LEGACY LIFTS Passenger Lift User manual

!
We Make Elevated Living Easier
PRODUCT OWNER’S MANUAL
PLATFORM LIFT
!
www.legacylifts.com
800-597-5438

TABLE of CONTENTS
FOREWORD
Legacy Lifts® places priority on safety, and encourages
product owners and their operators to do likewise. Safety is
a core value of Legacy Lifts® and your safety is important to
us. Therefore, it is strongly recommended that the product
owner read and heed all contents of this manual before
operating her/his lift product. This knowledge will help the
product owner execute his/her safety responsibilities with
this lift product more effectively, and will help ensure
Subject
Page
Introduction
3
Product Description
4
Safety Instructions
5
Safety Signage
8
Operations
9
Maintenance
10
Preparations for Hurricane
12
Technical
12
Warranty
12
Registration for Warranty
16
Record of Product Service
17
LEGACY LIFTS®, www.legacylifts.com Page 2

longevity of the lift. Each lift product operator should be
trained as well by the product owner, particularly in safety
considerations.
INTRODUCTION
Legacy Lifts, LLC d/b/a as Legacy Lifts® hereafter referred as Legacy
Lifts® is pleased to supply this Legacy Lifts® product. We appreciate your
confidence in our company that focuses upon the design, build and support
of lift products of various types. This is our business—lift products are our
core competence.
Legacy Lifts® serves its product owners through a capable network of
representation entities. In addition to customer order consummation, we
rely upon these capable entities to make field installation; to perform
maintenance “by contract” when the product owner agrees; and, to provide
service “by call” when requested. And, Legacy Lifts® supplies a ready
supply of parts for this important maintenance and service.
Legacy Lifts® Contact Information:
www.legacylifts.com;
6556 State Hwy 198, Mabank, Texas 75156
903-451-2507; 800-597-5438; FAX: [phone];
____________________________________________________________
Please record contact info for your representation entity here for reference:
____________________________________________________________
Please record also your product identification for convenient reference:
LEGACY LIFTS®, www.legacylifts.com Page 3

____________________________________________________________
____________________________________________________________
PRODUCT DESCRIPTION
This product is a Platform Lift. It is not a cargo lift; and, it is not a
residential elevator. These three product families—cargo lift, platform lift
and residential elevator—are differentiated by their design, build and
intended functionality. Accordingly, the design and build of each of these
products is controlled by different codes; and, each product within these
families should therefore only be operated according to its intended
functionality.
A platform lift is designed to carry human passengers. Design and build
considerations in this product properly accommodate its intended
functionality—human transport. Nonetheless, it is very important for each
product owner to accept responsibility for safe operations in the use of this
product. It is important to read and heed the safety instructions provided in
this manual, always.
The platform lift is designed to move between two or three levels of a
structurally sound building. It is typically mounted outside the structure,
and typically not in an enclosed runway. This external mounting is one of
the physical distinctions that separate the platform lift from the residential
elevator that is typically mounted within an enclosed runway with lockable
doors protecting the hoist way from unintended human intervention.
The Legacy Lifts® Platform Lift includes a cabin size of approximately 3.6’
X 4’ (maximum 15 SF); a carrying load capacity of 500 pounds; and, travels
up to 18 feet per minute. There is a natural balance between carrying
capacity and travel speed that is inherent to fundamental science; and,
these designs seek optimum. It is constructed of long-lasting aluminum and
stainless steel materials including anti-skidding flooring. It may be
powered-coated for optional improvement of life and aesthetics. There are
other options available as well.
LEGACY LIFTS®, www.legacylifts.com Page 4

The Legacy Lifts® Platform Lift is supplied with a reliable control system for
executing normal up, down, emergency stop and local lockout actions.
Remote control is absent in this design for safety reasons required by code.
Constant pressure on the control is required for the lift to move.
The electrical supply shall include provisions for halting electricity supply
(locking-out) to enhance a safer product environment when the lift is not
attended. Always, lock electrical supply to “off” when not attended.
Dual beam design provides a safer and more stable lift. A durable
enclosed motor transmits electric power to the unit drive reliably. Stainless
steel aircraft quality cable is applied with winding design that reduces cable
wear. Sealed limit switches are provided for additional operating safety and
smoother controlled stops. Design flexibility allows gate placement at time
of order. All of the above features achieve a rugged design that enhances
aesthetics; offers user-friendliness; and, withstands the natural
environment that sometimes can be demanding;
Legacy Lift® reserves the right to make changes or add improvements to
Legacy Lifts® products at any time without incurring any obligation to make
such changes to products previously manufactured. Legacy Lifts® does
not accept responsibility for variations that may be evident relative to the
actual specification of its products and the statements and descriptions
contained in this publication.
SAFETY INSTRUCTIONS
The product owner is responsible for safe handling of the lift at all
times in all circumstances. Therefore, the following safety
instructions are provided for the product owner, and any other person
that the product owner may authorize to operate the lift; as, any
person operating the lift shall have previous training:
1. Never begin operation of the lift until the installer and the product owner
consummate product owner acceptance that shall accompany each
installation. This shall include electrical, mechanical and structural
acceptance with final payment.
LEGACY LIFTS®, www.legacylifts.com Page 5

