Labom PL110 Series User manual

Electronic angle-of-rotation sensor 81.4
Type series PL110x
LABOM Mess- und Regeltechnik GmbH Im Gewerbepark 13 27798 Hude Germany
BA_057_en_2022-03_11.00
Hotline: [phone] Fax: [phone] e-mail: [e-mail] www.labom.com
Page 1/5
Operating Instructions
1General Information.......................................................................................................2
1.1 General Safety Notes..............................................................................................2
1.2 Intended Use...........................................................................................................2
1.3 Conformity with EU Regulations..............................................................................2
1.4 EX Approval............................................................................................................2
2Transportation and Storage..........................................................................................2
3Installation and Commissioning ..................................................................................2
3.1 Mechanical Installation............................................................................................3
3.2 Electrical Connection ..............................................................................................3
4Operation........................................................................................................................3
4.1 Zero-point setting....................................................................................................3
4.2 Maintenance / Service.............................................................................................4
5Disassembly...................................................................................................................5

BA_057_en_2022-03_11.00 Electronic angle-of-rotation sensor 81.4
Page 2/5
1 General Information
This document contains necessary information for the proper installation and use of this
device. In addition to this instruction, be sure to observe all statutory requirements, applica-
ble standards, the additional technical specifications on the accompanying data sheet (see
www.labom.com) as well as the specifications indicated on the type plate.
1.1 General Safety Notes
The installation, set up, service or disassembly of this device must only be done by trained,
qualified personnel using suitable equipment and authorized to do so.
Warning
Media can escape if unsuitable devices are used or if the installation is not
correct.
Danger of severe injury or damage
Ensure that the device is suitable for the process and undamaged.
1.2 Intended Use
The electronic angle-of-rotation sensor is used for the remote electronic monitoring of pres-
sure and temperature values and can be integrated in mechanical pressure and temperature
measuring devices as specified in the data sheet.
1.3 Conformity with EU Regulations
The CE-marking on the device certifies its compliance with the applicable EU Directives for
placing products on the market within the European Union.
1.4 EX Approval
Devices of the type PL1101 are certified for use in explosive environments.
If you purchased a device with EX approval, please refer to the accompanying document
XA_009 for EX-relevant information.
2 Transportation and Storage
Store and transport the device only under clean and dry conditions preferably in the original
packaging. Avoid exposure to shocks and excessive vibrations.
Please refer to the measuring device’s operating instructions to determine the permissible
storage temperatures.
3 Installation and Commissioning
Ensure that the device issuitable for the intended application with respect to pressure range,
overpressure limit, media compatibility, temperature range and process connection.
After the mechanical installation and electrical connection is completed, the device is ready
for operation as soon as the power supply is switched on.

BA_057_en_2022-03_11.00 Electronic angle-of-rotation sensor 81.4
Page 3/5
3.1 Mechanical Installation
Please pay attention to the measuring device operating instructions.
If the device is opened there is a risk of influencing the signals by touching the electronic
connections. This can be avoided by switching off the supply voltage or disconnecting the
signal circuit.
3.2 Electrical Connection
Complete the mechanical installation before you connect the device electrically.
Set up all electrical connections while the voltage supply is switched off.
Terminal box
2-wire
3-wire
Circular connector M12
2-wire
3-wire
Table 1: Versions of the electrical connection
4 Operation
During operation, take care that the device remains within its intended pressure and tem-
perature ranges. No other monitoring is necessary.
4.1 Zero-point setting
Set the zero-point of the measuring device and the angle-of-rotation sensor separately.
OUT
3
4
12 n.c.
3
4
12
A

BA_057_en_2022-03_11.00 Electronic angle-of-rotation sensor 81.4
Page 4/5
4.1.1 Zero-point correction
Zero point deviations can occur due to the
mounting, the installation position or due to
the type and duration of use. Measuring de-
vices with micro adjustment pointer can be
corrected in a depressurised state by
means of the adjusting screw on the pointer
hub (see figure 1).
You can find further information about zero-
adjustment of pressure gauge with micro
adjustment pointer in the document TA_029
on www.labom.com.
Figure 1: Zero-point correction
4.1.2 Adjusting the angle-of-rotation sensor
For adjustable devices the adjustment re-
quires to apply the lower limit pressure re-
spectively the upper limit pressure to the de-
vice. Bring the enclosed or another magnet
in the alignment position (see figure 2) to
adjust accordingly. After approx. 2 seconds
a light signal (1) in the scale acknowledges
the adjustment of the measurement range
begin and/or the adjusted range. The ad-
justment is possible within a tolerance of ap-
prox. ± 5 % F.S. Any settings that differ from
this will not be accepted.
Figure 2: Alignment position
4.2 Maintenance / Service
When properly installed in accordance with applicable specifications, this device is mainte-
nance-free. However, we recommend an annual recalibration of the device.
In the event of any damage or defect the customer cannot replace or repair any components
or assemblies.

BA_057_en_2022-03_11.00 Electronic angle-of-rotation sensor 81.4
Page 5/5
5 Disassembly
When measuring hot media, make sure that the device has cooled down prior to any dis-
mounting or wear appropriate protective clothing to avoid burns.
Switch off the power supply to the device before disconnecting the electrical connections.
Once this is done, the device may be mechanically removed.
Warning
Opening pressurized lines might cause severe injuries.
Danger of severe injuries or damage
Relieve the process pressure before attempting to remove the device. Shut
off the pressure supply for all feed lines to the device and relieve the pres-
sure in them.
Warning
Hazardous deposits and residues might remain on opened process connec-
tions and removed devices.
Danger of injury
After the device has been removed, seal off the measuring point and mark
the open process connection accordingly. Consider a possible danger due
to residues when handling the removed device.
