Labesto SMARTCHEF LSM7009BK User manual

0
Content - Inhalt - Spis treści
Instruction manual – English .................................................................. - 1 -
Bedienungsanleitung – Deutsch .............................................................- 10 -
Instrukcja obsługi – Polski ………………………………………………………………… - 18 -

1
English
Dear Customer!! Congratulations on purchasing a high quality LABESTO product.
This product is based on the latest technological solutions to provide high functionality, safety
and ease of use. Please take a few minutes to read the following user's manual and its
instructions.
SAFETY INSTRUCTIONS
Before use make sure to read all of the below instructions
in order to avoid injury or damage, and to get the best
results from the appliance. Make sure to keep this manual
in a safe place. If you give or transfer this appliance to
someone else make sure to also include this manual.
In case of damage caused by user failing to follow the
instructions in this manual the warranty will be void. The
manufacturer/importer accepts no liability for damages
caused by failure to follow the manual, a negligent use or
use not in accordance with the requirements of this
manual.
1. This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
2. Children shall not play with the appliance.
3. Caution: Keep any packaging materials well away from
children – such materials are a potential source of
danger e.g. of suffocation
4. Cleaning and user maintenance shall not be made by
children unless they are older than 8 years and
supervised.
5. Keep the appliance and its cord out of reach of children
less than 8 years.
6. If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
person in order to avoid a hazard.

2
7. Regarding the instructions for cleaning the surfaces
which come in contact with food or oil, please refer to
the paragraph “CLEANING AND MAINTENANCE” of the
manual.
8. This appliance is not intended to be operated by means
of an external timer or separate remote-control system.
9. Before inserting the plug into the mains socket, please
check that the voltage and frequency comply with the
specifications on the rating label.
10. If an extension cord is used it must be suited to the
power consumption of the appliance, otherwise
overheating of the extension cord and/or plug may
occur.
10 Disconnect the mains plug from the socket when the
appliance is not in use and before cleaning.
11 Ensure that the mains cable is not hung over sharp
edges and keep it away from hot objects and open
flames.
12 Do not immerse the appliance or the mains plug in
water or other liquids. There is danger to life due to
electric shock!
13 To remove the plug from the plug socket, pull the plug.
Do not pull the power cord.
14 Do not touch the appliance if it falls into water.
Remove the plug from its socket, turn off the appliance
and send it to an authorized service center for repair.
15 Do not plug or unplug the appliance from the electrical
outlet with a wet hand.
16 Never attempt to open the housing of the appliance, or
to repair the appliance yourself. This could cause
electric shock.
17 Never leave the appliance unattended during use.
18 This appliance is not designed for commercial use.
19 Do not use the appliance for other than intended use.

3
20 Do not wind the cord around the appliance and do not
bend it.
21 Place the appliance on a stable, level surface from
which it cannot fall off.
22 The use of accessory attachment not recommended by
the appliance manufacturer may cause injuries.
23 Only the pusher should be used for refilling the mincer.
24 Do not insert anything into the rotating hooks while the
machine is working.
DANGER OF OVERLOADING !
Please use the device either as a mincer or mixer, but never both functions at the same time.
Short operation time 4 – 10 min. Maximum weight of ingredients In bowl: 3kg
This device has been tested according to all relevant current CE guidelines, such as electromagnetic
compatibility
and low voltage directives, and has been constructed in accordance with the latest safety regulations.
Subject to technical changes without prior notice!
The product is designed for food contact
ENVIRONMENT FRIENDLY DISPOSAL
Recycling – European Directive 2012/19/EU
This marking indicates that this product should not be disposed with other household wastes. To prevent
possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources. To return your used device, please use the return and
collection systems or contact the retailer where the product was purchased. They can take this product for
environmental safe recycling.
TECHNICAL DATA
Model: LSM7009
Rated voltage: AC220-240V~ ,50/60Hz
Power consumption: 1000W
Max Lock Power: 1500W
Protection class: II
Short operation time: 4-10 Min

4
OVERVIEW OF
THE
COMPONENTS
Main Components and Standard/Optional Accessories:
1. crush main body 7. cover(diascope)
2. meat dish 8. dough hook
3. meat grinder 9. stainless steel bowl（7L）
4. flat pasta maker 10. power cord
5.
K beater 11. front end shield
6. whisk
NOTICE: positions 1-4 are optional attachments ( available if supplied)
CONTROL PANEL:
1 LCD
2 BUTTON(-)
3 BUTTON (+)
4 MANUAL/AUTO
5 ON/OFF
6 START/STOP
HOW TO USE:
1. Plug in the power, push the ”on/off” button, and the LCD & switch will be display with blue light. the
machine come to standby mode: LCD light 2 mins, times display “00:00”, and speed display“0”.
2. Push “manual/auto” button first times, the appliance will be in manual mode:
The ”manual” word flash alway in the LCD, we can seting speed “1 to 6” by” +/-“button,
And then push “start/stop” button once to let the machine start working, the times will display increase from
“00:00”, we can stop the machine by “manual/auto” button if you want.
3. If we push “manual/auto” button twice, the appliance will be in Auto mode:
The “soft yeast” word flash alway in the LCD,we can choice the 6 pcs working Auto modes by “+/-
“button, levels are:

