Lanner PGN-750 User manual

1
PGN-750
User Manual
Version: 1.0
Date of Release: 2022-06-29
Vehicle Computing

PGN-750 User Manual
2
This manual describes the overview of the various functionalities of this product, and the information you
need to get it ready for operation. It is intended for those who are:
-responsible for installing, administering and troubleshooting this system or Information Technology
professionals.
-assumed to be qualified in the servicing of computer equipment, such as professional system
integrators, or service personnel and technicians.
The latest version of this document can be found on Lanner’s official website, available either through the
product page or through the Lanner Download Center page with a login account and password.
This document is copyrighted © 2022 by Lanner Electronics Inc. All rights are reserved. The original
manufacturer reserves the right to make improvements to the products described in this manual at any
time without notice.
No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means
without the prior written permission of the original manufacturer.
Information provided in this manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, nor for any infringements upon the rights of third
parties that may result from such use.
All other product names or trademarks are properties of their respective owners.
Your feedback is valuable to us, as it will help us continue to provide you with more accurate and relevant
documentation. To provide any feedback, comments or to report an error, please email to
[email protected]m, Thank you for your time.

PGN-750 User Manual
3
Taiwan Corporate Headquarters
Lanner Electronics Inc.
7F, No.173, Sec.2, Datong Rd.
Xizhi District, New Taipei City 22184,
Taiwan
立端科技股份有限公司
221 新北市汐止區
大同路二段 173 號7樓
T: [phone]
F: [phone]
E: [email protected]m
China
Beijing L&S Lancom Platform Tech. Co., Ltd.
Guodong LOFT 9 Layer No. 9 Huinan Road,
Huilongguan Town, Changping District, Beijing
102208 China
T: [phone]
F: [phone]
E: [e-mail]
USA
Lanner Electronics Inc.
47790 Westinghouse Drive
Fremont, CA 94539
T: [phone]
F: [phone]
E: [e-mail]
Canada
Lanner Electronics Canada Ltd
3160A Orlando Drive
Mississauga, ON
L4V 1R5 Canada
T: [phone]
F: [phone]
E: [e-mail]
Europe
Lanner Europe B.V.
Wilhelmina van Pruisenweg 104
2595 AN The Hague
The Netherlands
T: [phone]
E: [e-mail]

PGN-750 User Manual
4
Follow these guidelines to ensure general safety:
Keep the chassis area clear and dust-free during and after installation.
Do not wear loose clothing or jewelry that could get caught in the chassis. Fasten your tie or scarf and roll up your
sleeves.
Wear safety glasses if you are working under any conditions that might be hazardous to your eyes.
Do not perform any action that creates a potential hazard to people or makes the equipment unsafe.
Disconnect all power by turning off the power and unplugging the power cord before installing or removing a
chassis or working near power supplies
Do not work alone if potentially hazardous conditions exist.
Never assume that power is disconnected from a circuit; always check the circuit.
Suivez ces consignes pour assurer la sécurité générale :
Laissez la zone du châssis propre et sans poussière pendant et après l’installation.
Ne portez pas de vêtements amples ou de bijoux qui pourraient être pris dans le châssis. Attachez votre cravate ou
écharpe et remontez vos manches.
Portez des lunettes de sécurité pour protéger vos yeux.
N’effectuez aucune action qui pourrait créer un danger pour d’autres ou rendre l’équipement dangereux.
Coupez complètement l’alimentation en éteignant l’alimentation et en débranchant le cordon d’alimentation avant
d’installer ou de retirer un châssis ou de travailler à proximité de sources d’alimentation.
Ne travaillez pas seul si des conditions dangereuses sont présentes.
Ne considérez jamais que l’alimentation est coupée d’un circuit, vérifiez toujours le circuit. Cet appareil génère,
utilise et émet une énergie radiofréquence et, s’il n’est pas installé et utilisé conformément aux instructions des
fournisseurs de composants sans fil, il risque de provoquer des interférences dans les communications radio.
Electrical equipment generates heat. Ambient air temperature may not be adequate to cool equipment to
acceptable operating temperatures without adequate circulation. Be sure that the room in which you choose to
operate your system has adequate air circulation.
Ensure that the chassis cover is secure. The chassis design allows cooling air to circulate effectively. An open
chassis permits air leaks, which may interrupt and redirect the flow of cooling air from internal components.
Electrostatic discharge (ESD) can damage equipment and impair electrical circuitry. ESD damage occurs when
electronic components are improperly handled and can result in complete or intermittent failures. Be sure to follow
ESD-prevention procedures when removing and replacing components to avoid these problems.
Wear an ESD-preventive wrist strap, ensuring that it makes good skin contact. If no wrist strap is available, ground
yourself by touching the metal part of the chassis.
Periodically check the resistance value of the antistatic strap, which should be between 1 and 10 megohms
(Mohms).
L’équipement électrique génère de la chaleur. La température ambiante peut ne pas être adéquate pour refroidir
l’équipement àune température de fonctionnement acceptable sans circulation adaptée. Vérifiez que votre site
propose une circulation d’air adéquate.
Vérifiez que le couvercle du châssis est bien fixé. La conception du châssis permet à l’air de refroidissement de bien
circuler. Un châssis ouvert laisse l’air s’échapper, ce qui peut interrompre et rediriger le flux d’air frais destiné aux
composants internes.
Les décharges électrostatiques (ESD) peuvent endommager l’équipement et gêner les circuits électriques. Des
dégâts d’ESD surviennent lorsque des composants électroniques sont mal manipulés et peuvent causer des pannes
totales ou intermittentes. Suivez les procédures de prévention d’ESD lors du retrait et du remplacement de
composants.
Portez un bracelet anti-ESD et veillez à ce qu’il soit bien au contact de la peau. Si aucun bracelet n’est disponible,
reliez votre corps à la terre en touchant la partie métallique du châssis.
Vérifiez régulièrement la valeur de résistance du bracelet antistatique, qui doit être comprise entre 1 et 10
mégohms (Mohms).

