Latte DeLite User manual

User Guide for Latte DeLite™
Thank you for choosing Latte LED Light Bluetooth Speaker,
DeLite™. The DeLite™is a portable LED powered light
equipped with a Bluetooth sound speaker (2-in-1), which can
be connected to your smart phone or any Bluetooth enabled
device via the latest Bluetooth Technology and play music
wirelessly.
The DeLite™eliminates the need to carry a flashlight, Lantern,
and Music Speaker separately and will make your camping or
outdoor BBQ experience more enjoyable and relaxing.
Besides outdoor uses, the DeLite™can also be used as the
perfect mood-light indoors.
Please read the manual carefully before use.
1. Main Key Operations
Turn on (Bluetooth) - press and hold for 2 seconds
Turn off (Bluetooth) - press and hold for 5 seconds
Turn on (Light) - press shortly
Pairing (Bluetooth) - turn on Bluetooth and go to
Setting>Bluetooth in your smart phone or Bluetooth
enabled device, scan to find "DeLite" and pair. If asked for
a passcode, enter "0000"
Press and hold the volume buttons ( / ) to change
songs (next/previous)
Press the volume buttons ( / ) shortly to adjust the
volume
Press and hold to adjust the brightness of the light.
2. Main features and Specifications
Music Play via Bluetooth
Handsfree Function (Built-in Microphone)
Φ3.5mm Audio Input Interface
Audio Max Power：5W*1
Frequency response: 20Hz-20kHz
8 LED lights with 150 Lumen
Run Time (Music Play): 6+ hours
Run time (Light): 10+ hours
Max. Power Consumption: 1W
Built-in 2200mAh Rechargeable Lithium Battery
Power Source: Via Micro USB Cable. DC 5V Micro
USB Power Adapter (sold separate)
Charging time : around 3-4 hours
LED Bluetooth/line in indicator and power charge
indicator
Water resistance level: IPX4
3. Main Keys
4. Key Functions
No
Current
mode
How To
Button
Operation
Indicator
1
Power off
Power on
Press & hold for 2
seconds
Blue light
ON
2
Power on
Power off
Press & hold for 5
seconds
Light
Off
3
Power on
Bluetooth
pairing
Manually establish
connection in the
setting of the
Bluetooth enabled
device
Blue light
light will
flash rapidly
4
Power on
Bluetooth
connection
established
Blue light will
flash slowly
5
Power on
Call back
Press twice
6
Call mode
Answer call
Press once shortly
7
Call mode
Reject call
Press and hold
8
Talk mode
End call
Press once shortly
9
Bluetooth
mode
Volume up
Press and hold
10
Bluetooth
mode
Volume down
Press and hold
11
Bluetooth
mode
Previous
song
Press once shortly
12
Bluetooth
mode
Next song
Press once shortly
13
Bluetooth
mode
Play/Pause
Press once shortly
14
Any mode
Charge
Red light
ON
15
Any mode
Battery is full
Green light
ON
16
Bluetooth
mode
Audio input
The line-in audio
cable is plugged into
the audio input port
Green light
ON
17
Audio
mode
Bluetooth
mode
Unplug
the line-in audio
cable
Blue light
ON
18
Any mode
Night light
ON/OFF
Press once shortly
19
Light On
Mode
Adjust
Brightness
Press and hold
5. Bluetooth Operations
Press and hold “ ”for 2 seconds to turn on the
Bluetooth function. The blue LED status light will be
ON and flashing rapidly. Please don’t plug the audio
cable (AUX cable) into the audio line-in jack when you
want to use the Bluetooth function.
Go to "Setting" on your cell phone or Bluetooth
enabled device and activate "Bluetooth" function. Scan
for available Bluetooth devices nearby.
When "DeLite" appears on the available Bluetooth
device list, select "DeLite" to establish connection ( if
asked for a passcode, enter "0000"). When the
connection is successfully established, it produces a
connection tone, and Blue LED light changes to flash
slowly. Now the speaker is ready for playing music.
Press “ ” shortly to play music.
During the music play, the music play will stop when
you receive a call. Press “ ” shortly to answer the
call, or press and hold “ ” for 2 seconds to reject the
call. Press and hold “ / ”to adjust the volume.
Short press “ ”to end the call. The music will resume
automatically.
Press “ ” shortly twice to redial the last phone
number.
If the connection is lost or not established correctly,
please repeat step 1 to 3 for re-connection. If the blue
indicator light is not flashing, please charge the
product fully and repeat steps 1 to 3.

6. Audio Input Mode
When the Bluetooth mode is on, please insert the
3.5mm line-in audio cable into the audio input port of the
product and your music player. Once connected, the
indicator light will change from blue to green. Press and
hold " / " to adjust the volume.
When the volume is set to Max, you will hear
"beep..beep..beep" sound.
Press " " shortly to mute the music. In the ‘audio
line-in’ mode, the last song and the next song function
will not work. Please control your music through your
music device.
Please pull out the audio cable to disconnect the device
from the speaker. The speaker will switch back to the
Bluetooth mode automatically and the blue LED light will
start flashing again. The product will be automatically
paired back with the last Bluetooth device.
7. Charging
Connect the included Micro USB Cable to your PC. Once it
is connected, the RED LED light will be ON. Once the
product is fully charged, the color will change to Green.
8. Night Light Operations
Please press “”shortly to turn on/off the light. Press
and hold “ ”to adjust the brightness of the light.
9. Troubleshooting
Issue
Solution
Intermittence during
music playback.
1. Lower battery. Please charge the product
fully before you start using the product again.
2. Move the speaker closer to your phone or
Bluetooth device.
Cannot establish
connection with your
phone or Bluetooth
device.
1. Lower battery. Please charge
2. Move the speaker closer to your phone or
Bluetooth device.
3. Try to turn off the speaker & restart
4. Please check if other phone or Bluetooth
device is already paired and connected to the
speaker. The speaker can only be connected to
one Bluetooth device at a time. In this case,
please disconnected the currently connected
device and pair the device you are trying to
connect again.
5. Please check if your phone is connected to
"DeLite" in your phone's Bluetooth setting.
Weak sound
Press and hold “ ”button
10. Accessories
Included in the box: Micro USB Cable, Line-in Audio
Cable, User Guide,
Available to purchase: Wall Charger, Hanging Hook,
Carrying Bag
Contact Information
Technical Support:
Telephone: [phone] (M-F, 9A.M - 5 P.M PST)
Email: [e-mail]
Online: support.lattezone.com
Facebook Support: www.facebook.com/lattestyle
RMA inquiry:
[e-mail] or visit support.lattezone.com
Genuine Accessories Purchase:
Please visit www.lattezone.com
Facebook: www.facebook.com/lattestyle
Twitter: www.tritter.com/lattestyle
Address:
Latte Communications Inc.
1622 Centre Pointe Dr
Milpitas CA 95035
Caution
Do not use the product in extremely hot, cold, dusty or
damp environments.
The product contains a lithium battery and should be
kept away from fire or extremely high temperature
environment to avoid explosion.
Do not disassemble, repair, or modify the product
arbitrarily. These actions will void the manufacturer's
standard warranty.
Please charge the unit fully before you start using the
product for first time.
If the product hasnot been in use for an extended time,
please make sure you charge the unit fully before you
start using it again.
