LEDDOO TRIGLOW GL-1 User manual

USER MANUAL TRIGLOW GL-1

Download Smart Garden App
Search for the latest version on Apple App store
Smart Garden App allows you to control and customize your
controls for Smart Solar Lamp via your smart device.
or Google Play
TRIGLOW GL-1

1
CONTENTS
02
03
07
12
IMPORTANT SAFETY INSTRUCTIONS
GETTING TO KNOW SMART SOLAR LAMP
USING YOUR SMART SOLAR LAMP
TROUBLESHOOTING
TRIGLOW GL-1

2
IMPORTANT SAFETY INSTRUCTIONS
GETTING TO KNOW SMART SOLAR LAMP
USING YOUR SMART SOLAR LAMP
TROUBLESHOOTING
IMPORTANT SAFETY INSTRUCTIONS
Read All Instructions Before Use And
Save For Future Reference
This is an electric lamp-not a toy!
To avoid risk of re, burns,personal injury and
electric shock,it should not be played with or placed
where small children can reach it.
SAVE THESE INSTRUCTIONS
TRIGLOW GL-1

3
Getting to Know Smart Solar Lamp
In The Box
USER MANUAL
SSoollaarr PPaanneell SSppiikkee xx 11
LLaammpp SSppiikkee xx 33
SShhoorrtt SSccrreeww xx 33
WWaallll PPlluugg xx 33
IInnssttrruuccttiioonnMMaannuuaall xx11
Solar Panel x 1 Smart Solar Lamp x 3
TRIGLOW GL-1

4
Specications
Model
Power Supply
Power
Input Power
Solar Panel
Body Material
IP Grade
Supported OS
Bluetooth
Voice Control
TriGlow Gl-1
Max. 3W
3 x 3.7V 2200mAh Li-Ion Battery
5V 1A
6V Monocrystalline
ABS +Glass Shade +Aluminum
IP44
Android 5.0 or iOS 9.0 and above
4.0 and above
Alexa & Google Assistant
(only available when connect to Galaxy link light)
USER MANUAL TRIGLOW GL-1

5
Before first use
min.8h
mm
L W H
95 95 150
mm
H
L
245
W
205 227
1
3X
X
H
L
ON OFF
H
L
3X
3 X
1X
3X
W
W
TRIGLOW GL-1

6
How to Install the Solar Panel
2
1
4
3
1
2
Ø 6 mm
VERSION1
VERSION2
TRIGLOW GL-1

7
Using Your Smart Solar Lamp
Connecting with Smart Device
3. Press the Power button to turn on the lamp
(if the lamp has been paired with another device
1. Download “SSmmaarrtt GGaarrddeenn” from Google Play
or AppleApp Store and install. Register as
instructed
before, please reset the lamp, see page 10)
4. Open App, follow the on-screen instructions to
add your lamp
2. Make sure your smart device’s bluetooth, cellular
and location have turned on before pairing
.
ON OFF
3sec
TRIGLOW GL-1

8
Controlling with APP
Always make sure your smart device’s bluetooth have turned on to control the lamp
About
Static Color Settings
Dynamic Scene Settings
Information about the device or
Music Rhythm
Quick Linkage
Power On/O󰀨
other
Customize the color or brightness
The device needs to be under gateway for the
Select the rhythm collected by mic of smart
Select a preset Scene(6 Scene available),
edit or add a new scene?
device.
intelligent linkage configuration to take effect.
Tap to turn ON/OFF the lamp
Lower the brightness when battery is low
Schedule for the auto-on/off and solar mode
Low Power Setting
Schedule Mode
timer.
TRIGLOW GL-1

9
Using Your Smart Solar Lamp
Controlling without Smart Device
The lamp can also been controlled without Smart device:
Press the power button once to switch mode between:
1. Mode A: Lamp breathe twice, then turn to Photosensitive* mode
2. Mode B: Constant Lighting
If lamp has connected to a smart device before, the lamp will automatically use color&brightness setting
from last time.
ON OFF
3sec
TRIGLOW GL-1

10
Switch to a new device/Reset the lamp
3. Open App on new device, follow the on-
screen instructions to add your llaammpp.
4. If you only want to reset the lamp, can press
the power button in
2. Make sure your new device’s bluetooth, cellular
and location have turned on
10 seconds to exit blue
3sec
ON OFF
1.Hold power button for 3s, the lamp will flash
in blue. Lamp has now been reset and
automatically turn to pairing mode.
TRIGLOW GL-1

11
Using Your Smart Solar Lamp
Create Group with other Lamps
1. Make sure all lamps have connected to your
device and controlable before create group
3. Touch ‘Create Group’ on the menu list 4. Add the lamp you need and touch ‘Save’ on
top right side of screen, then you can see the
2. Enter any lamp’s control panel, touch the ‘Pencil’
icon on right top side of screen
group in your device list
1
2
3
TRIGLOW GL-1

12
Troubleshooting
Problem
Connecting
Failure
Lamp Flashing
Can not turn o󰀨
the lamp
Can not turn on
the lamp
During Charging
Reason Reason
Cannot exit blue ashing
Cannot nd Smart Lamp
on App when adding lamp
paring mode
Lamp is out of power
Wait 10 seconds then click
Current adaptor’s charging
power is too low, cannot
properly charge the lamp
the button to turn o󰀨
Charge the lamp, delete
the lamp on App to save
the power if long time not
Make sure Bluetooth, Cellular
and Location have turned on
and Smart Garden App is
authorized to use above
When lamp is connected and
accidentally enter the pairing
mode, when connecting
with smart device again, the
progress is very slow and
nally lead to pairing failure.
function.
Remove the previous
lamp on App and hold
the power button to blue
ashing pairing model to
connect again function.
using the lamp
Change to a adaptor with
higher power ( ≥5V 1A)
Can not set the
scheduel mode
There may be an error of about
30s in timing
Set the timing time at least
30s
TRIGLOW GL-1

13
Instructions:
This light-set can be used outdoors.
Please keep all the relevant information for future reference!
GB
This unit contains rechargeable batteries. Switch the ON/OFF switch to “ON” on the
solar panel. The unit is ready to be used now. Place the solar panel in a way that it
will collect as much daylights as possible (not right under a tree, in the shade). When
it starts to get dark, a light/dark sensor will switch the unit on automatically. After 6-8
hours the lights will automatically stop burning. Then the next day, batteries will be
recharged again by the daylight. Please note that a sunny, bright day will make the
LED’s light up longer and brighter and a dark, cloudy day will make the light shorter
and dimmer.
The batteries in this set are replaceable.If you wish to replace the batteries, please
acquire at your local garden center or hardware store for rechargeable batteries that
match the technical specications of the battery(ies)used in this lighting set, for safe
and proper functioning.
Please note: Prior to rst use, the solar light must be charged for 1 or 2 days in
direct sunlight, with the switch turned on. This will benefit the lifetime of the bat-
tery(ies) and assures proper functioning of the lighting set.
