LEDDOO ECLIPSE SL-1 User manual

USER MANUAL ECLIPSE SL-1

Download Smart Garden App
Smart Garden App allows you to control and customize
your controls for Smart Garden Lamp via your smart device.
Search for the latest version on Apple App store
or Google Play

1
CONTENTS
02
03
07
12
IMPORTANT SAFETY INSTRUCTIONS
GETTING TO KNOW SMART LAMP
USING YOUR SMART LAMP
TROUBLESHOOTING

2
IMPORTANT SAFETY INSTRUCTIONS
Read All Instructions Before Use And
Save For Future Reference
This is an electric lamp-not a toy!
To avoid risk of re, burns,personal injury and
electric shock,it should not be played with or placed
where small children can reach it
SAVE THESE INSTRUCTIONS

3
Getting to Know Smart Lamp
In The Box
Smart Lamp x 1
Wall Plug x 4, Long Screw x 4,
Short Screw x 4, Chassis x 1
ECLIPSE SL-1

4
Specications
Model
Input Voltage
Power
Input Current
Rated Frequency
Body Material
IP Grade
Supported OS
Bluetooth
Voice Control
HY031PSH 0.7mB-T
6.7w
220-240V
50mA
50/60Hz
Aluminum die casting
IP44
Android 5.0 or iOS 9.0 and above
4.0 and above
Alexa & Google Assistant
(only available when connect to Galaxy link light)
ECLIPSE SL-1

5
mm
H
1956 g
LW
LW
H
170 100 700
N
L
N
L
270°
ON
50%
Explore
100%
Bri ghtness
ON / OFF
Whi te
ECLIPSE SL-1

6
How to Connect
AAtttteennttiioonn:1.The lamp shall be installed by licensed electricians
2.Cut off the power to avoid eletric shock before installation
2
3 4
1
OFF
N
L
N
L
ON
270°
Ø8mm
ECLIPSE SL-1

8
Using Your Smart Lamp
Connecting with Smart Device
5. Open App, follow the on-screen
1. Download “Smart Garden” from Google Play or Apple
App Store and install. Register as instructed
2. Make sure your smart device’s bluetooth and location
have turned on before pairing.
3.Make sure your smart device be connected to WIFI.
4.Power on the lamp, the lamp will light and
then flash for max.5 mins waiting to be paired.
(if the lamp has been paired with another device before, please reset the lamp, see page 8)
instructions to add your lamp.
ECLIPSE SL-1

9
1. Afterthe smart lamp is successfully
paired into intelligent mode, the color
2. The smart phone will keep the same
memory of brightness and color
temperature last time before resetting it.
temperature can be adjusted from 3000K
to 6500K.
Using Your Smart Lamp
*One smart lamp to one smart device.
Controlling with Smart Device
1. Before powering on the lamp, press the switch for
5 cycles into flashing state, the lamp has now been
reseted and automatically turn into pairing mode.
2. Make sure your new device’s bluetooth andlocation
have turned on.
3. Make sure your smart device be connected to WIFI.
4. Open App on new device, follow the on-screen
instructions to add your lamp.
Switch to a new device/Reset the lamp
ECLIPSE SL-1

10
Troubleshooting
Problem
Connecting
Failure
Enter into
Constant Mode
Reason Proposed scheme
Cannot nd Smart Lamp on
App when adding lamp
The Smart Lamp not be
Make sure Bluetooth,
connected to smart device
Cellular and Location have
turned on and Smart Garden
App is authorized to use
above function.
If your smart lamp is not
successfully paired with
smart device within flashing
state 3 mins, it will enter into
constant mode with 3000K.
Please keep all the relevant information for future reference!
