La Sommeliere TR2V150 User manual

INSTRUCTIONS FOR USE
MODEL: TR2V150

2
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS.
For your own safety and for the proper utilisation of the appliance,
read this manual carefully, including the warnings and
recommendations, before installing the appliance and using it for the
first time. In order to avoid damage to the appliance and/or personal injury,
persons using the appliance should be fully familiar with its operation and
safety functions. Keep these recommendations close to the appliance, for
future reference, and ensure that the document is transferred with the
appliance, if it is sold or in the case of moving. This will ensure optimum
operation of the appliance.
To avoid any risk of injury, keep this manual. The manufacturer declines any
liability whatsoever in the case of operating/handling errors concerning the
appliance.
Safety of children and other vulnerable persons
•This appliance may be used by children aged 8 years and above, and
by persons who are physically, sensorially or mentally handicapped, or
who have not learned to use the appliance, providing they are
supervised by a person familiar with the appliance and who is aware of
the risks involved. Children should not be allowed to play with the
appliance. User cleaning and servicing operations should not be
carried out by children, unless they are more than 8 years old and are
supervised.
•Keep all packaging out of the reach of children, as there is a risk of
suffocation.
•If you decide to scrap the appliance, disconnect it from the wall socket,
cut the connection cable (as close to the appliance as possible) and
remove the door, in order to prevent children playing with it, with the
resulting risk of electric shock or being trapped inside.
•If an appliance with a magnetic door seal is being replaced by another
appliance with a latch on the door or on the seal, ensure that the latch
is disabled before selling or scrapping the old appliance. This will
prevent the appliance from being transformed into a trap forchildren.
•Keep the appliance and its power cable out of reach of children less
than 8 years old.

3
General safety
•CAUTION — This appliance is designed for home use.
•CAUTION — Never store inflammable substances, such as aerosols,
inside the appliance, as they could leak or release fluids.
•CAUTION — A damaged power cable should be immediately replaced
by the manufacturer or by a qualified retailer, in order to avoid any risk
of electric shock.
•CAUTION — Keep the ventilation openings well open and ensure that
air can circulate, especially if the appliance is recessed into awall.
•CAUTION — Do not damage the refrigerating circuit.
•CAUTION — Do not use electrical appliances inside the compartment,
unless they are tolerated by the manufacturer.
•CAUTION — The refrigerating and insulating systems contain
inflammable gases. When the appliance is scrapped, it should be
deposited at an accredited collection centre. Do not expose the
appliance to fire.
Refrigerating fluid
The refrigerating circuit in the appliance uses refrigerating isobutane
(R600a), which is a highly inflammable natural gas and is therefore
dangerous for the environment. When transporting or installing the
appliance, ensure that no element of the refrigerating circuit is damaged.
The refrigerating fluid (R600a) is inflammable.
Caution: Fire risk
If the refrigerating circuit is damaged:
- Avoid open flames or any source of combustion.
- Ensure that the room in which the appliance is installed is wellventilated.
It is dangerous to change the specification of the appliance in any way
whatsoever.
Damage to the power cable may cause a short circuit and/or electric shock.

4
Electrical safety
•We decline any liability in respect of incidents caused by poor electrical
installation.
•Do not extend the power cable. Do not use an extension cable, or
adapter, or multi-way socket.
•Check that the wall socket is not damaged. A wall socket in poor
condition may cause the appliance to overheat and explode.
•Check that the wall socket used for the appliance is properly
accessible.
•Never pull on the main power cable.
•Ensure that the appliance is always electrically earthed.
•If the wall socket is loose, do not connect the cable, as there is a risk of
electric shock or fire.
•Do not use the appliance if the interior lighting cover is not installed.
•Disconnect the appliance before replacing the lightingbulb.
•The appliance operates on a single phase 220~240 V / 50 Hz power
supply. The appliance must be connected to an earthed wall socket, in
accordance with applicable recommendations.
•Do not attempt to replace a damaged power cable, contact your after-
sales service.
•The power socket must be easily accessible but out of reach of
children. In case of doubt, contact your installationtechnician.
Daily utilisation
•Do not store inflammable substances or fluids inside the appliance.
This would create a risk of explosion.
•Do not operate other electrical equipment inside the appliance (mixers,
whirling rotor for ice cream, etc.).
•When disconnecting the appliance, grip the plug firmly and do not pull
on the cable.
•Do not expose the appliance to direct sunlight.
•Keep the appliance away from candles, luminaires and open flames, in

