Lanner FW-8759 User manual

Network
Application Platforms
Hardware platforms for next generation networking infrastructure
FW-8759
V1.0
User's Manual
August 14, 2015

Overview
Icon Descriptions
The icons are used in the manual to serve as an
indication of interest topics or important messages.
Below is a description of these icons:
NOTE: This check mark indicates
that there is a note of interest and is
something that you should pay special
attention to while using the product.
WARNING: This exclamation point
indicates that there is a caution or
warning and it is something that could
damage your property or product.
Online Resources
The listed websites are links to the on-line product
information and technical support.
Resource Website
Lanner http://www.lannerinc.com
Product Resources http://www.lannerinc.com/support/
download-center
Copyright and Trademarks
This document is copyrighted © 2014. All rights are
reserved. The original manufacturer reserves the right to
make improvements to the products described in this
manual at any time without notice.
No part of this manual may be reproduced, copied,
translated or transmitted in any form or by any means
without the prior written permission of the original
manufacturer. Information provided in this manual
is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its
use, nor for any infringements upon the rights of third
parties that may result from such use.
Acknowledgement
Intel, Pentium and Celeron are registered trademarks of
Intel Corp.
Microsoft Windows and MS-DOS are registered
trademarks of Microsoft Corp.
All other product names or trademarks are properties of
their respective owners.
Compliances
CE
This product has passed the CE test for environmental
specifications. Test conditions for passing included
the equipment being operated within an industrial
enclosure. In order to protect the product from being
damaged by ESD (Electrostatic Discharge) and EMI
leakage, we strongly recommend the use of CE-
compliant industrial enclosure products.
FCC Class A
This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference when the equipment is operated in a
commercial environment. This equipment generates,
uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction
manual, may cause harmful interference to radio
communications. Operation of this equipment in a
residential area is likely to cause harmful interference
in which case the user will be required to correct the
interference at his own expense.

EMC Notice
This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference when the equipment is operated in a
commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction
manual, may cause harmful interference to radio
communications. Operation of this equipment in a
residential area is likely to cause harmful interference
in which case users will be required to correct the
interference at their own expense.
Safety Guidelines
Follow these guidelines to ensure general safety:
Keep the chassis area clear and dust-free during and•
after installation.
Do not wear loose clothing or jewelry that could get•
caught in the chassis. Fasten your tie or scarf and roll
up your sleeves.
Wear safety glasses if you are working under any•
conditions that might be hazardous to your eyes.
Do not perform any action that creates a potential•
hazard to people or makes the equipment unsafe.
Disconnect all power by turning off the power and•
unplugging the power cord before installing or
removing a chassis or working near power supplies
Do not work alone if potentially hazardous•
conditions exist.
Never assume that power is disconnected from a•
circuit; always check the circuit.
LITHIUM BATTERY CAUTION:
Risk of Explosion if Battery is replaced by an incorrect
type. Dispose of used batteries according to the
instructions.
Installation only by a trained electrician or only by•
an electrically trained person who knows all English
Installation and Device Specifications which are to
be applied.
Do not carry the handle of power supplies when•
moving to other place.
The machine can only be used in a fixed location•
such as labs or computer facilities.
Operating Safety
Electrical equipment generates heat. Ambient air•
temperature may not be adequate to cool equipment to
acceptable operating temperatures without adequate
circulation. Be sure that the room in which you choose to
operate your system has adequate air circulation.
Ensure that the chassis cover is secure. The chassis design•
allows cooling air to circulate effectively. An open chassis
permits air leaks, which may interrupt and redirect the flow
of cooling air from internal components.
Electrostatic discharge (ESD) can damage equipment and
impair electrical circuitry. ESD damage occurs when electronic
components are improperly handled and can result in complete
or intermittent failures. Be sure to follow ESD-prevention
procedures when removing and replacing components to avoid
these problems.
Wear an ESD-preventive wrist strap, ensuring that it makes•
good skin contact. If no wrist strap is available, ground
yourself by touching the metal part of the chassis.
Periodically check the resistance value of the antistatic•
strap, which should be between 1 and 10 megohms
(Mohms).
Rack Mounting Installation Environment Precaution
Elevated Operating Ambient - If installed in a closed1.
or multi-unit rack assembly, the operating ambient
temperature of the rack environment may be greater than
room ambient. Therefore, consideration should be given
to installing the equipment in an environment compatible
with the maximum ambient temperature (Tma) specified
by the manufacturer.
Reduced Air Flow - Installation of the equipment in a rack2.
should be such that the amount of air flow required for
safe operation of the equipment is not compromised.
Mechanical Loading - Mounting of the equipment in the
rack should be such that a hazardous condition is not
created due to uneven mechanical loading.
Mechanical Loading - Mounting of the equipment in the3.
rack should be such that a hazardous condition is not
achieved due to uneven mechanical loading.
Circuit Overloading - Consideration should be given to4.
the connection of the equipment to the supply circuit and
the effect that overloading of the circuits might have on
over-current protection and supply wiring. Appropriate
consideration of equipment nameplate ratings should be
used when addressing this concern.
Reliable Earthing - Reliable earthing of rack-mounted5.
equipment should be maintained. Particular attention
should be given to supply connections other than direct
connections to the branch circuit (e.g. use of power strips).”

