Lantech IGS-2404 User manual

4 10/100/1000T + 4 10/100/1000T/Dual
Speed SFP L2 Managed Industrial Switch
IGS-2404
User Manual
w/ Pro-Ring

Content
Overview.............................................................1
Introduction ..............................................................1
Features...................................................................4
Packing List..............................................................6
Safety Precaution.....................................................6
Hardware Description.........................................7
Front Panel............................................................... 7
Top View..................................................................8
Wiring the Power Inputs...........................................8
LED Indicators..........................................................9
Ports.......................................................................10
Cabling...................................................................11
Mounting Installation ........................................15
DIN-Rail Mounting..................................................15
Wall Mount Plate Mounting....................................16
Hardware Installation........................................18

Installation Steps....................................................18
X-Ring Application..................................................19
Coupling Ring Application...................................... 20
Dual Homing Application........................................21
Console Management......................................23
Connecting to the Console Port............................. 23
Pin Assignment...................................................... 23
Login in the Console Interface ...............................24
CLI Management....................................................25
Commands Level.............................................................26
Commands Set List..........................................................27
System Commands Set ...................................................27
Port Commands Set.........................................................30
Trunk Commands Set......................................................32
VLAN Commands Set......................................................33
Spanning Tree Commands Set........................................35
QOS Commands Set .......................................................38
IGMP Commands Set......................................................39
Mac / Filter Table Commands Set....................................39
SNMP Commands Set.....................................................40

Port Mirroring Commands Set..........................................42
802.1x Commands Set.....................................................43
TFTP Commands Set ......................................................45
SystemLog, SMTP and Event Commands Set ................46
SNTP Commands Set......................................................48
Pro-ring Commands Set...................................................49
Web-Based Management.................................50
About Web-based Management ............................50
Preparing for Web Management............................50
System Login .........................................................51
Main interface.........................................................52
System Information................................................53
IP Configuration .....................................................53
DHCP Server – System configuration....................54
DHCP Client – System Configuration ....................55
DHCP Server - Port and IP Bindings .....................56
TFTP - Update Firmware ....................................... 56
TFTP – Restore Configuration...............................57
TFTP - Backup Configuration.................................57
System Event Log – Syslog Configuration.............58

System Event Log - SMTP Configuration ..............59
System Event Log - Event Configuration...............61
Fault Relay Alarm...................................................63
SNTP Configuration...............................................63
IP Security..............................................................66
User Authentication................................................67
Port Statistics.........................................................68
Port Control............................................................69
Port Trunk ..............................................................70
Aggregator setting............................................................70
Aggregator Information ....................................................71
State Activity ....................................................................72
Port Mirroring .........................................................73
Rate Limiting..........................................................73
VLAN configuration................................................74
VLAN configuration - Port-based VLAN...........................75
802.1Q VLAN...................................................................78
Rapid Spanning Tree.............................................81
RSTP - System Configuration..........................................81
RSTP - Port Configuration ...............................................82

SNMP Configuration ..............................................83
System Configuration.......................................................84
Trap Configuration ...........................................................85
SNMPV3 Configuration....................................................86
QoS Configuration..................................................89
QoS Policy and Priority Type...........................................89
Port Base Priority.............................................................90
COS Configuration...........................................................91
TOS Configuration ...........................................................91
IGMP Configuration................................................91
Pro-Ring System....................................................93
Security..................................................................95
802.1X/Radius Configuration...........................................95
MAC Address Table.........................................................98
Factory Default.....................................................101
Save Configuration...............................................101
System Reboot..................................................... 101
Troubles shooting...........................................102
Technical Specification...................................103

1
Overview
Introduction
To create reliability in your network, the 4 10/100/1000T + 4 SFP
Managed Industrial Switch comes equipped with a proprietary
redundant network protocol:Pro-Ring provides users with an easy way
to establish a redundant Ethernet network with ultra high-speed
recovery time less than 10 ms. Also, the long MTBF (Mean Time
Between Failures) ensures that the industrial switch will continue to
operate until a Gigabit network infrastructure has been established,
without requiring any extra upgrade costs.
Aside from 4 x 10/100/1000Base-TX fast Ethernet ports, the 4
10/100/1000T + 4 SFP Managed Industrial Switch comes equipped with
4 SFP (mini-GBIC) ports. Traditional RJ-45 ports can be used for
uplinking wide-band paths in short distance (< 100 m), while the SFP
slots can be used for the application of wideband uploading and long
distance transmissions to fit the field request flexibility. Also, the long
MTBF (Mean Time Between Failures) ensures that the 4 10/100/1000T
+ 4 SFP Managed Industrial Switch will continue to operate until a
Gigabit network infrastructure has been established, without requiring
any extra upgrade costs.
The SFP Advantage
The SFP fiber slots provide a lot of flexibility when planning and
implementing a network. The slot can accept any SFP-type fiber module
and these modules are designed for transmitting over distances of
either 500m (multi-mode), 10km, 30km, 50km, 70km or 110km
(single-mode) – and the slot support SFP modules for WDM single-fiber
transmissions. This means that you can easily change the transmission
mode and distance of the switch by simply pulling out the SFP module
and plugging in a different module. The SFP modules are
hot-swappable and plug-and-play.

