Leadshine CS2RS-D503 User manual

CS2RS Series
Modbus RS485 Stepper Drive
User Manual
For Models of CS2RS-D503, CS2RS-D507 and CS2RS-D1008
©2019 Leadshine Technology Co., Ltd.
Address: 15-20/F, Block B, Nanshan I Valley, No.3185, Shahe West Road, Nanshan District,
Shenzhen, Guangdong, 518055, China
Tel: [phone] Fax: [phone]
Web: www.leadshine.com Sales: [e-mail]
Support: [e-mail]

CS2RS Series Modbus RS485 Closed Loop Stepper Drive User Manual
Notice
Read this manual carefully before any assembling and using. Incorrect handling of products in this manual can
result in injury and damage to persons and machinery. Strictly adhere to the technical information regarding
installation requirements.
This manual is not for use or disclosure outside of Leadshine except under permission. All rights are reserved. No
part of this manual shall be reproduced, stored in retrieval form, or transmitted by any means, electronic,
mechanical, photocopying, recording, or otherwise without approval from Leadshine. While every precaution has
been taken in the preparation of the book, Leadshine assumes no responsibility for errors or omissions. Neither is
any liability assumed for damages resulting from the use of the information contained herein.
This document is proprietary information of Leadshine that is furnished for customer use ONLY. Information in
this document is subject to change without notice and does not represent a commitment on the part of Leadshine.
Therefore, information contained in this manual may be updated from time-to-time due to product improvements,
etc., and may not conform in every respect to former issues.
◆Thank you for purchasing Leadshine CS2RS Series Products
◆Please read this manual carefully before operating
◆Please keep this manual appropriately
Record of Revisions
Manual
Reversion
Data
Description of Release
V1.0
20190517
Initial Release
V1.1
20191220
Modified Section 4 and Section 5
V1.5
20210830
Addition of some parameters.
Adding the content of safety precautions.
Adding the IO filtering configuration section.

CS2RS Series Modbus RS485 Closed Loop Stepper Drive User Manual
Safety Precautions
Overall Notes
Precautions for Storage and Transportation
Do not remove the housing with the drive powered on. Cables. Connectors and
optional equipment.
Please disconnect the power supply for at least 2 minutes and make sure the
power indicator is off before wiring and checking. Even if the power is
disconnected, voltage may remain inside the drive. Therefore, do not touch the
power terminals while the power indicator is on.
Please use the power supply specifications (number of phases.) that match the
product. Voltage. Frequency. AC/DC).
Be sure to connect the ground terminal of the driver (mounting surface) and
motor to the ground pole.
Do not damage or drag the cable, do not overstress the cable, do not hang
heavy objects on the cable, or get caught in the cabinet door.
Please do not disassemble the product yourself. Repair or modification.
When the machine is connected to the machine and starts to operate, make sure
that the machine is ready for emergency stop.
Do not touch the inside of the drive.
The heat sink of the driver may be hot when the power is on or when the power
is just cut off. The motor, etc. may be in a high temperature. Take safety
measures such as installing a cover to prevent accidental touching by hands and
parts (cables, etc.).
Use double-insulated or reinforced insulation for control power.
Do not use in places where water can be splashed. Corrosive environments. Do
not use the product in the vicinity of flammable gases and combustible
materials.
Do not use damaged. Drivers and motors with missing parts.
Please set up an emergency stop circuit externally to ensure that the
power can be cut off and the operation can be stopped immediately in case of
an abnormality.
If the product is used under poor power conditions, install protection
equipment (AC reactor, etc.) to ensure that the input power is supplied within
the specified voltage variation range.
Please use a noise filter to reduce the influence of electromagnetic interference.
The driver and motor should be used in the specified combination.
Please follow the Commands on the packaging for storage and do not overload
the product.
Please place this product in the following environment:
→No direct sunlight in the place.
→Ambient temperature does not exceed the product specification.
→Humidity does not exceed product specifications. Without condensation.
→No corrosive gases. Place of flammable gas.
→Dust. Dust. The place where there is less salt and metal powder.
→No water. Oil. The place where the splash of medicine, etc. occurs.
→Vibration or shock does not exceed product specifications.
→No equipment generating strong magnetic fields in the vicinity.

