LEDDOO QUADRA SL-1 User manual

USER MANUAL QUADRA SL-1

Download Smart Garden App
Smart Garden App allows you to control and customize
your controls for Smart Solar Lamp via your smart device.
Search for the latest version on Apple App store
or Google Play
QUADRA SL-1

1
CONTENTS
02
03
07
12
IMPORTANT SAFETY INSTRUCTIONS
GETTING TO KNOW SMART SOLAR LAMP
USING YOUR SMART SOLAR LAMP
TROUBLESHOOTING
QUADRA SL-1

2
IMPORTANT SAFETY INSTRUCTIONS
Read All Instructions Before Use And
Save For Future Reference
This is an electric lamp-not a toy!
To avoid risk of re, burns,personal injury and
electric shock,it should not be played with or placed
where small children can reach it.
SAVE THESE INSTRUCTIONS
QUADRA SL-1

3
Getting to Know Smart Solar Lamp
In The Box
Smart Solar Lamp x 1
USER MANUAL
SShhoorrtt SSccrreeww xx 44
WWaallll PPlluugg xx44
IInnssttrruuccttiioonnMMaannuuaall xx11
Smart Solar Lamp x 1
QUADRA SL-1

4
Specications
Model
Power Supply
Power
Input Power
Solar Panel
Body Material
IP Grade
Supported OS
Bluetooth
Voice Control
Quadra SL-1
Max 2.5W
1 x 3.7V 2200mAh Li-Ion Battery
5V 1A
6V Monocrystalline
Aluminum die casting
IP44
Android 5.0 or iOS 9.0 and above
4.0 and above
Alexa & Google Assistant
(only available when connect to Galaxy link light)
USER MANUAL QUADRA SL-1

5
Before first use
min.8h
4X 4X
1X
mm
L W H
152 152 435
ON OFF
H
LW
QUADRA SL-1

6
How to Charge
Method 1
Switch button turns Red when Charging
Switch button turns Green when Full Charged
Lift the silicone seal ring
Plug-in USB Type C Charge Cable and connect to the main
power via an adaptor
Remove the USB Type C charging Cable when Full Charged
Put Lamp in Sunlight for ≥ 8h
Cover the silicone seal ring
-
able when charging by cable)
USB Type-C
Input, 5V 1A
Method 2
QUADRA SL-1

7
Using Your Smart Solar Lamp
Connecting with Smart Device
1. Download “Smart Garden” from Google Play
or AppleApp Store and install. Register as
instructed
4. Open App, follow the on-screen instructions to
add your lamp
2. Make sure your smart device’s bluetooth, cellular
3. Press the Power button to turn on the llaammpp
(if the lamp has been paired with another device
before, please reset the lamp, see page 10)
and location have turned on before pairing
.
ON OFF
3sec
QUADRA SL-1

8
Controlling with APP
Always make sure your smart device’s bluetooth have turned on to control the lamp
About
Static Color Settings
Dynamic Scene Settings
Music Rhythm
Countdown
Information about the device or other
Customize the color or brightness
Select a preset Scene(6 Scene available),
edit or add a new scene?
Select the rhythm collected by mic of smart device.
The lamp will turn off automatically after the countdown.
Auto
Full Light Mode
Motion Detection
Customize lamp sensor mode
Set the full brightness duration:5s~60min.
Intelligent Linkage
Linkage between smart device and other smart devieces
Induction Recording
Record the details of each induction
Setting
Select three level detection sensitivity:High,Middle,
Luminance Detection:Trigger lamp under 5 brightness
circums:Day,Dusk,Evening,Night,Dark
Slight Brightness Mode Setting:
ON/OFF: If turn on,lamp will enter into slight light after
the completion of full light.
Brightness:set brightness from 1% to 30%
Duration:Set duration from 1min. to 8h
Low
QUADRA SL-1

9
Using Your Smart Solar Lamp
Controlling without Smart Device
ON OFF
3sec
In Default Sensor*Mode: motivation detected work in 100% high brightness for 10s convert
The lamp can also been controlled without Smart device:
Press the power button once to switch mode between:
1.Mode A: Lamp breathe twice, then turn into Sensor* mode
2. Mode B: Constant Lighting
3. Turn Off
If lamp has connected to a smart device before, the lamp will automatically use color,brightness&
duration set last time.
to 30% slight brightness for 1 mins turn off, any motivation will renew the circulation.
(Brightness and Duration of High/Slight brightness mode are both adjustable according to latest
smart device's setting)
QUADRA SL-1

10
Switch to a new device/Reset the lamp
1. Hold power button for 3 seconds, the lamp
and automatically turn to pairing mode
2. Make sure your new device’s bluetooth, cellular
3. Open App on new device, follow the on-
screen instructions to add your lamp.
and location have turned on
4. If you only want to reset the lamp, can press
the power button after 10 seconds to exit blue
3sec
ON OFF
QUADRA SL-1

11
Using Your Smart Solar Lamp
Create Group with other Lamps
1. Make sure all lamps have connected to your
device and controlable before create group
3. Touch ‘Create Group’ on the menu list
2. Enter any lamp’s control panel, touch the ‘Pencil’
logo on right top side of screen
4. Add the lamp you need and touch ‘Save’ on
top right side of screen, then you can see the
group in your device list
1
2
3
QUADRA SL-1

12
Troubleshooting
Connecting
Problem
Failure
Lamp Flashing
Can not turn on
Can not turn o󰀨
the lamp
the lamp
During Charging
Reason Reason
Cannot nd Smart Lamp
on App when adding lamp
Cannot exit blue ashing
paring mode
Lamp is out of power
Lamp is charging by cable
Current adaptor’s charging
power is too low, cannot
properly charge the lamp
Wait 10 seconds then click
the button to turn o󰀨
When lamp is connected and
accidentally enter the pairing
mode, when connecting
with smart device again, the
progress is very slow and
nally lead to pairing failure.
Remove the previous
lamp on App and hold
the power button to blue
ashing pairing model to
Make sure Bluetooth, Cellular
and Location have turned on
and Smart Garden App is
authorized to use above
function.
connect again function.
Charge the lamp, delete
the lamp on App to save
the power if long time not
using the lamp
Lamp is designed for
higher Safety purpose to
not open when charging
by cable
Change to a adaptor with
higher power ( ≥5V 1A)
QUADRA SL-1

13
Instructions:
This light-set can be used outdoors.
Please keep all the relevant information for future reference!
GB
This unit contains rechargeable batteries. Switch the ON/OFF switch to “ON”. The
unit is ready to be used now. Place the solar panel in a way that it will collect as much
daylight as possible (not right under a tree, in the shade). When it starts to get dark,
a light/dark sensor will switch the unit on automatically. After 6-8 hours the lights will
automatically stop burning. Then the next day, batteries will be recharged again by
the daylight. Please note that a sunny, bright day will make the LED’s light up longer
and brighter and a dark, cloudy day will make the light shorter and dimmer.
The batteries in this set are replaceable.If you wish to replace the batteries, please
acquire at your local garden center or hardware store for rechargeable batteries that
match the technical specications of the battery(ies)used in this lighting set, for safe a
nd proper functioning.
Please note: Prior to rst use, the solar light must be charged for 1 or 2 days in
direct sunlight, with the switch turned on. This will benefit the lifetime of the bat-
tery(ies) and assures proper functioning of the lighting set.