Consignes de sécurité
Suivez ces consignes pour assurer la sécurité générale :
Laissez la zone du châssis propre et sans poussière•
pendant et après l’installation.
Ne portez pas de vêtements amples ou de bijoux qui•
pourraient être pris dans le châssis. Attachez votre
cravate ou écharpe et remontez vos manches.
Portez des lunettes de sécurité pour protéger vos•
yeux.
N’effectuez aucune action qui pourrait créer un•
danger pour d’autres ou rendre l’équipement
dangereux.
•
Coupez complètement l’alimentation en éteignant•
l’alimentation et en débranchant le cordon
d’alimentation avant d’installer ou de retirer un
châssis ou de travailler à proximité de sources
d’alimentation.
Ne travaillez pas seul si des conditions dangereuses•
sont présentes.
Ne considérez jamais que l’alimentation est coupée•
d’un circuit, vérifiez toujours le circuit. Cet appareil
génère, utilise et émet une énergie radiofréquence
et, s’il n’est pas installé et utilisé conformément aux
instructions des fournisseurs de composants sans
fil, il risque de provoquer des interférences dans les
communications radio.
Avertissement concernant la pile au
lithium
Risque d’explosion si la pile est remplacée par une•
autre d’un mauvais type.
Jetez les piles usagées conformément aux•
instructions.
L’installation doit être effectuée par un électricien•
formé ou une personne formée à l’électricité
connaissant toutes les spécifications d’installation et
d’appareil du produit.
Ne transportez pas l’unité en la tenant par le câble•
d’alimentation lorsque vous déplacez l’appareil.
La machine ne peut être utilisée qu’à un lieu fixe•
comme en laboratoire, salle d’ordinateurs ou salle de
classe.
Sécurité de fonctionnement
L’équipement électrique génère de la chaleur. La•
température ambiante peut ne pas être adéquate
pour refroidir l’équipement à une température de
fonctionnement acceptable sans circulation adaptée.
Vérifiez que votre site propose une circulation d’air
adéquate.
Vérifiez que le couvercle du châssis est bien•
fixé. La conception du châssis permet à l’air de
refroidissement de bien circuler. Un châssis ouvert
laisse l’air s’échapper, ce qui peut interrompre et
rediriger le flux d’air frais destiné aux composants
internes.
Les décharges électrostatiques (ESD) peuvent•
endommager l’équipement et gêner les circuits
électriques. Des dégâts d’ESD surviennent lorsque
des composants électroniques sont mal manipulés et
peuvent causer des pannes totales ou intermittentes.
Suivez les procédures de prévention d’ESD lors du
retrait et du remplacement de composants.
- Portez un bracelet anti-ESD et veillez à ce qu’il soit
bien au contact de la peau. Si aucun bracelet n’est
disponible, reliez votre corps à la terre en touchant la
partie métallique du châssis.
Vérifiez régulièrement la valeur de résistance du
bracelet antistatique, qui doit être comprise entre 1 et
10 mégohms (Mohms).
Consignes de sécurité électrique
Avant d’allumer l’appareil, reliez le câble de mise à la•
terre de l’équipement à la terre.
Une bonne mise à la terre (connexion à la terre) est•
très importante pour protéger l’équipement contre
les effets néfastes du bruit externe et réduire les
risques d’électrocution en cas de foudre.
Pour désinstaller l’équipement, débranchez le câble•
de mise à la terre après avoir éteint l’appareil.
Un câble de mise à la terre est requis et la zone•
reliant les sections du conducteur doit faire plus de 4
mm2 ou 10 AWG.
Procédure de mise à la terre pour source
d’alimentation CC Procédure de mise à la
terre pour source d’alimentation CC
Desserrez la vis du terminal de mise à la terre.•
Branchez le câble de mise à la terre à la terre.•
L’appareil de protection pour la source•
d’alimentation CC doit fournir 30 A de courant.
Cet appareil de protection doit être branché à la
source d’alimentation avant l’alimentation CC.

