INSTRUCTION BOOKLET
Model: 19704
MINI ICE CREAM
MAKER

2
LAKELAND MINI ICE CREAM MAKER
Thank you for choosing the Lakeland Mini Ice Cream Maker.
Please take a little time to read this booklet before you use your machine and keep it in a
safe place for future reference.
The Ice Cream Maker makes mini portions of your favourite flavours of home-made ice
cream, sorbet and frozen yoghurt quickly and easily from fresh ingredients. It’s simple
to use, pre-freeze the bowl, add the lid, switch on and pour your mixture through the
opening. The maker will churn and stir to a creamy, smooth consistency. The compact
500ml bowl is small enough to store in your freezer ready for next time.
An award winning family-owned business, here at Lakeland we still have the same values
of excellent quality, value for money and exceptional customer care as we did when we
first set up the company in the 1960s.
Our products are carefully selected and rigorously tested to meet our high standards, so
you can be assured that any product you purchase will be easy-to-use and highly durable.
CONTENTS
Product features..............................................................................................................3
Safety cautions.............................................................................................................4-5
How to assemble the Mini Ice Cream Maker ....................................................................6
Instructions for use .........................................................................................................7
A guide to ingredients.....................................................................................................8
Adapting your own recipes..............................................................................................8
Hints and tips..................................................................................................................9
Recipes ....................................................................................................................10-13
Troubleshooting ............................................................................................................14
Care and cleaning .........................................................................................................14
Recycling your electricals ...............................................................................................15
Electrical connections....................................................................................................15

3
PRODUCT FEATURES
1. Bowl
2. Paddle
3. Lid
4. Motor
5. On/Off switch
6. Plug and cord
1
2
45
6
3

4
SAFETY CAUTIONS
Carefully read all the instructions before using the appliance and keep in a safe place
for future reference. Always follow these safety cautions when using the appliance to
avoid personal injury or damage to the appliance. This appliance should be used only as
described in this instruction book.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be done by
children unless they are older than 8 and supervised.
• Make sure your electricity supply matches the voltage shown on the appliance.
• Ensure all packaging materials and any promotional labels or stickers are removed from
the appliance before the first use.
• Always inspect the appliance before use for noticeable signs of damage. Do not use if
damaged or has been dropped. In the event of damage, or if the appliance develops a
fault contact the Lakeland customer care team on 015394 88100.
• Do not use this appliance if the lead is damaged. If the lead is damaged it must be
replaced with a special lead. Contact the Lakeland customer care team on
015394 88100.
• Always use the appliance on a dry, level, heat resistant surface.
• Unplug from the mains when not in use and before cleaning. To disconnect, turn the
socket to “off “and remove the plug from the mains socket.
• Do not use any accessories or attachments with this appliance other than those
recommended by Lakeland.
• To protect against fire, electric shock or personal injury, do not immerse cord, plug or lid
in water or other liquids.
• Do not leave the lead hanging over the edge of a kitchen table or worktop. Avoid
contact between the lead and hot surfaces.
• For indoor use only.
• For domestic use only.
• This appliance should be used for preparation of food as described within the
instructions for use that accompany it.

