LAZER MMC-P20 Owner's manual

QUICK USER MANUAL MMC-P20
1
4K SMART MEDIA PLAYER

QUICK USER MANUAL MMC-P20
2
Index
The Remote control 3
Wireless Screen Pointer 4
Player outputs 5
Connecting to TV 6
Connecting to the Internet 6
Cable connection to the internet using a Modem/Router 7
Wi-Fi connection to the internet using a Modem/Router 7
The home Screen 10
The apps Centre 11
Smart Apps 12
Settings 13
Calibrating the mouse 14
Feature overview 14
FAQ 16
Specifications 16
IMPORTANT SAFETY INSTRUCTIONS AND PRECAUTIONS
- Read all instructions carefully before use.
- Retain manuals for future reference.
- Use this product only in the manner described.
- Only use a water-dampened soft-cloth to clean the surface of this product.
- The following will damage this product: any liquid such as water or moisture, extreme heat;
cold; humidity, dusty or sandy environments.
- Only place this device on stable surfaces and ensure that any attached cables are secure and
will not cause the device to fall.
- If charging is required, it is recommended to thoroughly charge electronic devices for the first
time overnight. Subsequent charges can be as needed. During charging, or extended use, the
product may become warm.
- There are no user serviceable parts in this product.
- Un-authorized attempts to dismantle or repair thisproduct will void product warranty
- Using this device near other electronic devices may cause interference.
PRODUCT INCLUDES
Remote control with built-in compact keyboard, Remote Control Dongle, HDMI Cable,
RCA to 3.5mm Audio Visual Cable.

QUICK USER MANUAL MMC-P20
3
1
2
4
5
6
7
8
9
10
1
1
3
THE REMOTE CONTROL
1 Power ON, Power OFF
2 Rewind, Fast forward
Previous, Next
3
Play Pause
Stop
Internet
RF / IR (Switch between screen
pointer and remote control mode)
4 Screen pointer Calibration
5 Navigate UP, DOWN, LEFT, RIGHT
ENTER or CONFIRM
6 Home
7 Channel UP or DOWN
8 Volume UP or DOWN
9 Numerical keys
10 Adjust screen ratio
11 Return to previous screen
Note: Key functions may change in alternate modes or
have no function at all.
Tip. Some subscription
based Apps may require a
mouse or keyboard for easy
setup and operation. You
can connect a wired mouse
and keyboard if this is more
comfortable for you.

QUICK USER MANUAL MMC-P20
4
WIRELESS SCREEN POINTER
Connect the USB dongle to operate the on screen
pointer, a virtual mouse, which you can use to
navigate by simply pointing your remote at your TV
screen. Please remember to press the RF/IR button
on your remote control to swap between remote
control and screen pointer modes.
Note: Press and hold the ALT key to operate the dual function
keys which are marked with green markings.
For example: To enter the “@” symbol hold the ALT button and
press the down arrow button. +

QUICK USER MANUAL MMC-P20
5
THE PLAYER OUTPUTS
SIDE PANEL
REAR PANEL
USB P
orts
Power
Connector
3.5mm AV
Connector
Optical
Audio
Output
(SPDIF)
Rj45
Network
Ethernet
Port
HDMI
Output
for
Audio &
Video
Micro
SD
card
slot
ON /
OFF
Button

QUICK USER MANUAL MMC-P20
6
CONNECTING TO TV
BEST – via HDMI Cable
GOOD – via RCA Cables
CONNECTION TO INTERNET
BEST – Direct Connection (to a Modem/Router)
GOOD – Wi-Fi
Note: An Ethernet cable internet connection is recommended for streaming HD and FHD
video.
WIRELESS MODEM
MODEM
Note: Network cables not supplied

QUICK USER MANUAL MMC-P20
7
Cable connection to the internet using a Modem/Router
- Connect the network cable to the Media Player and your Modem/Router.
- In most cases your Modem/Router will automatically assign network settings to your
media player and display the screen below. Then click OK. If not, you may have to:
-Turn on and login into your Modem/Router to ensure an IP address can be
automatically assigned to your Media Player (DHCP (Dynamic Host Configuration
Protocol must be enabled)
- After connection has been successful the below screen will be displayed, showing IP,
Netmask, Gateway and DNS. Then click OK.
Wi-Fi connection to the internet using a Modem/Router
ADVANCE ICON
1) Go to the advance icon and press settings.
2) Goto Wireless and networks, then Wi-Fi to setup up your Wi-Fi

QUICK USER MANUAL MMC-P20
8
WIFI ICON (ALTERNATIVE)
- From the home screen press "Wi-Fi".
- A list of available Wi-Fi connections will be displayed. See the example screen below.
Note: The Ethernet cable musts be unplugged.
Note: If the wireless network is not encrypted, you can connect to it directly. If the
network is encrypted, select the Wi-Fi name to pop up the window for password, press
OK on the remote control and call out the soft keypad on the screen, enter the password,
select “Next” on the keypad or press the Return key on the remote control to hide the
keypad, and then select “Connect” to connect to it. (Note: to hide the keypad on the TV
box, press the Return key on the remote control.)
- To forget a WIFI connection, select it and press the Right button on the remote control.

