Labgear LDL204 User manual

Introduction
The name Labgear has been associated with quality signal
distribution since 1932 and the current range of ampliers
continues to uphold that tradition. All LDL amps can carry
analogue and digital TV and radio, DAB, Freeview,
DVB-T and DVB-T2 HD TV signals and have:
• More efcient Switch-Mode Power Supplies
which run cooler
• Improved gain atness delivering a better
balance across the performance range
• Lower noise gure for optimised signal quality
• Greater signal handling capacity to cope with
more channels
• Better impedance matching and therefore
improved signal transfer from amp to cable
• Labgear ampliers use F-type coaxial
connectors for better matching and security
These fully screened 4, 6 and 8 way aerial ampliers feature
separate inputs for VHF (Band III TV, FM and DAB digital radio)
and UHF (Freeview, DVB-T and DVB-T2 HD digital TV).They also have
an IR return path to enable channel changing from remote locations
and are compatible with Labgear and other Digilink remote control systems.
This makes them ideal for use in Sky™ digital satellite home installations, where
the output from a digibox can be distributed to several rooms with the capability
for full remote control of the Sky™ box from these rooms.
The LDL ampliers are compliant with the Radio Equipment Directive 2014/53/EU and
meet harmonised standard EN 303 354 for product Type D Class 0, they are suitable for
digital TV signal distribution of Ch21-60 from a receiver or from an aerial tted with a 4G
lter in the UK and EIRE.
LDL204R, LDL206R & LDL208R
Distribution Ampliers with IR Bypass
General Safety Precautions
To Prevent Overheating
The recommended clearances and other precautions given in these instructions must be
observed to prevent overheating. In addition, units should not be positioned where they are
likely to become covered by curtains, fabric or insulating material. The amp should not be
left resting on a carpet.
Other precautions
These appliances are not waterproof, they are intended for indoor use only and must not be
positioned where they could be exposed to dripping or splashing water. Objects containing
liquids should not be placed on or near the amplier.
To prevent re, make sure the unit and attached cabling is installed well away from
naked ames.
Mains Plug
Your amplier is supplied with a standard mains plug already tted, if you need to change
the plug use a competent professional (ELECSA or NICEIC) to make the connection.
If you need to change the fuse use a 3 Amp fuse to BS1362 carrying the ASTA or BSI
approved mark and ret the plastic fuse carrier.
1
COMPLIANT

Specications LDL204 LDL206 LDL208
No of Inputs / Outputs 2 / 4 2 / 6 2 / 8
Frequency Range VHF 87-230MHz & UHF 470-790MHz
Gain per port 10dB 10dB 10dB
Noise Figure Typ. <4dB Typ. <4dB Typ. <4dB
Max Out put level (IMA3-60dB). EN50083-5 90dBuv 86dBuv 86dBuv
Isolation between outlets 20dB 20dB 20dB
Return Path Range 5-30MHz
Return Path Gain 6dB 6dB 6dB
All Ports IR Enabled 9V 15mA short circuit protected 5-30MHz
RED, EMC and LVD Compliant
Built-in Power Supply 220-240V~50Hz at <3W
Dimensions 184x85x35mm 265x95x35mm 265x95x35mm
Typical Installation and Specications
COMPLIANT
2
Remote Rooms
Or
PVR/VCR
Digi Eye
MRX955
RF In
Digi Eye
MRX955
SAT
RF2 OUT
1
VHF
2 3 4 5 6
UHF
7 8
LDL208R
TV
FM/DAB
PSW122
Suitable for combined TV
and Radio outlet
PSW111
Suitable for TV outlet
TV
RF In
TUNER
TV
TV
TV
4G
Filter*
Please Note:
A UHF aerial can be connected
directly to the UHF input on
the amplier or connected
via a Satellite Receiver allowing
terrestrial TV channels to be
distributed via the RF2 outlet
*Install a 4G lter If required