5
order to avoid fire risk.
•This appliance is only designed to store wines and drinks.
•The appliance is heavy. Be careful when moving it.
•If your appliance is equipped with castors, remember that these are
only designed to facilitate minor movements. Do not move the
appliance over long distances.
•Do not lean or climb on the appliance or its elements.
•In order to avoid falling objects and to prevent damage to the
appliance, do not overload the compartments of theappliance.
Caution! Cleaning and servicing
•Before carrying out servicing, switch off the power supply and
disconnect the appliance.
•When cleaning the appliance, do not use metal objects, steam
systems, volatile fluids, organic solvents or abrasivesubstances.
•Do not use sharp or pointed objects to remove ice. Use a plastic
scraper.
Important information concerning installation!
•To ensure proper electrical connection, follow the recommendations
given in the present manual.
•Unpack the appliance and visually check that it is not damaged. Do not
connect a damaged appliance. Inform your retailer or point of sale of
any damage. In such a case, keep the packaging.
•It is recommended that the appliance be allowed to settle for at least
4 hours before connecting the electrical power supply, so that the
compressor fluid feed is correct.
•Proper air circulation is necessary to avoid overheating. To ensure
sufficient ventilation, observe the installation recommendations
provided.
•In order to avoid fire risk, wherever possible, ensure that the appliance
is not in contact with walls or with any hot element(compressor,

6
condenser). Observe the installation recommendations.
•The appliance should not be placed close to radiators or cookinghot
plates or gas rings.
•Check that electrical sockets remain accessible when the appliance is
installed.
POWER SAVING
To limit the electricity consumption of your appliance:
• Install it in an appropriate place (see “Installing yourappliance”).
• Leave the doors open as little time aspossible.
•To ensure that the appliance operates properly, clean the condenser
regularly (see “Routine servicing of your appliance”).
• Regularly inspect the door seals and ensure that they are stillclosing
properly. If this is not the case, contact your after-salesservice.
Trouble shooting
•Any electrical work should be carried out by a qualified and
skilled technician.
•The appliance should be repaired by an accredited repair centre, using
only manufacturer’s original spareparts.
The appliance is designed for home use only. The manufacturer declines any liability whatsoever in the case of other
utilisation.

7
R600a
Safety instructions
This appliance meets the requirements of all applicable European directives and their
amendments.
PROTECTION OF THE ENVIRONMENT
The packaging materials with this appliance may be recycled.
Contribute to their recycling and to the protection of the environment by depositing them in the specific
municipal containers provided for this purpose.
Your appliance also contains many materials that can be recycled. It therefore bears the logo that informs
you that scrapped appliances should not be mixed with other waste. Thus, the appliance will be recycled
by the manufacturer, under optimum conditions, in compliance with European directive 2002/96/EC
relating to Waste Electrical and Electronic Equipment. Contact your local municipal offices or your retailer,
to identify the nearest collection points for scrapped appliances. Thank you for helping to protect the
environment.
Caution: The refrigerating units use isobutane
(R600a), and should not be placed close to ignition
sources (for example, electrical contacts that are
exposed or open contacts that could be closed by the
refrigerating fluid in the event of a leak). The
refrigerating fluid type is specified on the power
cabinet identification plate.
Caution: Do not store explosive substances, such as
aerosol cans containing an inflammable propellant,
in the appliance.
Caution: Do not obstruct the ventilation grills on
the appliance.
Caution: Do not damage the refrigerating circuit in
the appliance.
Caution: Do not use electrical equipment in the
compartments of the appliance, unless they are of
the type recommended by the manufacturer.