QUICK USER MANUAL MMC-P20
9
Then the interface shows up as below picture. Choose Forget button to forget this WIFI
information.

QUICK USER MANUAL MMC-P20
10
APP OVERVIEW
The Home screen
Weather
Use this handy
app to monitor
the weather
and to check
forecasts.
YouTube Stream
Youtube Videos
Music Player
Play Music
through the
device
Media Centre
Connect to
DLNA Server to
play Media
Photo Viewer
View photos
on the device
Netflix Stream
Movies and TV
for a Monthly
price.(Account is
required)
Please note: A mouse
may be required for
use with this app
Note. Some subscription based Apps
may require a mouse or keyboard for
setup and operation. You can connect
a wired mouse and keyboard if this is
more comfortable for you.

QUICK USER MANUAL MMC-P20
11
The Apps Centre
FileBrowser
Browse your
files
My APPs View
app the installed
apps
Media Player
Play Media
through the
device
+Add apps to
the Apps Centre
screen

QUICK USER MANUAL MMC-P20
12
Smart Apps
Play Store
Access the Google Play Store.
Purchase andDownload
apps, music, movies and
more
ABC iView
Let’s you catch up on the best of
ABC TV
Please note: A mouse may be
required for use with this app
FaceBookFaceBook
Let’s you catch up on your
Facebook pages and posts.
Please note: A mouse may be
required for use with this app
Web Browse
Browse the Web
SBS on Demand
let’s youcatch up onthe best
of SBS TV
Please note: A mouse may be
required for use with this app
Miracast
Wirelessly display that allows you to
Mirror your Smartphone or tablet
Tenplay
let’s you catch up on the best
of Ten TV
Please note: A mouse may be
required for use with this app
XBMC (Kodi) is a free and open-
sourcemedia player software. It
allows users to play and view most
videos, music, such as podcasts from
the internet, and all common digital
media files from local and network
storage media. For more information
please visit:
kodi.wiki/view/Quick_start_guide

QUICK USER MANUAL MMC-P20
13
Settings
Ethernet
Check the Ethernet
Settings and IP
information
Wi-Fi
Setup a Wi-Fi connection
HDMI
Change the screen
resolution
Screen Scale
Adjust the screen scale to fit on
screen properly
System Upgrade
Upgrade the System
either via Storage or
OTA (Over the Air)
Language
Change Language
Sound Output
Change the sound
output
AutoRun
Allow apps to auto run
Device Info
View the device
information.
Advance
Press ADVANCE then
SETTINGS to turn on
Bluetooth and Wi-Fi if required. This button
will take you to the Android Settings page.
Note: To set up a new Wi-Fi or
BLUETOOTH connection, please select
the ADVANCE icon, followed by
SETTINGS then WIFI.
Reviewing a previous connection can
be accesseddirectly via the WIFI icon.

QUICK USER MANUAL MMC-P20
14
CALIBRATING THE MOUSE
If your screen pointer does not line up accurately on your TV screen you may need to
calibrate your device. In this case center the pointer (cursor) in the middle of your
screen. Press the calibration button which will turn the pointer off and stop it from
moving. Align and point your screen pointer (device) over the top of the pointer cursor
on the screen again and press the pointer button again on your remote to complete the
calibration.
FEATURE OVERVIEW
8Core GPU & QUAD Core CPU
Fast Processor & memory designed for video
With a Quad core 2Ghz processor and 8GB
storage/2GB flash of processor memory,
your movies will play smoothly and load
faster
4k Ultra HD resolution ready
Stunning clarity, vivid colour and sharp
detail will make the best of new generation
UHD TV’s, Full HD 1080p also looks great.
Digital Surround Sound
All sound formats from 2 channel stereo to
7.1 Dolby and DTS. Also Flac lossless HD
audio is supported.
3D ready*
Watch eye popping 3D content from files
(like BDMV / 3D BD-ISO or streamed 3D
movies)
DLNA
Playback content from your network of
DLNA devices.
Miracast ready
Share your tablet or smartphone screen
onto your TV for everyone to see. (it’s like
HDMI only wireless)
High Speed LAN
With up to 100MB lan fast
data transfer, wait times for
movie buffering are a thing
of the past
Android OS Smarts
Android opens a world of
possibilities through the
Google Play store. Games,
video players, apps,
utilities and lots more.