5
• Always ensure that your hands are dry before removing the plug from the mains socket.
Never pull the plug out of the mains socket by its lead.
• To avoid injury or possible fire, do not cover the appliance when in use.
• Do not connect this appliance to an external timer or remote control system.
• An extension cable may be used with care. The electrical rating of the cable should be
at least as great as the appliance. Do not allow the cable to hang over the edge of the
worktop or touch any hot surfaces.
• This appliance complies with the basic requirements of Directives 04/108/EC
(Electromagnetic Compatibility) and 06/95/EC (Safety of Domestic Electrical Appliances).
• WARNING: A cut off plug inserted into a 13amp socket is a serious safety (shock)
hazard. Ensure the cut off plug is disposed of safely.
• CAUTION: The plastic bags used to wrap this appliance or the packaging may be
dangerous. To avoid risk of suffocation, keep these bags out of reach of babies and
children. These bags are not toys.
• Keep the appliance, plug and lead away from hot ovens, electric and gas burners,
flames and hot surfaces.
• Never use the appliance in areas where certain vapours may be present (paint thinner,
flammable material, oil based paint and varnish, flammable liquids and gases) for risk of
a possible explosion.
• To prevent freezer burn, protect your hands when handling the freezer bowl, especially
when first removing it from the freezer. Never touch with wet hands.
• When the appliance is churning, do not attempt to move it, and never put your hands
or any utensils inside.
• Never attempt to take the freezer bowl apart. If the freezer bowl appears to be leaking
or damaged discontinue use. The freezing solution inside the bowl is non toxic.
• Ice cream or sorbet which contains raw eggs should not be given to children, pregnant
women or the elderly.
• Never refreeze ice cream that has been fully or partially defrosted.
• The paddle will change stirring direction if your recipe becomes too frozen to avoid the
motor overheating. Stop the machine immediately, the ice cream is ready. In the unlikely
event of overheating, the motor has a safety cut out and will automatically stop. Switch
off and unplug the appliance, and allow the motor to cool.

6
HOW TO ASSEMBLE THE MINI ICE CREAM MAKER
WARNING: Do not insert the plug into an electrical outlet, or turn on the Mini Ice Cream
Maker before you have fully assembled it.
1. Unpack the Mini Ice Cream Maker, remove all the packaging materials.
2. Before first use, wipe the motor with a clean damp cloth, dry.
3. Wash the bowl, lid and paddle in warm soapy water, rinse and dry.
4. Place the lid on a flat surface, for example a kitchen
table. Press the motor into the lid. You will hear a
click when it is connected correctly.
7. The Ice Cream Maker is now
ready to use.
6. Place the lid, motor and paddle
on top of the freezer bowl, lining
up the notches on the lid with the
grooves on the bowl. Twist the lid
anti-clockwise to lock it.
5. Insert the paddle into the bottom of the motor.

7
INSTRUCTIONS FOR USE
BEFORE USE:
Place the bowl in the freezer for 8-12 hours before use. The compact 500ml bowl is small
enough to store alone in your freezer ready to use whenever you want ice cream.
1. Choose a recipe and prepare your mixture and let it cool, chill in the fridge for 1-2
hours. Warm or room temperature ingredients will prolong the preparation time.
2. Take the bowl from the freezer and attach the lid with the motor and paddle.
WARNING: Use a dry towel to hold the freezer bowl. Direct contact with the frozen
bowl may make your hands stick to the freezer bowl. If this happens, hold your hands
under warm running water for a few moments. Never touch with wet hands.
3. Insert the plug into the socket and switch on. Press the On/Off switch to ‘On’, the
paddle will start mixing.
4. Pour your mixture into the bowl through one of the openings in the lid.
Note: The Mini Ice Cream Maker must be switched on with the paddle turning
before adding your mixture into the bowl. This stops the mixture immediately
freezing against the inside wall of the bowl.
DO NOT pour too much mixture into the bowl. Use no more than 350ml of mixture
to allow it room to expand. When the appliance is churning, do not attempt to move
it and never put your hands or any utensils inside.
5. Let the Ice Cream Maker run until the ice cream has reached the correct consistency.
The preparation time depends on the recipe and the temperature of the ingredients
and the room.
The paddle will change stirring direction if your recipe becomes too frozen to avoid
the motor overheating. Stop the machine immediately, the ice cream is ready. In the
unlikely event of overheating, the motor has a safety cut out and will automatically
stop. Switch off and unplug the appliance, and allow the motor to cool.
Do not turn off the Ice Cream Maker before the ice cream is ready. If it is switched off
too early the ingredients may freeze against the inside wall of the
freezer bowl.
6. When your ice cream is ready, turn off the Ice Cream Maker at the On/Off switch and
at the socket and unplug.
7. Use a plastic or wooden spoon or spatula to scoop the ice cream from the bowl.
Metal spoons or spatulas can cause damage to the bowl. Serve the ice cream or
transfer to a separate container and store in your freezer.

