Laser Technology CR40C User manual

南京晨锐腾晶激光科技有限公司
NANJING CRD LASER TECHNOLOGY CO., LTD
CR40C Laser
Operator’s Manual

南京晨锐腾晶激光科技有限公司
NANJING CRD LASER TECHNOLOGY CO., LTD
Table of contents Laser Safety
Dangerous Warning..…………………………………………………………………………………… .2
Possible injury……………………………………………………………………………………………2
CR40C label icon………………………………………………………………………………………2,3
Safety regulations ………………………………………………………………………………………..3
Getting Started
Packaging inspection …………………………………………………………………………… ………4
Packing List………………………………………………………………………………………………4
Optional configuration……………………………………………………………………………………4
Operation
Fan connection and installation requirements……………………………………………………………5
Figure1: Standard fan installation method………………………….……………………………………6
Figure2:Technological hole mustn’t be used…………………….………………………………………6
Choice and connection of power………………………………………………………………………6,7
Control signals connections...…………………………………………………………………………….7
Tickle pulse signals ….. ………………………………………………………………………………… .7
PWM signals ………………………………………………………………………………………….7,8
The back panel Description…………………………………………………………………………….8,9
Series CR Parameters and Installation diagram
CR Series laser parameter table………………………………………………………………………....10
CR40C Installation diagram……………………………………………………………………….…....10
Figure 1：The panel Description…………………………………………………………………….….11
Figure 2：CR40C Outline diagram……………………………………………………………… …… 12
Figure 3：CR40C Mounting hole…………………………………………………………………….…13
CRD Laser after-sales service commitment
CRD Laser after-sales service commitment………………………………………………………... 14,15

南京晨锐腾晶激光科技有限公司
NANJING CRD LASER TECHNOLOGY CO., LTD
Laser Safety
Dangerous Warning:
Danger: Imminent hazards which, if not avoided, will result in death or serious
injury.
Warning: Potential hazards which, if not avoided, could result in death or serious
injury.
Caution: Potential hazards or unsafe practices which, if not avoided, may result
in minor or moderate injury.
Caution: Potential hazards or unsafe practices which, if not avoided, may result
in product damage.
Possible injury:
CR40C CO2Lasers emit invisible infrared laser radiation at the 10.6 µm CO2
wavelength. Since direct or diffuse laser radiation can inflict severe corneal and skin
injuries, always wear eye protection when in the same area as an exposed laser beam.
CR40C Label Icon
①②③
④⑤
◆75 WATTS MAX，Wavelength 10200-10800nm.

南京晨锐腾晶激光科技有限公司
NANJING CRD LASER TECHNOLOGY CO., LTD
◆Class 4 laser product, Invisible laser radiation, Avoid eye or skin exposure to direct
or scattered radiation
◆Laser Radiation Warning.
◆Laser label. Model: CR40C; Serial Number: 309001；Production date: January
4th,2009
◆Anti-action label removed, damage cannot be maintained.
Safety Regulations:
Use CR Series RF CO2 laser equipment should be consistent with The People's Republic
of China National Standard GB10320 and GB7247.1.

南京晨锐腾晶激光科技有限公司
NANJING CRD LASER TECHNOLOGY CO., LTD
Getting Started
Inspection the packaging:
1. Inspect all shipping containers for signs of damage, severe deformation and damp.
2. Inspect the integrity of the sealing tape.
3. Inspect the position of Laser in the box is correct after the unpacking (loose in the
package of plastic bubble).
Packing List:
◆Laser ◆Manual ◆Test Report ◆Delivery note
Optional configuration:
◆Direct Current power.

南京晨锐腾晶激光科技有限公司
NANJING CRD LASER TECHNOLOGY CO., LTD
Operation
Fan connection and installation requirements:
Shell on the chassis shall be fitted with exhaust devices (exhaust fan can be
installed in the chassis in whole or in the middle of both sides of the chassis)and
the chassis are required to have vents，Chassis to ensure the air can be recycled,
heat can be promptly discharged from the chassis to ensure a good thermal
performance lasers.
Laser front and back covers are laser’s mirror stand, cannot hard contact with any
part of the machine frame, or the laser may be damaged. Could use soft materials
contact with the front cover to seal the light path and protect the laser window
lens.
The installation of a fixed laser floor thickness shall be not less than 8MM, in
order to prevent equipment working on the laser optical vibration impact.
Choice and connection of Power:
◆DC switching power chose by customer will be matched to the requirements
CR40C lasers, Voltage is 48V, current should be not less than 12.5A.
◆The diameter of connecting wire between DC power supplier and laser tube
should be larger than 2.5mm2. The connection cannot be reversed between the
power and laser; otherwise it will damage RF Driver IV
Control signals connections:

南京晨锐腾晶激光科技有限公司
NANJING CRD LASER TECHNOLOGY CO., LTD
◆The external control signals of CR40C Laser are accessed through the back panel
BNC connector of the laser.
Pulse width modulation (PWM):
CR40C Laser is controlled laser power by Pulse width modulation (PWM). The
low voltage range should be 0 to 0.5V (laser off), the high voltage, ranges should be
+3.5V to +5V (laser on). Pulse width modulation or PWM, controls laser power by
varying the duty cycle which is supplied by the external controller. The modulation
frequency is 0-20KHZ. The duty cycle is 0-100%.
As following:Waveform shown below is a typical 0-5V for PWM signal, duty
cycle (or Pulse width) and frequency is adjustable:
The Preionization Signal:
CR40C have preionization signal, do not need to add preionization signal. If add
preionization signal from the external controller, it may cause laser light leak.