Applications, and Installation
COMPLIANT
3
Applications
These ampliers are designed to boost and distribute signals from the RF2 output of a satellite
receiver and or terrestrial TV and radio aerial signals. When using these ampliers with a Sky
Digibox, the amplier must be fed from the RF OUT-2 socket of the Digibox. However if the RF2
Channel is set to 59 or above (68 is usually the default channel) you will need to reset it to a
channel from 21-58 in the Digibox Setup Menu.
To view satellite RF2 output TVs require an analogue tuner.
Later Digibox models such as the Sky+HD 2TB are not tted with an RF OUT2 output and you will
need an I/O converter such as the Labgear MRX600K to distribute signals from the Digibox to
other TVs.
The LDL distribution ampliers are suitable for digital TV signal distribution for Ch21-60. If you are
affected by 4G interference in your area you may need a Ch60 lter (currently available from
at800 free of charge).
Resetting the RF Channel on a Digibox
1. Switch on your Sky™/Sky+™/ Sky+ HD™ receiver and view on your main television.
2. Press the SERVICES button on your Sky™ remote.
3. Select SYSTEM SETUP option (for SKY+ HD there is no SYSTEM SETUP option press 0 instead).
4. Press the following buttons in sequence: 0, 1, SELECT (for SKY+ HD this is a hidden
option and does not appear on screen). You should now see the installers’ menu.
5. Select the RF channel number option and key in a new channnel number from 21-58 and
select ‘Power On’. Make a note of the channel number you choose as you may need it when
tuning your other TVs.
Installation
Important note: please read the General Safety Precautions before installing this amplier.
Location
Try to choose a location for the amplier which is convenient for cable runs to the system outlets
but which is not too far from the aerial. Select a cool, dry, well ventilated area which is free of
any risk of dripping or splashing water. Stand on a stable at surface (not a carpet or insulating
material) or x to a wall or sturdy upright (screws not provided). Do not allow the amp to hang
on the cables.
Ensure that there is adequate space to ensure cables are not kinked when connecting (mini-
mum 120mm radius recommended) and that above and on the free sides of the amp there is
at least 25mm for ventilation. Do not cover.
Electricity supply
Each unit is supplied with a tted mains plug with 3A fuse, if this is not suitable get a competent
professional (ELECSA or NICEIC) to make the connection with an isolating switch to allow it to be
disconnected when necessary.

Labgear Reserve the right to modify their designs or specications, In the light of future
developments, without prior notice. Performance gures quoted are typical and subject to
normal manufacturing and service tolerances.
This product is intended for use within the UK and Eire.
Declaration of Conformity
Hereby, Labgear declares that this amplier for TV broadcast reception in domestic premises is in
compliance with the Radio Equipment Directive 2014/53/EU.
The full Declaration of Conformity is available by contacting the following internet address: www.
labgear.co.uk/DoC
2 –Year Guarantee
Your amplier is guaranteed against faulty components or poor
workmanship for a period of two years from the date of purchase.
This guarantee does not cover accidental or malicious damage
(Including damage from natural causes such as lightning) and will be
invalidated by installation or use other than in accordance with these
instructions, repair or attempted repair other than by the manufacturer, or
opening or removal of the case.This does not affect your statutory rights.
4
Waste electrical products should not
be disposed of with household waste.
Please recycle where facilities exist.
Check with your Local Authority for
recycling advice.
© Philex Electronic Ltd. 2017 V1
COMPLIANT
Technical Support
For further help, advice or information visit
Our website www.labgear.co.uk
Technical team www.labgear.co.uk/technical
Email: [e-mail]
or live chat during ofce hours via our website
Member
No. M. 1125
Bedford MK42 0NX
www.labgear.co.uk
Guarantee and Technical Support
Signal connections
Input and output connections to the amp are
made using F-type (IEC 60169-24) connectors.
Connections can be made using a tool for
crimp or compression connectors or by hand
with twist-on connectors (see Fig.1 opposite).
Ensure that the correct size connector is used
to match the size of the coax cable.
Make sure that the external connections are
adequately weatherproofed to prevent water
ingress which could damage your amplier.
8mm
6mm
2mm approx.
fold braid back
over sheath
inner wire
cut or tear
away foil
screw connector
body onto cable
end of insulation
should be ush
with this face
Fig. 1