Version Date (Y/M/D) Description
0.1 2014/05/09 Preliminary
0.2 2014/08/01 -Take o Fan4
-Take o LED2 from the motherboard
1.0 2015/08/14 Ocial release

Table of Contents
Chapter 1: Introduction 7
System Specifications 7
Package Contents 8
Optional Accessories 8
Front Panel Features 9
Rear Panel Features 11
Chapter 3: Motherboard Information 12
Block Diagram 12
Motherboard Layout 13
Jumper Settings & Connector Pinouts 14
Chapter 2: Hardware Setup 20
Preparing the Hardware Installation 20
System Memory Installation 20
Hard Disk Installation 20
CPU and the Heat Sink Installation 22
CompactFlash Card Installation 23
IPMI Card Installation 23
Front Ethernet Module Installation 24
Riser Card Installation (optional) 24
Chapter 4: BIOS Settings 26
Updating the BIOS 26
Accessing the BIOS menu 26
Appendix A: Programming Watchdog Timer 41
Appendix B: Setting up Console Redirections 41
Appendix C: Programming the LCM 42
Appendix D: Programming Generation 2 and 3 LAN Bypass 43
Appendix E: Terms and Conditions 44

Chapter 1:
Introduction
Thank you for choosing FW-8759. The new system is
powered by the currently latest Intel Core Processors,
codenamed Shark Bay, with the Intel C226 Series chipset.
It supports up to 8GB of DDR3 system memory at
1600MHz on dual-channel DIMM banks.
FW-8759 is equipped with advanced I/O capacity
which includes a RJ-45 console port, two PCIe x8 (PCIe
Generation 3.0) gold finger connected directly to the CPU
for front Ethernet module as well as rear expansion, 3
Serial-ATA ports (comply with SATA Standard 3.0 or 2.0), a
CompactFlash slot, and an OPMA slot, etc.
The system also leverages Intel Active Management
Technology (Intel AMT), a hardware-based manageability
solution that offers the following management benefits:
Out of Band (OOB) access through the iAMT port•
(LAN8) allows remote management of PCs regardless
of system power or OS state
Remote troubleshooting and recovery significantly•
reduces desk-side visits and increases IT efficiency
Proactive alerting and event logging decreases•
downtime and minimizes time to repair
Remote HW and SW asset tracking eliminates time-•
consuming manual inventory tracking an reduces
asset accounting costs
The onboard Ethernet ports be configured with Lanner
Generation 3 bypass, which is a proprietary bypass
technology designed by Lanner to support uninterrupted
network connection even when a system is turned off
or operating system is not functioning. The system can
also accommondate one Ethernet module to provide
additional 2 10GbE or 8 GbE LAN ports.
Please refer to the chart below for a summary of the
system’s specifications.
System Specifications
Form Factor Rackmount 1U
Platform Processor Options
4th Generation Intel® Xeon
E3-1200 v3 or CoreTM i7/i5/i3 series
processor with C226 (Codenamed
“Denlow”)
Chipset C226
OS Support
Windows 7,8,2000, XP, Vista, Server
2008, 2012, Linux Kernel 2.6 or
above
BIOS AMI BIOS 64Mb
System Memory
Technology
Dual-channel DDR3/DDR3L
1066/1333/1600 MHz, un-buffered,
non-ECC or ECC
Max. Capacity 8 GB
Socket 2 x 240-pin DIMM
Storage HDD Bays 2 x 2.5 HDD/SSD kit (1x3.5”
reserved)
CF/SD 1 x CF card Type II
Networking
Ethernet Ports 8 x GbE RJ-45 onboard, Maximum
up to 16 ports (with LAN module)
Bypass 3 pair G3 LAN Bypass (optional)
Controllers 1x Intel i217, 7 x Intel i210AT
Ethernet Modules 1
Management Port 1x GbE RJ45
I/O Interface
Reset Button 1 reset button
Console 1 x RJ45
USB 2 x USB 2.0
IPMI via OPMA slot By project
Display N/A
Expansion PCIe
1 x PCIE x8 expansion for NIC
Module, 1 x Low-prole PCI-E *8
(Optional)
PCI N/A
Cooling
Processor CPU heatsink with fan duct
System 3 x cooling Fan with smart fan
control
Environmental
Parameters
Temperature,
ambient operating /
non-operating
0 ~ 40º C / -20~70º C
Humidity (RH),
ambient operating
/ ambient non-
operating
5~90%, non-condensing / 5~95%,
non-condensing
Miscellaneous
LCD Module 2 x 20 LCM with keypad
Watchdog Yes
Internal RTC with Li
Battery Yes
Physical
Dimensions
Dimensions
(WxHxD) 438 x 44 x 415 mm
Weight 10 Kg
Power Type / Watts 220W/300W ATX Power Supply
Input AC 100-240V 50-60Hz
Approvals and Compliance CE Class A, FCC Class A, RoHS

