LEDDOO ECLIPSE WL-1 User manual

USER MANUAL ECLIPSE WL-1

Download Smart Garden App
Smart Garden App allows you to control and customize
your controls for Smart Garden Lamp via your smart device.
Search for the latest version on Apple App store
or Google Play
ECLIPSE WL-1

1
CONTENTS
02
03
07
12
IMPORTANT SAFETY INSTRUCTIONS
GETTING TO KNOW SMART LAMP
USING YOUR SMART LAMP
TROUBLESHOOTING
ECLIPSE WL-1

2
IMPORTANT SAFETY INSTRUCTIONS
Read All Instructions Before Use And
Save For Future Reference
This is an electric lamp-not a toy!
To avoid risk of re, burns,personal injury and
electric shock,it should not be played with or placed
where small children can reach it.
SAVE THESE INSTRUCTIONS
ECLIPSE WL-1

3
Getting to Know Smart Lamp
In The Box
Smart Lamp x 1
Wall Plug x 2
Long Screw x 2
Short Screw x 2
Allen Key x 1
USER MANUAL
1
UP
UP
2
Bracket x 2
ECLIPSE WL-1

4
Specications
Model
Input Voltage
Power
Input Current
Rated Frequency
Body Material
IP Grade
Supported OS
Bluetooth
Voice Control
Eclipse WL-1
6.7w
220-240V
50mA
50/60Hz
Aluminum die casting
IP44
Android 5.0 or iOS 9.0 and above
4.0 and above
Alexa & Google Assistant
(only available when connect to Galaxy link light)
USER MANUAL ECLIPSE WL-1

5
mm
LWH
757 g
H
W
L
160 65 185
ECLIPSE WL-1

6
How to Connect
USER MANUAL
AAtttteennttiioonn:
OFF
1 2
Ø6mm
3
N
L
4
ON
1 2
3 4
Ø6mm
N
L
N
L
UP
2
UP
UP 12
X√
OFF
UP
UP 12
X
√
UP 1NL
ON
VERSION 1 VERSION 2
N
L
1.The lamp shall be installed by licensed electricians
2.Cut off the power to avoid eletric shock before installation
ECLIPSE WL-1

7
Using Your Smart Lamp
Connecting with Smart Device
1. Download “Smart Garden” from Google Play or Apple
App Store and install. Register as instructed
2. Make sure your smart device’s bluetooth and location
have turned on before pairing.
3.Make sure your smart device be connected to WIFI.
4.Power on the lamp, the lamp will light and
then flash for max.5 mins waiting to be paired.
(if the lamp has been paired with another device before, please reset the lamp, see page 8)
5. Open App, follow the on-screen
instructions to add your lamp.
ECLIPSE WL-1

8
Using Your Smart Lamp
Connecting with Smart Device
1. Before powering on the lamp, press the switch for 5
cycles into flashing state, the lamp has now been
reseted and automatically turn into pairing mode.
2. Make sure your new device’s bluetooth andlocation
have turned on.
3. Make sure your smart device be connected to WIFI.
4. Open App on new device, follow the on-screen
instructions to add your light.
Switch to a new device/Reset the lamp
1. After the smart lamp is successfully
paired into intelligent mode, the color
temperature can be adjusted from 3000K
to 6500K.
2. The smart phone will keep the same
memory of brightness and color
temperature last time before resetting it.
*One smart lamp to one smart device.
ECLIPSE WL-1

9
Troubleshooting
Problem
Connecting
Failure
Reason Proposed scheme
Cannot nd Smart Lamp on
App when adding lamp
if your smart lamp is not
successfully paired with
smart device within flashing
state 3 mins, it will enter into
constant mode with 3000K.
Location have turned on
and Smart Garden App is
authorized to use above
Make sure Bluetooth and
function.
The Smart Lamp not be
connected to smart device
Enter into
Constant
Please keep all the relevant information for future reference!
Mode
ECLIPSE WL-1

ECLIPSE WL-1
IMPORTER:
B&K LUMITEC
2 rue Alfred Kastler
Zone Industrielle
67850 Herrlisheim - France
