Laserworld PRO-300G User manual

PRO-300G
USER MANUAL
Please read this manual carefully before use!

USER MANUAL: Laserworld Proline PRO-300G
Date: 01/200
Page
2
of
15
I
Table of contents
Page
1. SAFETY INSTRUCTIONS 3
2. OPERATING DETERMINATIONS 4
3. OPEN THE BOX FOR CHECKING 5
4. INSTALLATION 5
5. ATTENTION 6
6. SCAN MOTOR REPLACEMENT 7
7. ADJUSTABLE MIRROR HOLDER
. CONTROL BOARD INSTRUCTION 9
9. DMX512 OPERATE 10
10. MAINTENANCE 11
11. TECHNICAL SPECIFICATIONS 11
12. ELECTRICAL DIAGRAM 12
13. TROUBLE SHOOTING 13
14. APENDIX: ILDA PINOUT 14
hecking Parts
Please check if the following parts are included:
1 x PRO-300G Laser
1 x Power cable
1 x User manual

USER MANUAL: Laserworld Proline PRO-300G
Date: 01/200
Page
3
of
15
DANGER LASER RADIATION!
Avoid direct eye exposure!
Laser radiation can cause eye damage and/or skin damage
All protective measures for a safe operation of this laser must be applied.
1. SAFETY INSTRU TIONS
- If the device has been exposed to drastic temperature fluctuation, do not
switch it on immediately. The arising condensation water might damage your
device. Leave the device switched off until it has reached room temperature.
1. The laser must only be used for shows. The operation is only allowed if it is
controlled by a skilled and well-trained operator.
- Never leave this device running unattended and keep it away from children
and unauthorized persons.
2. Keep away from heaters and other heating sources. In order to safeguard
sufficient ventilation, leave 50 cm of free space around the device.
3. Never direct the laser beam to people or animals.
4. CAUTION LASER DIODE: Never unscrew the housing!
There are no serviceable parts inside the device. Maintenance and service
operations shall only be carried out by authorized dealers.
5. Always disconnect from the mains when the device is not in use or before
cleaning it.
- HEALTH HAZARD! Never look directly into the light source, as
sensitive persons may suffer an epileptic shock!

USER MANUAL: Laserworld Proline PRO-300G
Date: 01/200
Page
4
of
15
2. OPERATING DETERMINATIONS
6. The operator has to make sure that laser radiation – also reflected laser
radiation –higher than the highest allowed level is avoided by technical or
organisational measures.
7. Make sure that the used voltage is : AC 220V~240V, 50/60Hz
. If the device is used in a flying installation, the mounting brackets and an
appropriate safety-rope must be fixed.
9. Laser effects are not designed for permanent operation. Consistent operation
breaks will ensure that the device will serve you for a long time without
defects.
10.In some countries, the operator must notify the accidence insurance and the
authority for industrial safety, before operating a laser. For more information,
contact the relevant authorities.
11.Please consider that unauthorized modifications on the device are forbidden
due to safety reasons!
12.If this device will be operated in any way differently than described in this
manual, the product may suffer damages and the guarantee becomes void.
Furthermore, any other operation may lead to dangers like short-circuit,
burns, electric shock, etc.

USER MANUAL: Laserworld Proline PRO-300G
Date: 01/200
Page
5
of
15

USER MANUAL: Laserworld Proline PRO-300G
Date: 01/200
Page
6
of
15

USER MANUAL: Laserworld Proline PRO-300G
Date: 01/200
Page
7
of
15

USER MANUAL: Laserworld Proline PRO-300G
Date: 01/200
Page
of
15

USER MANUAL: Laserworld Proline PRO-300G
Date: 01/200
Page
9
of
15

USER MANUAL: Laserworld Proline PRO-300G
Date: 01/200
Page
10
of
15

USER MANUAL: Laserworld Proline PRO-300G
Date: 01/200
Page
11
of
15
10. MAINTENAN E
Maintenance should be performed every 15-day period, by using a sponge which is
dipped with alcohol, rather than wet cloth or other chemical liquid, to clean the
mirror.
Always disconnect from the mains when the device is not in use or before cleaning it.
There are no serviceable parts inside the device. Maintenance and service operations
are only to be carried out by authorized dealers.
Never look directly into the light source.
Always disconnect from the mains when the device is not in use or before
cleaning it.
11. TE HNI AL SPE IFI ATIONS
Power supply: AC 220V-240V, 50/60 Hz
DMX 512: 16 channels
ondition temperature: -10°C ~ +35°C
Input signal bandwidth: 0~1000Hz
X/Y axes beam scanning optical angle: 0 ~ ±20°
Signal input power: -5V~+5V
Power consumption: 145W
Working mode: ILDA, DMX512
Optical power: Green: 300mW / 532nm
Laser classification: 3b
Weight: 20 kg
Dimensions: 670 x 3 0 x 270 mm (L x W x H)

USER MANUAL: Laserworld Proline PRO-300G
Date: 01/200
Page
12
of
15

USER MANUAL: Laserworld Proline PRO-300G
Date: 01/200
Page
13
of
15

USER MANUAL: Laserworld Proline PRO-300G
Date: 01/200
Page
14
of
15
PLEASE NOTE
This device has left our premises in absolutely perfect condition. In order to maintain
this condition and to ensure a safe operation, it is absolutely necessary for the user
to follow the safety instructions and warning notes written in this user manual.
Laserworld cannot be made liable for damages caused by incorrect installations and
unskilled operation!

USER MANUAL: Laserworld Proline PRO-300G
Date: 01/200
Page
15
of
15
EU- Declaration of onformity
We hereby confirm that the following device
Laserworld Proline PRO-300G
complies with the essential safety requirements, laid down in the regulations of the
committee to assimilate the provisions of law of all participating EU states on the
electromagnetic compatibility (9 /336/EWG).
The device has been classified considering the following EU-norms on
electromagnetic compatibility:
DIN EN 55103-1: 1996
DIN EN 55103-2: 1996
DIN EN 61000-3-2:2000 + A2: 2005
DIN EN 61000-3-3:1995 + A1: 2001
Assessment of compliance of the product with the requirements relating to the Low Voltage
Directive (LVD) was based on the following standards:
DIN EN 60065 : 2002
Furthermore, the device is verified in correspondence to the laser class regulations DIN EN
60 25-1, if properly set up according to the upper mentioned laser safety regulation.
After installing the device, an inspection and official approval is indispensable for the overall
setup. The inspection must follow the european guidelines EN 60 25-1 and corresponding
regulations for the prevention of accidents BGV-B2.
This declaration is executed on behalf of the Laserworld Proline PRO-300G Laser
manufacturer.
Laserworld (Switzerland) AG
Oberstrasse 1
274 Tägerwilen
SWITZERLAND
Authorized person:
Supervisory board Ms Rhea Gössel
place of business: 274 Tägerwilen / SWITZERLAND
company number: CH-440.3.020.54 -6
Commercial Registry Kanton Thurgau
www.laserworld.com
[e-mail]
representative according to EMVG:
Cleantech Europe GmbH
Managing Director: Thomas Schulze
Fürkhofstr. 5
1927 München / DE