Package Contents
Your package contains the following items:
FW-8759 Network Security Platform•
Power cable•
1 RJ-45 to DB-9 (female) console cable•
Serial-ATA hard drive cable•
1 threaded screw set•
1 ear bracket set•
Drivers and user’s manual CD.•
Optional Accessories
The system has a variety of optional accessories, visit the
following website for more information.
http://www.lannerinc.com/products/x86-network-
appliances/x86-rackmount-appliances/fw-8759
FW-8759A
4th Generation Intel® Xeon E3-1200 v3 or CoreTM i7/i5/i3
series processors with C226 chipset,8 Intel GbE LAN ports with
Gen.3 Bypass, 300W ATX PSU
Ordering Information

Front Panel Features
F1, F10 Power/Status/HDD LED
Power: If the LED is on it indicates that the system is powered on. If it is off, it indicates that the system is powered off.
Status: This LED is programmable. You could program it to display the operating status with the following behavior:
If the LED is green, it indicates that the system’s operational state is normal. If it is red, it indicates that the system is
malfunctioning.
HDD: If the LED blinks, it indicates data access activities; otherwise, it remains off.
F2 LCD System Panel with keypad
F3 Reset Switch
F4 Console Port
By using suitable rollover cable or RJ-45 to DB-9 console cable, you can connect to a computer terminal for diagnostic or
configuration purpose.
F5 Two USB 2.0 Ports
F6 Ethernet Ports (LAN1-LAN2: bypass pair, LAN3-LAN4: bypass pair; LAN5-LAN6: bypass pair)
LINK/ACT (Yellow)
On/Flashing: The port is linking and active in data transmission.•
Off: The port is not linking.•
SPEED (Green/Amber)
Amber: The connection speed is 1000Mbps.•
Green: The connection speed is 100Mbps•
Off: The connection speed is 10Mbps.•
3 pairs (LAN1-LAN2, LAN3-LAN4, LAN5-LAN6) can be configured as LAN bypass (Lanner Generation 3) when failure events
occur. This feature can be enabled with a watch dog timer.
F7 LAN7 IPMI Port (provided by Intel i210)1
F8 Intel iAMT Management Port (provided by Intel i217)
This port equips with Intel iAMT, which allows IT to better discover, heal, and protect their network computing assets. To
enter the Intel AMT setup menu, press CTRL-P when prompted during system boot process. It is also a serial over LAN (SOL)
port whose console redirection parameters can be configured in the BIOS menu. (You don’t need to enable the iAMT in the
BIOS; however, you will need to download the Intel AMT driver in order to emulate serial communication over a network
connection.
F9 Swappable Ethernet Modules
Note:
The IPMI port is optional.1.
F1
F2
F3 F4 F6
LAN1 LAN2 LAN3 LAN4 LAN5 LAN6 LAN7 LAN8
(bypassed pair) (bypassed pair) (bypassed pair)
F7 F8
F5 F9
F10

Slim Module Ports Chipset Bypass
NCS2-IGM428A 4 GbE RJ45 Intel i350AM-4 2 pairs Gen3
NCS2-IGM428B 4 GbE RJ45 Intel i350AM-4 N/A
NCS2-ISM405A 4 GbE SFP Fiber Intel I350-AM4 2 pairs
NCS2-ISM406A 4 GbE SFP Fiber Intel I350-AM4 N/A
NCS2-ISM802A 8 GbE SFP Fiber Intel i350AM-4 N/A
NCS2-IXM205A 2 10GbE SFP+ Intel 82599 1 pair Gen3
NCS2-IXM405A 4 10GbE SFP+ Intel 82599 N/A
Compatible Modules

Rear Panel Features
R1
FAN3 FAN2 FAN1
R1 Optional PCIe Expansion Slot (low profile PCIe expansion card)
R2 Power-on Switch
It is a switch to turn on or off the power.
R3 FAN1~FAN3
These fans have smart fan feature which can be turned on automatically when the temperature exceeds the set
threshold.
R4 Redundant Power Supply
The 300W redundant power supply is hot-swappable and can be withdrawn and replaced when the alarm sounds. You
can turn off the alarm when it sounds by pressing the alarm switch. To replace the failed power supply unit, press the
latch to release the unit and pull it out.
R3
23
PSU LED
PSU latch
R4
Alarm-off Switch

Chapter 3:
Motherboard Information
Block Diagram
The block diagram depicts the relationships among the
interfaces or modules on the motherboard. Please refer
to the following figure for your motherboard’s layout
design.

