Larzep AU02015 User manual


HYDRAULICTOEJACK
“AU02015”“AU03015”“AU06015”
“AU02030”“AU03030”“AU06030”





LARZEP,S.A.
AvenidaUrtiaga,6
48269Mallabia,Spain
Tel.+34943171200
Fax.+34943174166
e‐mail: [email protected]
www.larzep.com



2
InstructionManual
HydraulicToeJack“AU”

INDEX
1. BEFOREUSINGTHEEQUIPMENTANDSECURITY‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐2
2. WARRANTY‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐2
3. TECHNICALFEATURES‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐2
4. START‐UP‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐2
5. MAINTENANCE‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐2
6. DECLARATIONOFCONFORMITY‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐3
ANNEX
 DRAWINGANDSPAREPARTLIST

1.BEFOREUSINGTHEEQUIPMENTANDSECURITY
Readcarefullytheinstructionmanualandpracticewiththeequipmentbeforetheapplication.

Usetheprotectivedevicessuchasgoggles,bootsandsecuritygloves.

Donotexceedthe80%ofnominalcapacityoftheequipmentduringitsutilization.
 Maketheoperationsinwell‐lightedandstableareaandlookforsafetylocationtotheoperators.
 Blocktheloadmechanicallyoncetheapplicationisdoneavoidingtheoperationunderneath.
 Useallthesupportingareaofthehydraulicjackasinthesaddleasinthetoe.
 Preventtheuseoftiltingsaddlesiftheriskofsideloadispresent.
 
Donotexposetheequipmenttointenseheatsourcessuchaswelding.
 Dothemaintenanceoperationswithfreeloadequipmentsandincleanandwell‐lightedareas.
 Oncetheoperationisfinished,checkfordamagesintheequipment,cleanandstoreitinasafetyway.
 Abadconnectionoftheplugs,etc.couldproduceabadfunctionoftheequipmentandcouldcreatedangeroussituations.
 Donotmodifytheequipment(weldedparts,lever…)withoutmanufacturer’sconsent.Donotusethehosesfortransportoperations.
 Beforestartinganyoperation,makesurethat:theinstallationiswelldone,thesafetyoftheworkstationfortheoperatorandassurethatnoauthorized
personnelcouldaccesstotheexposedarea.
 Therefore, the operator must be perfectly trained inthe use of the equipment and acts under the logical security standards that themovement of
heavyloadsincludes.
2.WARRANTY

LARZEP,S.A.guaranteesitsproductsagainstalldesignandmanufacturingdefectsforthedurationsoftwoyearsfromthedateofpurchase.
This guarantee does not include the ordinary wear of both metalandnon‐metal parts, abuse, usingthe equipment beyond itsratedcapacityand any wear or
damageincurredasaresultofusingahydraulicfluidwhichisnotrecommendedbyLARZEP,S.A.Pleasenotethatiftheequipmentisdisassembledorservicedby
anyoneotherthananauthorizedservicedealerorbyLARZEP,S.A.,thisguaranteeisrenderednullandvoid.
Intheeventofawarrantyclaim,returntheequipment,toLARZEP,S.A.ortheauthorizeddealerwhichsoldyouthehydraulicequipment,LARZEP,S.A.willrepair
orreplacethefaultyequipment,whicheverisdeemedmostappropriate.LARZEP,S.A.shallnotbeheldliableforanyconsequentialdamagesorlosses,whichmay
occurasaresultoffaultyequipment.

3.TECHNICALFEATURES








4.START‐UP
TheLARZEPhydraulictoejacksarecompact,easy‐handleandlight‐weightedforeasytransport,especiallysuitetoloadelevationinconfinedspaces.
Tostart‐upitisenoughtointroducetheleverinthebacksideofthejack,therearethreepositionstooptimizetheergonomics,andpumpseveraltimesuntilyou
reachthewishedheight.
Tolowertheload,youhavetoreleasetheleverandfindthereleasescrew.Turnthisscrewinanticlockwisesensetoreturnthepistonandtheload.
Thereturnspeeddependsontheangleofturninitially.Toavoidunwantedmovementsopenitinsmallangle.
Releasetheleverafterusingthejackandstoreitwithretractedpistonandinverticalposition.