QUICK USER MANUAL MMC-P20
15
USB Ports & Micro SD input
Connect USB flash drives, hard drives or
input devices like mice, keyboards or web
cams or read content from a Micro SD
card.
HDMI or Analogue AV output
Connect to older TV’s via Composite video
and L/R stereo (cable included) or connect
to new TV’s with HDMI for the ultimate in
sound and vision.
Wireless Connectivity
Wifi and Bluetooth on board means that
you can connect to wireless networks or
connect wireless products to the media
player
Play it all -Multi source, Multi Format
ready
Whether it’s 4K movies from Netflix®,
Youtube® videos online or movies/music
from your home network or USB storage
drive, with KODI and other media players
file playback is assured*
Note: Although this android Media Player can support all the above features, you must
have the correct hardware and compatible video files. For example, if you would like to
playback a 3D movie you must have a 3D TV and a 3D movie file first, in order for this
feature to work correctly.

QUICK USER MANUAL MMC-P20
16
FAQ
Some apps I downloaded are not working
properly. Why?
They may have not installed correctly.
Please uninstall the apps and reinstall
them again.
My remote control is not working. Why?
Make sure the batteries are installed
correctly. Try a different set of batteries.
Please note: Some apps will not work
correctly with a remote. A mouse may be
required for use.
The new app I installed takes a long time to
open. Is this normal?
News Apps may need a little more time to
set up when first installed. If your app
takes a little longer than usual to start, try
closing the app and reopening it in a few
mins. In most cases this will allow the app
to setup in the background and to open
correctly.
I cannot connect with my WiFi network
First go to the Advance settings and ensure
Wifi is turned on. Then check available
WiFi networks. You can also click the WiFi
icon from the main screen if you have
already turned on your Wi-Fi.
Why can’t I see my screen pointer?
Please ensure that you have 1) plugged in
your screen pointer dongle, 2) adjust the
screen pointer location by using the
calibration button, 3) check that you have
selected RF from your remote control
SPECIFICATIONS
Interface
Composite AV Out (Jack to RCA)
HDMI
Optical Audio
USB x 2
LAN
Micro SD Card
Power Supply 5V 2A
Dimensions 11 x 9 x 2.5cm

QUICK USER MANUAL MMC-P20
17
Warranty Against Defects
Laser Corporation Pty Ltd (“Laser”) warrants your new product to be free from defects in materials and
workmanship for 12 months, from the date of purchase, provided that the product is used in
accordance with accompanying recommendations or instructions where provided. The benefit of this
warranty is in addition to your rights under the AustralianConsumer Law and to other rights and
remedies of the consumer undera law in relation to thegoods or services to whichthe warranty
relates.
Through a network of retailers and resellers, Laser will provide you with your choice of a repair,
exchange (where possible) or refund (within Dead on Arrival period) for this product if itbecomes
defective within the warranty period.
This warranty will no longer apply where the defect is a result of alteration, accident, misuse, abuse,
normalwearand tear, neglect orimproperstorage. Please retainyour receipt as proof of purchase
How to make a product warranty claim:
Step 1: Find your receipt which proves the date of purchase. Where the date of purchase cannot be
verified, your place of purchase or Laser will make an assessment based on the date of manufacture,
the condition of the Laser Product and the type of defect.
Step 2a): Contact your place of purchase. They will assess the nature of the fault and repair, replace or
fund the product as per their store refund or warranty policy.
Step 2b): If your place of purchase cannot be contacted, then you can contact Laser. Customer Service
with details of your defective Laser Product: Phone: [phone]; or Email: [email protected]
or online www.laserco.com.au/warranty (click on “Consumers (End Users)”). Our business address is at
1/6-8 Byfield Street, North Ryde, NSW 2113
Step 3: Laser will issue you with a Return Authorisation (RA) number within 48 hours. When
requested, send us the defective Product and a copy of your receipt. Laser will cover the cost of the
return delivery.
Step 4: Wait for us to contact you. Once we have received your defective Laser Product for
inspection, we will inform you ofour assessment ofyour claim within 7 days. When we contact you, we
will firstly let you know whether you have a valid claim under this Warranty, and if so, we will inform
you whetheryour defective Laser Product will be replaced or repaired, together with the number of
days you can expect to wait to receive your replaced or repaired Laser Product.
Step 5: For further details on warranty cover and returns, please check Terms and Conditions for
Warranty Returns section on http://www.laserco.com.au/warranty
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You
are entitled to a replacement or refund for a major failure and compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods
failto be ofacceptablequality andthe failure does notamount to amajorfailure.