PGN-750 User Manual
5
Packge Content.............................................................................................................................6
Ordering Information ...................................................................................................................6
System Specifications...................................................................................................................6
Setting up the PGN Module..........................................................................................................8
Mounting Omni Antennas..........................................................................................................10
Warranty Policy ..........................................................................................................................11

PGN-750 User Manual
6
Lanner PGN-750 is a 5G Pigeon (PGN) module, compatible with Lanner Vehicle Computers. PGN-750
supports a built-in 5G radio modem, backward compatible with 4G/LTE, in addition to SIM card readers, four
5G antenna jacks and indoor/outdoor omni-directional antenna/cable kit, in addition to a hot-swappable
interface for maximum flexibility. To assure constant connectivity, PGN-750 offers failover mechanism for
24/7 operation. The module is optimally designed for public safety, video surveillance and in-vehicle SD-
WAN applications.
1x PGN-750 5G Pigeon Module
4x External Omni-directional Antennas and Cables
SKU No.
Main Features
PGN-750
Swappable 5G Quectel RM500Q-AE module with antenna/cable kit. (Options for
Thales MV31-W and Telit FN980 5G modules)
System Compatibility
Lanner Vehicle PC V3S
Interface
Connector
SATA connector with USB 3.0 signal
M.2
1x M.2 3042/50/52 B-Key socket with dual-SIM card reader
Environmental Parameters
Temperature
-40~70ºC Operating,
-40~85ºC Non-Operating
Humidity (RH)
5%~90% RH, Non-condensing
System Dimensions
Size (WxDxH)
75 x 115.97 x 14.5mm
Weight
0.4kg
Approvals and Compliance
CE/FCC

PGN-750 User Manual
7

PGN-750 User Manual
8
To reduce the risk of personal injury, electric shock, or damage to the system, please remove all power
connections and wear ESD protection gloves when handling the installation steps.
The PGN module kit contains the following
items:
1x PGN Module
4x Antennas
Installing SIM Cards
1. Locate the SIM card holder on the bottom
sides (one right, one left) of the PGN
module.
2. Insert and push the SIM card all the way in
until it clicks into place.
3. To remove the SIM card, push the card once, and the card will automatically eject.
PGN-750 Module
4x Antennas
Left Side
SIM 2
Right Side
SIM 1
SIM 1
SIM 2

PGN-750 User Manual
9
Switch Pin Coordination
SKU No.
5G Model No.
Switch Pin
PGN-750A
Reserved
3-2
PGN-750B
RM500Q-AE
2-1
Installing PGN Module
1. Locate the PGN module slot on the panel
of the system. (Placement of the module
slot will be different based the system.)
2. Insert the PGN module. (Image is for
reference only.)
3. Once the module is firmly seated, secure
with two (2) screws.
4. Secure the four (4) antennas on the front
side of the PGN module.
5. Installation has now been completed.
Switch Pin
3 –2 –1

PGN-750 User Manual
10
PGN-750 comes with 4x omni-directional dipole antennas and cable kit that can be mounted indoors or
outdoors on a mast/pole.
Specification
Each antenna mounting kit contains the following items:
1x Omni Antenna & Cable
1x Surge Arrester
1x L Bracket
1x Pole-clamp
1x 1/4” U-bolt
2x Flat washer
2x Spring washer
2x 1/4” Wing nut
1x Lock washer
1x HEX. Hut
Installing Omni Antenna
Usage Environment
Indoor / Outdoor
Frequency Range
3300~ 4800 MHz
Impedance
50 Ohms
Type/Polarization
Dipole, Vertical
Cable Length
2000mm
Antenna Dimensions (HxW)
231mm x 23mm
Operating Temperature Range
-20°C ~ 70°C
Mounting
Mast/Pole, Pole diameter: 1.5”~2.0” max
Pole
1/4” U-bolt
Pole-clamp
L Bracket
HEX. Nut
Lock washer
1/4” Wing nut
Spring
washer
Flat
washer
Antenna

PGN-750 User Manual
11
TERMS AND CONDITIONS
1. All products are under warranty against defects in materials and workmanship for a period of one year
from the date of purchase.
2. The buyer will bear the return freight charges for goods returned for repair within the warranty period;
whereas the manufacturer will bear the after-service freight charges for goods returned to the user.
3. The buyer will pay for repair (for replaced components plus service time) and transportation charges
(both ways) for items after the expiration of the warranty period.
4. If the RMA Service Request Form does not meet the stated requirement as listed on “RMA Service, “RMA
goods will be returned at customer’s expense.
5. The following conditions are excluded from this warranty:
Improper or inadequate maintenance by the customer
Unauthorized modification, misuse, or reversed engineering of the product
Operation outside of the environmental specifications for the product.
1. To obtain an RMA number, simply fill out and fax the “RMA Request Form“ to your supplier.
2. The customer is required to fill out the problem code as listed. If your problem is not among the codes
listed, please write the symptom description in the remarks box.
3. Ship the defective unit(s) on freight prepaid terms. Use the original packing materials when possible.
4. Mark the RMA# clearly on the box.
Note: Customer is responsible for shipping damage(s) resulting from inadequate/loose packing
of the defective unit(s). All RMA# are valid for 30 days only; RMA goods received after the
effective RMA# period will be rejected.

PGN-750 User Manual
12
When requesting RMA service, please fill out the following form. Without this form enclosed, your RMA
cannot be processed.
