USER MANUAL
P6R WORK
P7R WORK

2
P6R Work P7R Work
User Manual P6R Work |P7R Work V.01 06.2021
Many Thanks
We are pleased that you have chosen a
product from our company. To familiarize
yourself with your new product, you will
find information for safety and operation
in these operating instructions.
These instructions for use must be read
carefully before using the product. It must
be kept and handed over to third parties
when the product is passed on.
This also serves to ensure that you get
the maximum benefit from your product,
get answers to your questions and avoid
operating errors. Therefore, pay particular
attention to the warning and safety
instructions and properly dispose of the
lamp, batteries and packaging material.

3
User Manual P6R Work |P7R Work V.01 06.2021
General product information
The Ledlenser P6R Work and P7R Work
are flashlights and may only be used
as such for lighting purposes. Use the
products only at ambient temperatures of
-20°C to + 40°C. The flashlights do not be
used in areas with a potentially explosive
atmosphere. The flashlights are no toys
and are not suitable for small children.
Please register your product with the
enclosed registration card to obtain an
extended warranty, check the authenticity
of the product and receive updates about
products or product improvements.
Table of contents
1. Scope of delivery
2. Warning
3. Magnetic Charging System
4. Battery Replacement
5. Default Operation
6. Boost Function
7. Advanced Focus System
8. Backup Mode
9. Customizing Light Modes
10. Additional Functions
11. Reset to Factory Settings
12. Further Information

4
1
P7R Work
21700
18650
P6R Work
5V
1. 2.
User Manual P6R Work |P7R Work V.01 06.2021
1. The flashlight is delivered with the scope of
delivery shown. The product may only be used
with the following rechargeable batteries:
P6R Work: 18650 Li-ion, 3.7V (Item No. 501001)
P7R Work: 21700 Li-ion, 3.7V (Item No. 502262)
Rechargeable batteries may only be charged at
temperatures from 10°C to 40°C.
Intelligent Clip +
Lamp Adapter
Scope of delivery
Pouch
Lanyard

5
4x blink
3
+
?
-
2
5V
User Manual P6R Work |P7R Work V.01 06.2021
2. CAUTION: The lamp generates heat when in use. Do
not cover the lamp during operation, this can lead to
heat build-up. Maintain a distance of at least 10 cm
between the lamp and illuminated surfaces.
Make sure that the lamp is locked during transport
and cannot be switched on accidentally.
3. The included USB magnetic charging cable is used for
charging. If the contacts on the lamp or cable are dirty
or dusty, first clean them with a dry cloth. Then connect
the cable to the lamp, paying attention to the correct
orientation of the contacts. Finally, connect the charging
cable to a standard USB power supply or computer.
While the lamp is charging, the charge level indicator
lights up red. When the charging process is complete,
the display changes to green. If an error occurs, the
charge indicator flashes (e.g. defective or incorrectly
inserted battery).
A wall bracket is included with the lamp, in which the
USB magnetic charging cable can also be inserted.
The lamp is placed in the charging station / wall
bracket for charging. When the lamp is inserted
correctly, the charging indicator lights up during the
charging process as described above.
Rechargeable batteries may only be charged at
temperatures of 10°C to 40°C. Optionally, the batteries
can be removed from the lamp and charged externally
with a suitable charger.
WARNING
hold
=5s
Transportation Lock
Magnetic Charging System
red green red + green blink 5V

6
2.
1.
<3s
<3s
4
5
+1x
+1x
1x
+1x
User Manual P6R Work |P7R Work V.01 06.2021
4. To remove the rechargeable battery, the end cap of
the lamp is screwed o. The battery can then be
removed. When inserting a new battery, pay attention
to the correct polarity (+/-). This is marked on the
battery and inside the lamp shaft. Only approved
batteries may be used. Then close the lamp again by
screwing the end cap on. To ensure watertightness,
make sure that the seals are undamaged.
5. This lamp has several light functions or brightness
levels.
The desired function can be selected within the first
three seconds after switching the lamp on. To do this,
first switch the lamp on and then tap the switch once
within three seconds to switch to the next function.
If the switch has not been pressed for more than
three seconds or if the last available light function
has been selected, the lamp switches o the next
time the switch is pressed.
When the lamp is switched on, the remaining battery
capacity is displayed (GREEN fully charged; ORANGE
half full; RED almost empty)
If the „Memory Mode“ is active, the lamp always
turns on with the previously selected light function. If
the „Memory Mode“ is deactivated, the lamp always
starts with the same light function. The „Memory Mode“
can be activated and deactivated in the advanced
settings (10).
Battery Replacement
O
O
Power
Mid Power
Low Power
Default Operation

