LAEGENDARY TORNADO User manual

TROUBLESHOOTING
GUIDE
1:12 SCALE
TORNADO
RC CAR

2
Troubleshooting
TROUBLESHOOTING
PROBLEM SOLUTION
Scratched top The RCcarcomes with a protectiveplasticfilm that needs
to be removed prior to using thecar.
If a new truck shell is needed, it can be ordered through our
website www.laegendary.com
Steering not working
properly
1. Replacethe batteries ofthe remotewith brand new ones
and fully charge the car battery.
2. Turn o the switch on the transmitter, then on, and
pair again. Make sure not to touch the throttle when pairing.
3. Cleanthe steering arm set and make sure the arm is still in
place, connected to the car.
4. Check the light of the transparent wire coming out of the
car; it should be a solid red.
5. Unplug the wires connecting the servo and the ESC, then
pair the car with the transmitter again.
This is to check the defective part; if the car pairs with the
remote, then the servo might be the problem.
6. Servo and remote controller can be ordered through
our website www.laegendary.com
Reverse command
not responding
When the car is moving forward in order to go in reverse
please execute the following commands on the remote:
first throttle push will bring the car to a stop and in
neutral mode. The second throttle push will make the car
go in reverse. (please refer to Transmitter Instructions in
this User Manual)
Car going on its own
and not responding
correctly
Do not press any buttons on the remote control while
pairing with the car because it will recognize that command
every time.
Rebind the remote and car and turn them on within
3 seconds so you reset the commands and car
responds properly.

3
Troubleshooting
PROBLEM SOLUTION
Car will not pair with
the remote
1. Our Tornado car has a thermal protection feature.
When the ESC detects that the temperature is too high, it
will automatically start thermal protection.
Thus, it needs to be switched o and wait for a few minutes
to cool the temperature down.
2. Keep the remote and the car a few feet away from each
other while pairing.
3. Keep the remote and the car away from large metal
objects while pairing so there is no interference.
Wheels are not
spinning properly
1. Tighten the locknuts (Part Number TO-1013) that are
holding the wheels in place.
2. Check for any missing pieces like hub hex with shafts
(Part Number TO-1016) and/or rear dog bone
(Part Number TO-2002). If parts are missing, they can be
ordered through our website www.laegendary.com
3. If all parts are intact, the dierential may be broken and
needs to be replaced.
Stripping sound upon
accelerating
1. Inspect the car and make sure all the pieces are in place
and no foreign objects were caught up in it.
Please refer to the schematic in this User Manual to properly
check the parts.
2. Check the rear dierential (Part number TO-2000) if it is
working properly.
Make sure the dierential and/or rear dog bones are not
stripped or missing the pins.

PROBLEM SOLUTION
Battery/charger
not working
1. Solid red light on the charger – charger is plugged in.
2. Blinking red light – charger is defective.
3. Blinking green light on the charger – battery is plugged
in and charging.
4. Solid green light on the charger – battery is fully charged.
5. Blinking green light after 3-4hrs of charging – battery
is defective.
6. Please try charging the battery using the second USB
charger to determine which is defective.
Replacement batteries and chargers can be purchased
through our website www.laegendary.com
Rebinding the remote
control with the car
Turn on the remote control first and within 3 seconds turn
on the car as well in order to rebind them; if not successful,
repeat this action 2-3 times. If the pairing is still not
successful, the remote and/or the ESC needs to be replaced.
The car shuts o when
the remote is turned on
The servo had a short circuit and needs to be replaced.
Wheels come o the
car while running
1. Tighten the Locknuts before and after each play.
2. Apply a Locktite threadlocker to prevent it from
coming o
4
