PRODUCT GUIDE
Mobilia MobiBed
with
Mobilia Module Insert Cushions,
Maress and Posiong Cushions

September 2015

September 2015
Mobilia MobiBed Product guide page 3
LASAL A/S, Industrivej 15, DK-8881 Thorsoe
Phone: [phone] * www.lasal.dk
Table of content
Presentaon of Mobilia MobiBed ........................................................................................ 4
Who can use Mobilia MobiBed ............................................................................................ 5
Benets of Mobilia MobiBed................................................................................................ 5
Standard funcons ............................................................................................................... 5
Accessories for posioning the user in Mobilia MobiBed.................................................... 5
Specicaons........................................................................................................................ 6
Mobilia Module Insert Cushions .......................................................................................... 7-8
Mobilia Maress .................................................................................................................. 9
Mobilia Posioning Cushions ............................................................................................... 10-12
Material specicaons ......................................................................................................... 13
Cleaning and maintenance .................................................................................................. 13
Disposal ................................................................................................................................ 13

September 2015
LASAL A/S, Industrivej 15, DK-8881 Thorsoe
Phone: [phone] * www.lasal.dk
4
Regardless of any reducon in funconal ability – and regardless
of how few resources an individual has – all children and adults
love to be part of the group.
People who are very immobile and who need to recline for many
hours in the day, oen experience that they are socially excluded.
This is because oen a bed or other kind of staonary locaon is
oen the preferred place for posioning the reclining person.
Regardless of how well-intenoned this posioning may be, the
user becomes excluded from the group. Reclining provides
physical support but not mental support.
Everyone enjoys being part of the community
Mobilia MobiBed means the user can be both mobile and social.
The transporter can be used for resng, stabilising, supporng
and yes of course, to transport the user around indoors. It creates
many posioning opons and is easy to adjust. These opons
allow the user to parcipate in several acvies, regardless of
whether the person needs to be in a reclining or sing down
posion.
1. Presentaon of Mobilia MobiBed
There are many opons with Mobilia MobiBed

September 2015
Mobilia MobiBed Product guide page 5
LASAL A/S, Industrivej 15, DK-8881 Thorsoe
Phone: [phone] * www.lasal.dk
1.1. Who can use Mobilia MobiBed? 1.3. Standard funcons
1.2. Benets of Mobilia MobiBed
 Children, young adults and adults with highly reduced
funconal ability
 People who have diculty sing in the same posion long
periods of me
 People with deformies, e.g. in the back or hip
 People with low muscle tone
 People, who primarily stay indoors and need to have mobile/
transportable posioning
 People who cannot move under their own volion
 People who need to be driven around by an escort
 People who need to change posion regularly, sing down or
lying down
 For resng, relaxaon, stability and transport.
 Simple to adjust and operate with electrically driven
adjustment of height, and back and foot support.
 Low-noise and durable LINAK control system. Environmentally
-friendly baery with connecon to 100 V - 240 V.
 Adjustment opons from reclining to sing up.
 The assistant’s working posture is improved signicantly
because of the height adjustment.
 Gives the user security and at the same me the opon of
parcipang in several acvies; at school, day care centre,
etc.
 Funcons as a social aid by increasing contact with users, who
need to recline a lot.
 Insert cushions and support cushions allow for unique
posioning adjusted to suit the individual.
 The user is mobile, even when he or she needs to stay in a
reclining posion.
 There are three length sengs in the back secon and three
in the seat secon, which allows for up to nine length
posions.
 Electrical raising and lowering funcon.
 Tilt funcon in the back and foot support.
 Can be used in reclining and sing posion.
 Electric-powered manual control of all electric-powered
adjustable sengs.
 Step adjustable handlebar.
 Parking brake on handlebar.
 Not suitable for use outdoors, though can be used on terraces
and other similar paved level surfaces.
 Supplied with one belt.
1.4. Accessories for posioning
We provide several products as accessories for posioning the
user in Mobilia MobiBed:
 Module insert cushions consist of separate cushions, which
can be put together using clasps.
 Visco elasc maress with removable cover with strap for
posioning cushion.
 As a supplement for the insert cushions, a series of Mobilia
cushions, Mobilia cushions have been developed, specially
made for use in the Mobilia MobiBed.
 Combined with the large LASAL cushion series, a soluon can
be found to suit any user, child or adult.

