LabStrong Rapids D003312 User manual

Rapids™ Type I Water
Purification System
D003312
LT0033-4
Rapids™
Type I Water
Purification System
User
Manual
01/22/2020

Page 2

LabStrong™ Cop.
NOTICE
LabStrong™ Corp. shall not be liable for any damages arising out of or related to the incorrect installaon or
operaon of the unit. LabStrong™ shall have no liability to you or any other person or enty for indirect, spe-
cial, incidental or consequenal damages of any descripon, whether arising out of warranty or other con-
tract, negligence or other tort, or otherwise.
The Rapids™ Type I Water Puricaon System is designed to provide ultrapure water that meets ASTM Type I
specicaons, provided it is fed with water that meets certain quality specicaons and is properly main-
tained as recommended by LabStrong™
LabStrong™ does not warrant the Rapids™ for any specic applicaon. The end user must evaluate and de-
cide if the water produced is to the standards needed for their purposes and procedures. LabStrong™ is not
responsible for any results obtained due to usage of water produced by the Rapids™ Type I Water Puricaon
System.
LabStrong™ reserves the right to change/update the informaon in this manual at anyme. This manual
should not be construed as a commitment by LabStrong™. This manual is believed to be complete and accu-
rate at the me of publicaon and LabStrong™ assumes no responsibility for any errors that might appear in
this document. LabStrong™ makes no representaon or warranty to you of any kind, express or implied, with
respect to installaon, use, maintenance, or replacement of products as described in this manual. Lab-
Strong™ fully disclaims all express and implied warranes, whether as to merchantability, tness for a parc-
ular purpose, warranes arising from course of dealing or usage or trade or any other maer with respect to
its replacement products.
No employee representave or agent of LabStrong™ has any authority to bind the company to any arma-
on, representaon or warranty.
Copyright
©2019 LabStrong™ Corporaon. ALL RIGHTS RESERVED. THIS MANUAL OR PARTS THEREOF MAY NOT BE RE-
PRODUCED IN ANY FORM WITHOUT WRITTEN CONSENT OF LABSTRONG™.
Trademarks
LabStrong™, Rapids™ and LabStrong Link™ are trademarks of LabStrong™ Corporaon. All other trademarks
are trademarks of their respecve manufacturers.
iii