Motherboard Layout
The motherboard layout shows the connectors and
jumpers on the board. Refer to the following picture
as a reference of the pin assignments and the internal
connectors.
CF1
COMB2
J11
OPMA1
FAN3
LCM1
J6
SATA1
SATA3
SATA2
DIO1
ATX2 FAN2
PCIESLOT1
DIMM2/DIMM1
J3
J4
J5
J1
PCIESLOT2
FAN1
ATX1
CON3
SPIROM1
80PORT1
VGA1
COMB1
CONN4
CONN1
SW2
USB1
J12
J8
J7
J13
CONN5
CON1
CON2

Note:
To configure your Hard disk using the1.
integrated RAID feature, the Intel®Rapid
Storage Technology Utility has to be installed
on your Operating System.
You will need to select the RAID mode in the2.
BIOS for your SATA drives first. There is also a
Intel®RSTe OpROM utility for creating RAID
volume; to enter the RSTe OpROM, press Ctrl-I
during POST.
For operating systems other than Microsoft3. ®
Windows Vista and Windows®7, it is
required to pre-install the Intel Rapid Storage
Technology driver during the F6 installation of
Windows setup (“press F6 if you need to install
a third party SCSI or RAID driver....”).
Visit the Intel support page at http://www.intel.
com/p/en_US/support/highlights/chpsts/imsm
for more information and download links.
The Intel controller hubs are also supported4.
by Linux. Beginning with Linux kernel
version 2.6.27, the mdadm utility 3.0
supports RAID 0, RAID 1, RAID 5, and RAID
10. To use the RAID features in dmraid and
mdadm, you will need to set up the RAID
volume using the Intel® Matrix Storage
Manager option ROM (click CTRL + I when
prompted during boot to enter the option
ROM user interface).
SATA1/SATA2/SATA3: supports SATA 3.0/SATA2.0/ SATA
2.0 connection respectively
SATA HDD Power Connector (CON1/CON2):
Jumper Settings & Connector Pinouts
Fan Connectors(FAN1/FAN2/FAN3): The 5-pin
connector is for connecting the CPU and system
fans. It comes with the smart fan feature by which
the fans could be monitored and turned on when
the temperature exceed the set threshold.
DIMM Socket (DIMM1/DIMM2): The 240-pin DDR3
DIMM is for connecting the DDR3/DDR3L 1600 MHz.
The system can support up to 8 GB in maximum. A
DDR3 module has the same physical dimensions as a
DDR2 DIMM but the notch on the pins is positioned
differently.
Note: Since the system is capable of dual
channel architecture, both DIMMs have to be
populated to enable dual channel mode.
SATA 1, 2 and 3 Connectors (SATA1/SATA2/
SATA3): It is for connecting a SATA harddisk to
be served as your system’s storage. The system can
accommodate 2 disks (2.5") in maximum. SATA
1complies fully with SATA Revision 3.0 standard
with data transfer rates of up to 6.0 Gb/s; SATA 2,
3comply with SATA Revision 2.0 standard.The
controller contains two modes of operation—a
legacy mode using I/O space, and an AHCI mode
using memory space. Software that uses legacy
mode will not have AHCI capabilities.
You will need to configure your disk to one of the
3 modes of SATA configuration, i.e., IDE, RAID,
and AHCI in the BIOS.
Pin No. 1 2 3 4 5
Function CPUFANOUTPWM_1 NC CPUFANIN P12V GND
6Pin No. Function
1 GND
2 TX+
3 TX-
4 GND
5 RX-
6 RX+
7 GND
6Pin No. Function
1 +12V
2 GND
3 GND
4 +5V
7
6
5
1
5
4
3
2
1
SATA1
SATA2, SATA3
CON1
4 3 2 1
CON2
1 2 3 4

CONN1: Power-switch Connector
USB Connector USB2&USB3 (J5): It is for connecting
the USB module cable. It complies with USB3.0 .
RJ45 Console Connector (COMB2): It is for serial
communication.
Serial Interface Connectors (COMB1): It is for
connecting the RS-232 serial port interface cable.
This serial port setting can be altered in the
BIOS menu: go to BIOS->Advanced->Super IO
Conguration->Serial Port 0 Conguration
Note: In the Super IO Configuration of
the BIOS menu, Serial Port 0 refers to the
console port on the front panel whereas
Serial Port 1 refers to the COMB1 here.
Port 80h POST Debug (80Port1): It is a proprietary
connector for connecting a checkpoint device to
generate diagnostic progess codes (POST codes) to
I/O port 80h throughput booting and Power-On
Self Test (POST) to indicate the task the system is
currently executing.
SPI-ROM Update Connector (SPIROM1): Using the
appropriate cable to connect this 10-pin ISP-in
header connector, the user can update the SPI Flash
soldered on board.
PSU PMBUS and TTL Function Connectors (CON3):
Pin No. Signals
1 PWR_BTIN_N
2 GND
2
4
6
8
10
1
3
5
7
9
Pin No. Function Pin No. Function
1 CLK 2 LAD1
3 RST- 4 LAD0
5 LFRAME- 6 P3V3
7 LAD3 8 KEY
9 LAD2 10 GND
Pin No. Function Pin No. Function
1 NC 2 USB+5
3 USB+4 4 USB-5
5 USB-4 6 GND
7 GND 8 USB3T+2
9 USB3T+1 10 USB3T-2
11 USB3T-1 12 GND
13 GND 14 USB3R+2
15 USB3R+1 16 USB3R-2
17 USB3R-1 18 V5USB2
19 V5USB2 20 NC
2
1
19
1
20
2
Pin No. Function Pin NO. Function
1 Data Carrier De-
tect (DCDA#)
2 Data Set Ready
(DSRA#)
3 Receive Data
(RXDA)
4 Request To Send
(RTSA#)
5 Transmit Data
(TXDA)
6 Clear To Send
(CTSA#)
7 Data Terminal
Ready (DTRA #)
8 Ring Indicator
(RIA#)
9 Ground (GND) 10 Key
Pin No. Function Pin NO. Function
1 NC 2 NC
3 SPI_CS0- 4 P3V3ME
5 SPI_MISO 6 HPLD-
7 NC 8 SPI_CLK
9 GND 10 SPI_MOSI
2
12
1
11
1 8
Pin No. Signal Pin NO. Signal
1 LNRTSB# 2 LNDTRB#
3 LNSOUTB# 4 GND
5 GND 6 LNSINB
7 LNDSRB# 8 LNCTSB#
91
1
2
8
Pin No. Signal
1 PSU_TTL1
2 PSU_TTL2
3 NC
4 GND
5 NC
6 PMBUS_CLK
7 PMBUS_DAT
8 GND

