Larson Electronics MPD CB-SF-489 Series User manual

MPD-XX-CB-SF-489 Series
Larson Electronics, LLC
Phone: [phone]
Fax: [phone] www.larsonelectronics.com
1 of 10
C-Curve MCCB Circuit Breaker Assembly - Surface Mount - Fixed
Thermal Fixed Magnetic Trip
Installation Manual
Thank you for your purchase of a MPD-XX-CB-SF-489 series circuit breaker from Larson Electronics.
WARNING
Standard Warning (General)
WARNING:
READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
CRITICAL SAFETY INSTRUCTIONS:
•INSTALLATION SHOULD ONLY BECONDUCTED BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH NEC AND ANY
RELEVANT LOCAL BUILDING CODES.
•RISK OFFIRE OR ELECTRIC SHOCK. FIXTURE INSTALLATION REQUIRES KNOWLEDGE OF FIXTURE'S ELECTRICAL
SYSTEMS. IFNOTQUALIFIED, CONTACT A QUALIFIED ELECTRICIAN.
•BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.
•MAKE SURE THE SUPPLY VOLTAGE IS THE SAME AS THE FIXTURE'S RATED VOLTAGE.
•TO PREVENT WIRING DAMAGE OR ABRASION, DO NOT EXPOSE WIRING TO EDGES OF SHEET METAL OR SHARP
OBJECTS. SUITABLE FOR DAMP LOCATIONS.
WARNING: MAKE SURE POWER IS TURNED OFF BEFORE STARTING THE
INSTALLATION OR PERFORMING ANY MAINTENANCE.
RISK OF FIRE/ELECTRIC SHOCK –DISCONNECT POWER AT BREAKER BEFORE INSTALLING OR SERVICING.
RISK OF PERSONAL INJURY –FIXTURE MAY BECOME UNSTABLE OR DAMAGED IF NOT INSTALLED PROPERLY.
RISK OF BURN –ALLOW FIXTURE TO COOL BEFORE SERVICING.
SAVE THESE INSTRUCTIONS

Larson Electronics, LLC
Phone: [phone]
Fax: [phone] www.larsonelectronics.com
2 of 10
INSTALLATION
CIRCUIT BREAKER INSTALLATION
Make sure that the equipment is suitable for the installation by comparing nameplate ratings with system requirements.
Inspect the equipment for completeness and check for any damage.
WARNING: MAKE SURE POWER IS TURNED OFF BEFORE STARTING THE
INSTALLATION OR PERFORMING ANY MAINTENANCE.
HAZARD OF ELECTRIC SHOCK, BURN, OR EXPLOSION
1. Before mounting the circuit breaker in an electrical system, make sure there is no voltage present
where work is to be performed.
2. Mount no closer to enclosure metal or live parts than is indicated in drawing.
3. All enclosure closing hardware must be installed.
FAILURE TO FOLLOW THESE INSTRUCTONS WILL RESULT IN DEATH OR SEVERE INJURY.
<Table.1> Size of Enclosure /
Tamaño del cierre /
Taille du boîtier
●Dimensions / Dimensiones / Dimensions: inch / pulg / inch(mm)
Metal or Live Electrical Parts / Partes eléctricos metales o
vivos /Métal ou pièces électriques sous tension
<Fig. 1> Clearances for Circuit Breaker / Espacio libre para el interruptor / Dégagements pour disjoncteur <Fig. 2> Circuit Breaker Mounting
Bolt Drilling Plan /
Plan de perforación de
tornillo de montaje del
interruptor/ Plan de forage
des Vis de montage du
Disjoncteur
<Fig. 3> Circuit Breaker
Escutcheon
Dimensions /
Dimensiones del escudo
del interruptor /
Dimensions d’écusson
du Disjoncteur
W
H
D
W
1.1.8989
((448)8)
1.1.0606
(2(27)7)
#6-32#6-32 UNC UNC
Tap (2 ap (2 Holes)Holes)
4.4.3333
[1110]0]
4.4.3333
[1110]0]
0.0.9898
[2 [25]5]
0.0.4949
[12[12.5].5]
[2[2P]P] [3[3P]P]
#6-32#6-32 UNC UNC
Tap (2 ap (2 Holes)Holes)
80% and 100% RATED inch / pulg / po (mm)
W H D a b c
Circuit
Breaker
Type
UTE100
2P, 3P
17.3
(439.4)
8.27
(210)
3.94
(100)
2.58
(65.4)
6.03
(153.1)
3.29
(83.5)
Dimensions for electrical and mechanical clearance to metal or live electrical parts.
(See Fig. 1) To mount the circuit breaker perform the following steps:
1. For individual surface mounting, drill and tap mounting bolts holes according to the drilling plan shown in Fig. 2.
For dead- front cover applications, cut out cover to correct escutcheon dimensions refer to Fig. 3 .
2. If circuit breaker includes factory-or field-installed internal accessories, make sure that accessory wiring can be reached when the
circuit breaker is mounted.
3. Position circuit breaker on mounting surface.
4. Install circuit breaker mounting screws and washers. Tighten hardware securely, but do not exceed 13.3 pound-inches (1.5N.m.)
MPD-XX-CB-SF-489 Series