iv
WARRANTY
New Equipment Limited Warranty
LabStrong™ Corp. warrants that this product is free from defects in materials and workmanship and for any
unit sold in the connental United States or Canada the warranty period for labor is ninety (90) days, and for
a period of twelve (12) months, the parts required to repair such defect. Outside the connental United
States or Canada, the warranty period covers for twelve (12) months the parts required to repair such defect.
Labor outside of the connental United States or Canada is not covered. The warranty period for this product
begins from date of shipment to the original buyer.
The exclusive remedy of buyer in the event of a breach of the foregoing warranty is expressly limited to the
replacement or repair (at LabStrong™ Corp.’s opon) of any product that malfuncons in condions of nor-
mal use. An authorized agent or representave of must perform all warranty inspecons and work. No goods
shall be returned to LabStrong™ Corp. for inspecon, repair or replacement pursuant to this warranty with-
out prior wrien approval. All cleaning, decontaminaon, and shipping costs shall be the sole responsibility of
the buyer together with any damage to the goods that might occur in transit to or from LabStrong™ Corp.’s
warranty as stated herein is rendered null and void if the defect or malfuncon occurred because of misuse,
neglect, accident, improper service or other reasons unrelated to defects in materials or workmanship.
Under no circumstances does LabStrong™ Corp.’s responsibility or warranty extend to products other than
those manufactured or distributed by; nor does LabStrong™ Corp.’s liability extend to any products, arcles
or parts which are furnished by buyer or obtained from other manufacturers or suppliers at buyer’s request
and/or in accordance with buyer’s specicaons. In the event that is unwilling or unable to repair or replace
any defecve or nonconforming product during the warranty period due to change in technical standards,
technical modicaons, non-availability of material or parts, or any other reason, buyer shall be entled to a
return of the purchase price paid for such product as its sole and exclusive remedy assumes no responsibility
whatsoever for the accuracy of designs, specicaons or materials furnished or specied by buyer.
THE WARRANTIES EXPRESSLY STATED HEREIN ARE IN LIEU OF ANY AND ALL OTHER WARRANTIES, EXPRESSED
OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE WARRANTIES OF DESIGN, MERCHANTABILITY AND FIT-
NESS FOR A PARTICULAR PURPOSE. THE BUYER ACKNOWLEDGES THAT IT IS NOT RELYING ON LAB-
STRONG™CORP.’S SKILL OR JUDGEMENT TO SELECT OR FURNISH GOODS SUITABLE FOR ANY PARTICULAR
PURPOSE. IN NO EVENT WILL LABSTRONG™ ™CORP. BE LIABLE TO ANY PARTY FOR ANY DAMAGES CAUSED
BY USE OR POSSESSION OF THE PRODUCT OR THE FAILURE OF THE PRODUCT TO PERFORM, INCLUDING ANY
LOST PROFITS OR SAVINGS, ANTICPATED OR OTHERWISE, OR INCIDENTAL, CONSEQUENTIAL OR SPECIAL
DAMAGES OF ANY KIND. LABSTRONG™ CORP. IS NOT LIABLE FOR ANY CLAIM MADE BY A THIRD PARTY OR
MADE BY YOU FOR A THIRD PARTY.
Accessory Limited Warranty: The accessories manufactured by LabStrong™ Corp. have a warranty period of
90 days from the date of purchase. Consumables (e.g. cartridges, drive belts, lters, heang elements, and
thermistors) are not considered accessories and do not have a warranty period, except for an out of box fail-
ure.
LT0029-2 rev
LT0033-4

LabStrong™ Cop.
.

vi
LT0029-2 rev
LT0033-4
TABLE OF CONTENTS
Noce, Copyright, Trademarks iii
Warranty, Accessory Limited Warranty iv
Table of Contents vi
List of Figures vii
Using this Manual and Safety Informaon 8
Introducon 9
Package Contents 10
Compable Accessories 11
Compable Cartridges 12
Replacement Parts 13
Regulatory Informaon 14
Product Informaon 15
Photo Diagram of the Rapids™ Type I Water Puricaon System 16
Drawing of the Rapids™ Type I Water Puricaon System 19
Flow Diagram of the Rapids™ Type I Water Puricaon System 20
Photo Diagram of the Rapids™ Cartridge Kits 21
Graphical Touchscreen Diagrams 22
Safety Precauons Before Installaon 29
Installaon Requirements 30
Installaon Instrucons for the Rapids™ Type I Water Puricaon System 31
Operaon of the Rapids™ 38
Service 40
Service Warranty 41
Troubleshoong—Nocaon Codes 42
System Maintenance—Inial Cartridge Installaon 45
System Maintenance—Exhausted Cartridge Replacement 46
System Maintenance—When to Change the 0.2 Micron Final Filter (FL0016-1) 48
System Maintenance—Cleaning 49
NFC Tag Reader Tester Back Cover