8
A GUIDE TO INGREDIENTS
The beauty of home-made ices are you can tailor the ingredients to your tastes and dietary
requirements, and use seasonal fruits to flavour. For some simple ideas to get you started
see RECIPES.
• Ice cream or sorbet that contains raw or partially cooked eggs should not be given to
young children, pregnant women, the elderly or people who are generally unwell.
• Using alcohol in mixtures slows down freezing so only use small amounts to add flavour
and allow for extra freezing time.
• Chill your ingredients/mixture for 1-2 hours before making ice cream, to help it
set quicker.
• Any ice cream or sorbet recipes will work in the machine, but do not add more than
350ml of mixture to the bowl at one time, to allow it to expand as it freezes.
• Make sure all the ingredients are thoroughly mixed, the sugar has completely dissolved
and the mixture has cooled before pouring your mixture into the Ice Cream Maker.
• For the fullest flavour, choose ripe fruits. Wash carefully, remove all seeds, skin and core,
and chop into small pieces.
ADAPTING YOUR OWN RECIPES
After you have made some of the recipes supplied you may wish to adapt a few of your
own recipes. Start by selecting one of the recipes in this booklet, which is similar to your
own and use this as a guide.

9
HINTS AND TIPS
• Place the bowl in the freezer for 8-12 hours before use. Ideally store the bowl in the
freezer so it is ready to use whenever you want ice cream.
• Remove ice cream you have frozen from the freezer 5 minutes before serving, to allow
it to soften.
• To prevent freezer burn, protect your hands when handling the freezer bowl, especially
when first removing it from the freezer. Never touch with wet hands. Use oven gloves
or put the bowl in a plastic bag before freezing.
• Use no more than 350ml of mixture in the bowl to allow it room to expand.
• Use the Ice Cream Maker in a cool room with chilled ingredients to speed up the ice
cream making process.
• Never refreeze ice cream that has been fully or partially defrosted.
• Any ice cream or sorbet containing raw ingredients should be consumed within one
week. Ice cream tastes best when fresh.
• The times indicated in these recipes are guidelines. The actual preparation time depends
on the ingredients used, the temperature of the ingredients and the room temperature.
Monitor the mixture through the transparent lid.

10
RECIPES
Please note all spoon measures given in these recipes use standard metric measuring
spoons e.g. 5ml is 1 tsp and 15ml is 1 tbsp, and we recommend you use a set of
measuring spoons for accuracy. These recipes are great to serve as a dessert or as an
accompaniment to other puddings.
Whole milk 100ml
Double cream 25ml
Egg yolk 1
Granulated sugar 50g
Vanilla bean paste ¼ tsp
Ingredients 1 portion
1.Heat the milk and cream until they are simmering, remove from the heat.
2.Combine the egg yolk, sugar and vanilla bean paste. Pour the heated milk mixture over
them and stir to combine and dissolve the sugar. Return to the heat and gently bring to
the boil. Remove from the heat.
3.Transfer to a clean jug, allow the mixture to cool slightly then refrigerate for 1-2 hours
until chilled.
4.Follow the directions in ‘How to assemble the Mini Ice Cream Maker’ and ‘Instructions
for use’. Churn the mixture for 15-20 minutes until it has reached a soft scooping
consistency.
You can use this recipe as a base and add other ingredients and flavours.
VANILLA ICE CREAM

11
Water 50ml
Caster sugar 100g
Unwaxed lemons zest of 2, juice of 5
Ingredients 1 portion
1.Boil the water in a pan, add the sugar and stir until it has dissolved. Allow the mixture
to simmer for 5 minutes until it thickens a little. Remove from the heat.
2.Stir in the lemon zest and juice, transfer the mixture to a clean jug, allow to cool slightly
then refrigerate for 1-2 hours until chilled.
3.Follow the directions in ‘How to assemble the Mini Ice Cream Maker’ and ‘Instructions
for use’. Churn the mixture for 15-20 minutes until it has reached a soft scooping
consistency.
This recipe is a great palate cleanser between courses and is also wonderful served with
other desserts.
LEMON SORBET