Larson Electronics, LLC
Phone: [phone]
Fax: [phone] www.larsonelectronics.com
3 of 10
MANUAL OPERATION
●Handle Position Indicator Color / Color del indicador de posición de la palanca /
Couleur de l'indicateur de la Position de la poignée
RED / ROJO / Rouge - ON
GREEN / VERDE / Verte - OFF (RESET)
<Fig. 4> Circuit Breaker Manual Controls /
Control manual del interruptor /
Commande manuelle du Disjoncteur
ON(I)
Tripped
OFF(I)
Reset
PUSH TO TRIP button /
Botón de disparo /
Bouton PUSH TO TRIP
Auxiliary cover /
Cubierta auxiliar /
Ccouvercle auxiliaire
Tripped position /
Posición de disparado /
Position déclenché
Manual Operation of the circuit breaker is controlled by the circuit breaker handle and the PUSH TO TRIP button. The circuit breaker
has three positions, two of which are shown on the auxiliary cover with raised lettering to indicate ON and OFF. The third position
indicates a TRIP position and is between the ON and OFF positions. (See Fig. 4)
Circuit Breaker Reset
After an automatic or accessory initiated trip, or a manual PUSH TO TRIP operation, the circuit breaker is reset by moving the circuit
breaker handle to the reset position.
Note: In the event of a thermal trip, the circuit breaker cannot be reset until the thermal element in the trip unit cools.
PUSH TO TRIP Button
The PUSH TO TRIP button checks the tripping function and is used to manually exercise the operating mechanism.
Note: Press PUSH TO TRIP button once a year to exercise circuit breaker.
WIRE INSTALLATION
1. Do not allow conductor strands to interfere with threads of wire binding screw.
2. When installing two cables into a lug body make sure cables do not back out during tightening of
the wire binding screw.
MPD-XX-CB-SF-489 Series
WARNING: MAKE SURE POWER IS TURNED OFF BEFORE STARTING THE
INSTALLATION OR PERFORMING ANY MAINTENANCE.
HAZARD OF FALSE TORQUE INDICATION
FAILURE TO FOLLOW THESE INSTRUCTONS WILL RESULT IN EQUIPMENT DAMAGE