September 2015
LASAL A/S, Industrivej 15, DK-8881 Thorsoe
Phone: [phone] * www.lasal.dk
6
2. Specicaons
Max. length with handlebar and foot support fully extended 2150 mm
Max. width of Mobilia MobiBed measured across cushion frame bar 720 mm
Height of cushion frame measured from oor to top of bar
Lowest posion
Highest posion
500 mm
735 mm
Cushion frame length (adjustable)
Min. length
Max. length
1460 mm
1830 mm
Max. reclining dimension fully extended:
with Mobilia Maress (person height max. 172 cm)
with Mobilia Module insert cushion (person height max. 180 cm)
1835 mm
1930 mm
Wheel base between front and rear wheel measured from the middle of axle to middle of axle 720 mm
Total weight without insert cushion 55 kg
Load capacity
Safety tested to 120 kg
Ulisaon weight (max. person weight) recommended 90 kg
Front wheel diameter 200 mm
Rear wheel diameter 300 mm
Actuator, motor, li, back lt and leg lt - LINAK LA40-100 24 V Load 4000 N
Control box - LINAK CA40 - SMPS - IPX6 24 V
Built-in charger in control box. To charge connect: 100V/240V
Manual control LINAK HB83 3-way
Minimum dimension, e.g. when packing for transport: The transporter is folded together and
lowered to the lowest posion. The back is raised to maximum, the foot support is in the lowest
posion and the handlebar is pushed fully forward.
Length: 1340 mm
Width: 720 mm
Height: 1070 mm

September 2015
Mobilia MobiBed Product guide page 7
LASAL A/S, Industrivej 15, DK-8881 Thorsoe
Phone: [phone] * www.lasal.dk
3. Insert cushions
Mobilia MobiBed uses insert cushions, which are available in several sizes and models. The insert cushions are made from
comfortable materials and have removable and washable outer covers. The core insert cushions have a water-repellent and
antibacterial polyester cover.
In addition, the modules are equipped with a zip, so that the core filling can be varied as required. The removed filling is stored
in a fabric bag. Since the small beads can easily spill out, it is recommenced that when removing them, a sheet is placed below
the cushion.
Module Insert Cushions are made from three modules and can be compared to a beanbag chair. The modules can be shaped to
suit the user and surface. For users with Scoliosis or other severe deformities, this is a natural option for creating support and
comfort, in the sitting or reclining position.
Item No. Product Length Width Height Black cover Grey cover
164121 Module AB Back Cushion, size S 50 cm 65 cm 10/17/26 cm 164122 164129
164221 Module AB Back Cushion, size M 64 cm 65 cm 10/17/26 cm 164222 164229
164321 Module AB Back Cushion, size L 69 cm 65 cm 10/17/26 cm 164322 164329
Item No. Product Length Width Height Black cover Grey cover
1604141 Module D Foot Cushion, unisize 51 cm 65 cm 17/10/26 cm 1604142 1604149
Item No. Product Length Width Height Black cover Grey cover
164131 Module C Seat Cushion, size S 48 cm 65 cm 17/10 cm 164132 164139
164231 Module C Seat Cushion, size M 62 cm 65 cm 17/10 cm 164232 164239
164331 Module C Seat Cushion, size L 68 cm 65 cm 17/10 cm 164332 164339
The modules are assembled
using clasps in the sides.
All of the undersides of the modules are
covered with non-slip material.
The foot cushion is shaped to give good
support to the feet and lower legs.
3.1. Mobilia Module Insert Cushions
The back module consists of two separate inner cushions.
Module A (the smallest cushion) has a more solid lling to
support the head and neck. Module B has less solid lling, which
makes it more exible and can be shaped in accordance with the
user’s shape and requirements.
Module A
Module B

