Lafayette Instrument 76871V User manual

ASSEMBLY:
1) Attach the Right and Left Arm Assemblies (3,4)
to the Seat Assembly (1) using the 1/4-20 x 3/4
Socket Screws (9), 1/4-20 Split Washers (10),
and 5/16 Flat Washers (6) with the supplied Allen
wrench. See Figure 1.
2) Attach the Back Rest Assembly (2) to the Seat
Assembly (1) using the 1/4-20 x 1 1/2 Hex Bolts
(5), 5/16 Flat Washers (6), Bronze Bushings (7),
and 1/4-20 Hex Nuts (8). See Detail A.
3) Adjust the Back Rest to the desired position
and secure with the Locking Pins on the Right and
Left Arm Assemblies. See Figure 2.
Model 76871
Model 76871V
SUBJECT’S CHAIR
USER’S MANUAL

Lafayette Instrument Subject’s Chair
Model 76871V User’s Manual