CS2RS Series Modbus RS485 Closed Loop Stepper Drive User Manual
Precautions for Installation
Precautions for Wiring
Precautions during operation
Please install the drive in a cabinet that provides fire protection. Electrical
protection in the control cabinet.
Please install the driver and motor in a position with sufficient weight
resistance.
Please install this product in the following environment:
→No direct sunlight in the place.
→Ambient temperature does not exceed the product specification.
→Humidity does not exceed product specifications. Without condensation.
→No corrosive gases. Place of flammable gas.
→Dust. Dust. The place where there is less salt and metal powder.
→No water. Oil. The place where the splash of medicine, etc. occurs.
→Vibration or shock does not exceed product specifications.
→No equipment generating strong magnetic fields in the vicinity.
Do not block the air inlet and exhaust ports, and do not allow foreign objects to
enter the drive and motor.
Do not step on the product or place heavy objects on the drive.
Please install the driver in the specified direction.
Make sure to keep the specified intervals between the inner surfaces of the
drive control cabinet and other machines.
Do not pass the magnetic contactor in the wiring between the drive and the
motor.
Please connect the power terminal and motor terminal firmly.
Keep a minimum distance of 10mm between the drive and the control cabinet
or other equipment.
Allow at least 30mm of wiring space above and below the driver.
Signal cable. The encoder cable should be a twisted shielded cable with the
shield grounded at both ends.
The wiring length of the encoder is up to 20m.
Reduce the frequency of power on/off as much as possible.
To prevent accidents, perform a test run of the servo motor at no load (without
the driver connected).
When you install the machine and start operation, please set the user
parameters in advance to match the machine.
Positive limit (POT) during JOG operation and zero return operation. The
signal of negative limit (NOT) is not valid.
When using the motor on a vertical axis, please provide a safety device to
avoid dropping the work-piece in case of alarm or over travel.
When an alarm occurs, please reset it after investigating the cause and making
sure it is safe.
Do not use the brake of the holding motor for normal braking.

Table of Contents
1 Introduction.........................................................................................................................................................- 1 -
1.1 Product Introduction.................................................................................................................................. - 1 -
1.2 Features...................................................................................................................................................... - 1 -
1.3 Application Scenarios................................................................................................................................ - 1 -
1.3.1 Hands-on Tuning............................................................................................................................ - 1 -
1.3.2 Practical Application Scenarios......................................................................................................- 2 -
1.4 Check of Product....................................................................................................................................... - 3 -
1.4.1 Arrival inspection............................................................................................................................- 3 -
1.4.2 Nameplate information................................................................................................................... - 3 -
1.4.3 Part number.....................................................................................................................................- 3 -
1.4.4 Parts description..............................................................................................................................- 4 -
1.4.5 Accessories Information................................................................................................................. - 4 -
2 Installation........................................................................................................................................................... - 5 -
2.1 Storage and Installation Conditions...........................................................................................................- 5 -
2.1.1 Storage condition............................................................................................................................ - 5 -
2.1.2 Operating ambience conditions...................................................................................................... - 5 -
2.2 Dimensions................................................................................................................................................ - 5 -
2.3 Installation Direction and Space................................................................................................................- 6 -
3 Product Specifications........................................................................................................................................ - 7 -
3.1 Electrical and Operating Specifications.................................................................................................... - 7 -
3.1.1 Electrical and Operating Specifications......................................................................................... - 7 -
3.2 Wiring Instructions.................................................................................................................................... - 8 -
3.2.1 Power Cable & Encoder Cable.......................................................................................................- 8 -
3.2.2 I/O Signal Cable............................................................................................................................. - 8 -
3.2.3 RS485 Communication Cable........................................................................................................ - 8 -
3.3 Interface Specifications............................................................................................................................. - 9 -
3.3.1 Connectors Definition.....................................................................................................................- 9 -
3.3.2 CN1 &CN2 Input Power Connector.............................................................................................. - 9 -
3.3.3 CN3-I/O Signals Connector......................................................................................................... - 10 -
3.3.4 CN4-RS485 Communication Connector......................................................................................- 10 -
3.3.5 CN5-RS232 Tuning Port...............................................................................................................- 11 -
3.3.6 CN6-Encoder Input Signals Connector........................................................................................ - 11 -
3.3.7 DIP Switches.................................................................................................................................- 11 -
3.4 I/O Connection.........................................................................................................................................- 13 -
3.4.1 Digital Inputs................................................................................................................................ - 13 -
3.4.2 Digital Output............................................................................................................................... - 13 -
3.4.3 Brake Output.................................................................................................................................- 14 -