5
1) Soft Yeast 6) Meat grinder
7) Stiff Yeast 6) Pasta maker
6) Fruit cake 7) Egg Beater
8) Shortcrust
And then push “start/stop”once to let the machine start working, it can be working Smart
by IC Control (with Suggested Recipes),will be step by step to finsh the work automatic,
sound the alarm bell 3 times.
NOTE:
Short operation time: With heavy mixtures, do not operate the machine for more
than 4 minutes, and then allow it to cool down for a further ten minutes.
Use the splash guard to protect against liquid mixtures.
Don’t use the egg beater for heavy mixtures (eg creaming fat and sugar) - you could damage it.
After kneading/stirring switch back to the “ON/OFF” position as soon as the mixture has formed a ball.
Then remove the mains plug.
Press the lever downwards and the arm will be raised.
The mixture can now be released with the help of a spatula and removed from the mixing bowl.
The mixing bowl can now be removed by turning to the left.
Clean the parts as described under “Cleaning” .

6
OPTIONAL ACCESSORIES - Meat Grinder: ( if supplied)
1. Metal dish
2. Crush
3. Meat grinder
4. Roler
5. Blade
6. Cutter (fine)
7. Cutter (coarse)
8. Cutter (middle)
9. Nut
Assembling the unit: put the spiral (4) insi der the mincer (3), the blade (5) on the spiral and choose one of the discs
(6,7 or 8) depending on the kind of chopping you want to obtain. Place disc over the blade.
Block the elements by srewing the ring (9).
Assemble the dish (1) over the top of the mincer (3). In the end, attach the meat grinder to the main bodyby
removing the cover (11) In order to Discovery front gear and fitting the mincer to it.
OPTIONAL ACCESSORIES - Pasta Maker (if supplied)
1 flat pasta maker
2 pasta maker (thin noodle)
3 pasta maker(thick noodle)
Assemble the attachment to the main body by removing the cover (11) in order to discover the front gear
and fitting it.

7
SUGGESTED RECIPIES
NO SMART mode Recipes Operation Remark
1. white bread Flour weight: 1.5kg (3.3lb 53oz) (1) pour the warm water into the
(Stiff yeast dough) 15ml (3tsp) salt bowl.Then add the flour (with fresh
25g (1oz) fresh yeast; or 15g/20m yeast if used), salt and lard. Knead at
(1.2oz) dried yeast + 5ml (1tsp) minimum speed for 60 seconds.
sugar (2)Then increase to speed 3, adding
750ml (11.4pts) warm water: 43.C more flour if necessary, until a dough
(110.F). Use a thermometer or has formed,
add 250ml (3)Knead for 3 minutes at speed 3
(9fl oz) boiling water to 500ml (18f until the dough is smooth, elastic and
oz) cold water leaves the sides of the bowl clean
Total weight: 2.4kg (5.3lb 84oz) Total: KB=5 mins
2. white bread Flour weight: 2.1kg (4.6lb 74oz) (1)Pour the milk into the bowl. Add the
(Soft yeast dough) 1.05 litre (21.4pts) milk beaten eggs and 1.5kg (3.3lb 53oz)
300g (10oz) sugar flour.
450g (1lb) margarine
(2)Mix at minimum speed for 1 minute,
100g (4oz) fresh yeast or 50g then at speed 1 for a further minute.
(2oz) dried yeast Scrape down.
6 eggs, beaten (3)Add the remaining flour and mix at
5 pinches salt minimum speed for 1 minute, then at
Total weight: max. 4.0kg
speed 4 for 2 minutes until smooth and
(8.8lb 141oz) evenly mixed.
(4)Half fill some 450g (1lb) greased tin
with the dough, or shape it into rolls.
Then cover with a tea towel and leave
somewhere warm until doubled in size
Total: KB=5 mins
3 fruit cake 3 eggs (1)To make the sponge, whisk the egg
(strawberry 75g (3oz) caster sugar and sugar at maximum speed until ver
and apricot
75g (3oz) plain flour
pale and thick.

8
gateau)
150ml (1.4pt) double cream (2) Remove the bowl and the whisk.
Sugar to taste Fold in the flour by hand using a large
225g (8oz) strawberries metal spoon
225g (8oz) apricots 1 Halve the (3)Put the mixture into two 18cm (7”)
apricots and remove the stones greased and lined sandwich tins.
Total weight: 1.0kg( 3.3kg max. )
(4)Bake at 180.C/350.F/for about 20
minutes until the cake springs back
when lightly touched.
(5) Turn out onto a wire rack.
(6) Whisk the cream at maximum
speed until stiff. Add sugar to taste.
(7) Roughly chop the apricots and a
third of the strawberries.
max. 5 minutes
4 shortcrust pastry 450g (1lb) flour, sieved with the (1)Put the flour into the bowl. Chop the
salt fat up roughly and add to the flour.
5ml (1tsp) salt (2)Using the stainless steel K beater
225g (8oz) fat (mix lard and mix at speed 1 until it resembles
margarine straight from the fridge) breadcrumbs. Stop before it looks
About 80ml (4tbsp) water greasy.
Total weight: 910g (3) Add the water and mix at minimum
(2.7kg max.) speed. Stop as soon as the water is
incorporated.
(4) Cook at around200.C/400.F/Gas
Mark 6, depending on the filling. honey
and nut spread using the liquidiser
max. 4 minutes
5. Meat grinder Cut the meat into pieces of about Cut at minimum speed for max. 5
