose of
this product at your local, licensed recycling/waste centre.
•For further information on the disposal of electrical goods, please contact your local authority.

Parts list
4
Prior to assembly: read the instructions carefully. Check all parts against the parts list.
This product MUST NOT be used if the power cable is damaged. If there is damage, it must be
replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a
hazard.
For ease of assembly only loosely tighten bolts and then tighten fully when assembly is complete.
WARNING! - DO NOT over tighten bolts; only tighten with moderate pressure to avoid damaging
the bolts or components of the heater.
Assembly diagram
2
A
4
4
5
6
8
6 (1x)
8 (1x)
1 (1x)
2 (1x)
4 (2x)
3 (1x)
7 (2x)
5 (1x)
A (2x)
B (3x)
C (3x)
D (4x)
3
8
1
1
Figure 1
Figure 2
Pre-attached
to part 1.
Pre-attached
to part 6.
Pre-attached
to part 6.
Diagram A
6
7
4

Assembly instructions
5
IMPORTANT! - Remove any packaging before use, but retain the safety instructions and store
them with this product. Please refer to diagram A on page 3 when following the instructions
below.
ASSEMBLY
STEP 1 - Screw the bottom tube (5) clockwise into the base (6). Make sure to attach end with
the least (more prominent) thread.
STEP 2 - Feed the power cable (8): female plug first, up through the hole in the base (6) and
through the bottom tube (5) and pull through approximately 1m of cable (8).
STEP 3 - Connect one of the middle tube sections (4) to the bottom tube (5) by screwing them
in a clockwise direction.
STEP 4 - Repeat Step 3 connecting the second middle tube section (4) to the one already in
place. Remember to feed the power cable (8) through as you go.
STEP 5 - Connect the top tube section (2) to the middle tube section (4) by screwing them in a
clockwise direction.
STEP 6 - Lie the product on its side on the floor, connect the plug on the heater head (1) to
the power cable (8), encase the connected plugs inside the plastic housing (3).
Please refer to diagram A, figure 1.
STEP 7 - Feed the plastic housing (3) down into the top tube section (2).
STEP 8 - Push the heater head (1) onto the top tube (2), aligning the holes on the heater head
(1) and the top tube section (2). Once aligned, fix in position using 2x screws (A).
STEP 9 - Fix the power cable (8) to the base (6), using the 2x pre-attached plastic fittings (7)
and 4x nuts (D). Please refer to diagram A, figure 2. Now stand the heater upright
onto its base.
To fix your heater to the ground, drill three holes into the ground, evenly positioned around the
edge of the base section. Use one floor fixing bracket (B) per hole to secure the base section,
ensuring the elongated hole on each bracket correctly aligns with each hole. Secure using one
floor fixing bolt (C) per bracket, ensuring each bolt is fully tightened with a spanner.
The heater is now ready to use. Please see operation instructions. Ensure you have
read these instructions thoroughly prior to use.