Clear CMOS and Disable ME Jumper Setting (J4):
It is for clearing the CMOS memory and system
setup parameters by erasing the data stored in
the CMOS RAM such as the system passwords.
The ME_disable setting allows updating the Intel
Management Engine rmware through software
without a electronic programmer. The Intel ME's
leverage of non-volatile storage prevents users
from removing critical inventory, remote control, or
virus protection agents.
To clear CMOS, disconnect AC power supply. Set the
jumper to 4-6 and wait a minute to be sure the
CMOS has been cleared. Then return the CMOS
jumper to it's original position.Restore power to
the system.
Bypass LED Function (J12)
Generation 3 Bypass Firmware Download Connector
(J7)
Generation 3 Bypass Program Selection Header (J8)
Hardware or Software Reset Jumper(J3): The jumper
can be adjusted to be in either hardware or software
reset mode when the reset switch is pressed. The
hardware reset will reboot the system without
turning off the power. The software reset can be
programmed to reset a software to its default
setting.
ATX Power Connector(ATX1, ATX2): Find the proper
orientation when inserting the plugs, for the supply
plugs are designed to fit these connectors in only
one orientation.
AT/ATX Mode Selection Header (J13)
AT Mode Power Connector (CONN5)
Pin No. Signal Pin No. Signal
1 GND 2 +12V
3 GND 4 +12V
5 GND 6 +12V
7 GND 8 +12V
Pin No. Function
1-2 HW Reset
2-3 Software Reset
(default)
1
2
7
8
20
2
19
1
Pin No. Signal Pin No. Signal
1 +3.3V 2 +3.3V
3 +3.3V 4 -12V
5 GND 6 GND
7 +5V 8 PSON
9 GND 10 GND
11 +5V 12 GND
13 GND 12 GND
15 PROK 16 -5V
17 5VSB 18 +5V
19 +12V 20 +5V
3 2 1
1 2 Pin No. Signal
1 P3V3
2 MR#
3 1
4 2
Pin No. Signal
1 GND
2 GND
3 PWR_BTIN_N
4 PWR_BTIN_N
Pin No. Signal
1 GND
2 PSON-
2 1
1
3
5
2
4
6
Pin No. Function
1-3 ME_DISABLE
3-5 NORMAL
2-4 NORMAL
4-6 CLEAR CMOS
9
1
10
2
Pin No. Function Pin No. Function
1 NC 2 NC
3 NXP_RXD 4 NXP_RTS_N
5 NXP_TXD 6 NXP_CTS_N
7 NC 8 NC
9 GND 10 P3V3SB
Pin No. Signal Pin No. Signal
1 CPLD_LED1_L 2 CPLD_LED1
2 CPLD_LED2_L 4 CPLD_LED2
3 CPLD_LED3_L 6 CPLD_LED3
2 6
1 5
Pin No. Function
1 P3V3SB
2 CPLD_LED3
3 GND
1 2 3
Pin No. Signal Pin No. Signal
1 P3V3SB 2 NC
3 ME_DISABLE 4 RTCRST#
5 NC 6 GND

