OPERATING AND PARTS MANUAL
PFLUX2 & PFLUX3 Next Generation
Mobile Dust Cyclone Collectors
Please read and save these instructions. Read carefully before attempting to assemble,
install, operate, or maintain the product described. Protect yourself and others by
observing all safety information. Failure to comply with instructions could result in
personal injury and/or property damage! Retain instructions for future reference.

Mobile Dust Cyclone Manual
1
Thank you for investing in a Laguna Tools PFLUX2 or PFLUX3 cyclone dust collector.
This cyclone is one of a family of unique machines proudly offered by Laguna Tools.
Every Laguna machine is engineered for years of dependable service. Please feel
free to contact Laguna Tools if you have a question or suggestion. We appreciate
working with you and your choice of a Laguna Tools machine for your shop.
Regards,
Torben Helshoj
President & Founder Laguna Tools
Dealer Machinery Warranty
New woodworking machines sold by Laguna Tools carry a two-year warranty effective from the
date of dealer invoice to consumer. Machines sold through dealers must be registered with
Laguna Tools within 30 days of purchase to be covered by this warranty. Laguna Tools
guarantees all new machine sold to be free of manufacturers’ defective workmanship, parts,
and materials. We will repair or replace, without charge, any parts determined by Laguna
Tools, Inc. to be a manufacturer’s defect. We require that the defective item/part be returned to
Laguna Tools with the complaint. An RMA (return merchandise authorization) must be
requested, from Laguna Tools, and included with any and all parts or machines returned to
Laguna Tools for warranty consideration. Any machines returned to Laguna Tools must be
returned with packaging in the same manner in which it was received. If a part or blade is
being returned it must have adequate packaging to ensure no damage is received during
shipping. In the event the item/part is determined to be damaged due to lack of maintenance,
cleaning or misuse/abuse, the customer will be responsible for the cost to replace the
item/part, plus all related shipping charges. This limited warranty does not apply to natural
disasters, acts of terrorism, normal wear and tear, product failure due to lack of maintenance or
cleaning, damage caused by accident, neglect, lack of or inadequate dust collection,
misuse/abuse or damage caused where repair or alterations have been made or attempted by
others.
This manual applies to the PFLUX2 and PFLUX3 cyclone dust collectors. Enter the
model number and serial number below for quick reference when ordering
accessories, supplies or parts. NOTE: The model and serial number plate can be
found on the Top Upright Support, on the right side near filter and ON/OFF switch.
Model: ___________
Serial: ___________
Laguna Tools
800-234-1976 www.lagunatools.com

Mobile Dust Cyclone Manual
2
CONTENTS
Warranty: 01
Safety: 03
Important Safety Instructions 04
General Safety Rules 08
Wiring Diagrams: 10
Power Connections 12
Power Supply 13
Programming Remote Control: 15
Unpacking: 16
Assembly: 17
Power Supply: 29
Operation: 30
Maintenance: 30
HEPA Filter Replacement 31
Trouble Shooting: 33
Parts Breakdown / Exploded Views: 39
Parts List 44
Specifications: 48
Supplies: 48

Mobile Dust Cyclone Manual
3
Warranty Registration
Register your machine at https://lagunatools.com/policies/warranty/
To prevent voiding this warranty, all products sold must be registered within thirty (30) days of
receiving the product. Registering the product will enable the original purchaser to receive
notifications about important product changes, receive customer service, and be able to file a warranty
claim against defective workmanship, parts, or materials.
SAFETY
READ AND UNDERSTAND THIS MANUAL AND ALL INSTRUCTIONS BEFORE USING THIS EQUIPMENT.
Failure to follow all instructions may result in electric shock, fire and/or serious personal injury or
property damage! Electronic copies of this manual are available at www.lagunatools.com.
SAFETY GUIDELINES - DEFINITIONS
This manual contains information that is important for you to know and understand. This
information relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS.
To help you recognize this information, we use the symbols below. Please read the manual
and pay attention to these sections.
Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate
injury.
(Used without the safety alert symbol) indicates a potentially hazardous situation which, if not avoided,
may result in property damage.