LabStrong™ Cop.
List of Figures
vii
Tables
1.2 Package Contents 10
1.3 Compable Accessories 11
1.4 Compable Cartridges 12
1.5 Replacement Parts 13
1.6 Product Specicaons 15
2.5 Photo diagram ref. 16
2.10 Photo diagram ref. 17
2.13 Photo diagram ref. 18
2.17 Drawing diagram ref. 19
2.18 Flow diagram ref. 20
3.6 Ref. to Home screen 22
3.13 Ref. to Menu screen 23
3.15 Ref. to Help screen 24
3.17 Ref. to Maintenance screen 25
3.19 Ref. to Diagnoscs screen 26
3.21 Ref. to Sengs screen 27
3.23 Ref. to Specicaons screen 28
4.1 Installaon Requirements 30
Figures
2.14 Front drawing 19
2.15 Le side drawing 19
2.16 Underside drawing 19
2.19 Flow Diagram 20
3.1 Idle mode 22
3.2 Standby mode 22
3.3 On mode 22
3.4 Dispense mode 22
3.5 Timed dispense mode 22
3.7 Menu screen 23
3.8 Help sub-menu 23
3.9 Maintenance sub-menu 23
3.10 Diagnoscs sub-menu 23
Figures
3.11 Sengs sub-menu 23
3.12 Specicaons sub-menu 23
3.14 Help sub-menu 24
3.16 Maintenance sub-menu 25
3.18 Diagnoscs sub-menu 26
3.20 Sengs sub-menu 27
3.22 Specicaons sub-menu 28
6.2 Nocaon codes 42
QR Codes
1.1 Register Rapids™ 9
4.24 Installaon Video 37
6.1 RFID Technology 41
Images
2.1 Front view of unit 16
2.2 Le side view of unit 16
2.3 Underside view of unit 16
2.4 Final Filter view of unit 16
2.6 View of unit plumbing 17
2.7 View of unit cartridges 17
2.8 View of grommet holder 17
2.9 View of grommet holder 17
2.11 View of electrical parts 18
2.12 View of control board 18
2.20 Cartridge kit D00336KT 21
2.21 Cartridge kit D00337KT 21
2.22 Cartridge kit D00338KT 21
2.23 Cartridge kit D00339KT 21
2.24 Cartridge kit D003310KT 21
2.25 Cartridge kit D003311KT 21
4.2 Installaon step 2 31
4.3 Installaon step 3 32
4.4 Installaon step 4 32
Images
4.5 Installaon step 5 32
4.6 Installaon step 6 33
4.7 Installaon step 7 33
4.8 Installaon step 8 33
4.9 Installaon step 9 33
4.10 Installaon step 10 34
4.11 Installaon step 11 34
4.12 Installaon step 12 34
4.13 Installaon step 13 34
4.14 Installaon step 14 35
4.15 Installaon step 15 35
4.16 Installaon step 16 35
4.17 Installaon step 17 36
4.18 Installaon step 18 36
4.19 Installaon step 18 36
4.20 Installaon step 18 36
4.21 Installaon step 19 37
4.22 Installaon step 20 37
4.23 Installaon step 21 37
5.1 Turning on Rapids 38
5.2 Dispensing - On mode 38
5.3 Dispensing - Press and Hold 38
5.4 Dispensing - Timed dispense 38
5.5 Accessing menu 39
5.6 Exhauson threshold 39
5.7 Scanning QR codes 39

Page 8
USING THIS MANUAL
It is highly recommended to read this manual in its enrety prior to use in order to fully understand how to
appropriately install, operate and maintain the Rapids™ Type I Water Puricaon System.
SAFETY INFORMATION
Your Rapids™ System was designed with safety and funconality in mind. For a safe and opmal use please
pay aenon to the alert signals throughout the rest of the manual.
Statements indicate informaon considered important, but
not related to personal injury (e.g. messages relang to
property damage).
Statements indicate hazardous situaons that, if not avoid-
ed, could result in minor or moderate
injury.
Statements indicate hazardous situaons that, if not avoid-
ed, could result in death or serious
injury.
LT0033-4

Page 9
INTRODUCTION
The LabStrong™ Rapids™ Type I Water Puricaon System is an easy-to-use and economical Type I ASTM
Water Puricaon System. This water system is ideal for any laboratory that is looking for a system that
produces analycal grade water. The Rapids™ Type I Water Puricaon System is simple to install and
mounts directly to the wall near your water source. The Rapids™ achieves superior water puricaon with
conducvity readings of up to 18.2 when paired with LabStrong™'s organic or standard cartridge kits.
For your reference, make a note of the serial number, date of purchase and supplier here:
REGISTER YOUR NEW PRODUCT ONLINE AT
hps://www.labstrong.com/reg
Serial Number
Model Number D003312
Date of Purchase
Supplier
LabStrong™ Cop.
QR Code 1.1

