Labtron 300DLX Series User manual

300DLX Series
Lightweight Single-Head
Stethoscope
Instructions for Use
Features:
• Unitweight2.5oz(70g)
• 13/4"(4.5cm)diameterdiaphragmwithnon-chillring
• WhitefirmthreadedPVCeartips
• Adjustableanodizedaluminumbinaurals
• FlexiblePVCtubing
• 22"(56.5cm)tubing;31.5"(80cm)totallength
• One-yearlimitedwarranty
*Thisproductisnotmadewithnaturalrubberlatex.
300DLX-INS-LAB-RevA16

300DLX-INS-LAB-RevA16 2
INTRODUCTION
Congratulations on your
purchase of the Labtron
300DLX Series Lightweight
Single Head Stethoscope! The
slim, lightweight, anodized
aluminum chestpiece easily
slides beneath a blood
pressure cuff, and the
binaurals are anatomically
adjustable to ensure a
comfortable, acoustically-
sealed aural t.
ImportantSafetyInformation
WARNING:Important!
Readandunderstand
theseinstructionsbefore
assemblingorusingtheLabtron300DLXSeriesStethoscope.
Ifyoudonotunderstandanypartofthesewarningsor
instructions,contactahealthcareprofessionalfordirection
intheuseofthisproduct.Ifthestethoscopeisnotproperly
assembled,personalinjuryanddamagetothestethoscope
couldresult.
WARNING: DONOTusethisproductwithoutproperinstruction
fromahealthcareprofessional.
WARNING:Ifcomponentsaredamagedormissing,contactyour
GFdistributorimmediately.DONOTusesubstituteparts.Use
onlyLabtronreplacementparts.Non-Labtronreplacementparts
couldcausepersonalinjuryanddamagetothestethoscope.
WARNING:CaliforniaProposition65WARNING:Thisproduct
containsachemicalknowntotheStateofCaliforniatocause
cancerandreproductiveordevelopmentalharm.
WARNING:GFHealthProducts,Inc.assumesnoresponsibility
foranydamageorinjurycausedbyimproperassembly,
installationoruseofthisproduct.
IntendedUse
The 300DLX Series Stethoscope is intended to facilitate the ability to
hear internal sounds. This unit is ideal for general examination and
blood pressure measurement.
Components
Included: stethoscope with diaphragm-only chestpiece, tubing,
binaurals, and one set of eartips.
Eartips
Diaphragm
Chestpiece
Tubing
Binaurals

300DLX-INS-LAB-RevA16 3
INSTRUCTIONSFORUSE
AdjustingtheBinauralTension
sNOTICE:Thebinauralsonlyneedtobe
adjustedslightly—DONOTsqueezeor
pullexcessively.
To tighten the binaurals, hold binaurals at
the base, at the bottom of the "Y", as shown at
right. Squeeze together gently until the eartips
cross and the desired tension is achieved.
To loosen the binaurals, grasp binaurals with
both hands above the "Y", as shown at right.
Pull binaurals apart gently until the desired
tension is achieved.
Operation
1. If not already assembled, screw eartips
into binaurals.
2. Clean the stethoscope (see the following
instructions).
3. Ensure binaurals are adjusted to a
comfortable tension. If not, follow previous
instructions to adjust binaural tension.
4. Gently insert binaural eartips into ears, ensuring the eartips are
pointing forward.
5. Tap the diaphragm softly; this should produce sounds clearly.
6. During use, in order to better hear different frequencies, vary the
amount of pressure on the diaphragm.
7. To ensure your stethoscope remains comfortable, check frequently
to ensure the eartips are tightly secured to the binaurals.
CARE,MAINTENANCE,ANDCLEANING
sNOTICE:DONOTsubjectthestethoscopetoextreme
temperaturesordirectsunlight.
sNOTICE:DONOTimmerseinliquid,sterilize,orapplysolventor
oiltothestethoscope.
Wipe stethoscope with a clean, soft, nonabrasive cloth dampened
with a mild soap and water solution, then dry with a clean, soft,
nonabrasive cloth. Clean stethoscope thoroughly before each use. If
disinfection is required, wipe the stethoscope with a 70% isopropyl
alcohol solution.
Remove and clean eartips as needed to prevent body secretions or
other foreign matter from entering the eartips or tubing. To remove,
grasp eartips rmly and unscrew them from binaurals. Reinstall eartips
immediately after cleaning.
Increase binaural tension (tighten)
Decrease binaural tension (loosen)