7
6
7
8
<25%
<25%
Backup
2x
Boost
=10s
User Manual P6R Work |P7R Work V.01 06.2021
6. In boost mode, the lamp lights up with the maximum
available brightness for a period of ten seconds. The
boost mode can be activated at any time by double
tapping the switch, except when the transportation
lock is activated. After ten seconds the lamp switches
back to the previously selected light function.
7. Dierent activities require dierent light. By turning
the lamp head whilst moving it forwards or backwards,
the light can be focused for maximum beam distance
or defocused for even illumination of the close-up area.
8. If the remaining battery capacity is low - after the
regular runtime has expired - the lamp switches to
„Backup Mode“. In this mode the lamp can only be
used in the lowest brightness level. It prevents the
lamp from suddenly switching o and ensures that
the user still has light available when the battery
is weak.
The „Backup Mode“ can be activated or deactivated
in the advanced settings. If the backup mode is
deactivated, the lamp is operated at full brightness
until the end of the battery capacity and then switches
o immediately.
When the „Low Battery Warning“ is active, which can
be activated or deactivated in the advanced settings,
the lamp gives a flashing signal every 15 minutes
when the battery capacity is low.
Advanced Focus System
Boost Function
Backup Mode
defocused
focused

8
9
User Manual P6R Work |P7R Work V.01 06.2021
9. The flashlight is preset with selected light
functions and brightness levels. If desired, the
default settings can be changed via the switch
on the lamp. Proceed as follows:
- Hold down the switch for five seconds while the
light is on. Do not cover the switch completely,
in order to still be able to see the indicator light
inside the switch.
- After five seconds the switch will flash briefly.
Release the switch immediately.
- By briefly pressing the switch, you can switch
through all available light functions and brightness
levelsn.
- If you want to save the selected light function, hold
the switch down for two seconds. The switch will
flash twice to confirm. You can repeat this process
up to a total of ten times in order to save further
light functions.
- Alternatively, press and hold the switch for four
seconds to save the selected light function(s) and to
end the process (after the switch has flashed three
times).
- The lamp was now been programmed with the
selected light functions. These can now be activated
in the selected order by tapping the switch several
times within three seconds after switching the
lamp on.
Customizing Light Modes
hold
=8s
NEXT
hold
=4s
SAVE & EXIT
Low Power
Mid Power
Power
Dim
Blink
Flashing
Position
SOS
Strobe
2x blink
hold
=2s
2x blink
3x blink
1x blink
On
hold
=5s
White

9
1x
2x
3x
10
User Manual P6R Work |P7R Work V.01 06.2021
10. You can use the advanced settings to switch additional
functions on or o. To do this, switch on the lamp. Hold
down the switch for about eight seconds. The switch
flashes once, then twice. Release the switch when it
has blinked twice.
Now tap the switch briefly several times to activate
or deactivate functions. If you want to activate or
deactivate another function, start the process again
from the beginning (10.).
With a single tap, the Memory Mode is switched on or
o (see also No. 5).
If you tap it twice, the Low Battery Warning is switched
on or o (see also No. 8).
If you tap it three times, the Emergency Mode is
switched on or o. When the emergency mode is
active, the lamp is switched on automatically if it is
disconnected from the power supply while charging.
This means that the lamp comes on automatically in
the event of a power failure or is immediately active
when it is removed from the holder.
Additional Functions
hold
=8s
On
2x red blink: Memory Mode OFF
2x green blink: Memory Mode ON
2x red blink: Low Battery Warning OFF
2x green blink: Low Battery Warning ON
2x red blink: Emergency Mode OFF
2x green blink: Emergency Mode ON
2x blink
1x blink

10
4x
11
User Manual P6R Work |P7R Work V.01 06.2021
If you tap the switch four times, the Backup Mode is
switched on or o (see also No. 8).
11. The lamp can be reset to factory settings. To do this,
switch on the lamp. Hold down the switch for about
eight seconds. The switch flashes once, then twice.
Release the switch when it has blinked twice.
Then press the switch again for five seconds until it
flashes four times. Now release the switch. The lamp
has been reset to the factory settings and can be used
again as usual.
2x red blink: Backup Mode OFF
2x green blink: Backup Mode ON
Reset to factory settings
ON
2x blink
1x blink
4x green blink: Reset
hold
=8s
hold
=5s

11
?
i
Ledlenser GmbH & Co. KG
Kronenstr. 5-7, 42699 Solingen
Phone [phone] Fax [phone]
[e-mail]
ledlenser.com
P7R WorkP6R Work
12
User Manual P6R Work |P7R Work V.01 06.2021
12. Further information, tutorials and accessories can be
found on our website. Simply scan the QR code or visit
www.ledlenser.com.
Further Information