Page 10
PACKAGE CONTENTS
Unpack the Rapids™ Type I Water System carefully. Ensure that all components are removed prior to discard-
ing packaging. Items listed below.
LT0033-4
Part/Form
Number Part/Form Name Part/Form Descripon
D003312 LabStrong™ Rapids™ Type I Water
Puricaon System
The ASTM Type I Water System including all major
components. See schemac on page 20
LT0033-1LabStrong™ Rapids™ User Manual
Instrucon manual detailing the components,
installaon, maintenance and accessories of the
water unit.
LT0033-3LabStrong™ Rapids™ Mounng
Guide/Template
Guide/template to aid in the mounng and instal-
laon of the water unit.
PS-006 LabStrong™ Rapids™ System Power
Supply with Cord Used to supply power to the water unit.
ST0033-2LabStrong™ Rapids™ Power Supply
Velcro™ Holder
Can be mounted to a wall to hold the power
supply.
FL-001 Air Filter Used for ltering the air. Installed during the in-
stallaon process.
TU0033-2Tubing—10 Cut to t and used to connect the water unit and
the water source.
TL0012-2Fing Removal Tool Used for removing the top and boom ngs of
the cartridge end covers
PM037 Dispense Hose Fing Used to aach a hose so that water can be routed
to a drain.
Table 1.2

Page 11
COMPATIBLE ACCESSORIES
All accessories are sold separately. Consult your distributor or visit www.labstrong.com.
LabStrong™ Cop.
Part
Number Part Name Part Descripon
FL-001 Air Filter Used for ltering the air. One (1) is included in the
original shipment of the water unit.
FL0016-1Final Filter
Aached to the dispense solenoid valve, the 0.2
micron nal lter will provide bacteria-free product
water. Not included in original shipment.
CMX25LS Cleaning Syringe
Contains a cleaning soluon specically formulated
to sanize and ush away bacterial contaminants.
It is recommended to use cleaning syringe to sani-
ze the water puricaon unit when the unit is
new and when installing new cartridge packs.
Table 1.3

Page 12
COMPATIBLE CARTRIDGES
All cartridges are sold separately as kits. Individual components of the kits are listed below along with the
available kits and the contents of the kit. To purchase, consult your distributor or visit www.labstrong.com.
LT0033-4
Cartridge
Number Cartridge Kit Name Cartridge Kit Contains
AVAILABLE CARTRIDGE KITS FOR THE LABSTRONG™ RAPIDS™ TYPE I WATER PURIFICATION SYSTEM
D00336KT Tap/DI Feed Low Organic D00331, D00332, D00332,
D00333
D00337KT Tap Feed Low Organic D00331, D00334, D00332,
D00333
D00338KT Tap Feed Type 1 D00331, D00334, D00332,
D00332
D00339KT Tap/DI Feed Type 1 D00331, D00332, D00332,
D00332
D003310KT RO/Dislled Low Organic D00335, D00332, D00332,
D00333
D003311KT RO/Dislled Type 1 D00335, D00332, D00332,
D00332
DESCRIPTIONS OF COMPONENTS IN THE CARTRIDGE KITS. NOT SOLD SEPARATELY.
D00331 Pretreat Colloid/Organic Removal Cartridge
D00332 Mixed Med High Purity Cartridge
D00333 Organic Removal Cartridge
D00334 Two Bed High Capacity Cartridge
D00335 Pretreat Type I Cartridge
Table 1.4