2
High-Speed Transmissions
The 4 10/100/1000T + 4 SFP Managed Industrial Switch includes a
switch controller that can automatically sense transmission speeds
(10/100/1000 Mbps). The RJ-45 interface can also be auto-detected, so
MDI or MDI-X is automatically selected and a crossover cable is not
required. All Ethernet ports have memory buffers that support the
store-and-forward mechanism. This assures that data is properly
transmitted.
Dual Power Input
The redundant power input design of 4 10/100/1000T + 4 SFP Managed
Industrial Switch is with power reserve protection to prevent the switch
device broken by wrong power wiring. When one of power input is fail,
P-Fail LED will turn on and send an alarm through a relay output for
notifying user.
Flexible Mounting
4 10/100/1000T + 4 SFP Managed Industrial Switch is compact and can
be mounted on a DIN-rail or panel, so it is suitable for any
space-constrained environment.
Advanced Protection
The power line of 4 10/100/1000T + 4 SFP Managed Industrial Switch
supports up to 3,000 VDC EFT protection, which secure equipment
against unregulated voltage and make systems safer and more reliable.
Meanwhile, 4,000 VDC ESD protections for Ethernet ports make 4
10/100/1000T + 4 SFP Managed Industrial Switch more suitable for
harsh environments.
Wide Operating Temperature

3
The operating temperature of the 4 10/100/1000T + 4 SFP Managed
Industrial Switch is between -20 ~ 60 ℃. With such a wide range, you
can use the 4 10/100/1000T + 4 SFP Managed Industrial Switch in
some of the harshest industrial environments that exist.
Easy Troubleshooting
LED indicators make troubleshooting quick and easy. Each
10/100/1000 Base-TX port has 2 LEDs that display the link status,
transmission speed and collision status. Also the three power indicators
P1, P2 and Fault help you diagnose immediately.

4
Features
Provides 4 x 10/100/1000Base-T Mbps Ethernet ports
Provides 4 x SFP (mini-GBIC) port (support 100/1000 Dual Mode)
Supports full/half duplex flow control
Supports auto-negotiation
Supports MDI/MDI-X auto-crossover
Supports Packet Buffer up to 1Mbits
Supports MAC Address up to 8Kbytes
Supports surge (EFT) protection 3,000 VDC for power line
Supports 4,000 VDC Ethernet ESD protection
Power Supply
¾Wide-range Redundant Power Design
¾Power Polarity Reverse Protect
¾Overload Current Protection
Case/Installation
¾IP-30 Protection
¾DIN Rail and Wall Mount Design
Spanning Tree
¾Support IEEE802.1d Spanning Tree
¾Support IEEE802.1w Rapid Spanning Tree
VLAN
¾Port Based VLAN
¾Support 802.1 Q Tag VLAN
¾GVRP
¾Double Tag VLAN (Q in Q)*
¾Private VLAN**
Pro-Ring
¾X-Ring, Dual Homing, Couple Ring Topology
¾Provide redundant backup feature and the recovery time below
10ms
Port Trunk with LACP
Support 802.1ab LLDP
QoS (Quality of Service)
¾Support IEEE 802.1p Class of Service
¾Per port provides 4 priority queues
¾Port Base, Tag Base and Type of Service Priority
Bandwidth Control
¾Ingress Packet Filter and Egress Rate Limit

5
¾Broadcast/Multicast Packet Filter Control
Port Mirror: Monitor traffic in switched networks.
¾TX Packet only
¾RX Packet only
¾Both of TX and RX Packet
System Event Log
¾System Log Server/Client
¾SMTP e-mail Alert
¾Relay Alarm Output System Events
Security
¾Port Security: MAC address entries/filter
¾IP Security: IP address security management to prevent
unauthorized intruder
¾Login Security: IEEE802.1X/RADIUS
SNMP Trap
¾Device cold start
¾Power status
¾Authentication failure
¾X-Ring topology changed
¾Port Link up/Link down
IGMP with Query mode for Multi Media Application
TFTP Firmware Update and System Configure Restore and Backup
Supports operating temperatures from -40 ~ 85 ℃(wide operating
temperature model) or -20 ~ 60 ℃(standard model)

6
Packing List
1 x 4 10/100/1000T + 4 SFP Managed Industrial Switch
1 x User Manual
2 x Wall Mounting Bracket and Screws
Safety Precaution
Attention IF DC voltage is supplied by an external circuit, please use a
protection device on the power supply input.