Mobile Dust Cyclone Manual
4
Woodworking (and similar materials) can be dangerous if safe and proper operating procedures are
not followed. As with all machinery, there are certain hazards involved with the operation of the
machine. Using the machine with respect and caution will considerably lessen the possibility of
personal injury. However, if normal safety precautions are overlooked or ignored, personal injury to
the operator may result. Safety equipment such as guards, push sticks, hold-downs, featherboards,
goggles, dust masks and hearing protection can reduce the potential for injury. Even the best guard
will not make up for poor judgement, carelessness, or inattention. Always use common sense and
exercise caution in the workshop. If a procedure feels dangerous, do not try it. Figure out an
alternative procedure that is safer. REMEMBER: Your personal safety is your responsibility.
IMPORTANT SAFETY INSTRUCTIONS
This machine was designed for certain applications only. We strongly recommend that this
machine not be modified and/or used for any application other than that for which it was
designed. If you have any questions relative to a particular application, DO NOT use the
machine until you have first contacted the manufacturer to determine if it can or should
be performed on the product.
If you have any questions relative to its application DO NOT use the product until you
have contacted the manufacturer and we have advised you.
When using an electrical appliance/machine, basic precautions should always be followed,
including the following:
READ ALL INSTRUCTIONS BEFORE USING (THIS APPLIANCE/MACHINE)
To reduce the risk of fire, electric shock, or injury:
1. Do not leave appliance when plugged in. Unplug from outlet when not in use and before
servicing.
2. Do not use outdoors or on wet surfaces
3. Do not allow to be used as a toy. Close attention is necessary when used by or near
children.
4. Use only as described in this manual. Use only manufacturer’s recommended
attachments.
5. Do not use with damaged cord or plug. If appliance is not working as it should, has
been dropped, damaged, left outdoors, or dropped into water, return it to a service
center.

Mobile Dust Cyclone Manual
5
6. Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord
around sharp edges or corners. Do not run appliance over cord. Keep cord away from
heated surfaces.
7. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
8. Do not handle plug or appliance with wet hands.
9. Do not put any object into openings. Do not use with any opening blocked; keep free of
dust, lint, hair, and anything that may reduce air flow.
10. Keep hair, loose clothing, fingers, and all parts of body away from openings and
moving parts.
11. Turn off all controls before unplugging.
12. Use extra care when cleaning on stairs.
13. Do not use to pick up flammable or combustible liquids, such as gasoline, or use in
areas where they may be present.
14. Connect to a properly grounded outlet only. See Grounding Instructions.
SAVE THESE INSTRUCTIONS
1. Read and understand the warnings posted on the machine and in this manual.
Failure to comply with all warnings may cause serious injury.
2. Replace the warning labels if they become obscured or removed.
3. This Portable Cyclone Dust Collector is designed and intended for use by properly
trained and experienced personnel only. If you are not familiar with the proper and
safe operation of this type of dust collector, do not use until proper training and
knowledge have been obtained.
4. Do not use this machine for other than its intended use. If used for other purposes,
LAGUNA TOOLS INC., disclaims any real or implied warranty and holds itself
harmless from any injury that may result from that use.
5. Always wear approved safety glasses/face shields while using this machine.
6. Before operating this dust collector, remove tie, rings, watches, and other jewelry,
and roll sleeves up past the elbows. Remove all loose clothing and confine long hair.
Non-slip footwear or anti-skid floor strips are recommended. Do not wear gloves.
7. Wear ear protectors (plugs or muffs) during extended periods of operation.
8. Some dust created by power sanding, sawing, grinding, drilling and other
construction activities contain chemicals known to cause cancer, birth defects or
other reproductive harm. Some examples of these chemicals are: (next page)

