Lauf Anywhere User manual

USER’S MANUAL
Anywhere
LaufCycling.com

We understand you are in a hurry to go riding a.s.a.p. - but please take a deep
breath and read this installation guide rst.
Remember, there is no shame in taking your bike to a local bike shop for
assembling, maintenance and bike tting. If you have the tools and skills to
perform it yourself you’ll nd some basic tricks and tips below.
Intended Use
Congratulations on your Anywhere!
The Lauf Anywhere is a carbon mixed terrain bike intended for use on pavement, gravel
and buff single-track. The Lauf Anywhere is tested to ISO mountain bike standards. It is not
intended for downhill riding or dirt jumping.
Warranty
The Lauf Anywhere is warranted against production defects for 5 years (frame and fork) from
sales date to the original owner of the bike. By registering your bike online we extend the
warranty to lifetime. You can either scan the QR code under the bottom bracket area on the
frame or follow the link below:
http://laufcycling.com/serial/?########
If you received a faulty product or you have any concerns about your product, please
contact [email protected]
Should anything happen outside the warranty period please contact us anyway because we
still care about you.

Crash Replacement
If you happen to crash and somehow break the bike we got you covered. Lauf offers 50%
discount from the MSRP of framesets to the original owner of the bike. Please contact us at
[email protected] or your local Lauf Premium Dealer, with a photo of the product
and a short description. We’ll be in touch shortly.
We reccommend that you inspect your bike and fork before every ride and after crashes to
make sure it is safe to ride further. If you have any questions, please contact
[email protected]
The Lauf Anywhere can be adjusted in various ways to ne tune the rider’s t. Components
to adjust are saddle, seatpost, stem and handlebar.
Rider Fit
R1
Handlebar:
The handlebar can be adjusted in tilt to accommodate different riding styles. If your saddle
is tilted forward the handlebar is usually also tilted forward a little bit. In order to do so
follow the diagram below (R1)
However, a good rule of thumb is to align the handlebar such that the top of the handlebar
is parallel to the ground (R2). The stem has so called Top-Lock system from Easton. Make
sure the arrow on the inside of the faceplate is pointing upwards (or the text “5Nm/45in-
lbs” on the outside of the faceplate facing downwards) (R3). First install the two upper bolts
and tighten to 5 Nm. The faceplate should touch the stem at the top. After adjusting the
handlebar install the lower bolts and tighten to 5 Nm. There should be a gap between the
faceplate and bottom of the stem. For more details visit:
https://www.eastoncycling.com/media/Install%20stems-v16.pdf
Rotate handlebar to
desired postition.
2.
Loosen two 4mm
hex/allen key bolts.
Tighten to 5Nm
after adjusting the
handlebar.
1.
R2
R3

R6
Loosen bolt with 4 mm
hex/allen key.
Tighten to 7 Nm afterwards.
Slide saddle back or forth.
Tilt saddle back/forth
Saddle:
The saddle can be adjusted in tilt and moved back/forth. Most like their saddle horizontal to
the ground but some with a little tilt. To tilt it, follow the diagram (R6) below. The saddle is
set in the middle but to micro adjust the reach, the saddle can be moved back or forth at the
same time when tilting the saddle.
R4 R5
Loosen bolts with
4mm hex/allen key.
Remove top-cap with
6mm hex/allen key.
Remove spacers.
1.
2.
3. Add desired spacers
beneath the stem.
4. Flip the stem up for a
more up right riding
position.
SPACER
SPACER
SPACER
Tighten bolts with 4mm
hex/allen key after
adjusting the stem in-line
with thte tire.
Adjust the handelbar
and tighten the bolts
according to the
Assembly Guide.
Fasten top-cap with 6mm
hex/allen key. Remember
to have min. 5mm of
spacers above the stem
and max 30mm below.
1.
2.
3.
SPACER
SPACER
SPACER
Stem:
The bike is delivered with the maximum amount of spacers (20mm below the stem and
15mm over the stem). There should always be at least 5mm of spacer above the stem. The
stem can be adjusted in two ways to accommodate different rider t. Either by moving it up
or down by putting spacers that are above it underneath it and/or by ipping the stem up-
side down. This will allow the rider to go from a very racey (R4) postion to a more
up-rigth position (R5). Remember to check the “Assembly Guide” or the stem
manufacturer’s guide lines when tightening.

