WIRING
Suite Stations - may be wired in risers as shown in the wiring
layout diagram, Fig. 1. Each riser requires one twisted pair,
#22 (or as required for type of station) plus one conductor,
#22 for each suite served by the riser. Maximum length is
400 ft. (120 meters). Additional risers may be added as
needed. Cable should not be run in the same conduit with
(or too close to) electrical wiring, background music wiring
or very close to fluorescent lights, dimmers or other electri-
cal equipment. Leave sufficient cable in each box to make
connections. Do not cut cable at each station.
Transformer - wiring should be 2 conductor, #18. Maximum
cable length is 80 feet (24 meters), or up to 200 feet (60 meters)
using #14 wire. Route cable away from suite station wiring.
Door Release - wiring should be 2 conductor, #18 cable. Maxi-
mum length is 50 feet (15 mtr). To use 24 volt door release, use
a LEE DAN PS-30A transformer and connect as in Fig. 2.
Connections -Before connecting, make certain wires are free
from shorts or grounds. Make connections as shown in
Fig. 4, observing the following notes:
1. Do not apply power to transformer primary until entire
system has been installed and all wiring checked for
shorts or grounds. The common wires connecting to
terminals 1,2,3,E and 5 should show open circuit when
tested with an ohmmeter.
2. Use twisted pair wiring as shown. Do not interchange
wires or reverse polarity.
5-4-3 WIRE APARTMENT INTERCOM AMP
WIRING INSTRUCTIONS
Fig. 1
Add Risers
as required
117 VAC
PS-30A Transformer
Entry
Panel
Door
Opener
Door
Opener
To Additional
Suites
For 3-wire stations:
1 twisted pr #22, plus 1 cond.
#22 gauge per suite
or,
For 4-wire stations:
1 twisted pr #22 and 1 cond.
#22 common, plus 1
cond. #22 gauge per suite
or,
For 5-wire stations:
2 twisted pr #22, plus
1 cond. #22 per suite
Transformer
816
24 VAC #18
D
K
C
24
PK-543
2 cond. #18
ZW
Fig. 3 OPTIONAL DIODE CONNECTION
Fig. 2 OPTIONAL CONNECTION FOR 24 VAC
DOOR RELEASE
3. PK-543amplifiermaybeinstalledinsideentrypanelwhen
using BB-200 series housing. If necessary to install the
amplifier elsewhere due to temperature extremes, etc., or
because a small panel is being used, 2 conductor, shielded
cable must be used for the entrance panel speaker wiring
anda1conductorshieldedwiremustbeusedforthe‘Buzz’
wire (connect shield drain wire to amplifier terminal G).
NOTE: PK-543shouldbelocatedatleastthreefeet(1meter)
away from transformers or other electrical equipment and
must be kept away from direct heat or extreme cold.
Operating Temp. 0-30º C
4. If the PK-543 must be located away from the entry
panel, shielded cable must be used for terminals A, G,
and Z (or ZW). Connect shield drain wire to amplifier
terminal G. In addition, one of the following steps must
be taken to prevent the possibility of Oscillation occur-
ring at the Suite Stations and the Entry Panel Speaker
when switching from Talk to Listen:
a. The ENTRANCE TONE switch must be set to the
‘OFF’ position.
b. A 1N4003 diode must be placed in series with the
ZW terminal. The anode of the diode must be
connected to the ZW terminal. Refer to Fig. 3.
c. If the Z terminal is not being used for a second
suite entrance, connect the 'BUZZ' wire to Z
instead of ZW. This will give a steady tone instead
of a warble tone.
d. Adjust the VOICE VOLUME level down until the
Oscillation disappears.
Suite Stations:
Innovations in Communications
since 1955
TM
®
®
PK-543
IN-487 (5/01)
800-231-1414 • 631-231-1414
155 Adams Avenue•Hauppauge, NY 11788-3699
Fax [phone] • www. LEEDAN .com
INTERCOMS•MAILBOXES •DIRECTORIES
ANNUNCIATORS •WIRE & CABLE •NURSE-CALL
With continuous product improvement, specifications are subject to change without notice.