4 Modbus RTU..................................................................................................................................................... - 15 -
4.1 Communication Specifications................................................................................................................- 15 -
4.2 Modbus Function Codes (FC)................................................................................................................. - 15 -
4.2.1 Read Holding Registers FC= 03...................................................................................................- 16 -
4.2.2 Preset Single Register FC= 06......................................................................................................- 17 -
4.2.3 Preset Multiple Registers FC= 10................................................................................................ - 18 -
4.3 Modbus & PR Parameters....................................................................................................................... - 19 -
4.3.1 Basic Parameters...........................................................................................................................- 19 -
4.3.2 Input and Output Parameters........................................................................................................ - 22 -
4.3.3 Smooth Filter Time Setting for Digital Inputs............................................................................. - 22 -
4.3.4 Status Monitoring Parameters...................................................................................................... - 24 -
4.3.5 Control Word and Status Word.....................................................................................................- 24 -
4.4 Error Codes and Troubleshooting............................................................................................................- 25 -
4.4.1 Communication Error Codes........................................................................................................- 25 -
4.4.2 Drive Alarm Codes and Troubleshooting.....................................................................................- 26 -
4.4.3 Error Clear.................................................................................................................................... - 26 -
4.5 Register Mapping Continuous Read/Write Function.............................................................................. - 27 -
4.6 S-code Application...................................................................................................................................- 28 -
4.7 Enable Drive............................................................................................................................................ - 29 -
5 PR Mode (Indexer Table)................................................................................................................................. - 30 -
5.1 PR Main Features.....................................................................................................................................- 30 -
5.2 Homing / Return to Zero Position........................................................................................................... - 30 -
5.2.1 Homing Parameters...................................................................................................................... - 31 -
5.2.2. Homing by Home Switch............................................................................................................ - 32 -
5.2.3. Homing by Limit Switch............................................................................................................. - 34 -
5.3 Soft Limit & JOG & Quick Stop.............................................................................................................- 35 -
5.3.1 Soft Limit......................................................................................................................................- 35 -
5.3.2 JOG............................................................................................................................................... - 35 -
5.3.3 Quick Stop.................................................................................................................................... - 36 -
5.4 PR Path.....................................................................................................................................................- 37 -
5.4.1 PR Parameters...............................................................................................................................- 37 -
5.4.2 PR Path Configuration..................................................................................................................- 38 -
5.4.3 Other functions of PR................................................................................................................... - 38 -
5.5 Trigger Methods.......................................................................................................................................- 40 -
5.5.1 CTRG Trigger...............................................................................................................................- 40 -
5.5.2 IO Combination Trigger............................................................................................................... - 41 -
5.5.3 Fixed Trigger................................................................................................................................ - 42 -
5.5.4 Immediate Trigger........................................................................................................................ - 42 -
6 Tuning Operations............................................................................................................................................ - 44 -

6.1 Basic operation of Leadshine MotionStudio........................................................................................... - 44 -
6.1.1 Preparation and Steps................................................................................................................... - 44 -
6.1.2 Operation of Trial Run..................................................................................................................- 46 -
6.1.3 Operation of PR Function.............................................................................................................- 47 -
6.2 Basic Operation of Serial Port Tools Software........................................................................................- 49 -
6.2.1 Preparation and Steps................................................................................................................... - 49 -
6.2.2 Operation Instruction Format....................................................................................................... - 50 -
6.2.3 Command Cases of Modbus RTU................................................................................................- 50 -
Appendix A Parameters List...............................................................................................................................- 52 -

