SPK-BT520
1
QUICK USER MANUAL
IMPORTANT SAFETY INSTRUCTIONS AND PRECAUTIONS
- Read all instructions carefully before use.
- Retain manuals for future reference.
- Use this product only in the manner described.
- Only use a water-dampened soft-cloth to clean the surface of this product.
- The following will damage this product: any liquid such as water or
moisture, extreme heat; cold; humidity, dusty or sandy environments.
- Only place this device on stable surfaces and ensure that any attached
cables are secure and will not cause thedevice to fall.
- There are no user serviceable parts in this product.
- Un-authorized attempts to dismantle or repair this product will void product
warranty
- Using this device near other electronic devices may cause interference.
PACKAGE INCLUDES
Bluetooth Speaker, USB cable, 3.5mm Audio cable, Usermanual
SPK-BT520
2
QUICK USER MANUAL
BUTTONS AND CONNECTIONS
Feature
Function
1 Mode
Toggle between Bluetooth and FM
Radio Mode (and Micro SD Card, USB
and Auxiliary when connected)
2
Press for p
revious /
Hold to
decrease Volume
Turn volume DOWN
/ Goto next track
or radio station
3
Press for
Next /
Hold to i
ncrease
Volume
Turn
volume UP
/ Goto previous
track or radio station
4
Play /Pause /
Press to answer call
/ Hold 3 Secs to Reject Call
Play and pause music playback or
answer or reject phone calls
5 LED Indicator (inside speaker)
Displays charging and Bluetooth
status
6
Micro SD Card Slot
Playback music files from storage
7
USB Slot
Playback music files from storage
8
Power On / Off button
Turn speaker ON or OFF
9
Micro USB
/ AUX S
lot
(Via
supplied cable) Charge you speaker via this port
LED Indicator
Status of the
speaker
Blue LED light flash
Pairing
mode
Blue LED light flash slowly
Bluetooth c
onnected
Solid
Blue LED light
Phone call received (during music playback)
Red LED light
ON
Battery is charging
Red LED light
OFF
Battery is full
1
2
3
4
5
6
7
8
9
SPK-BT520
3
QUICK USER MANUAL
CHARGING THE BATTERY
Before using, fully charge the battery using the supplied USB cable. Plug in to
any USB port supplying power (Computer, AC Charger,Car Charger, etc.)
A solid red LED indicates that the speaker is charging, the battery is fully
charged after about 2-3hrs.
POWER ON/OFF
Move the power switch to the “on” or “off” side to power on /off the device.
Note: Modes other than Bluetooth and FM radio will only be available
if there is an Audio storage device connected to the speaker.
BLUETOOTH® PAIRING
- Turn thespeaker ON. By default the first mode will be Bluetooth mode and the
indicator light will beflashing.
- Enable the Bluetooth function on your mobile deviceand search for
the Bluetoothspeaker. (SPK-BT520)
- Pair and connect to the speaker.
Note: Ifprompted, enter the pairing code0000.
FM RADIO MODE
Note: Please plug the Micro USB Cable into your speaker, as this will act as
the antenna in FM Radio MODE.
- PressthePLAY/PAUSEbutton toautomaticallysearch and save all available
radio stations. The blue indicator will flash while searching.
- When finished, press PREVIOUS orNEXT button to select previous or next
station.
OTHER MODES
- PresstheMODEbuttonto toggle betweentheaudiosources, when
connected. (Bluetooth / Micro SD Card /USB / FMRadio / AUX.)
- Connect external audio devices and storage to the provided inputs. Playback
will start straight away.
Note: Modes other than Bluetooth and FM radio will only be available
if there is an Audio storage device connected to the speaker.
SPK-BT520
4
QUICK USER MANUAL
HANDS-FREE FOR CALLING
Answer or reject a call by pressing the Play button once quickly.
Reject a call by pressing the Play button for about 3 seconds.
Redial the last call by pressing the Play Button twice shortly.
Note:After making or dropping a call the speaker willre-startyour music.
SPECIFICATIONS
Bluetooth Version
V
3.0
Profiles
HSP, HFP, A2DP
Play Time
Up to
4
hours
Charge Time
Up to
2 hours
Production Dim
ensions
108
x
35
x
55mm
Warranty Against Defects
Laser Corporation Pty Ltd (“Laser”) warrants your new product to be free from defectsin materials and workmanship for 12
months, from the date of purchase, provided that the product is used in accordance with accompanying recommendations
or instructions where provided. Thebenefit ofthis warranty is in addition to your rights under the Australian Consumer Law
and to other rights and remedies of the consumer under a law in relation to the goods or services to which the warranty
relates.
Through a network of retailers and resellers, Laser will provide you with your choice of a repair, exchange (where possible)
or refund (within Dead on Arrival period) for this product if it becomes defective within the warranty period.
This warranty will no longer apply where the defect is a result of alteration, accident,misuse, abuse,normal wear and tear,
neglect or improper storage. Please retain your receipt as proof of purchase
How to make a product warranty claim:
Step 1: Find your receipt which proves the date of purchase. Where the date of purchase cannot be verified, your place of
purchase or Laser will make an assessment based on the date of manufacture, the condition of the Laser Product and the
type of defect.
Step 2a): Contact your place of purchase. They will assess the nature of the fault and repair, replace or fund the product as
per their store refund or warrantypolicy.
Step 2b): If your place of purchase cannot be contacted, then youcancontact Laser.Customer Service with details ofyour
defective Laser Product: Phone: (02) 9870 3388; or Email: support@laserco.com.au or online www.laserco.com.au/warranty
(click on “Consumers (End Users)”). Our business addressis at 1/6-8 Byfield Street, North Ryde, NSW 2113
Step 3: Laser will issue you with a Return Authorisation (RA) number within 48 hours. When requested,send us the
defective Product and a copy of yourreceipt. Laser will cover the cost of the return delivery.
Step 4: Wait for us to contact you. Once we have received your defective Laser Product for inspection, we will inform you
of our assessment of your claim within 7 days. When we contact you, we will firstly let you know whether you have a valid
claim under this Warranty, and if so, we will inform you whether your defective Laser Product will be replaced or repaired,
together with the number of days you can expect to wait to receive your replaced or repaired Laser Product.
Step 5: For further details on warranty cover and returns, please check Terms and Conditions for Warranty Returns section
on http://www.laserco.com.au/warranty
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and compensation for anyother reasonably foreseeable loss or damage. You are
also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure doesnot
amount to a major failure.