Larson Electronics, LLC
Phone: [phone]
Fax: [phone] www.larsonelectronics.com
4 of 10
WIRE INSTALLATION (cont.)
0.7 inch
(17.8mm)
<Table.2 / Tabla.2 / Tableau.2> Lug Information / Información de las zapatas / Information sur les cosses
Wire Binding Screw
Torque /
Par de apriete del
tornillo de sujeción de
cables /
Couple de la vis de
fixation de fils
31.9 lb-in/ lbs-pulg/ lbpo
(3.6 N�m)
39.9 lb-in/ lbs-pulg/ lbpo
(4.5 N�m)
47.8 lb-in/ lbs-pulg/ lbpo
(5.4 N�m)
55.7 lb-in/ lbs-pulg/ lbpo
(6.3 N�m)
55.7 lb-in/ lbs-pulg/ lbpo
(6.3 N�m)
Cu 1
14~10AWG
8AWG
6~3AWG
2~1AWG
2~1/0AWG
1
1
1
1
Cu
Cu / AI
Cu / AI
AI
AL100TE 15 ~100A
Strip Length / Sección sin
alslamiento /
Longuer de denudage
Size/
Tamaño/
Calibre
Number per Lug /
Cantidad por
zapata /
Nombre par cosse
Conductor / Conductor / Conducteur
Type /
Tipo /
Type
Ampere
Range /
Gama en A /
Gamme (A)
Catalog
Number /
No. de catalogo /
N de catalogue
Lug /
Zapatas /
Cosses
1. Square conductor ends and perform conductors to final configuration. Using a proper insulation stripping tool, strip conductor
ends as recommended in Table 2. Do not nick strands.
2. If terminal mounter assemblies are not installed, install it (A).
3. Install cable in terminal mounter assemblies (B), and torque wire binding screw as recommended on the faceplate and Table 2
(C).
31.9, 39.9, 47.8, 55.7lb-
in /lbs-pulg / lb-po
(3.6, 4.5, 5.4, 6.3 N•m)
(UTE100 2P) (UTE100 3P)
<Fig. 5> wire installation /
instalación de
cable /installation de
fil.
MPD-XX-CB-SF-489 Series

Larson Electronics, LLC
Phone: [phone]
Fax: [phone] www.larsonelectronics.com
5 of 10
ACCESSORY & CONTROL WIRING INSTALLATION
HAZARD OF ELECTRIC SHOCK, BURN, OR EXPLOSION
WARNING: MAKE SURE POWER IS TURNED OFF BEFORE STARTING THE
INSTALLATION OR PERFORMING ANY MAINTENANCE.
1. Turn off all power supplying this equipment before working on or inside equipment.
2. Before removing the auxiliary cover in a circuit breaker, make sure there is no voltage present where work
is to be performed and circuit breaker is tripped.
FAILURE TO FOLLOW THESE INSTRUCTIONS WILL RESULT IN DEATH OR SEVERE INJURY
1. Loosen four screws from the auxiliary cover and open it (A).
2. Install field-installable accessories according to instructions supplied with them (B).
3. Arrange wire through wire opening in auxiliary cover to avoid pinching wires.
4. Replace auxiliary cover (C), and be careful not to pinch wires when installing cover.
Replace all auxiliary cover screws (D). Do not exceed torque specification of screws (E).
5. If circuit breaker has factory-installed accessories, refer to label on circuit breaker for electrical specifications.
Auxillary Devices / Dispositivos auxiliares / Dispositifs auxiliaires
Auxilliary Contact
AX Contacto auxiliar
Contact auxiliaire 24 AWG
(0.20 mm2)
AL
Alarm Switch
Contacto de alarma
Interrupteur d’alarme
UVT
Undervoltage Trip
Disparo en baja tensión
Declencheur sur baisse de tention 18 AWG
Shunt Trip (0.82 mm2)
SHT Bobina de disparo
Declencheur shunt
<Table.3 / Tabla.3 / Tableau.3>
Accessory Information / Información de
accesorio /Informations sur les accessoires
<Fig. 6> Accessory installation / Instalación de accesorio /
Installation des accessoires
MPD-XX-CB-SF-489 Series