CS2RS Series Modbus RS485 Closed Loop Stepper Drive User Manual
-1-
1 Introduction
1.1 Product Introduction
CS2RS Series are closed loop stepper drive based on standard Modbus RTU protocol, using RS485 communication can
network up to 31 axes, built-in 16-segment position table (PR Mode --Position Register mode ). They can not only solve the
problem of step loss in the open loop stepper system, but also can save additional controllers in most of point-to-point
applications, to greatly enhance system reliability and reduce the cost. CS2RS Series also support the feature of teaching, the
operation modes of Profile Position, Profile Velocity and Homing. They can power 2-phase NEMA 8, 11, 14, 17, 23, 24, 34
stepper motors with 1000 ppr to 5000 ppr incremental encoders.
The CS2RS series is highly reliable and affordable and performs excellently in many industrial applications such as solar
equipment, textile, civil, robotics, power generation equipment, 3C, packaging...
1.2 Features
No loss of step, No hunting, No torque reservation
Low noise and vibration, smooth motion
Support Modbus RTU protocol, Internal 16-segment position instructions
Motion can be started by External IO or RS485
Support operation modes: Profile Position, Profile Velocity, Homing
7 configurable digital inputs, 3 optically isolated digital outputs
Limit +, Limit -, Origin, Quick stop, Enable, JOG +, JOG - and Position Table inputs
Alarm, Brake, Homing complete, In Position complete, instructions complete, Path complete outputs
20-50VDC supply voltage for CS2RS-D503, max output current 3A
20-50VDC supply voltage for CS2RS-D507, max output current 7A
18-80VAC or 30-100VDC supply voltage for CS2RS-D1008, max output current 8A
RS232 communication for parameters configuration
Encoder resolution: 1000 ppr to 5000 ppr for NEMA8/11/17/23/24/ 34 CS-M motors
Protections for over voltage, over current and position following error, encoder cable error, etc.
Compare with Step/Direction
Built-in single-axis control can save the PLC in most of point-to-point applications to reduce cost;
Built-in rich diagnostic functions and input and output signals to setup easily;
Modbus brings more expansion possibility to add value;
1.3 Application Scenarios
Divided into simple hands-on tuning and practical application scenarios
1.3.1 Hands-on Tuning
(1) The trial run can be performed with Leadshine's MS tuning software, which requires Leadshine’s tuning software, RS232
tuning cable (provided by Leadshine), RS232toUSB converter, drive and motor, as described in Section 6.1
(2) Simple motion can also be performed with serial port tools, which requires General serial port tools software, RS485 tuning
cable (User-provided), RS485toUSB converter, drive and motor, as described in Section 6.2.

CS2RS Series Modbus RS485 Closed Loop Stepper Drive User Manual
-2-
1.3.2 Practical Application Scenarios
(1) Controlled by Modbus RS485 (PLC or HMI)
The RS485 (Modbus-RTU protocol) communication triggers the drive's PR motion register, which can realize the drive's path
motion. Both PLC and HMI have RS485 communication so user can choose one or both. Using PLC can write more complex
programs to let motion more intelligent, and the HMI can monitor and modify the drive parameters in real time.
(2) Controlled by I/O (switch signal or PLC)
The user only needs to turn off the switch signal to realize the PR motion, which is simple to control and low-cost design.
User can also use PLC I/O module to realize PR motion, which is more intelligent than switch signal control.

CS2RS Series Modbus RS485 Closed Loop Stepper Drive User Manual
-3-
1.4 Check of Product
1.4.1 Arrival inspection
Check whether the surface of the product is damaged or not during transportation.
Check the nameplate models of the drive and motor are what you have ordered.
Cheek if it is fully equipped with accessories. Accessories include power supply and I/O signals
connector.
1.4.2 Nameplate information
1.4.3 Part number
Neither the damaged nor missing accessories of stepper system
is allowed to install.
Contact Leadshine or local distributor if any failure was found.