Mobile Dust Cyclone Manual
6
•Lead from lead-based paint.
•Crystalline silica from bricks, cement, and other masonry products.
•Arsenic and chromium from chemically treated lumber.
Your risk of exposure varies, depending on how often you do this type of work. To
reduce your exposure to these chemicals, work in a well-ventilated area and work
with approved safety equipment, such as face or dust masks that are specifically
designed to filter out microscopic particles.
9. Do not operate this machine while tired or under the influence of drugs, alcohol, or
any medication.
10.Make certain the switch is in the OFF position before connecting the machine to the
power source.
11.Make certain the machine is properly grounded.
12.Make all machine adjustments or maintenance with the machine unplugged from
the power source.
13.Form a habit of checking to see that all extra equipment such as adjusting keys,
wrenches, scrap, stock, and cleaning rags are removed away from the machine
before turning on.
14.Always keep safety guards in place when the machine is in use. If removed for
maintenance purposes, use extreme caution, and replace the guards immediately
when maintenance is complete.
15.Make sure the dust collector is on a flat even surface and the wheels locked in place
before use.
16.Check damaged parts. Before further use of the machine, a guard or other part that
is damaged should be carefully checked to determine that it will operate properly
and perform its intended function. Check for alignment of moving parts, binding of
moving parts, breakage of parts, mounting and any other conditions that may
affect its operation. A guard or other part that is damaged should be properly
repaired or replaced.
17.Provide for adequate space surrounding work area and non-glare, overhead
lighting.
18.Keep the floor around the machine clean and free of scrap material, oil, and grease.
19.Keep visitors a safe distance from the work area. Keep children away.

Mobile Dust Cyclone Manual
7
20.Make your workshop child proof with padlocks, master switches or by removing
starter keys.
21.Give your work undivided attention. Looking around, carrying on a conversation and
“horse-play” are careless acts that can result in serious injury.
.
22.Always maintain a balanced stance so that you do not fall or lean against the dust
collector. Do not overreach or use excessive force to perform any machine
operation.
23.Use the right tool at the correct speed and feed rate. Do not force a tool or
attachment to do a job for which it was not designed. The right tool will do the job
better and safer.
24.Use recommended accessories; improper accessories may be hazardous.
25.Maintain machinery with care. Follow instructions for lubricating and changing
accessories.
26.Turn off the machine before cleaning. Use a brush or compressed air to remove
dust or debris —do not use your hands.
27.Do not stand on the machine. Serious injury could occur if the machine tips over.
28.Never leave the machine running unattended. Turn the power off and do not leave
the machine until it comes to a complete stop.
29.Never operate or run the machine without closing the drum up against the lid.
Failure to do so will result in the machine amperage increasing and may trip your
circuit.
Familiarize yourself with the following safety notices used in this manual:
SAFETY GUIDELINES - DEFINITIONS
This manual contains information that is important for you to know and understand. This
information relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS.
To help you recognize this information, we use the symbols, described earlier. Please read
the manual and pay attention to these sections.

Mobile Dust Cyclone Manual
8
GENERAL SAFETY RULES
FAILURE TO FOLLOW THESE RULES MAY RESULT IN SERIOUS INJURY.
FOR YOUR OWN SAFETY, READ AND UNDERSTAND THE INSTRUCTION MANUAL
BEFORE OPERATING THE MACHINE. Learn the unit’s application and limitations as well
as the specific hazards peculiar to it.
KEEP WORK AREA CLEAN. Cluttered areas and benches invite accidents.
DON’T USE IN DANGEROUS ENVIRONMENT. Don’t use this unit in damp or wet
locations or expose it to rain. Keep work area well-lighted.
KEEP CHILDREN AND VISITORS AWAY. All children and visitors should be kept a safe
distance from work area.
DISCONNECT UNIT before servicing.
CHECK DAMAGED PARTS. Before further use of the unit, properly repair or replace any
part that is damaged.
FAILURE TO FOLLOW THESE RULES MAY RESULT IN SERIOUS INJURY.
ADDITIONAL SAFETY FOR DUST COLLECTORS
Intended use. This dust collector is only intended for collecting wood dust and chips from
woodworking machines. Do not use this dust collector to collect metal, dirt, pebbles,
drywall, asbestos, lead paint, silica, liquids, aerosols, or any flammable, combustible, or
hazardous materials.
Hazardous dust. Dust created while using machinery may cause cancer, birth defects, or
long-term respiratory damage. Be aware of dust hazards associated with each work piece
material, and always wear a NIOSH-approved respirator to reduce your risk.
Dust allergies. Dust from certain woods may cause an allergic reaction in people and
animals.
Make sure you know what type of wood dust you will be exposed to in case there is a
possibility of an allergic reaction.

