Lasermate S200111-650 User manual

Product Specification and User Manual
Lasermate Group, Inc. Visual Fault Locator, Fiber Checker R01.1220
Fiber Checker Optical Testing Tool
Description
The Fiber Checker is a particularly useful tool designed for checking the defects of a fiber cable. It emits a visible 650 nm
wavelength red laser light through fiber optic cables, then if there are breaks or defects in the fiber will refract the light, creating
a bright glow around the faulty area. The universal connector can be used for all the most widespread fiber interfaces such as
ST / SC / FC connector. It is suitable to test both Single mode and Multimode cables. With an optional 2.5 mm to 1.25 mm
optional Adapter, you can easily test 1.25 mm diameter fiber LC or MU connector. The visibility is from 3 km to 5 km
dependent upon the output power of the Fiber Checker.
Internally there is also a specifically designed power circuit called an APC (Auto Power Control) circuit which provides steady
power. The APC prevents unstable laser output when the battery is low. The LD output signal can be switched to CW or Pulse
Mode to obtain different visual effects. There is a dust cap which will prevent dirt from getting into the LD connector. The cover
also prevents accidental exposure of the laser beam into anyone’s eyes.
Features
•Easy to check fiber faults by using 650 nm visual red laser
•Range: visibility up to 3 ~ 5 km
•Universal Connector for testing additional ST, SC, FC, MU, and LC interfaces when using our Optional Adapter
•Operates with both Single mode and Multimode cables
•Highly effective power circuits designed for stable laser power
•Operating in both Continuous Wave (CW) & Pulse Mode
•Dustproof cap keeps fiber connectors clean
•Powered by two AAA-size alkaline batteries
•LED indicator for Power On, Battery Low alerts
Applications
•Installation and Maintenance CATV / Telecom / FTTH in fiber optical fiber networks.
•Installation and Maintenance 4G / 5G mobile system.
•Installation and Maintenance data center network.
•Testing in standard laboratories.
•High throughput quality assurance.

Visual Fault Locator, Fiber Checker Product Specification and User Manual
Lasermate Group, Inc. Visual Fault Locator, Fiber Checker, Pen Style R01.1220
Specifications
Fiber Checker
Laser Class
Class 2M
Wavelength
650 nm ± 10 nm @ 25oC
Spectral Width
<10 nm
Output Power
> 0.5 mW @ 25℃into 9 μm fiber
Output Power (Part number -1)
> 1 mW @ 25℃into 9 μm fiber
Output Power (Part Number -2)
> 2 mW @ 25℃into 9 μm fiber
Mode
Continuous Wave / Pulse Mode
Battery Type
AAA [1.5 V x 2]
LED Indicator
GREEN Light - Power On
RED Light - Battery Low
Emitting Range
Visibility to 3 ~ 5 km
Operating Temperature
0oC ~ 50oC
Storage Temperature
0oC ~ 70oC
Weight
0.06 kg
Dimensions
132 x 34 x 19 mm
Dimensions (unit: mm)

Visual Fault Locator, Fiber Checker Product Specification and User Manual
Lasermate Group, Inc. Visual Fault Locator, Fiber Checker, Pen Style R01.1220
Operating Instructions
1) Dust Cap: prevents dirt
contamination of the LD
connector.
2) Button: pressing to Turn On /
Turn Off the LD emitting.
3) Mode Switch: slide to select
Continuous Wave or Pulse
Mode.
4) Pen Clip: to fasten the tool
while inside pocket.
5) Battery Lid: open to change
batteries.
6) Linchpin: mechanical design
to lock the battery lid.
1. The Fiber Checker is powered by two 1.5 V AAA batteries
2. To check if the power is on press the button and see if the LED is GREEN.
3. Lift the front of the dust cap up and insert on end of the fiber connector to the universal connector or directly insert
onto an output connector of the fiber or patch cord.
4. Switch to Continuous Wave or Pulse Mode.
5. Press the Button and check for breaks or defects in the fiber that will refract the light, creating a bright glow around
the faulty area, as shown below in Illustration 1.
6. When the LED is RED, the batteries are in low voltage status and must be replaced.
7. Do not touch the fiber’s interface to avoid getting dirt in the connector.
8. Keep the fiber connector capped at all the times when the device is not in use.
9. Clean the fiber before testing so as to obtain accurate results and longer service.

Visual Fault Locator, Fiber Checker Product Specification and User Manual
Lasermate Group, Inc. Visual Fault Locator, Fiber Checker, Pen Style R01.1220
Maintenance
This tool requires no maintenance other than periodic battery changes. Like any other electronic equipment, this tool should be
kept away from water, high damp, dust, electricity, and environments of extreme temperature. The Fiber Checker has an
internal fiber stub that requires periodic cleaning with specific cleaning tools, as shown in Illustration 2. The Fiber Checker is
fragile and must not be dropped on a hard surface. Modifying any of this tool’s internal components can cause a malfunction
and will invalidate the manufacturer’s warranty.
Warranty
The manufacturer warrants this product to be free of defects in workmanship and materials for a period of 10 months after
purchase. This warranty (excluding batteries) is solely limited to the repair and replacement of original parts, which are
defective in workmanship of materials. All other costs are the sole responsibility of the owner. This warranty does not cover
any defects, damage, or deterioration due to misuse, alteration, or negligence.
Ordering Information
Part Number
Wavelength
Output Power
S200111-650
650 nm
> -3 dBm (0.5 mW)
S200111-650-1
650 nm
> 0 dBm (1 mW)
S200111-650-2
650 nm
> +3 dBm (2 mW)
S200411
LC adaptor, 2.5 mm to 1.25 mm
S200421
MU adaptor, 2.5 mm to 1.25 mm
Note: Specifications are subject to change without notice.
