KitchenAid KSM152PSCP - Custom Metallic 5-qt. Stand... User manual

c2003 KITCHENAID
11−03 Litho in U.S.A. (bd) Part No. 8204547
MIXER
VARIATIONS
OF
SOLID STATE
KSM152

COLOR VARIATION PARTS
2
For Model: KSM152
8204547
Illus. Part
No. No. DESCRIPTION
1 Motor Housing
240291−19 Chrome
9704752 Satin Copper
9706270 Nickel
2 Trim Band
9707540 Black
3 Planetary
240286−21 Chrome
9704755 Satin Copper
9706271 Nickel
4 End Cover
240253−20 Chrome
9704757 Satin Copper
9706268 Nickel
5 Lower Gearcase
9701398 Chrome
9704749 Satin Copper
9706269 Nickel
6 Pedestal And Foot
Assembly
9703206 Chrome
9704746 Satin Copper
9706272 Nickel
Availability of All
Colors Subject to Change.
Any Color Not Listed is
No Longer Available.
If Additional Colors Are
Added, This Page Will Be
Updated.

BASE AND PEDESTAL UNIT
3
For Model: KSM152
8204547
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
LIT9707917 Use And Care Guide
LIT8204547 Repair Parts List
2 4162529 Screw Cap Kit
3 4176024 Lever, Latch
4 24450 Link, Latch
5 115792 Foot, Base
6Pedestal
7 16910 Pin, Hinge
8 103993 Screw, Latch
Bearing
9 24452 Latch, Link &
Lever (Incls.
Illus. 3, 4,
& 10)
10 240494−2 Latch
11 3400020 Screw,
10−24 x 1/2
12 110679 Screw, Pivot
13 116241 Washer, Spring
14 9706619 Bowl (5 QT)
15 9707944 Beater, Flat
16 9706619 Bowl & Base (5 QT)
17 9707671 Dough Hook
18 9704329 Wire Whip
19 9706633 Pouring Shield

CASE, GEARING AND PLANETARY UNIT
4
For Model: KSM152
8204547

CASE, GEARING AND PLANETARY UNIT
5
For Model: KSM152
8204547
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Gearcase Motor
Housing
(Includes Illus 2)
2 16897 Ring, Attachment
Hub
3 242765−2 Cap, Attachment
Hub
4 240374 Thumb Screw
5Band, Trim
10 4159479 Lock Washer,
#10 Light
11 3180161 Washer, Fiber
Black, Gray
12 4162897 Worm Gear (23T)
14 240308 Worm Gear Bracket
And Bearing
15 3400022 Screw And L.W.
Assy.
#10−24 X 7/16"
Phil. Fil. Hd.
(3)
17 240210−2 Shaft & Pinion
(10T)
18 9705444 Pin
19 240026 Shaft, Vertical
Center
20 9703907 Gear, Attachment
Hub Bevel (23T)
21 9703905 Bevel Pinion
(19T) & Center
Gear (62T)
22 240018−1 Pin (Vertical
Center Shaft)
23 3180163 Washer, Fiber
Black, Gray
25 9704677 Groov−Pin, Type
E, 1/4" X 7/8"
26 4162324 Gasket,
Transmission
Case
27 Lower Gear Case
29 3180163 Washer, Fiber
Black, Gray
31 9703904 Gear, Internal
(59T)
32 103994 Screw, Special
(5)
33 Planetary
40 4176067 Agitator Shaft
(Includes Illus.
60)
42 240285−2 Ring, Planetary
Drip
240285 (KSM152PSCP0
Model)
45 3180160 Washer, Shim
(.015" Thk.)
(.031" Thk.)
47 9703903 Pinion, Gear
(18T) (Agitator
Shaft)
50 4160413 Screw, Adjusting
51 3400203 Set Screw, 1/4"−
28 X 3/8" Hdls.,
Cup Pt.
52 3400025 Machine Screw,
10−24 X 1
Fil. Head
53 67500−55 "O" Ring
54 4159430 Screw, Self
Tapping
6−32 X 1/4"
Phil. Pan Hd.
Type F
55 Cover, End
56 4162914 Screw, 6−32 X 3/8
Phil. Oval Hd.
58 240309−2 Worm Gear Bracket
And Gear (10 T &
23 T) (Incls.
Illus 11 thru 14
17 & 18)
59 3179559 Center Shaft
& "O" Ring
(Incls. Illus.
19,22,25,26, &
53)
60 9703438 Ring
Refer to Page 2
Color Variation Parts