Page 13
REPLACEMENT PARTS
To purchase, consult your distributor or visit www.labstrong.com. Need technical assistance? Contact us via
phone or email at 563-588-8900 or [e-mail]
LabStrong™ Cop.
Part # Part Name Quanty
ST0033-1Strap, Velcro™ Cartridge 1
ST0033-2Strap, Velcro™ Power Supply 1
TL0012-2Fing Removal Tool 1
PM0033-8Pressure Regulator 1
PM-009 Fing 3/8” x 3/8” Bulkhead
Union 1
PM-036 Check Valve 3/8” 1
PM-037 Fing 3/8” Stem x 1/4”
Male NPTF KYNAR 3
PM-038 Fing 3/8” x 3/8” x 3/8” Tee
Union 1
PM-039 Fing 3/8” x 3/8” Elbow
Union 1
PM-040 Fing 3/8” Stem x 1/4”
Male NPTF PP 2
PM-041 Fing 3/8” Tube x 1/4”
Male NPTF 5
PM-042 Fings 3/8” x 3/8” Tube El-
bow 10
PM-043 Fing 3/8” x 3/8” x 3/8” Tee
Union 3
PM-045 Fing Female Luer with
1/4” Barb 1
PM-046 Fing Male Luer Plug 1
PU0033-1Water Pump 1
PM0033-3Dispense Solenoid 1
PM0033-6Air Inlet Solenoid 1
PM0033-6Inlet Water Solenoid 1
PM0033-7Recirculaon Solenoid 1
Part # Part Name Quanty
PC0033-2Display PCB 1
PC0033-3Main Control PCB 1
PC0033-4NFC Reader PCB 1
WH0027-5Wire Harness, Display
Connector 1
WH00033-3Wire Harness, Power Supply
to Control Board 1
WH-002 Wire Harness, Display Cable 1
WH0033-2Wire Harness, Control Board
to NFC Controller 1
SW-001 Switch, Rocker 1
PM-050 Check Valve 1/4” 1
PM-051 Check Valve 5/16” 2
CR-001 Cord Set 125V 10 amps 1
PS-006 Power Supply 115V AC to
24 VDC 1
PM-052 Conducvity Cell 1
Table 1.5

Page 14
LT0033-4
REGULATORY INFORMATION
FCC Noces (United States of America)
Contains FCC ID: 2ASQK-EA00351
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two condions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operaon.
Changes or modicaons to this device not expressly approved by LabStrong Corp. could void the user’s au-
thority to operate the equipment.
IC Noces (Canada)
Contains IC: 24977- EA00351
This device complies with Industry Canada license-exempt RSS standard(s). Operaon is subject to the follow-
ing two condions: (1) this device may not cause interference, and (2) this device must accept any interfer-
ence, including interference that may cause undesired operaon of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de li-
cence. L'exploitaon est autorisée aux deux condions suivantes : (1) l'appareil ne doit pas produire de
brouillage, et (2) l'ulisateur del'appareil doit accepter tout brouillage radioélectrique subi, même si le brouil-
lage estsuscepble d'en compromere le fonconnement.