8
INSTALLATION INSTRUCTIONS
➢ Before Using Your Wine Cooler
Remove the exterior and interior packing.
Before connecting the Wine Cooler to the power source, let it stand upright for
approximately 2 hours. This will reduce the possibility of a malfunction in the
cooling system from handling duringtransportation.
Clean the interior surface with lukewarm water using a softcloth.
➢ Installation of Your Wine Cooler
This appliance is designed to be for free standing installation or built-in (fully
recessed) (Refer to sticker location the back of this appliance).
Place your Wine Cooler on a floor that is strong enough to support it when it is
fully loaded. To level your Wine Cooler, adjust the front leveling leg at the
bottom of the Wine Cooler.
Locate the Wine Cooler away from direct sunlight and sources of heat (stove,
heater, radiator, etc.). Direct sunlight may affect the acrylic coating and heat
sources may increase electrical consumption. Extreme cold ambient
temperatures may also cause the unit not to performproperly.
Avoid locating the unit in moistareas.
Plug the Wine Cooler into an exclusive, properly installed-grounded wall outlet.
Do not under any circumstances cut or remove the third (ground) prong from
the power cord. Any questions concerning power and/or grounding should be
directed toward a certified electrician or an authorized Products servicecenter.
OPERATING YOUR WINE COOLER
The Wine Cooler should be placed in where the ambient temperature is between 16-
32°C. If the ambient temperature is above or below this range, the performance of the
unit may be affected. For example, placing your unit in extreme cold or hot conditions
may cause interior temperatures to fluctuate. The range of 5-20℃ may not be reached.
The above temperatures may fluctuate depending on whether or not the interior bulb
is ON or OFF or whether the bottles are located on the upper/middle or lowersection.

9
➢ The controls of your wine Cooler
RUN
Indicator light illuminates to signify the cooling mode is currently in operation.
Light
To control the inner light, turn on/off.
Power
To control this appliance, turn on/off.
•“Set Upper” Button
To set the temperature of the upper chamber.
•“Set Lower” Button
To set the temperature of the lower chamber.
•“Up chamber”
To shows the temperature of the up chamber.
•“Lower chamber”
To shows the temperature of the lower chamber.
➢ Setting the Temperature Control
Each cooling compartment of the wine cooler (upper & lower) is independently
controlled. To set the temperature:
Connect the power cord to a properly grounded outlet. In the event of a power
interruption, all previous temperature settings are automatically erased and each
compartment will default to a preset temperature setting of: 7℃ for upper
compartment and 12℃ for lower compartment.
• Set the desired cooling temperature by pressing the buttons adjacent to the “set
upper/set lower” program. Each depression of the buttons will scroll through the
available temperature settings (for each compartment) in increments of 1 degree.
The temperature selected will flash in the LED display for approximately 5 seconds,
then revert back to display the temperature of the internalcabinet
Upper compartment: The temperature setting can be adjusted from 5 to 20°C.
Lower compartment: The temperature setting can be adjusted from 5 to 20°C.
• To view the “set” temperature. (anytime) press and hold the corresponding button
for approximately 5 seconds, the “set” temperature will temporarily “flash” in the
LED display for 5 seconds.
➢ Temperature Alarm
The temperature adjust range is from 5 to 20°C.
• When temperature is lower than 0, it will have “Beep” sound, and “LO” will show in
display, this is for low temperature alarm. When temperature is higher than 23, it
will have “Beep” sound, and “HI” will show in display, this is for high temperature
alarm. When alarm happens, please call servicer formaintain

10
➢ Interior Light
You can turn the interior light ON or OFF by pushing the button marked with the “bulb”
symbol or “LIGHT”.
In order to save energy consumption, the light will be automatically off after 10
minutes when turned on.
But if you want to keep the light on permanently, please keep pressing "LIGHT"
button for 5 seconds after a “beep” and the display shows "LP”.
If you want to reset (automatically off after 10 minutes), please keep pressing
"LIGHT" button for 5 seconds again until display shows"LF".
➢ Shelves
To prevent damaging the door gasket, make sure to have the door all the way
opened when pulling shelves out of the rail compartment.
For easy access to the storage content, you must pull the shelves approximately 1/3
out of the rail compartment, however this unit was designed with a notch on each
sides of the shelf tracks to prevent bottles fromfalling.
Put the shelf gap (left and right) under the square plastic block, up tilt the shelf,
then pull the shelf from the Wine Cooler.
➢ Note
If the unit is unplugged, power lost, or turned off, you must wait 3 to 5 minutes
before restarting the unit. If you attempt to restart before this time delay, the
Wine Cooler will not start.
When you use the wine cooler for the first time or restart the wine cooler after
having been shut off for a long time, there could be a few degrees variance
between the temperature you select and the one indicated on the LED readout.
This is normal and it is due to the length of the activation time. Once the wine
cooler is running for a few hours everything will be back tonormal.
➢ Door Lock
Your unit is provided with a lock and key combination.
The keys are located inside the plastic bag that contains the User’s Guide. Insert the key
into the lock and turn it counterclockwise to unlock the door. To lock the door, do the
reverse operation making sure metal pin is engaged completely. Remove the key and
place it in a secure place for safekeeping.