7
Hardware Description
In this paragraph, we will introduce the Industrial switch’s hardware spec, port, cabling
information, and wiring installation.
Front Panel
The Front Panel of 4 10/100/1000T + 4 SFP Managed Industrial Switch is shown as
below.
-E Model
Standard Model

8
Top View
The top panel of 4 10/100/1000T + 4 SFP Managed Industrial Switch is equipped one
terminal block connector of two DC power inputs.
Top panel of the 4 10/100/1000T + 4 SFP Industrial Switch
Wiring the Power Inputs
Please follow the steps below to insert the power wire.
Insert the positive and negative wires into the V+ and V- contacts on the terminal block
connector.

9
Tighten the wire-clamp screws for preventing the wires from loosing.
Note The wire gauge for the terminal block should be in the range
between 12~ 24 AWG.
LED Indicators
There are few LEDs display the power status and network status located on the front
panel of 4 10/100/1000T + 4 SFP Industrial Switch, each of them has its own specific
meaning as tabled below.
LED Color Description
On System power on
PWR Green
Off No power inputs
On The industrial switch is the master of the X-ring
group
R.M. Green
Off The industrial switch is not the master of the X-ring
group
On Power input 1 is active
PWR1 Green
Off Power input 1 is inactive
On Power input 2 is active
PWR2 Green
Off Power input 2 is inactive
On Power input 1 or 2 is inactive or port link down
(depends on Fault Relay Alarm configuration)
Fault Red
Off Power input 1 and 2 are both functional, or no power
inputs
On SFP port is linkingLink/Active
(P5 ~ P8)
Green
Flashing Data is transmitting or receiving

10
Off Not connected to network
On Connected to network
Flashing Networking is active at speed of 100Mbps
P1 ~ P4
(Upper LED)Green
Off Not connected to network
On Connected to network at speed of 1000MbpsP1 ~ P4
(Lower LED) Green Off Not connected to network
LED indicators of 4 10/100/1000T + 4 SFP Managed Industrial Switch
Ports
RJ-45 ports (Auto MDI/MDIX): The RJ-45 ports are auto-sensing for 10Base-T,
100Base-TX or 1000Base-T devices connections. Auto MDI/MDIX means that you can
connect to another switch or workstation without changing straight through or
crossover cabling. See figures as below for straight through and crossover cable
schematic.
RJ-45 Pin Assignments
Pin Number Assignment
1 Tx+
2 Tx-
3 Rx+
6 Rx-
Note “+” and “-” signs represent the polarity of the wires that make up each wire
pair.
All ports on this industrial switch support automatic MDI/MDI-X operation, you can use
straight-through cables (See Figure below) for all network connections to PCs or
servers, or to other switches or hubs. In straight-through cable, pins 1, 2, 3, and 6, at
one end of the cable, are connected straight through to pins 1, 2, 3 and 6 at the other
end of the cable. The 10BASE-T/100BASE-TX/1000BASE-T MDI and MDI-X port pin
outs are as tabled below.
Pin MDI-X Signal Name MDI Signal Name

11
1 Receive Data plus (RD+) Transmit Data plus (TD+)
2 Receive Data minus (RD-) Transmit Data minus (TD-)
3 Transmit Data plus (TD+) Receive Data plus (RD+)
6 Transmit Data minus (TD-) Receive Data minus (RD-)
Straight Through Cable Schematic
Cross Over Cable Schematic
Cabling
Use the four twisted-pair, Category 5e or above cabling for RJ-45 port connection. The
cable between the switch and the link partner (switch, hub, workstation, etc.) must be
less than 100 meters (328 ft.) long.
As for the small form-factor pluggable (SFP), which is a compact optical transceiver
used in optical communications for both telecommunication and data communication
applications.
To connect the transceiver and LC cable, please take the steps shown as follows:
First, insert the transceiver into the SFP module. Notice that the triangle mark is the
bottom of the module.

12
Transceiver to the SFP module
Transceiver Inserted

13
Second, insert the fiber cable of LC connector into the transceiver.
LC connector to the transceiver
To remove the LC connector from the transceiver, please follow the steps shown
below:
First, press the upper side of the LC connector from the transceiver and pull it out to
release.
Remove LC connector

14
Second, push down the metal loop and pull the transceiver out by the plastic part.
Pull out from the SFP module