Page 15
PRODUCT SPECIFICATIONS
LabStrong™ Cop.
Dimensions (WxHxD) 26.5’’ x 22” x 11.5” / 67.31cm x 55.8cm x 29.21cm
Weight
Operaonal 56lbs./26kg
Shear 225lbs./102kg *Shear weight means mounted on wall with safety factor.
Per Cartridge 4lbs./1.8kg
Feed Water Requirements
Type of Feed Water Tap (TDS 100-300 ppm), RO, DI, Dislled
Inlet Water Pressure 15 PSI Minimum, 100 PSI Maximum
Inlet Water Temperature 4°C to 38°C (40°F to 100°F)
TOC < 1.0 ppm
Total Silica < 1.0 ppm
Turbidity 1.0 NTU Max
Piping connecon Fing capable of accepng a 3/8” OD tube
*System’s capacity will be lower with tap water feed due to the amount of dissolved solids in the tap water. Recommended for low usage only.
Product Water Quality Type I ASTM (Maximum 18.2 MΩ/cm)
Product Water Flow Rate Type I water, up to 2 Liters per Minute (LPM)
Voltage 100-240VAC 120W 50/60Hz at receptacle to 24 VDC at unit.
Cartridge Storage Shelf life is two (2) years from date of manufacture, provided cartridge remains
as delivered from LabStrong™ in the sealed plasc bag. Don’t remove cartridge
from bag unl use. Keep cartridge away from heat. Exchange capacity is greatly
reduced if resins are allowed to dry completely. Resins shrink due to moisture
loss. Cartridges may not appear full; resins expand when wet to ll cartridges.
Cartridge Odor A normal by-product of some ion exchange resins is a slight release of amines
that have a ‘shy’ smell upon opening a sealed bag. Higher temperatures can
increase intensity of the odor. Odor should greatly diminish and/or disappear
aer 3-5L of water are rinsed through the cartridge.
Operang Condions Temperature: 5°C to 40°C (41° to 104°F); Relave Humidity: 20% to 80 % non-
condensing. Polluon Degree 2 in accordance with IEC 60664. Altude Limit:
6562 . (2000meters).
Non-Operang Condions
(Storage)
Temperature: 5°C to 40°C (41° to 104°F); Keep out of direct sunlight and away
from heat. Relave Humidity: 10% to 85 % relave humidity / non-condensing.
Altude Limit: 6562 . (2000meters).
Table 1.6

Page 16
PHOTO DIAGRAM OF THE RAPIDS™
LT0033-4
1 2 3
4
5
10
9
8
7
7
6a
6a
6b
Ref. # Descripon Funcon
1Housing
Cover
Houses the touchscreen display
and protects the mechanical
components of the unit.
2Cartridge
Cover
Aached by hinge pins on the
top and magnets on the boom.
It Covers the installed cartridges.
3Power Cord Delivers electrical power to the
unit.
4Inlet Water
Tube
10  of tubing is supplied.
Connects unit to a water source.
5Touchscreen
Display
Screen that allows a user to op-
erate the Rapids™ unit.
6a Dispense
Hose Fing
Water will dispense from this
ng. If the oponal nal lter
is used, 6b, the ng will be
replaced by the nal lter, 6b.
6b 0.2 µm Final
Filter
Removes parculates down to
0.2 µm to provide bacteria-free
water. This is an accessory that
does not come with the unit.
The nal lter is purchased sep-
arately.
7Air Filter The air lter aaches here and
lters the incoming air.
8Power Switch Toggle the switch up or down
will turn the unit on or o.
9Power Source
Connector
Connecon point for the power
cord and the unit.
10 Water Input
Connector
Connecon point for the tubing
from the water source to the
unit.
Image 2.1
Image 2.2
Image 2.3 Image 2.4
Table 2.5

Page 17
PHOTO DIAGRAM OF THE RAPIDS™
LabStrong™ Cop.
13
15
17
Ref. # Descripon Funcon
11 Metal Rods
Rods funcon as a hinge for
aaching the cartridge cover to
the unit. The boom of the
cover is secured with magnets.
12
Cartridge
Cover
Magnets
Helps aach the cover to the
unit.
13 Fings
Fings connect the tubes to
the cartridges. There are four
ngs on top and boom of
the cartridges.
14 Ultra Pure
Fing
Far le ng is considered an
ultra pure ng. Water running
through this ng is
considered pure water.
15 Velcro™ Strap This strap helps secure installed
cartridges.
16 NFC Tag
Reader
Scans informaon from the NFC
(Near-Field Communicaon) tags
on the cartridges and relays it to
the control board.
17 Fing
Removal Tool
Aids in cartridge ng removal.
When not in use, aach tool to
the Velcro™ strap.
18
Grommet
Holder for the
Dispense
Hose Fing
(see 6A)
When not using the Dispense
Hose Fing (see 6A) store it in
the grommet holder so as not
to loose the part for later use.
19 Cartridges
(x4)
Cartridges contain dierent res-
ins to purify the water. Turn
unit on and follow direcons on
display, located in Mainte-
nance/Install New Cartridges or
follow instrucons listed on
LT0033-3 yer.
11
15
16
18
19
12
12
Image 2.6
Image 2.7
Image 2.8 Image 2.9
Table 2.10
14