Mobile Dust Cyclone Manual
9
Wear respirator. Fine dust that is too small to be caught in the filter will be blown into
the ambient air during operation. Always wear a NIOSH-approved respirator during
operation and for a short time after to reduce your risk of permanent respiratory damage.
Emptying dust. When emptying dust from the collection container, wear a respirator and
safety glasses. Empty dust away from ignition sources and into an approved container.
Disconnecting power supply. Turn the switch off, disconnect the dust collector from the
power supply, and allow the impeller to come to a complete stop before leaving the
machine unattended or doing any service, cleaning, maintenance, or adjustments.
Suspended dust particles and ignition sources. Do not operate the dust collector in
areas where explosion risks are high. Areas of high risk include, but are not limited to,
areas near pilot lights, open flames, or other ignition sources.
Fire suppression. Only operate the dust collector in locations that contain a fire
suppression system or have a fire extinguisher nearby.
Impeller hazards. Do not place your hands or tools near the open inlet during operation
for any reason. The powerful suction could easily cause accidental contact with the
impeller, which will
cause serious personal injury or damage to the machine. Always keep small animals and
children away from open dust collection inlets.
Avoiding sparks. Do not allow steel or rocks to strike the impeller—this may produce
sparks.
Sparks can smolder in wood dust for a long time before a fire is detected. If you
accidentally cut
Into wood containing tramp metal (nails, staples, spikes, etc.), immediately turn off the
dust collector, disconnect it from power, and wait for the impeller to stop—then empty the
collection container into an approved airtight metal container.
Operating location. To reduce respiratory exposure to fine dust, locate permanently
installed dust collectors away from the working area, or in another room that is equipped
with a smoke detector. Do not operate the dust collector in rainy or wet locations—
exposure to water may create a shock hazard or decrease the life of the machine.
Static electricity. Plastic dust lines generate high amounts of static electricity as dust
chips pass through them. Although rare, sparks caused by static electricity can cause
explosions or fire. To reduce this risk, make sure all dust lines are thoroughly grounded by
using a grounding wire.
Regular cleaning. Regularly check/empty the collection bags or drum to avoid the
buildup of fine dust that can increase the risk of fire. Make sure to regularly clean the

Mobile Dust Cyclone Manual
10
surrounding area where the machine is operated—excessive dust buildup on overhead
lights, heaters, electrical panels, or other heat sources will increase the risk of fire.
SAVE THESE INSTRUCTIONS.
Refer to them often and use them to instruct others.
WIRING DIAGRAMS
POWER CONNECTIONS
Figure 1: Power Connections & Wiring

Mobile Dust Cyclone Manual
11
CONTROL PANEL
Figure 1A: Control Panel

Mobile Dust Cyclone Manual
12
SECONDARY JUNCTION BOX
Figure 2: Internal Wiring
DO NOT EXPOSE THE MACHINE TO RAIN OR OPERATE THE MACHINE IN DAMP
LOCATIONS.
MOTOR SPECIFICATIONS
Your machine is wired for 220 volts, 60 HZ alternating current. Before connecting the
machine to the power source, make sure the switch is in the "OFF" position. An (appx.) 8’
cord is included, a “plug” is NOT included. A plug must be installed by a qualified
technician.
GROUNDING INSTRUCTIONS
THIS MACHINE MUST BE GROUNDED WHILE IN USE TO PROTECT THE OPERATOR FROM
ELECTRIC SHOCK.
1. This appliance must be connected to a grounded metal, permanent wiring system; or
an equipment-grounding conductor must be run with the circuit conductors and connected
to the equipment-grounding terminal or lead on the appliance.