南京晨锐腾晶激光科技有限公司
NANJING CRD LASER TECHNOLOGY CO., LTD
The back panel Description:
The panel including (see Installation Figure 1): ● Power input terminals ●Switch
●Power indicator light(green light) ● Laser indicator light(green red) ●BNC
connector(signal input)
Specific steps are as follows:
1. 48VDC power access to laser power input terminal block. +connect
+,-connect-.
2. The external controller signals access to laser BNC connector through
Coaxial cable. The inner core of BNC connector connects with + of PWM
signal. The shell of BNC connector connects with ground of PWM signal.
3. Open the DC power, at this time the green indicator should illuminate (shown
that Laser has been normally powered). PWM signal is set to a certain duty
cycle by Controlling card software on the computer, at this time the red
indicator should illuminate (shown that it has laser output).

南京晨锐腾晶激光科技有限公司
NANJING CRD LASER TECHNOLOGY CO., LTD
Series CR Lasers Parameters and Installation
diagram
1. Series CR Lasers Parameters
Model
CR40C
CR40Ch
CR40Ci
Wavelength
10.6μm
10.2μm
9.3μm
Power
>45W
>40W
>30W
Power Stability
<±5％
Model Quality
M2<1.2
Beam Waist Size
2±0.2mm
Beam Divergence
<7mrad
Polarization
>100：1 Horizontal
Modulation
0-25kHz，0-100%
Power Supply
48VDC/10A
Cooling
Air cooling/water cooling 4L/M
Heat Dissipation
500W
Dimensions
Air cooling 357×93×145/water cooling 357×93×95
Life
20000Hours
2. CR40C Installation diagram

南京晨锐腾晶激光科技有限公司
NANJING CRD LASER TECHNOLOGY CO., LTD
CRD Laser after-sales service commitment
Dear customers:
Thank you for purchasing series CR lasers from Nanjing CRD Laser Technology
Co., LTD., in order to relieve your worries; we will make our warranted services for
you, as the following commitments:
1. Free warranty 18 months
Since you purchased this product from Nanjing CRD Laser (Subject to
delivery), the product will be warranty free for 18 months.
2. Maintenance services methods
If yours the series CR laser have malfunctions, you can consult us by Web site
of the Nanjing CRD Laser Company or on the telephone, and then after confirming
the malfunction still cannot be eliminated, please send the laser to Nanjing CRD
Laser Company by courier, Please contact with salesperson of Nanjing CRD for
detailed address.
3. Disaster recovery period (5days)
When we receive your laser been repaired, we will inspect the laser as soon as
possible, and repair it as the fastest speed (5days) and send to your hands by express.
We can provide temporary back-up machine according to your choice,
exempting from your worries at the maximum degree.
4. Case of no belonging to free warranty obligations
Belongs to the following conditions, No matter whether the product is during the

南京晨锐腾晶激光科技有限公司
NANJING CRD LASER TECHNOLOGY CO., LTD
Belongs to the following conditions, No matter whether the product is during the
period of free warranty, are not within the free warranty:
■The fault or the damage caused by without following manual request, wrongly
install or use and so on.
■ Maintenance by non-manufacturers, the man-made treatment of customer
resulted in failure and damage.
■ Warranty stickers were damaged.
■Due to majeure of natural disasters (such as earthquake, fire, etc.), that caused
failure or damage.
■Other quality issues itself are not the fault or damage caused.

2
0
2
03
5
65.5
93
356.4
270.4 12.5 12.5
83
64
6
5
.
5
9
48V DC + 48V DC -
1
4
5
30.5
1
0
.
9
12.95
LASER OUTPUT
4-M38
标记 处数 更改文件号 签 字 日期
设 计
日 期
图 样 标 记 重 量 比 例
共 张 第 张
CRD
CR30C OUTLINE
CR30CWX
BNC
1:1
2016.6.28
借 (通) 用
件登记
旧底图总号
底图总号
签 字
日 期
日 期
档案员
CR30CWX
BNC/PWM+
BNC/PWM G
DC LED/GREENLASER LED/GREEN

2
0
2
03
5
6
5
.
5
65.5
93270.4 12.5 12.5
378.4
356.4
Ø6.4
6438.1
9
4
.
8
DC LED/GREEN
BNC/PWM+
BNC/PWM G
LASER LED/GREEN 48V DC + 48V DC -
LASER OUTPUT
标记 处数 更改文件号 签 字 日期
设 计
日 期
图 样 标 记 重 量 比 例
共 张 第 张
CRD
CR35CL OUTLINE
CR35CL.WX
1:1
2016.6.28
借 (通) 用
件登记
旧底图总号
底图总号
签 字
日 期
日 期
档案员
CR35CL.WX
4-M38