LEE DAN
®
COMMUNICATIONS, INC. Page 2 IN-487 (5/01)
FINISH INSTALLATION
Install the amplifier in one of three manners: 1) Inside
optional JB-200 junction box, 2) In remote location such as
utility closet, basement, etc., 3) To rear of specifically
designed LEE DAN entrance panel, in a position that will
not interfere with panel components. Install suite stations on
housings. Do NOT overtighten screws on plastic panels.
Connect power transformer primary to 117 VAC.
TEST AND CHECKOUT
At entrance panel, push each button. Check to determine if the
correct suite is buzzed each time. At each suite, pushTALK and
LISTENbuttons to communicate with someone at the entrance
panel; then push DOOR button to check door release option.
OPERATION
1. VOICE VOLUME: is adjustable externally using a small screw-
driver through the port hole on the front of the PK-543
labeled “VOICE VOLUME”.
2. PROGRAMMING SWITCHES:
Switch #
#1 DOOR DELAY: to enable door delay, switch to left. To
disable door delay, switch to right.
#2 SHORT DOOR TIME: with thedoor delayswitch enabled,the
short door delay may be selected. With the second dip
switch to the left, the door delay will be approx. 16
seconds. To the right, the delay is 8 seconds.
#3 ENTRANCE TONE: call tone at entry panel is enabled with
the 3rd dip switch to the right, and disabled to the left.
#4 Not used.
1. Entire System Dead - Check 117
VAC at transformer primary, 16
VAC at transformer secondary,
and wiring to PK-543.
2. No Talk -Checkwiringto terminals
1and 2 shortedoropen,andwiring
to entrance panel speaker open or
shorted.Suitestationmaybetested
by replacement.
3. No Listen - Check wiring to termi-
nals 1 and 3 shorted or open and
short between terminals 1 and 2.
4. No Door Operation -Checkwiringto
door release shorted or open, de-
fective door release, and door but-
ton on suite station. Check wiring
to terminals 2 and 3, or 1 and E.
5. No Buzzing - Check wiring to
PK-543 terminal Z, or ZW, panel
push-buttons, and wiring to suite
stations terminal X.
6. Excessive Hum or Distortion Check
wiring installed too close to
electrical wiring or electrical
devices, PK-543 installed too
close to transformers or electrical
devices, twisted pair wiring not
used as required, or PK-543
volume set too high.
7. Radio Interference - Check
connection from the PK-543
terminal G to electrical ground.
Note: This connection is not
shown on wiring diagram, since
the situation is not always
improved by adding it. If
problems persist, consult factory.
8. Oscillation -Checkwiringstep4on
page 1. If oscillation persists, con-
nect a model 15-MFD non-polar
capacitoracrossterminalsAandG
on the PK-543 amplifier.
Note: Entrance Tone (if used) will
be lower with capacitor.
3. TONE VOLUME: is adjustable externally using a small screw-
driver through the port hole on the front of the PK-543
labeled “TONE VOLUME”. NOTE: Adjust Tone Volume to
maximum only when using PK-502B multi-entrance adaptor.
4. BUZZ 1: ZW terminal is a warble tone output.
5. BUZZ 2: Z terminal is a steady tone output. To be used for call
tone at suite station.
TROUBLESHOOTING
If the system fails to operate properly, check wiring. If wiring is
correct, check the following points:
NOTES: 1. USE #22 WIRE UNLESS SHOWN OTHERWISE.
2. IFTHEENTRANCEPANELHASAHANDSET,CONNECTIT
IN PLACE OF THE SPEAKER.
3. FOR DC DOOR OPERATION CONNECT DOOR RELEASE
TO L- (YELLOW) AND L+ (YELLOW/BLACK).
4. 3, 4 AND 5 WIRE STATION TYPES MAY BE USED IN ANY
COMBINATION,BUTNOTUSUALLYONTHESAMECABLE
RUN.