Larson Electronics, LLC
Phone: [phone]
Fax: [phone] www.larsonelectronics.com
6 of 10
ACCESSORY & CONTROL WIRING INSTALLATION (cont.)
Detail
AX / AL 3 wires / cables / fils
24 AWG (0.20 mm2)
AX / AL
SHT or UVT
AX / AL
<Fig. 7> Control Wiring Installation / Instalación de cable de control / Installation de câblage de contrôle
BUS INSTALLATION
HAZARD OF ELECTRIC SHOCK, BURN, OR EXPLOSION
WARNING: MAKE SURE POWER IS TURNED OFF BEFORE STARTING THE
INSTALLATION OR PERFORMING ANY MAINTENANCE.
1. Apply appropriate personal protective equipment and follow safe electrical work practices.
2. This equipment must be installed and serviced only by qualified electrical personnel.
3. Turn off all power supplying this equipment before working on or inside equipment.
4. Always use a properly rated voltage sensing device to confirm power is off.
5. Replace all devices, doors and covers before turning on power to this equipment.
FAILURE TO FOLLOW THESE INSTRUCTIONS WILL RESULT IN DEATH OR SEVERE INJURY
1. Change terminal mounter assemblies (A) to terminal assemblies (B), if installed.
2. Install bus, using supplied hardware (C) (D).
3. Do not exceed torque specification of screws or bolts (E).
<Table.4 / Tabla.4 / Tableau.4>
Bus and Bus Insulation Dimensions /
Dimensiones de la barra y del
aislamiento de la barra / Dimensions
de la barre-bus et de son isolation
Dimension/
Dimensiones/
Dimension
Length/
Longitud/
Longueur
0.164in
(4.16mm)
A
B
C
D
E
0.08~0.28in
(2~7.2mm)
0.35in
(9mm)
0.47in
(12.1mm)
0.29in
(7.4mm)
MPD-XX-CB-SF-489 Series

Larson Electronics, LLC
Phone: [phone]
Fax: [phone] www.larsonelectronics.com
7 of 10
BUS INSTALLATION (cont.)
(UTE100 2P/3P)
(UTE100 2P) (UTE100 3P)
15.2 lb-in/
lbs-pulg/
lb-po(1.72N•m)
15.2 lb-in/
lbs-pulg/
lb-po(1.72N•m)
D
E
B
A
C
<Fig. 8> bus installation/ Instalación de barras / Installation de bus
TRIP UNITS
Circuit breaker includes factory-installed internal trip units. Be careful not to interchange trip units in the field.
There are various kinds of trip units according to rated current and function as follows.
Rated current, In[A]
FTUTU MCS
UTE100 3P 100
UTE100 2P - 100
Type of trip units / Tipo de unidad de disparo / Type de déclencheurs
FTU Fixed thermal, Fixed magnetic / Térmico fijo, magnético fijo / Thermique fixe, magnétique fixe
FMU Adjustable thermal, Fixed magnetic / Térmico ajustable, magnético fijo /
Thermique réglable, magnétique fixe
MCS Molded Case Switch / Switch de caja moldeada / Interrupteur à boîtier moulé
<Table.5 / Tabla.5 / Tableau.5> Type of trip units / Tipo de unidad de disparo / Type de déclencheurs
Circuit
Breaker
Type
100, 90, 80, 70,
60, 50, 40, 30,
25, 20, 15
100, 90, 80, 70,
60, 50, 40, 30,
25, 20, 15
100, 80, 60,
40, 25
MPD-XX-CB-SF-489 Series

Larson Electronics, LLC
Phone: [phone]
Fax: [phone] www.larsonelectronics.com
8 of 10
TRIP UNITS (cont.)
FTU - Fixed thermal, Fixed magnetic / Térmico fijo, magnético fijo / Thermique fixe, magnétique fixe
<Fig.9> Type of trip units / Tipo de unidad de disparo/ Type de déclencheurs
100A
40°C
2P
Im=1000A
100A
40°C
3P
Im=1000A
001 A
40°C
3P
Im=1000A
FMU - Adjustable thermal, Fixed magnetic / Térmico ajustable, magnético fijo / Thermique réglable, magnétique fixe
MCS - Molded Case Switch (Fixed magnetic only) / Switch de caja moldeada (solamente magnético fijo) / Interrupteur à boîtier moulé (seulement magnétique fixe)
MPD-XX-CB-SF-489 Series