September 2015
LASAL A/S, Industrivej 15, DK-8881 Thorsoe
Phone: [phone] * www.lasal.dk
8
The illustraon shows a Mobilia Module Insert Cushion with black cover
made from 3D spacer, a material with increased airow.
Moving from a sing to a horizontal posion is simple and easy.
Mobilia MobiBed has an adjustable back and foot support, and the
height can also be adjusted.
The user can be posioned in either a reclining or lateral posion. It is
recommended to always transfer the user to/from the transporter
using a hoist.
Mobilia MobiBed is not equipped with a guard rail, so the belt must
always be used when the user has been moved into posion.
3.2. Posioning in Mobilia Module Insert Cushions
Cushions from both the Mobilia series and LASAL series can be used. The insert cushion can benecially be shaped before the user is placed on it,
so that the user can be placed deep into the material and thus achieve the
best support.

September 2015
Mobilia MobiBed Product guide page 9
LASAL A/S, Industrivej 15, DK-8881 Thorsoe
Phone: [phone] * www.lasal.dk
The Mobilia Maress consists of a TempraFlex® viscoelasc foam maress, where the “nest” is built up using loose posioning
cushions. This provides the real opon of creang individual posioning for the individual user. The same cushions can also be
used for posioning in a bed. The maress is available in three lengths with a washable cover.
MobiBed with Mobilia Maress with cover made from black spacer. The
cover is made from polyester. Rear with non-slip PU coang.
Straps are ed on the top of the maress, which are used to hold
the posioning cushions in place. In this example, a LASAL banana
cushion is being ed.
“The nest” is built up using loose posioning cushions from the Mobilia
series or the LASAL series.
The belt and straps on the Mobilia Maress are both used to keep the
cushions and user in posion.
The choice of cushions depends on the user’s desired posioning.
Mobilia Neck Cushion to
support head posion
Belt ed across
the hip.
3.3. Mobilia Maress
Item No. Product Length Width Height Black cover
165101 Maress, size S 148 cm 65 cm 7 cm 165102
165111 Maress, size M 163 cm 65 cm 7 cm 165112
165121 Maress, size L 183 cm 65 cm 7 cm 165122

September 2015
LASAL A/S, Industrivej 15, DK-8881 Thorsoe
Phone: [phone] * www.lasal.dk
10
3.4. Mobilia Posioning Cushions
Child sing on a Mobilia Maress. LASAL Banana supports the neck
and back. NB: The straps hold the banana cushion in posion. LASAL
Crescent supports the arms. Mobilia Triangular Cushion supports the
knees and the LASAL T-Cushion corrects the feet’s direcon and lis
the heels from the surface.
Reclining, LASAL Banana Cushion, Crescent, T-Cushion, and Mobilia
Triangular Cushion under the knees.
Child lying in a circle of LASAL Banana Cushions.
The body is well-supported, which at the same me provides a feeling of
security and protecon.
Lateral posion, encircled by two LASAL Bananas, front and rear.
T-Cushion is to support upper leg.
Child sing, again with LASAL Banana Cushion to stabilise the upper
body, LASAL T-Cushion for abducon of knee. Lower leg and feet
resng on LASAL Large Square.

September 2015
Mobilia MobiBed Product guide page
LASAL A/S, Industrivej 15, DK-8881 Thorsoe
Phone: [phone] * www.lasal.dk
Mobilia Positioning Cushion series is specially made for use with the Mobilia MobiBed, but naturally can also be used in other
situations.
In addition to the Mobilia series, cushions from the LASAL series of positioning cushions can also be used (see the product guide
for LASAL Positioning Cushions).
The loose positioning cushions are placed around the user in the lying/sitting position on the Mobilia Mattress, which is also
equipped with straps for securing, for example, the Banana Cushion (LASAL series). The two-part hip belt also helps to hold the
cushions and user in the desired position.
The inner cushions are made from a stretchable and water-repellent material with a removable and washable cover.
Item No. Product Length Width Height Cushion alone Grey cover
164530 Triangle Cushion incl. cover 68 cm 24 cm 21 cm 164531 164539
Product Length Width Height Cushion alone Grey cover Black cover
Wedge Cushion incl. cover 45 cm 64 cm 10 cm 164541 164549 164542
In the supine posion, the triangular cushion is placed under the hollow
of the knees to correct any distorons and relieve the lower back. The
legs sink into the cushion and prevents light abducon of the knee and
hip. It can also be used behind the back in the lateral posion. The
Triangular Cushion is moderately lled and thus easy to shape. Matching
width for Mobilia MobiBed
The Wedge Cushion is almost as high as the Triangular Cushion and is
used to provide relief for the knee and lower leg, where there is a need
for a slight li. The cushion is placed between the hollows of the knee
and seat. The cushion can be shaped and also provides good relief for
the lower back.
The Wedge Cushion in combinaon with the LASAL T-Cushion.
3.4. Mobilia Posioning Cushions

