Labgear LDL206LP User manual

LDL206LP - 6 Way Remote Powered Amplifier
LDL208LP - 8 Way Remote Powered Amplifier
(with DigiLink IR return paths)
For further information or any queries please contact
Customer Careline: 08457 573 479
(Local rate – UK only)
Technical Support: www.philex.com/support
2 –Year Guarantee
Your amplier is guaranteed against faulty components or poor workmanship for a
period of two years from the date of purchase.
This guarantee does not cover accidental or malicious damage (Including damage from
natural causes such as lightening) and will be invalidated by installation or use other
than in accordance with these instructions, repair or attempted repair other than by the
manufacturer, or open or removal of the case. This does aect your statutory rights.
Labgear Reserve the right to modify their designs or specications, In the light of future
developments, without prior notice. Performance gures quoted are typical and subject
to normal manufacturing and service tolerances
Installation Instructions
Introduction
These fully screened 6 and 8 way TV and FM/DAB
ampliers are line powered by the separate PSUF
power unit supplied. This allows the ampliers to be
positioned anywhere in the building as long as they
are connected with good quality coax cable to the
power unit. This makes them ideal for installation in
lofts where no 13 Amp power supply is available.
The ampliers have IR return paths on all outlets making them fully
compatible with Labgear DigiLink and other similar remote control systems.
This makes them perfect for use in digital satellite home
installations, where the output from a digibox™ can be
distributed to several rooms with the capability for full
remote control of the digibox™ in these rooms.
The addition of a number of MRX955 DigiLink remote
‘eyes’in the relevant rooms completes the installation.
Alternatively the products may be used as traditional distribution
ampliers without making use of the infra red capability.
Separate inputs are provided for UHF TV (470-790 MHz) and for FM/DAB (47-300 MHz).
Remote capability is provided over a 5-15 MHz RF return path.
All amplier outputs are line powered at 9V DC to supply remote infra-red receivers. The line power
at any output(s) can be short-circuited safely, without aecting the operation of any other output(s).
Both units are also suitable for direct amplication of digital terrestrial TV (Freeview™) signals and
the UHF input can be connected directly to a UHF antenna instead of a satellite receiver.
When connected directly to a UHF aerial the integrated lter will remove any signals from Lte 800 4G
mobile phone transmitters picked up by the attached aerial.
Please Note: These ampliers are NOT COMPATIBLE with the Labgear Handylink Remote control
extender system (MRX120). These ampliers do not provide line-power for masthead preampliers.
Applications
Applications include the following:
• Simple multipoint distribution of radio and TV signals, without remote control.
This will allow quick and easy addition of an IR control at a later date;
• Use in conjunction with a Sky Digibox™ or other unit with an IR-return enabled RF output.
An MRX955 DigiLink room kit will be required for each room from which remote control
is needed (because the Digibox can decode the IR return signals directly, this application
does not require any base unit or IR re-emitters).
Example application diagram is shown on page 2.
Please Note: when using these amplifiers with a Sky Digibox, the amplifier must be fed from
RF OUT-2 socket of the Digibox. However if the RF Channel is set to 61 or above (68 is usually
the default channel) you will need to reset it to a channel from 21-60 in the Digibox Setup
Menu (see bottom of page 3). Later Digibox models such as the Sky+HD 2TB are not fitted
with an RF OUT2 output and you will need an I/O link to distribute signals from the Digibox
to other TVs.To view satellite RF2 output TVs require an analogue tuner.
General Safety Precautions
To Prevent Overheating
The recommended clearances and other precautions given in these instructions must be
observed to prevent overheating. In addition, units should not be positioned where they
are likely to become covered by curtains/fabrics or thermal insulation materials in a roof
space or similar building void. The unit should not be left resting on a carpet.
Other Precautions
These appliances are not waterproof. They are for indoor use only and must not be posi-
tioned where they could be exposed to dripping or splashing water. Objects containing
liquids should not be placed on or near the appliance. To prevent risk of re, keep the
unit and attached wiring well away from naked ames.
Fitted Mains Plug
These power supplies are tted with a standard xed plug. If this is not suitable, refer
to the instructions below. If you need to change the fuse in this plug, a 3 Amp fuse to
BS1362 carrying the ASTA or BSI approved mark must be used.
Always re-t the plastic fuse carrier when replacing the fuse.
Changing the Plug
If the tted mains plug is not suitable for the socket outlet in use, it should be cut o
and an appropriate new plug tted. Any instruction supplied with the plug should be
followed. The Brown wire must be connected to the live (L) terminal of the plug and the
Blue wire to the neutral (N) terminal. Neither wire should be connected to the earth (E)
terminal of a 3-pin plug (this appliance does not require an earth connection). Ensure
that the cord grip in the plug is correctly used and clamps the sheath of the cord rmly.