PHOTO DIAGRAM OF THE RAPIDS™
LT0033-4
Ref. # Descripon Funcon
20 Conducvity
Cell
Measures the electrical conduc-
vity of the product water.
21 Water Pump
Pump provides opmal ow
rates for proper resin exchange
while in recirculaon mode and
22 Inlet Water
Solenoid
Allows supply water to enter
the unit.
23 Air Inlet
Solenoid
Assists in purging water during
depressurizaon cycle.
24 Recirculaon
Solenoid
Allows for recirculaon of
the water.
25 Dispense
Solenoid
Allows for dispense of high puri-
ty water at a rate of up to
2 liters/minute.
26 Display
Connector
Connects the unit to the display
board on the housing cover.
27 Pump Outlet Water exits the pump through
this tube into cartridge #1.
28 Pressure
Regulator
Regulates the pressure of the
unit water.
29 Control Board Controls all the major electronic
components of the unit.
21
20
24
25
23
22
26
27
29
28
Page 18
Image 2.11
Image 2.12
Table 2.13

DRAWINGS OF THE RAPIDS™
LT0033-3
Ref. # Descripon Funcon
1Housing
Cover
Houses the touchscreen display
and protects the mechanical
components of the unit.
2Cartridge
Cover
Aached by magnets, it covers
the installed cartridges.
5Touchscreen
Display
Screen that allows a user to op-
erate the Rapids™ unit.
6a Dispense
Hose Fing
Water will dispense from this
ng. If the oponal nal lter
is used, 6b, the ng will be
replaced by the nal lter, 6b.
7Air Filter The air lter aaches here and
lter the incoming air.
8Power Switch Toggle the switch up or down
will turn the unit on or o.
9Power Source
Connector
Connecon point for the power
cord and the unit.
10 Water Input
Connector
Connecon point for the tubing
from the water source to the
unit.
11 Metal Rods
Rods funcon as a hinge for
aaching the cartridge cover to
the unit. The boom of the
cover is secured with magnets.
13 Fings
Fings connect the tubes to
the cartridges. There are four
ngs on top and boom of
the cartridges.
14 Ultra Pure
Fing
Far le ng is considered an
ultra pure ng. Water running
through this ng is
16 NFC Tag
Reader
Scans informaon from the NFC
(Near-Field Communicaon) tags
on the cartridges and relays it to
the control board.
26 Display
Connector
Connects the unit to the display
board on the housing cover.
2
1
5
7
8
9
10
11
13
7
16
26
6a
6a
Page 19
Figure 2.14
Figure 2.15
Figure 2.16
Table 2.17
14

FLOW DIAGRAM OF THE RAPIDS™
29
Ref. # Part # Part Name
6b FL0016-10.2 µm Final Filter
21 PM-052 Conducvity Cell
22 PU0033-1Water Pump
22 PM0033-6Inlet Water Solenoid
23 PM0033-6Air Inlet Solenoid
24 PM0033-7Recirculaon Solenoid
25 PM033-3Dispense Solenoid
31
28
22
32
23
24
22
Ref. # Part # Part Name
28 PM0033-8Pressure Regulator
31 PM-036 Check Valve
32 PM-050 Check Valve
33 Refer to Kit Cartridge 1
34 Refer to Kit Cartridge 2
35 Refer to Kit Cartridge 3
36 Refer to Kit Cartridge 4
21
25
6b
36 35 34 33
Page 20
Figure 2.19
Table 2.18
LT0033-4