Mobile Dust Cyclone Manual
13
The installer, such as a qualified electrician, cut (or bend over) and insulate the grounding
conductor from a field wiring supply cable.
In the event of certain types of malfunctions or breakdowns, grounding provides a path of
least resistance for electric current—to reduce the risk of electric shock.
Improper connection of the equipment-grounding wire can result in a risk of electric
shock. The wire with green insulation (with or without yellow stripes) is the equipment-
grounding wire. If repair or replacement of the power cord or plug is necessary, do not
connect the equipment-grounding wire to a live (current carrying) terminal.
Check with a qualified electrician or service personnel if you do not understand these
grounding requirements, or if you are in doubt about whether the tool is properly
grounded. If you ever notice that a cord or plug is damaged or worn, disconnect it from
power, and immediately replace it with a new one.
Full Load a mperage Draw
PFLUX2 (2HP/220V/60HZ/Single phase) Amp draw at 220V ................... 14 Am ps
PFLUX3 (3HP/220V/60HZ/Single phase) Amp draw at 220V ................... 22 Am ps
Power Supply Circuit Requirements
The power source c i r cu i t for your m a ch i ne must be g r o u n d e d and r a t e d f o r the
amperage g iv en below. Never replace a circuit breaker on an exist ing circuit with
one of higher amperage without consulting a qualified electrician to ensure
compl i ance with wiring codes. If you are unsure about the wiring codes in your
area or plan to connect your machine to a shared circuit, consult a qualified
electrician.
PFLUX2 (2HP/220V/60HZ/Single phase) C i r cu i t Size ( 220 V ) ......... 20 A m p
m i n i m u m
PFLUX3 (3HP/220V/60HZ/Single phase) C i r cu i t Size ( 220 V ) ......... 30 A m p
m i n i m u m
IN ALL CASES, MAKE CERTAIN THE RECEPTACLE IN QUESTION IS PROPERLY GROUNDED.
IF YOU ARE NOT SURE, HAVE A QUALIFIED ELECTRICIAN CHECK THE RECEPTACLE.
220 VOLT Single-Phase Operation
The motor supplied with your machine is a 220 Volt motor. It is shipped ready-to-run for
220 Volt operation. An (appx.) 8’ cord is included; a “plug” is NOT included. A plug must
be installed by a qualified technician.

Mobile Dust Cyclone Manual
14
FUNCTION
Figure 3: High Frequency Remote Control Receiver and Manual Switch
HEPA Filter detection –will illuminate when filter cleans (automatic cleaning/override)
Full drum detection –when drum is full, buzzer* will constantly sound off and light will illuminate.
*When the drum is close to 70%-80% full; intermittent buzzing will occur; this is a normal state.
ON/OFF Switch –turns cyclone ON or OFF.
On board circuit breaker –Pops out if machine overloads. Press to reset.
Override –Press for (3) seconds to activate override cleaning while the cyclone is ON. You can also
activate this function by pressing the CLEAN button on the handheld remote for (3) seconds.
Receiver SET button –Used to program receiver.
ON/OFF Illuminate drum –controls the LED light on the drum lid to illuminate inside the drum for
visuals of the dust level.
Figure 4: Handheld Remote
PROGRAMMING THE REMOTE CONTROL
Requires a 12V, type 27A alkaline battery.
OFF button
ON button
*Remote set button
*Used to match up a new handheld
control with the remote switch
CLEAN button
ON/OFF Switch
Receiver SET button
Full drum detection
*includes sound alert.
HEPA Filter detection
On board circuit breaker
Override
ON/OFF button to
illuminate drum

Mobile Dust Cyclone Manual
15
1. Confirm the machine is switched ON before programming the remote control.
2. Press the black set button on the bottom of the remote switch until you hear two beeps.
3. Press the Remote set button on your handheld controller simultaneously with the black
button until you hear three beeps to complete the set up.
Figure 5: Receiver Set Button
MULTIPLE HANDHELD REMOTE CONTROL SETUP
You can pair up to five (max.) handheld remotes. Each handheld remote needs to be set
up individually following the programming steps above. If you set up a sixth handheld
remote, it will override the first handheld remote. If a seventh handheld remote is setup,
it will override the second handheld remote. And so on.
UNPACKING
Receiver set button

