Laser SPK-BTSTP User manual

Bluetooth Version: 5.0
Bluetooth Range: 10 meters
Bluetooth Name: SPK-BTSTP
Built in Microphone: For hands free calls
Battery: 3.7V 500mAh
Battery Runtime: Approx 2 hours (at medium volume)
Speaker Driver Size: YЀNN
Speaker Power: 1 x 5W
Frequency Response: 120Hz – 20 KHz
Product Dimensions: 86.5 x 72.3 x 31.6mm
Charging: 5V
:+$7·6,17+(%2;
• 1 x SPK-BTSTP Speaker
• 1 x Micro USB cable
• 1 x User Manual
63(&,),&$7,216
Manual
Laser Pocket Speaker
SPK-BTSTP

1. Micro USB
vInsert one end of cable into the Micro USB Port and the other end
into a USB wall adapter (not included) to start charging.
vApprox 6 - 8 hours for a full charge.
vThe Micro USB cable also provides better FM reception.
vA fast blinking blue light signals the device is in BT pairing mode.
vA slow blinking blue light signals the device is ON.
vA red light signals the device is charging.
2. Micro SD Card
v0OMZ.1GJMFTPO'"5PSFY'"5GJMFTZTUFNBSFTVQQPSUFE
v1MFBTFUSZGPSNBUUJOHTUPSBHFUPTVHHFTUFEGJMFTZTUFNJGOPU
detected.
3. USB
v0OMZ.1GJMFTPO'"5PSFY'"5GJMFTZTUFNBSFTVQQPSUFE
v1MFBTFUSZGPSNBUUJOHTUPSBHFUPTVHHFTUFEGJMFTZTUFNJGOPU
detected.
4. Power vTurn device ON/OFF
5. Mode vTap to change between Bluetooth, FM, Micro SD or USB.
vTap to SKIP between stations in FM Mode.
6. - vHold to decrease volume.
vTap to SKIP backwards between stations or tracks.
7. + vHold to increase volume.
vTap to SKIP forwards between stations or tracks.
8. Play/Pause
vTap to PLAY/PAUSE when using USB, Micro SD Card or Bluetooth
mode.
vTap to start AUTO SEARCH function when using FM Radio.
&21752/6

)($785(6
• Bluetooth Wireless Connectivity (can be used for phone calls)
•64#o6QUPHCBOE'"5PSFY'"5mMFTZTUFNPOMZ
•.JDSP4%$BSE6QUPHCBOE'"5PSFY'"5mMFTZTUFNPOMZ
• TWS – True Wireless Stereo
• FM Radio
• AUX IN
• Rechargeable Battery
%/8(7227+
• Turn on the speaker and tap “M” until “BLUETOOTH MODE” is heard (by defaultthe
device should turn ON in BT mode).
• Search for “52-$6562” under the Bluetooth settings of device being connected.
7,3,ISDVVZRUGLVUHTXHVWHGHQWHU´µ
)05$',2
• Tap Play/Pause to start the AUTO SEARCH function for FM stations.
• This operation will scan all FM stations and record them to memory.
•The scan procedure will take 1 -2 minutes to complete and should not be interrupted.
• Once complete you can tap + or - to skip between the saved stations.
7,3&RQQHFWD0LFUR86%FDEOHLQWRWKHFKDUJLQJSRUWWRLPSURYH)0UHFHSWLRQ
758(:,5(/(6667(5(27:6
63($.(565(48,5('
• Turn ON both speakers and switch them into Bluetooth mode.
• Press and hold Mbutton on one of the speakers.
• A sound will be heard which indicates the speakers are now connected for TWS.
• You can now connect one of the speakers to a Bluetooth source device and when
music/sound is played it will come through on both speakers.
•7RWXUQRII7:6SRZHUGRZQRQHRIWKHVSHDNHUVWKHUHLVQRRWKHUZD\WR
GLVFRQQHFW7:6

For more
helpful guides
visit us at
LASER
www.youtube.com/LasercoAu
WARRANTY
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. Youare entitled to a replacement
or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have
the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
www.laserco.com.au
7528%/(6+227,1*
1R3RZHU
1.Check battery level and charge if required.
2.Try turning on speaker while connected to power source.
3.Try charging with USB Wall Adapter instead of a laptop/computer.
5DGLRQRWFOHDU
1.Change speaker location.
2.Connect a Micro USB cable into the charging port to improve FM
reception as this also doubles as an aerial.
3.Isolate speaker from other devices as this may be caused by
interference.
86%RU0LFUR6'&DUGQRWUHFRJQLVHGRUÀOHVQRWSOD\LQJ
1.Make sure the USB or Micro SD Card is 32gb or less.
2.Check USB or Micro SD Card has been formatted to the FAT32 or
FY'"5mMFTZ TUFN*GOPUQMFBTFGPSNBUPOB8JOEPXTCBTFEDPNQVUFS
3..BLFTVSFUPPOMZVTF.1NVTJDmMFTDPQJFEUPUIF64#PS
Micro SD Card.