12
Caster sugar 25g
Pecan nuts 25g, chopped
Double cream 75ml
Whole milk 90ml
Egg yolks 2
Soft dark brown sugar 60g
Butter caramel flavouring 6 drops
Ingredients 1 portion
1. Heat the caster sugar over a low heat in a small heavy-based pan until it has melted to
liquid. Add the chopped pecans, stir them to coat them well, then remove them from
the pan and spread them on a sheet of Magic Liner or greaseproof paper. Allow them
to cool and set.
2. Heat the milk and cream until they are simmering and them remove from the heat.
3. Combine the egg yolk, sugar and butter caramel flavouring in a bowl. Pour the heated
milk mixture in and stir to combine and dissolve the sugar. Return the whole mixture to
the heat and gently bring to the boil. Remove from the heat.
4. Transfer the mixture to a clean jug, allow to cool slightly then refrigerate for 1-2 hours
until chilled.
5. Follow the directions in ‘How to assemble the Mini Ice Cream Maker’ and ‘Instructions
for use’. Churn the mixture for 15-20 minutes until it has reached a soft scooping
consistency.
6. Chop up the caramelised pecans with a knife, stir the pieces through the ice cream
and serve.
BUTTER CARAMEL ICE CREAM WITH CARAMELISED PECAN NUTS

13
Skimmed milk 100ml
Egg 1, beaten
Honey/Agave syrup 1 tsp
Vanilla extract 1 tsp
Yoghurt, low or full fat 100ml
Ingredients 1 portion
1. Heat the milk until simmering and remove from heat.
2. Combine the egg and honey or agave syrup and vanilla extract. Pour the heated milk
mixture over them and stir to combine and dissolve the ingredients. Return the mixture
to the heat and gently bring to the boil. Remove from the heat.
3. Transfer to a clean jug, allow to cool slightly then add the yogurt and whisk to mix well.
Refrigerate for 1-2 hours until chilled.
4. Follow the directions in ‘How to assemble the Mini Ice Cream Maker’ and ‘Instructions
for use’. Churn the mixture for 15-20 minutes until it has reached a soft scooping
consistency.
You can add fruit purées to this recipe, or other flavours.
FROZEN YOGURT

14
Problem Possible cause Solution
The paddle is not turning. The appliance is not switched on
or there is a build up of frozen
ingredients at the bottom of the
bowl.
Check the power is on, then use
a non-metallic spatula to free any
mixture from the base of the bowl.
To avoid this happening again,
always turn paddle on first and
then add the mixture to the bowl.
The appliances has cut out, or
the paddle has changed mixing
direction.
The mixture is too thick for
the appliance. The motor has
overheated and the safety cut-out
has come on.
The ice cream is thick enough to
eat. Switch off the appliance and
serve. Allow the appliance to fully
cool before it is used again.
The mixture won’t freeze. The bowl is not frozen enough, or
there is a high alcohol level in the
mixture.
Always freeze the bowl for 8-12
hours before using. Ideally keep
in the freezer when not in use.
Alcohol stops freezing, so only use
small amounts in recipes.
TROUBLESHOOTING
The following are some common problems that can occur when using the Mini Ice Cream
Maker. Please review the problems, their possible cause and any corrective action that
should be taken.
CARE AND CLEANING
• Before the first use and after every use, clean each part thoroughly.
• Periodically check all parts before reassembly.
• Always switch off and unplug the Mini Ice Cream Maker from the wall socket before
cleaning.
• Let the freezer bowl come back up to room temperature before cleaning.
• Wash the inside and outside of the freezer bowl by hand with a soft cloth and warm
soapy water, then dry.
• Wash the lid and paddle in warm soapy water. Rinse well, then dry.
• Wipe the motor with a damp clean cloth, then dry thoroughly.
• CAUTION: Never immerse the motor or power cord in water or any
other liquids.
• Do not use abrasive cleaners, bleaching agents or metal scourers on any parts. This will
damage the appliance.
• Do not place any parts in the dishwasher.
• Make sure that the appliance and attachments are completely clean and dry before you
store them.
• Store the motor with the power cable loosely coiled. Never wrap it tightly around the
appliance. Store the bowl in the freezer so it is ready when you need it next, and store
the other parts separately.