5.MAINTENANCE
Thejackworksnormallyinenvironmentalstandardconditions,iftheproposaltemperaturesareveryextremeandtheyexceedthe‐20ºor+50ºC,consultthe
manufacturer.
Checkingtheoillevel,releasethedipstickandseeforthelevel,itislabelledwiththemaximumofoil,neversuperiorto5mmbyexcessordefectofthismark.
UsehydraulicoilofhighqualityHVIISO32viscosity;makesurethatisnotdirtyinsidetheoilwemustaddtothejack.
MODELS SADDLECAPACITY TOECAPACITY STROKE TOEHEIGHT CLOSEDHEIGHT WEIGHT
AU02015 20ton 8ton 152mm 67mm 276mm 15kg
AU02030 20ton 8ton 305mm 67mm 452mm 23kg
AU03015 30ton 12ton 152mm 73mm 281mm 21kg
AU03030 30ton 12ton 305mm 73mm 470mm 32kg
AU06015 60ton 24ton 152mm 78mm 327mm 44kg
AU06030 60ton 24ton 305mm 78mm 533mm 65kg

3
InstructionManual
HydraulicToeJack“AU”

6.DECLARATIONOFCONFORMITY

4
InstructionManual
HydraulicToeJack“AU”
GENERALSPAREPARTS“AU02015”“AU03015”“AU06015”“AU02030”“AU03030”“AU06030”

5
InstructionManual
HydraulicToeJack“AU”
Nº DESCRIPTION
1 LINER
2 RAM
3 BASE
4 CISTERN
5 RAM PACKING
6 LINER SEAL
8 CISTERN JOINT
9 BASE PLUG
10 BASE PLUG BALL
11 CISTERN SEAL
12 CISTERN SCREWS
13 FILLER SCREW
14 DIPSTICK
15 TUMBLER
16 TUMBLER ROLLER
17 TUMBLER PIN
18 TUMBLER ROLLER CIRCLIP
19 PUMP QUADRANT SHAFT
21 QUADRANT SHAFT SEAL
22 PUMP PLUNGER
23 PUMP PLUNGER SEAL
24 PUMP PLUNGER CLIP
25 PUMP BARREL
26 PUMP BARREL JOINT
27 VALVE BALLS
28 VALVE SPRINGS
29 SUCTION VALVE SCREW
30 DELIVERY VALVE SCREW
31 VALVE SCREW JOINT
32 SUCTION FILTER
33 RELEASE VALVE
34 RELEASE VALVE SEAL
35 RELEASE VALVE SPRING
36 RELE
A
SE VALVE SCREW
37 CISTERN BREATHER PIPE
38 OPERATING LEVER
39 OPERATING LEVER KEY
40 NAME PLATE
41 RELEASE VALVE INST.PLATE
42 NAME PLATE SCREW
ROUNDHEAD
43 RELEASE VALVE SCREW
46 RETAINING NUT FOR SCREWED
RAM MODELS
48 RAM WIPER
48 A RAM SCRAPER RING
49 RAM WIPER RET.RING
52 RAM CAP
Nº DESCRIPTION
53 RAM CAP SCREW
54 RAM CAP SCREW LOCKING WASHER
55 RETAINING PIN
56 CONTROL RING
57 TRIP BAR
58 TRIP PIN
59 SPRING FOR CONTROL RING
60 SEATING FOR VALVE
61 TRIP VALVE CAGE
62 TRIP VALVE SPRING
63 TRIP VALVE BALL
64 PLUG SCREW
65 SEAL WASHER
69 PUMP PACKING ANTIEXTRUSION RING
70 PUMP PACKING RETAINING SLEEVE
71 PUMP PACKING CIRCLIP
72 PLUNGER CLIP
73 PLUG SCREW
74 SEAL WASHER
79 RELIEF VALVE SUB-ASSEMBLY
88 BREATHER VALVE ASSEMBLY
166 RUBBER GAITER
173 RAM PACKING ANTIEXTRUSION RING
(
NOT ILUSTRATED
)
174 RAM LINE SEAL
175 TRIP VALVE CAGE
176 VALVE SUPPORT WIRE
178 RELEASE BALL CARRIER
179 TRIP VALVE BALL
180 RELIEF VALVE BODY SEAL
181 TRIP VALVE PLUNGER SEAL
182 TRIP VALVE PLUNGER
186 RELIEF VALVE ANTIEXTRUSION RING