Larson Electronics, LLC
Phone: [phone]
Fax: [phone] www.larsonelectronics.com
9 of 10
CIRCUIT BREAKER REMOVAL
HAZARD OF ELECTRIC SHOCK, BURN, OR EXPLOSION
WARNING: MAKE SURE POWER IS TURNED OFF BEFORE STARTING THE
INSTALLATION OR PERFORMING ANY MAINTENANCE.
1. Apply appropriate personal protective equipment and follow safe electrical work practices.
2. This equipment must be installed and serviced only by qualified electrical personnel.
3. Turn off all power supplying this equipment before working on or inside equipment.
4. Always use a properly rated voltage sensing device to confirm power is off.
5. Replace all devices, doors and covers before turning on power to this equipment.
FAILURE TO FOLLOW THESE INSTRUCTIONS WILL RESULT IN DEATH OR SEVERE INJURY
1. Turn off all power supplying this equipment before working on or inside equipment.
2. Remove circuit breaker in reverse order of installation.
TROUBLESHOOTING
If problems occur during installation, refer to the following guide. If trouble persists, contact Larson Electronics.
Circuit breaker fails to stay closed.
Circuit breaker trips, but no short circuit
or overload is evident.
Push-to-trip button will not trip circuit breaker.
Condition
1. Undervoltage trip not energized.
2. Shunt trip energized.
3. Short circuit or overload on system.
System voltage below undervoltage trip setting.
Circuit breaker already tripped.
Possible Causes
1. Energize undervoltage trip.
2. De-energize shunt trip.
3. Check system for short circuit or overload.
Circuit breaker already tripped.
1. Move circuit breaker handle to reset then to ON
2. Press push-to-trip button.
Solution
OTHER SAFETY INSTRUCTIONS
Check area where circuit breaker is installed for any safety hazards including personnel safety and fire hazards.
Exposure to certain types of chemicals can cause deterioration of electrical connections.
MPD-XX-CB-SF-489 Series

Larson Electronics, LLC
Phone: [phone]
Fax: [phone] www.larsonelectronics.com
10 of 10
MAINTENANCE
Caution: To avoidpersonal injury, disconnect all power and allow the unit to cool downbefore
performing maintenance.
Warning: No user serviceable parts inside of fixture. Risk of electric shock. Removal of the lens will void
the warranty.
1. Perform visual,mechanical,and electrical inspections on a regular basis.We recommend routine
checks to be made on a yearly basis. Frequency of use and environment shoulddetermine this. It is
recommendedto follow an Electrical Preventive Maintenance Program as described in NFPA 70B:
Recommendedpractice for Electrical Equipment.
2. The housing should be cleaned periodically as needed. Clean the housing with a damp, non-
abrasive,lint-free cloth. If not sufficient, use mild soapor a liquid cleaner.
3. Do not operate if the housing is cracked or damaged. All fasteners shouldbe properly seated.
USE AND CARE
Unauthorized modification may impair the function and/or safety of this device and could affect the life of the equipment.
Always check for damaged or worn out parts before using the device. Store it in a secure place out of the reach of
children when not in use.Inspect for good working condition prior to storage and before re-use.
REPLACEMENT PARTS
The MPD-XX-CB-SF-489 series circuit breakers are designed to provide years of reliable performance. Should the need
for replacement parts arise, please contact Larson Electronics.
NOTES
THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS.
SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT
SAL[email protected] OR BY PHONE AT 1-877-348-9680 FOR FURTHER ASSISTANCE.
PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.
MPD-XX-CB-SF-489 Series