Mobile Dust Cyclone Manual
16
The Mobile Dust Cyclone comes packed in a single box. Before attempting to assemble
this machine, follow these directions for unpacking:
1. Carefully cut the banding straps and remove them from the box.
2. Cut along the tape line at the top of the box.
3. Remove all parts from the top of the foam and set aside.
4. Remove the foam packing material from the top of the machine and set aside for further
use, during assembly.
5. Cut the cardboard box (top to bottom) in the four corners for easy removal of the box.
6. Carefully take out the machine components from the box and set aside.
7. Using the diagram below, ensure that all parts are present and in good condition.
DESCRIPTION (QUANTITY) Figure 6:
A. Motor
B. Remote controller + Manual
C. Dust chute
D. Canister shield (front and back)
E. Top upright supports (3)
F. Canister cover plate
G. Drum insert (4)
H. HEPA Canister filter
I. Filter rotation shaft
J. Filter cleaning arm (2)
K. Crossbar
L. Collection bag for drum (3)
M. Cyclone funnel
N. Cyclone barrel
O. Intake cylinder
P. Octagon drum (front and back panel)
G
J
K
M
N
Q
R
S
U
W
X
Y
Y
Y1
Y2
Y3
Hardware
box
Manual
AD
A
B
C
D
E
O
K
AA
A
AB
B
Z
F
A
C
D
E
G
AC
I
J
L
K
P
T
V
Q. Drum lid
R. Foot pedal bar
S. Filter end cap with 4”suction port
T. Octagon drum base panel
U. Lower upright supports (3)
V. Drum side plate (left and right)
W. Upright support reinforcement plate (3)
X. Foot pedal bar (left and right)
Y. Foot pedal assembly fittings
Y1. Lower triangular support plate (2)
Y2. Foot pedal bar support (2)
Y3. Lower support plate (2)
Z. Intake Reducer (8”by 6”) PFLUX2 only
AA. Intake adapter (6”by 4”x 2 ports) PFLUX2 only
AB. Intake adapter (8”by 4”x 3 ports) PFLUX3 only
AC. Autoclean plate
AD. Hardware box
H

Mobile Dust Cyclone Manual
17
Report any missing or damaged parts to your dealer or distributor. Prior to tool
assembly and use, read this manual thoroughly to familiarize yourself with proper
assembly, maintenance, and safety procedures.
ASSEMBLY
This step requires two adults. This Mobile Dust Cyclone is heavy, be
careful when lifting and handling it! Failure to comply may cause serious
injury and/or damage to the machine and/or property!
Tools/items Required:
10mm wrench / 12mm wrench / 14mm wrench
Phillips screwdriver
4mm hex wrench / 5mm hex wrench
Plug for cord, 3 wire
To assemble your dust cyclone, follow these steps:
For your own safety, do not connect the machine to the power source until
the machine is completely assembled. Please also make sure that you read
and understand the entire instruction manual.
ASSEMBLY TIME ESTIMATE 5 to 6 hours
Visit the Laguna Tools Video page for setup assistance.

Mobile Dust Cyclone Manual
18
1. Remove (2) 5/16”x 5/8”hex
bolts on the motor plate (shown
by red arrow). Install (2) 5/16”eye
bolts (not supplied) on the motor
plate. With the help of another
person, lift the upper cyclone
assembly using a forklift. Make
sure to hold the opposite side of
the dust chute to prevent swaying
while lifting the assembly up.
2. Remove the base which has
been bolted to the (3) top upright
supports. Keep the (6) 3/8”x3/4”
hex bolts and (6) 3/8”flat washers
for assembling the lower supports
to the base. Keep the upper
assembly lifted for step 5.
3. Turn base upside-down. Use (16)
5/16”x 3/4”hex bolts and (16) 5/16”
flat washers. Attach the (2) 4” casters
with brakes to the base. The casters
with brakes should be attached to the
side with the opening. The remaining
(2) 4”swivel casters must attach to
the other side of the base.
4. Turn the base over with it
standing on the (4) 4” casters and
secure the three lower upright
support panels using (6) 3/8” x
3/4” hex bolts and (6) 3/8” x 7/8”
flat washers.
A –shown with one dot is located
on the canister side.
B –shown with two dots is located
on the front side.
C –shown with three dots is
located on the opposite end.
A
B
C
A
B
C
Swivel caster
Swivel caster
With brakes

Mobile Dust Cyclone Manual
19
5. With the help of another person
carefully lift the upper cyclone
assembly high enough to place on
stands that you have completed in
steps 3 and 4. Take note on
precisely positioning the upper
cyclone assembly onto the three
lower upright supports. Using (6)
5/16”x 3/4”hex bolts and (6) 5/16”
flat washers connect and secure the
upper and lower upright supports.
*The forklift is no longer required
for the next steps.
6. Secure the (3) upright support
reinforcement plates using (12)
5/16” x 3/4” hex bolts and (12)
5/16” x 1” flat washers.
7. Take the intake cylinder, cyclone
barrel and cyclone funnel and install
3 x 6mm foam tape to the rims on
each location shown.
- Top rim of the intake cylinder
- Top rim of the cyclone barrel
- Top and lower rim of cyclone
funnel