September 2015
LASAL A/S, Industrivej 15, DK-8881 Thorsoe
Phone: [phone] * www.lasal.dk
12
Item No. Product Length Width Height Cushion alone Grey cover
164520 Gouda Wedge Cushion incl. cover 30 cm 31,5 cm 4 cm 164521 164529
Ideal as support for head and neck in reclining posion
and lateral posion. The cushion’s shape is formed by
stching and provides rm support.
Item No. Product Length Width Height Cushion alone Grey Cover
164510 Neck Cushion incl. cover 36 cm 6,5 cm 10 cm 164511 164519
A rm cushion, whose shape is stched with high sides.
Place behind the neck to support and correct in the
reclining or sing posion.
The belt is available in two lengths, and is secured to either
reclining surface bar or the frame under the reclining surface.
If only a single belt is used it should be posioned across the
hip of the user. If two belts are used, they should posioned
as a cross on top of the user.
NB: The belt does not prevent the user from sliding forward.
Item No. Product Length Width
166221 Belt, size S 125 cm 10 cm
166201 Belt, size L 137 cm 10 cm
3.4. Mobilia Posioning Cushions
Avoid sharp edges and pointed items
that can poke holes in the cushions.

September 2015
Mobilia MobiBed Product guide page
LASAL A/S, Industrivej 15, DK-8881 Thorsoe
Phone: [phone] * www.lasal.dk
Insert cushions and cushion accessories
The inner cushion: 100% PU covered and ame retarded polyester.
Filling: Flame retarded expanded polystyrene (EPS) beads.
Maress: TempraFlex® viscoelasc foam, OEKO-TEX®-cered and ame retarded.
Maress cover: 100% PU covered and ame retarded polyester.
Removable and washable cover in respecvely, grey single jersey and black spacer:
Grey cover:
100% bio-based (Lenzing/Tencel), skin-friendly, OEKO-TEX®-cered material.
The so and comfortable cover ts ghtly around the cushion and helps the body to sink pleasantly into the material. The fabric’s rear is
covered with a polyurethane lm, which prevents liquids penetrang. The cover also has an anbacterial barrier, is temperature regulang,
breathable and ame retarded.
Black cover:
Mobilia modules and maresses are available with a cover made from black spacer (3D) 100% polyester, OEKO-TEX®-cered and ame
retarded. The cover has an aracve design, 3D eect and also helps the increase the airow in the material. The thick material is
comfortable to lie in and provides a xed base in the so cushions.
Both covers on the Module Insert Cushions and Maress are ed with a non-slip boom.
4. Material specicaon
The inner cushion and maress cover do not tolerate chemical cleaning and may not come into contact with solvents, as these can dissolve
the polystyrene beads and damage the maress. The cushion and cover can be wiped o using alcohol or normal cleaning products and
water.
Outer cover:
Grey single jersey:
Wash at 60° C and dry in tumble dryer set at low heat. Does not tolerate bleaching agents or chemical cleaning.
Black spacer:
The polystyrene cover can be machine washed at 40° C but cannot be dried in a tumble dryer. Does not tolerate bleaching agents or chemical
cleaning.
5. Cleaning and maintenance
6. Disposal
Cushions and maresses may be disposed of in ordinary household waste.