CS2RS Series Modbus RS485 Closed Loop Stepper Drive User Manual
-4-
1.4.4 Parts description
1.4.5 Accessories Information
Name
Necessary
Description
Motor
extension
cable
Yes
(CABLEM-RZ*M*)
for CS2RS-D503/507;
(CABLEH-RZ*M*)
for CS2RS-D1008;
Optional length:
1.5m,3m,5m,8m,
10m,12m,15m
Motor Side:
Manufacturer: TE
Housing: 172159-1-4P
Terminal: 770904-1
Drive Side:
Manufacturer: Molex
Housing: 39012040
Terminal: 39000038
Encoder
extension
cable
Yes
(CABLEM-BM*M*)
Optional length:
1.5m, 3m, 5m,8m,
10m,12m,15m
Motor Side:
Manufacturer: NSTECH
Drive Side:
Manufacturer: Molex
Housing: 513531200
Terminal: 561349000
Tuning Cable
No
CABLE-PC-1 cable
Network
cable
Yes
Optional length:
0.1m, 0.2m, 0.3m,
0.4m, 1m, 1.5m, 2m,
3m,5m,7m, 10m
Note:
(1) Tuning cable is not necessary it can also modify parameters by controller PC software.
(2) Network cable is necessary but you can also buy shielded network cable through 3rd party.

CS2RS Series Modbus RS485 Closed Loop Stepper Drive User Manual
-5-
2 Installation
2.1 Storage and Installation Conditions
2.1.1 Storage condition
Correctly packaged and store in a clean and dry environment where direct sunlight is avoided.
Store within an ambient temperature ranging from -20℃to +65℃.
Store within a relative humidity ranging from 40% to 90% and non-condensed.
Avoid any type of exposure to corrosive gases.
2.1.2 Operating ambience conditions
Temperature ranging from 0℃to 50℃. The ambient temperature of drive for long-term reliability should be under 40℃.
Please install the drive in a well-ventilated area.
Operation within a relative humidity ranging from 40% to 90% and non-condensed.
Vibration lower than 0.15mm at a frequency of 10Hz-55Hz.
2.2 Dimensions
Unit: mm (1inch=25.4mm)
CS2RS-D503 / 507
DO NOT mount the drive and motor in a location subjected to corrosive or
flammable gases, and combustibles.
Please mount the drive and motor in an indoor electric control cabinet without
liquid where direct sunlight is avoided.
DO NOT mount the drive and motor in a location subjected to airborne dust.
Please ensure grounding wires are securely connected

CS2RS Series Modbus RS485 Closed Loop Stepper Drive User Manual
-6-
CS2RS-D1008
Figure 2.1: CS2RS series mechanical drawing
2.3 Installation Direction and Space
The mounting of drive, wiring and motor should be under the regulations of EN 61800-5-1.
Incorrect installation may result in a drive malfunction or premature failure of the drive and /or motor. Please follow the
guidelines in this manual when installing
The drive should be mounted perpendicular to the wall or in the control panel.
In order to ensure the drive is well ventilated, ensure that the all ventilation holes are not obstructed and sufficient free
space is given to the drive, and a cooling fan is mounted in the control panel.
Please ensure grounding wires are securely connected.
Figure 2.2: CS2RS series installation drawing

CS2RS Series Modbus RS485 Closed Loop Stepper Drive User Manual
-7-
3 Product Specifications
3.1 Electrical and Operating Specifications
3.1.1 Electrical and Operating Specifications
Name
CS2RS-D503
CS2RS-D507
CS2RS-D1008
Supply Voltage
20-50VDC
20-50VDC
30-100VDC or 18-80VAC
Output Current (Peak)
0.5-3.0A
1.0-7.0A
2.1-8.0A
Size (H*W*L mm)
118*79.5*25.5
151*97*53
Weight (kg)
0.65
0.92
Matched Motor
NEMA 8, 11, 14, 17
NEMA 17, 23, 24
NEMA34
Input Signals
Limit +, Limit -, Origin, Quick stop, Enable, JOG +, JOG - and Position Table
Output Signals
Brake, Alarm, In Position, GPIOs
Protection Functions
Over Current, Over Voltage, Position Following Error, Encoder Cable Error, etc.
PC Software
Leadshine ProTuner (coming soon)
Operating Environment
Environment