15
ELECTRICAL CONNECTIONS
This appliance is fitted with a fused three-pin plug to BS1363 which is suitable for use
in all homes fitted with sockets to current specifications. If the fitted plug is not suitable
for your socket outlets, it should be cut off and carefully disposed of. To avoid an electric
shock, do not insert the discarded plug into a socket.
This product is a Class II electrical appliance and does not include an earth wire.
Fitting a new plug
If for any reason you need to fit a new plug, the flexible mains lead must be connected
as shown here. The wires in the mains lead fitted to this appliance are coloured in
accordance with the following code:
Connect BLUE to Neutral (N)
Connect BROWN to Live (L)
3 amp fuse to be used
If the colours of the wires in the mains lead of this appliance do not correspond with the
coloured markings identifying the terminals in your plug, proceed as follows. The wire
which is coloured blue MUST be connected to the terminal which is marked with the letter
N (Neutral). The wire which is coloured brown MUST be connected to the terminal which
is marked with the letter L (Live).
Before refitting the plug cover, check that there are no cut or stray strands of wire inside
the plug. Use a 3 amp BS1362 fuse. Only BSI or ASTA approved fuses should be used. If
you are at all unsure which plug or fuse to use, always refer to a qualified electrician.
Note: After replacing or changing a fuse on a moulded plug which has a fuse cover, the
cover must be refitted to the plug; the appliance must not be used without a fuse cover.
If lost, replacement fuse covers can be obtained from an electrical shop. This appliance
complies with the following EU Directives: 2006/95/EC (Low Voltage Directive) and
2004/108/EC (EMC Directive).
RECYCLING YOUR ELECTRICALS
Along with many other high street retailers, Lakeland has joined a
scheme whereby customers can take their unwanted electricals to
recycling points set up around the country.
Visit www.recycle-more.co.uk to find your nearest recycling point.
3 amp fuse
BS1362

16
MINI-EISMASCHINE

17
GEBRAUCHSANWEISUNG
Modell: 70150
MINI-EISMASCHINE

18
LAKELAND MINI-EISMASCHINE
Vielen Dank, dass Sie sich für den Kauf der Mini-Eismaschine von Lakeland entschieden
haben.
Bitte lesen Sie sich diese Anleitung vor der Inbetriebnahme Ihres neuen Geräts aufmerksam
durch und bewahren Sie sie gut auf, falls Sie später auf die hier enthaltenen Informationen
zurückgreifen möchten.
Mit der Eismaschine von Lakeland stellen Sie selbstgemachtes Eis und Sorbet sowie
Frozen Yogurt schnell und bequem aus frischen Zutaten und in all Ihren Lieblingssorten
her. Die Eismaschine ist einfach in der Anwendung: Schüssel im Voraus einfrieren,
Deckel aufsetzen, Maschine einschalten und Ihre Eismasse durch die Öffnung einfüllen.
Die Eismaschine rührt die Eismasse, bis sie eine cremig-glatte Konsistenz angenommen
hat. Die kompakte 500 ml Schüssel ist klein genug, um sie für das nächste Mal im
Gefrierschrank aufzubewahren.
Unser mehrfach ausgezeichneter Familienbetrieb legt heute genauso viel Wert auf ein
Höchstmaß an Qualität, ein gutes Preis-Leistungsverhältnis und einen hervorragenden
Kundenservice wie damals in den 60er Jahren, als Lakeland gegründet wurde.
Unsere Artikel werden mit größter Sorgfalt ausgewählt und im Einklang mit unseren
strengen Standards gründlich geprüft. So haben Sie die Gewähr, dass jeder Artikel, den Sie
bei uns kaufen, ebenso benutzerfreundlich wie haltbar ist.
INHALT
Ausstattungsmerkmale..................................................................................................19
Sicherheitshinweise ..................................................................................................20-21
Montageanleitung für die Mini-Eismaschine ..................................................................22
Gebrauchsanweisung....................................................................................................23
Zutaten im Überblick.....................................................................................................24
Verwendung eigener Rezepte........................................................................................24
Tipps und Tricks.............................................................................................................25
Fehlersuche...................................................................................................................26
Pflege und Reinigung ....................................................................................................27