VGA Interface (VGA1): It is for connecting the VGA
interface cable (2X6 pin to female DB15 connector)
Onboard or IPMI VGA Signal Selection (J6): A jumper
to select VGA output between the onboard VGA
connector and the VGA connector on the IPMI card.
PCIe Interface Signal Reversal Header (J11)
PCIe Bandwidth Selection between x8 or x4 (J1): It is
for selecting PCIESLOT1 PCIe bandwidth.
Pin No. Function
1-2 Onboard
2-3 IPMI
3
2
1
21
20
19
Pin No. Function
1 NC
2 CFG2
3 GND
3 2 1
Pin No. Function PIN NO. Function
1 CRT-R 2 GND
3 CRT-G 4 GND
5 CRT-B 6 GND
7 AHSYNC 8 NC
9 AVSYNC 10 GND
11 DDC_DATA 12 DDC_CLK
1 2
11 12
Pin No. Function
1 NC
2 NC
3 CFG6
4 CFG5
5 GND
6 GND
6
5
2
1
Pin No. Function
1-3 Select two x8 signals
3-5 Select one x8, two x4 signals
4-6 Select low default
PCIe Connector (PCIESLOT1): A Generation 3 PCIe x8 gold finger
Pin No. Signal Pin No. Signal
B1 P12V A1
B2 P12V A2 P12V
B3 P12V A3 P12V
B4 GND A4 GND
B5 SLOT2SMBCLK A5
B6 SLOT2SMBDAT A6
B7 GND A7
B8 P3V3 A8 PCIE1_IO_GP
B9 A9 P3V3
B10 P3V3SB A10 P3V3
B11 PCIWAKE- A11 PCIESLOT2REST-
B12 A12 GND
B13 GND A13 PCIESLOT2CLK+
B14 PEG_TX+8 A14 PCIESLOT2CLK-
B15 PEG_TX-8 A15 GND
B16 GND A16 PEG_RX+8
B17 A17 PEG_RX-8
B18 GND A18 GND
B19 PEG_TX+9 A19
B20 PEG_TX-9 A20 GND
B21 GND A21 PEG_RX+9
B22 GND A22 PEG_RX-9
B23 PEG_TX+10 A23 GND
B24 PEG_TX-10 A24 GND
B25 GND A25 PEG_RX+10
B26 GND A26 PEG_RX-10
B27 PEG_TX+11 A27 GND
B28 PEG_TX-11 A28 GND
B29 GND A29 PEG_RX+11
B30 PCIEX8_RISER_2_CLK+ A30 PEG_RX-11
B31 PCIEX8_RISER_2_CLK- A31 GND
B32 GND A32
B33 PEG_TX+12 A33
B34 PEG_TX-12 A34 GND
B35 GND A35 PEG_RX+12
B36 GND A36 PEG_RX-12
B37 PEG_TX+13 A37 GND
B38 PEG_TX-13 A38 GND
B39 GND A39 PEG_RX+13
B40 GND A40 PEG_RX-13
B41 PEG_TX+14 A41 GND
B42 PEG_TX-14 A42 GND
B43 GND A43 PEG_RX+14
B44 GND A44 PEG_RX-14
B45 PEG_TX+15 A45 GND
B46 PEG_TX-15 A46 GND
B47 GND A47 PEG_RX+15
B48 A48 PEG_RX-15
B49 GND A49 GND