11

12
CARE AND MAINTENANCE
➢ Cleaning Your Wine Cooler
Turn off the power, unplug the appliance, and remove all items including
shelves and rack.
Wash the inside surfaces with a warm water and baking soda solution. The
solution should be about 2 tablespoons of baking soda to a quart ofwater.
Wash the shelves with a mild detergentsolution.
Wring excess water out of the sponge or cloth when cleaning area of the
controls, or any electrical parts.
Wash the outside cabinet with warm water and mild liquid detergent. Rinse
well and wipe dry with a clean soft cloth.
➢ Power Failure
Most power failures are corrected within a few hours and should not affect the
temperature of your appliance if you minimize the number of times the door is
opened. If the power is going to be off for a longer period of time, you need to take
the proper steps to protect your contents.
➢ Vacation Time
Short vacations: Leave the Wine Cooler operating during vacations of less than
three weeks.
Long vacations: If the appliance will not be used for several months, remove all
items and turn off the appliance. Clean and dry the interior thoroughly. To prevent
odor and mold growth, leave the door open slightly: blocking it open ifnecessary.
➢ Moving Your Wine Cooler
Remove all items.
Securely tape down all loose items (shelves) inside yourappliance.
Turn the adjustable leg up to the base to avoid damage.
Tape the door shut.
Be sure the appliance stays secure in the upright position during transportation.
Also protect outside of appliance with a blanket, or similaritem.
➢ Energy Saving Tips
The Wine Cooler should be located in the coolest area of the room, awayfrom
heat producing appliances, and out of the directsunlight.

13
PROBLEMS WITH YOUR WINE COOLER?
You can solve many common Wine Cooler problems easily, saving you the cost of a
possible service call. Try the suggestions below to see if you can solve the problem
before calling the servicer.
TROUBLESHOOTING GUIDE
PROBLEM
POSSIBLE CAUSE
Wine Cooler does not operate.
Not plugged in.
The appliance is turned off.
The circuit breaker tripped or a blown
fuse.
Wine Cooler is not cold enough.
Check the temperature control setting.
External environment may require a
higher setting.
The door is opened too often.
The door is not closed completely.
The door gasket does not seal properly.
Turns on and off frequently.
The room temperature is hotter than
normal.
A large amount of contents has been added
to the wine cooler.
The door is opened too often.
The door is not closed completely.
The temperature control is not set
correctly.
The door gasket does not seal properly.
The light does not work.
Not plugged in.
The circuit breaker tripped or a blown
fuse.
The bulb has burned out.
The light button is “OFF”.
Vibrations.
Check to assure that the Wine Cooler is
level.
The Wine Cooler seems to make too much
noise.
The rattling noise may come from the flow
of the refrigerant, which is normal.
As each cycle ends, you may hear gurgling
sounds caused by the flow of refrigerant in
your Wine Cooler.
Contraction and expansion of the inside
walls may cause popping and crackling
noises.
The Wine Cooler is not level.
The door will not close properly.
The Wine Cooler is not level.
The door was reversed and not properly
installed.
The gasket is dirty.
The shelves are out of position.

14
EUROPEAN DATA SHEET
according to the regulations (UE) N°1060/2010
-
AGEING AND SERVICE TEMPERATURE WINE CELLAR
BRAND LA SOMMELIERE
COMMERCIAL REFERENCE TR2V150
POWER SUPPLY 220-240 V / 50 Hz
PRODUCT DIMENSIONS (W x D x H) 595 x 680 x 1760 mm
NET WEIGHT 112 kg
APPLIANCE CATEGORY
2
ENERGY EFFICIENCY CLASS
D
ENERGY CONSUMPTION
Energy consumption 337 kWh per year
calculated on the basis of results obtained over
24 hours in standardized test conditions.
Actual energy consumption depends on
conditions of use and the location of the
appliance.
NET VOLUME 413 L
ADJUSTABLE TEMPERATURES 5 – 20°C / 5 – 20°C
NO FROST NO
CLIMATE CLASS
Climate class: N
This appliance is designed to be used at an
ambient temperature of between 16°C (lowest)
and 32°C (highest).
ACOUSTIC EMISSIONS IN AIR IN dB(A) RE 1
pW
44 dB(A)
INSTALLATION TYPE Free-standing
This appliance is intended exclusively for the storage of wine.
Wine Corner Ltd – Unit 4 Brunel Close,Harworth,Doncaster,DN11 8QA – [e-mail] –
www.winecorner.co.uk