Fuse Rating: If the new plug is a fused type, the fuse tted should be rated at no more
than 3 Amp. Caution: The old plug should be disposed of promptly since it would be
dangerous if plugged into a live socket.
1
Installation Instructions
Lte 800
READY
Waste electrical products should not
be disposed of with household waste.
Please recycle where facilities exist.
Check with your Local Authority for
recycling advice.
© Philex Electronic Ltd. 2014 V1.2
4

Remote Rooms
Or
VCR/DVR
Digi Eye
MRX955
TV
RF In
Digi Eye
MRX955
SAT
RF2 OUT
1
VHF
2 3 4 5 6
UHF
7 8
LDL208LP
Remote Powered
POWER
Lte 800
READY
PSM114E
TV
FM/DAB
PSW122
Suitable for combined
TV and Radio outlet
PSW111
Suitable for TV outlet
RF In
TV
TUNER
TV
TV
Installation
Important note: attention is drawn to the General Safety Precautions Panel on page 4 which
contains advice on safe installation and operation of these products.
Location
Choose a location for the amplier from which it is convenient to run cables from the
antennas and to the system outlets. Typical examples of suitable locations are a loft space or a
cupboard. In weak signal areas it is best to keep the antenna cables as short as possible.
Select a cool, dry location to install the amplier. This means a location where the ambient
temperature will remain between -10°C and +40°C, and which is free from risk of dripping or
splashing water.
The xing location should allow adequate access to the equipment for wiring and maintenance.
Clearance of at least 25mm should be allowed around the top and left hand side of the amplier
and also around the three sides of the power supply that don’t have connections to allow
adequate ventilation. More clearance will be needed on the sides with connections to allow
access for cables.
Fixing
The amplier should be xed to a wall or other suitable hard surface, using suitable screws and
masonry plugs (not supplied). The amplier should not be left supported by its own wiring, nor
should it be left resting on a carpet or other insulating and/or inammable surfaces.
Electricity Supply
Fixed wiring and connection of the electrical supply to these products should be carried out in
accordance with BS7671 (IEE Wiring Regulations) .
Each amplier is supplied with a separate PSUF tted with a 13A mains plug. If this is not
suitable, see General Safety Precautions Panel on page 4. As an alternative to the use of plug
and socket connection, the power supply may be connected to the mains using a switched
fused connection unit BS 1363-4. A 3 Amp fuse to BS1362 should be tted in the fused
connection unit. If the power unit is connected to the supply other than by means of its tted
fused plug or a fused connection unit, It must be protected by a non-time delayed fuse or a
type B MCB at the distribution board of rating not exceeding 6A. An isolating switch should be
provided near to the unit to allow it to be disconnected from the supply when necessary.
Signal Connections
Input and output signal connections are made using F type (IEC 60169-24) connectors.
Good quality plugs should be used, preferably of the crimp on type. If twist on connectors are
used make sure they are the right size to t the cable you are using. For outside connections
use waterproof connectors. Attention is drawn to the need to maintain DC continuity through-
out the system for correct operation of infra-red remote control functions
Resetting RF Channel on a Digibox
1.Switch on your Sky™/Sky+™/ Sky+ HD™ receiver and view on your main television.
2.Press the SERVICES button on your Sky™ remote.
3.
Select SYSTEM SETUP option (for SKY+ HD there is no SYSTEM SETUP option press 0 instead).
4.Press the following buttons in sequence: 0, 1, SELECT (for SKY+ HD this is a hidden option
and does not appear on screen). You should now see the installers’menu.
5. Select the RF CHANNEL NUMBER option and key in a new channnel number from 21-58.
Make a note of the channel number you choose as you may need it when tuning your
other TVs. 3
2
Amplier LDL206LP LDL208LP
No of Inputs 2
No of Outputs 6 8
Return Path Frequency Range 5-15MHz 5-15MHz
Return Path Gain -4dB
Frequency Range UHF: 470-790MHz FM/DAB: 47-300MHz
UHF/FM/DAB Gain per port 8dB
Max Out put level (IMA3-60dB). EN50083-5 98dBµv 96dBµv
Noise Figure 3.5dB
All Ports IR Enabled 9V 15mA short circuit protected
Isolation between outlets 20dB
Dimensions 265 x 95 x 35mm
Power Supply PSUF
DC Output 12VDC at 200mA max.
Output Voltage Tolerance ± 5%
Power Requirement 220-240V~50Hz at <3W
Signal Insertion Loss 0.5dB
Dimensions 88 x 67 x 45mm
Installation Instructions
Please Note: A UHF aerial can be
connected directly to the UHF input
on the amplier or connected via
a Satellite Receiver.
Installation Instructions