19
AUSSTATTUNGSMERKMALE
1. Schüssel
2. Rührschlegel
3. Deckel
4. Motorblock
5. Ein/Aus-Schalter
6. Netzstecker und Netzkabel
1
2
45
6
3

20
SICHERHEITSHINWEISE
Lesen Sie sich die Gebrauchsanweisung vor Inbetriebnahme des Geräts sorgfältig durch
und bewahren Sie diese für den weiteren Gebrauch sicher auf. Befolgen Sie beim
Gebrauch des Geräts stets diese Sicherheitshinweise, um Körperverletzungen oder
Schäden am Gerät zu vermeiden. Dieses Gerät ist nur für den vorgesehenen Zweck gemäß
der Beschreibung in dieser Gebrauchsanweisung vorgesehen.
•Dieses Gerät darf von Kindern ab 8 Jahren und Personen
mit verminderter körperlicher, sensorischer oder geistiger
Fähigkeit oder mit fehlenden Erfahrungen und Kenntnissen
nur dann verwendet werden, wenn sie von einer Person, die
für ihre Sicherheit verantwortlich ist, beaufsichtigt werden
und sie im Gebrauch und hinsichtlich der potentiellen
Gefahren des Geräts unterwiesen wurden. Dieses Gerät ist
kein Spielzeug. Das Gerät darf nicht von Kindern unter 8
Jahren benutzt werden. Kinder ab 8 Jahren dürfen das Gerät
nur unter Aufsicht benutzen und reinigen.
• Stellen Sie sicher, dass Ihre Stromversorgung mit der auf dem Gerät angegebenen
Spannung übereinstimmt.
• Entfernen Sie vor der ersten Ingebrauchnahme alle Verpackungsmaterialien sowie
Werbeetiketten vom Gerät.
• Vergewissern Sie sich stets vor Gebrauch des Produkts, dass es keine erkennbaren
Schäden aufweist. Verwenden Sie es nicht, falls es Schäden aufweist oder versehentlich
fallen gelassen wurde. Wenden Sie sich im Falle von Schäden oder Defekten am Gerät
an den Kundenservice von Lakeland unter der Rufnummer 0800 444 1500.
• Verwenden Sie das Produkt nicht, falls das Netzkabel beschädigt ist. Sollte das Netzkabel
Schäden aufweisen, muss es durch ein Spezialkabel ersetzt werden. Kontaktieren Sie
den Kundenservice von Lakeland unter der Rufnummer 0800 444 1500.
• Stellen Sie das Gerät zum Gebrauch stets auf einer trockenen, ebenen und
hitzebeständigen Fläche auf.
• Ziehen Sie den Netzstecker bei Nichtgebrauch und vor der Reinigung des Geräts aus
der Netzsteckdose. Um das Gerät abzuschalten, bedienen Sie den Ein/Aus-Schalter und
ziehen den Netzstecker aus der Netzsteckdose.
• Verwenden Sie nur die von Lakeland empfohlenen Zubehörteile oder Einsätze.
• Tauchen Sie Netzkabel, Netzstecker, Deckel oder Gerät nicht in Wasser oder andere
Flüssigkeiten ein. Es besteht Brand-, Stromschlag- und Verletzungsgefahr!
• Lassen Sie das Netzkabel nicht vom Küchentisch oder von der Arbeitsplatte
herunterhängen. Sorgen Sie dafür, dass das Netzkabel nicht mit heißen Oberflächen in
Berührung kommt.
• Nur für Innenräume.
• Nur für den häuslichen Gebrauch.