R7
Loosen seatclamp
bolt with 4mm
hex/allen key
1.
2.Slide saddle up or down.
Make sure to align the nose of the
saddle along the top tube.
Top Tube
Saddle Nose
Seatpost:
The saddle can be adjusted in height by loosening the bolt on the seatclamp and sliding the
seatpost up or down (R7). A good rule of thumb is to adjust the height such that when you
sit in the saddle and put your heels on the pedals your knee should be straight. Ensure the
minimum insertion length indication on the Seatpost Shaft (MINIMUM INSERTION) is below
the top of seat tube (R8). Tighten the seatpost clamp to 5 Nm (R7).
R8
Going on an adventure? If you decide to use frame bags, saddle bags or any other bags that
are strapped on the bike please make sure you protect the frame/fork/seatpost/handlebar
with a frame protector or just simply a packing tape. Make sure to cover all areas where the
bags can touch the bicycle.
Bike Packing
For each ride make sure there’s no play in the headset, the handlebar is rm, the hub thru-
axles are tight, the brakes are working properly, cables don’t rub frame/fork and the chain is
clean and lubed. Always pay attention if you hear or feel something new as your bike might
need some love and care.
To check if there is play in the headset you lock the front brake with one hand, place the
ngers of your other hand where the headset cup and frame meet, move the bike back
and forth and check if you can feel any play. If there is play you loosen the two stem clamp
bolts with a 4 mm hex/allen key (don’t remove them), tighten the top cap with a 6 mm hex/
allen key until there is no play (don’t overtighten), make sure the stem is aligned to the front
wheel and tighten the two stem clamp bolts again (5 Nm).
In case you crash please examine frame, fork, seatpost and handlebar for any visible cracks
as well as making sure everything is aligned and tightened properly.
Maintenance

Characteristics of the Lauf Anywhere – Intended Use
The Lauf Anywhere is a carbon gravel bike intended for gravel racing and riding.
THE LAUF ANYWHERE IS NOT INTENDED FOR DOWNHILL MOUNTAIN BIKING.
THE LAUF ANYWHERE IS NOT INTENDED FOR DIRTJUMPING.
WARRANTY
LAUF FORKS WARRANTS ITS PRODUCTS TO BE FREE FROM MANUFACTURING FAULTS AND DEFECTS
FOR A PERIOD OF FIVE YEARS AFTER THE ORIGINAL PURCHASE. THIS WARRANTY ONLY APPLIES TO THE
ORIGINAL BUYER AND IS NOT TRANSFERABLE. PROOF OF PURCHASE IS REQUIRED WITH ALL POTENTIAL
WARRANTY CLAIMS. ANY ITEM REPLACED UNDER THIS WARRANTY WILL BE COVERED BY A WARRANTY
PERIOD EQUAL TO THE REMAINING PART OF THE WARRANTY PERIOD OF THE ORIGINAL ITEM.
THIS WARRANTY GIVES YOU ADDITIONAL RIGHTS BEYOND MANDATORY STATUTORY RIGHTS.
LIMITATIONS OF WARRANTY
LAUF FORKS DOES NOT WARRANT AGAINST FAILURE OR DAMAGE DUE TO MISUSE SUCH AS, BUT
NOT LIMITED TO, INCORRECT INSTALLATION OR ADJUSTMENT, POOR MAINTENANCE, NEGLECT AND
ALTERNATION OF THE PRODUCT, UNLESS EXPRESSLY PERMITTED BY LAUF FORKS.
THIS WARRANTY DOES NOT APPLY TO DAMAGE TO THE PRODUCT CAUSED BY A CRASH IMPACT, ABUSE
OF THE PRODUCT, NON-COMPLIANCE WITH THE SPECIFICATIONS OF ITS USAGE (INTENDED USE) OR
ANY OTHER CIRCUMSTANCES IN WHICH THE PRODUCT HAS BEEN SUBJECT TO FORCES OR LOADS
BEYOND ITS DESIGN.
THIS WARRANTY DOES NOT APPLY WHEN THE SERIAL NUMBER OR PRODUCTION CODE HAS BEEN
DELIBERATELY ALTERED, DEFACED OR REMOVED.
THE WARRANTY DOES NOT COVER GENERAL WEAR AND TEAR OF THE PRODUCT.
ULTRAVIOLET RADIATION DETERIORATION OF CARBON FIBER STRUCTURES AND/OR GLASS FIBER
SPRINGS CAUSED BY THE FORK BEING STORED OVER EXTENDED PERIODS OF TIME WHERE EXPOSED
TO DIRECT SUNLIGHT WILL NOT BE COVERED UNDER THIS WARRANTY.
Lack of Conformity
If you detect a lack of conformity you must inform Lauf Forks within a period of two months from the date on
which you detected it.
If lack of conformity is conrmed within the warranty period Lauf Forks will replace your Lauf Grit and cover the
necessary costs incurred to bring the goods into conformity.
Complaints and Warranty Claims
Eventual complaints and/or warranty claims shall be sent to Lauf Forks at [email protected]
or
Lauf Forks Ltd.
Customer Service
Ingólfsstræti 3
101 Reykjavík
Iceland
For warranty claims you are kindly requested to use the Warranty Claim Form. If and when Lauf Forks needs to
receive the product, you will be contacted with information on how to resend the product.
Legal

Dispute Resolution
The parties of this Agreement shall attempt to resolve any disputes amicably. If an amicable agreement is not
reached, you can sumbit a notication to
The Icelandic Consumer Agency
Borgartúni 21
105 Reykjavík
Iceland
or at their on-line portal
http://www.neytendastofa.is/English/Consumer-Rights-Divison.
Jurisdiction
The parties submit all their disputes arising out of or in connection with this Agreement to the exclusive
jurisdiction of the Courts of Iceland.