MOTOR AND CONTROL PARTS
6
For Model: KSM152
8204547

MOTOR AND CONTROL PARTS
7
For Model: KSM152
8204547
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 110679 Screw, Pivot
2 116241 Washer, Spring
3 3184193 Switch Lever
And Stud
4 3183680 Spring, Control
Plate
5 3184176 Speed Link & Cam
6 240205 Spring, Flat
7 240769 Screw, Stator
8 9702695 Field Assembly
(Must Use With Item
# 41) 115 Volts
10 9704324 Washer, Ball
Bearing (Front)
11 9708320 Ball Bearing
12 3400402 Screw, Self Tapping
4−40 X 5/16"
Phil. Pan Hd.
Type TT
13 16998 Stud, Governor
Drive
14 3180162 Washer, Spacing
15 3400900 Washer
21 240775−1 Seal, End
22 3180526 Bracket, Bearing
Asm.
25 8533905 Nut, Machine
Hex (10−24)
28 240680 Insert, Brush
Holder
29 9706416 Brush, Carbon
30 9707926 Set Screw,
10−24 X 1/4"
Hdls. Cup Pt
32 116286 Cap, Spring
Seat
33 116287 Spring, Cap
34 3184212 Cap, Brush Holder
35 17830 Governor Assembly
36 240904−2 Control Plate
Assembly
37 9701026 Power Cord
39 9706595 Phase Control
Board
41 9708315 Armature &
Bearing
Incls. Illus 11)
(Must use with
Illus. 8)
44 4162634 Sleeve, Motor
Stud
45 3184609 Screw, Self
Tapping (10−32
X 1/4") Phil.
Pan Hd. Type TT
46 3179908 Housing, Brush
Holder
47 4162546 Brush Holder
(Incls. Illus.
28, 32, 33, 34,
& 46)
OPTIONAL PARTS
AND SERVICE ITEMS
4164839 Speed Disc
(Service Tool)
4160588 Grease, Planetary
4164778 Mixer Attachment
Pak (Includes Food
Grinder (FG−A),
Food Strainer
(FVSP), And
Vegetable Slicer,
(RVS−A)
(FPP−A)
4164749 Food Grinder
(FG−A)
4164751 Grain Mill
(GM−A)
4164768 Pasta Maker And
Food Grinder
(Includes SNP
Pasta Maker
Plates)
(SN/FG−A)
4164775 Fruit/Vegetable
Strainer Parts (Use
With FG−A Model
Only) (FVSP)
4164750 Rotor Slicer/Shredder
(With 4 Standard
Cones) Fine Shredder,
Coarse Shredder,
Thick Slicer, And
Thin Slicer (RVS−A)
9704568 Pouring Shield
(KPS2CL)
4164824 Pasta Maker Plates
(SNP−A)
4164774 Fruit/Vegetable
Strainer And Food
Grinder (FVS/FG−A)
3180617 Cover, Decorative
(Cotton Polyester)
4162838 Food Tray (FT)
4164748 Juicer (JE)
4164747 Can Opener (CO)
4164803 Sausage Stuffer
Kit (SSA)
3177924 Bowl Cover, Plastic
Non−Sealing
4163337 Bowl, Stainless
With Handle
3180262 Bowl, 3 Qt.
4162160 Bowl, Satin
Stainless