PCIe Connector (PCIESLOT2): A Generation 3 PCIe x8
slot
Pin No. Signal Pin No. Signal
B1 P12V A1
B2 P12V A2 P12V
B3 P12V A3 P12V
B4 GND A4 GND
B5 SLOT2SMBCLK A5
B6 SLOT2SMBDAT A6
B7 GND A7
B8 P3V3 A8
B9 A9 P3V3
B10 P3V3SB A10 P3V3
B11 PCIWAKE- A11 PCIESLOT1REST-
B12 A12 GND
B13 GND A13 PCIESLOT1CLK+
B14 PEG_TX+0 A14 PCIESLOT1CLK-
B15 PEG_TX-0 A15 GND
B16 GND A16 PEG_RX+0
B17 A17 PEG_RX-0
B18 GND A18 GND
B19 PEG_TX+1 A19
B20 PEG_TX-1 A20 GND
B21 GND A21 PEG_RX+1
B22 GND A22 PEG_RX-1
B23 PEG_TX+2 A23 GND
B24 PEG_TX-2 A24 GND
B25 GND A25 PEG_RX+2
B26 GND A26 PEG_RX-2
B27 PEG_TX+3 A27 GND
B28 PEG_TX-3 A28 GND
B29 GND A29 PEG_RX+3
B30 PCIEX8_SLOT2_2_CLK+ A30 PEG_RX-3
B31 PCIEX8_SLOT2_2_CLK- A31 GND
B32 GND A32
B33 PEG_TX+4 A33
B34 PEG_TX-4 A34 GND
B35 GND A35 PEG_RX+4
B36 GND A36 PEG_RX-4
B37 PEG_TX+5 A37 GND
B38 PEG_TX-5 A38 GND
B39 GND A39 PEG_RX+5
B40 GND A40 PEG_RX-5
B41 PEG_TX+6 A41 GND
B42 PEG_TX-6 A42 GND
B43 GND A43 PEG_RX+6
B44 GND A44 PEG_RX-6
B45 PEG_TX+7 A45 GND
B46 PEG_TX-7 A46 GND
B47 GND A47 PEG_RX+7
B48 A48 PEG_RX-7
B49 GND A49 GND
Front LCD Module Connector (LCM1): It is for
connecting the front LCD and Keypad module.
CompactFlash Connector (CF1): ACompactFlash Type I/
II connector.
Pin No. Signal Pin No. Signal
1 P5V 2 GND
3 SLIN- 4 VEE
5 AFD- 6 INIT-
7 FL_PD1_R 8 FL_PD0_R
9 FL_PD3_R 10 FL_PD2_R
11 FL_PD5_R 12 FL_PD4_R
13 FL_PD7_R 14 FL_PD6_R
15 LCM_LCD- 16 P5V
17 KEY_UP 18 KEY_RIGHT
19 KEY_LEFT 20 KEY_DOWN
21 LCM_RST- 22 CTR_GRN_R
23 CTR_YLW_R 24 HD_LED-
1 2
23 24
Pin No. Function Pin No. Function
1 GND 26 DET1
2 CF_DD3 27 CF_DD11
3 CF_DD4 28 CF_DD12
4 CF_DD5 29 CF_DD13
5 CF_DD6 30 CF_DD14
6 CF_DD7 31 CF_DD15
7 -CF_DCS0 32 -CF_DCS1
8 GND 33 CF_VS1
9 GND 34 CF_DIOR_N
10 GND 35 CF_DIOW_N
11 GND 36 P3V3
12 GND 37 CF_IDEIRQ
13 P3V3 38 P3V3
14 GND 39 MST_SLV
15 GND 40 CF_VS2
16 GND 41 CF_IDERST_
N
17 GND 42 CF_IORDY
18 CF_DA2 43 CF_DMARQ
19 CF_DA1 44 CF_DDACK_
N
20 CF_DA0 45 CFASTLED-
21 CF_DD0 46 CF_PDIAG
22 CF_DD1 47 CF_DD8
23 CF_DD2 48 CF_DD9
24 49 CF_DD10
25 CF_DS_N 50 GND

PC Case Open Detection Header (CONN4): It is for
detecting case open event.
Digital Input/Output Port (DIO1)
Pin No. Signal
1 CASEOPEN-
2 GND
2
1
2 10
1 9
Pin No. Signal Pin No. Signal
1 GPO_1 2 GPI_1
3 GPO_2 4 GPI_2
5 GPO_3 6 GPI_3
7 GPO_4 8 GPI_4
9 GND 10 GND

Chapter 2:
Hardware Setup
Preparing the Hardware Installation
To access some components and perform certain service
procedures, you must perform the following procedures
first.
WARNING: To reduce the risk of personal
injury, electric shock, or damage to the
equipment, remove the power cord to
remove power from the server. The front
panel Power On/Standby button does not
completely shut off system power. Portions of
the power supply and some internal circuitry
remain active until AC power is removed.
Unpower the FW-8759 and remove the power cord.1.
Unscrew the screws (two on each side and one on the2.
rear) from the top cover of the FW-8759 System.
Slide the cover backwards and open the cover3.
upwards.
System Memory Installation
The motherboard supports DDR3/DDR3L memory that
features data transfer rates of 1066/1333/1600 MHz
(with unbuffered ECC or non-ECC) to meet the higher
bandwidth requirements of the latest operating system
and Internet applications. To install the memory:
Open the DIMM slot latches.1.
Install the DIMM.2.
Note:
All DIMMs installed must be the same speed1.
(DDR3/DDR3L 1066/1333/1600MHz, unbuffered
ECC or non-ECC ). Do not install DIMMs
supporting different speeds.
The system can support up to 8 GB in maximum.2.
Since the system is capable of dual channel3.
architecture, insert DIMMS on both DIMM1
and DIMM2 slots to enable dual channel
configuration.
Hard Disk Installation
The system can accommodate two 2.5”Serial-ATA disks.
Follow these steps to install hard disks into the FW-8759:
Unscrew the 4 screws on the hard disk tray to take out1.
the hard disk tray from the system.
Place hard disk on the hard disk tray and align the2.
holes of the hard disk with the mounting holes on the
tray.
Secure the hard disk with 4 mounting screws on the3.
hard disk tray.
Connect the Serial-ATA power and data cables to the4.
hard disk’s power and data connectors respectively.
Plug the Serial-ATA cable to the Serial-ATA Connector5.
on the main board.
Put the hard disk tray with the installed hard disk back6.
to the system and install it with the mounting screws.
1
21