2. Never allow a person under the age of 18 to operate this lift without
adult supervision.
3. Never allow persons under the age of 18 to be near the lift unattended
when it is operating.
4. Never allow anyone to be within 10 feet of the operating path of this lift
when in operation moving up or down.
5. Never enter lift or be near the unit when under the threat of lightening or
severe weather.
6. Never allow anyone except a qualified service person to enter the
runway of the lift, above or below the car. Similarly, no object or animal
shall be allowed in the runway of the lift; as, a moving lift can cause
severe injury to anyone in the cabin runway.
7. Never exceed rated carrying load capacity.
8. Never by-pass, remove or otherwise disable any control sensors or
safety features.
9. Never operate when showing signs of damage or unusual operations
including unusual noise and/or vibrations; and,
10.Never operate when cables appear to be frayed or damaged.
The product owner’s responsibility for safe handling of this lift
continues as follows:
1. Never operate lift when the cabin gate and/or landing door are not
functioning properly.
2. Never enter lift when car floor is not even with structure floor level.
3. Never lean against lift gate or its controls.
4. Never allow access to car controls except for qualified operators.
5. Never open car or adjacent structure gate when still in motion.
LEGACY LIFTS®, www.legacylifts.com Page 6

6. Never extend any part of body or other object beyond the immediate
perimeter of the cabin from any direction or access point.
7. Never operate lift in the case of fire and/or smoke.
8. Never start-stop or reverse the lift continuously.
9. Never allow anyone to operate the lift when under the influence of
alcohol or drugs; and,
10.Never allow anyone using prescription drugs to operate the lift, as lifts
are considered as moving equipment.
In still continuing the product owner’s responsibility for lift safety, the
following instructions further apply:
1. Never allow children under the age of 18 to access the machinery area
that provides for the lift’s mobility.
2. Never use the lift for cargo or storage. Code prohibits cargo use.
3. Never operate the lift without a properly installed ground fault
interruption device in the electric power supply circuit.
4. Never remove covers from any machinery components.
5. Never attempt to service the lift or any of its machinery unless a
qualified person performs.
6. Never allow unauthorized persons to operate the lift. Remove electric
power at the power supply control box by locking the breaker into the
“off” position when not attended.
7. Never allow anyone to operate the lift if any of the above-stated or other
evidences of safety concern exist; and, declare the unit inoperable by
placing signage on the unit to this effect. Barricade the unit during such
an outage period to prevent access. Finally in this situation, remove
power at the main electrical breaker control box source and do not
operate again until repaired and re-certified for safe operations by
Legacy Lifts® or an Authorized Representative.
LEGACY LIFTS®, www.legacylifts.com Page 7

8. Never attempt to extricate anything from a disabled lift without qualified
assistance, in the event that the lift should stop between normal ingress
and egress points.
9. Never panic but rather stay calm; and,
10.Always seek assistance from a qualified person.
In the event that there are any further questions about the safe
operation of this lift, please contact Legacy Lifts® as provided in this
manual.
SAFETY SIGNAGE
The following safety messages are prominently installed with letters greater
than 1/2”on the lift inside and shall remain throughout the life of unit.
DO NOT ENTER AND DO NOT BE NEAR THIS
UNIT DURING THREAT OF LIGHTNING.
DO NOT ALLOW ANY PERSONS UNDER AGE
18 TO ENTER WITHOUT ADULT
SUPERVISION.
DO NOT EXCEED THE 500 POUNDS RATED
LOAD CARRYING CAPACITY.
LEGACY LIFTS®, www.legacylifts.com Page 8

DO NOT OPERATE WITH ANY PERSON OR
ANY OBJECTS WITHIN 10 FEET OF THE
OPERATING PATHWAY.
DO NOT ALLOW ANY PARTS OF ONE’S
BODY OR OTHER OBJECTS TO EXTEND
OUTSIDE THE UNIT PERIMETER.
DO NOT OPERATE IN THE EVENT OF ANY
UNUSUAL NOISE AND/OR VIBRATION; AND,
CONTACT THE PRODUCT OWNER.
OPERATIONS
Before proceeding with operating this product, please be reminded of
our strong commitment to safety including safe operations of this lift
product and your personal safety. In this serious regard, please
ensure that you have read carefully the safety instructions within this
manual and that you fully understand the product owner’s
responsibility for safe operations of this product, and that you further
understand how to execute that responsibility. If there are any
concerns or doubts about this understanding, please contact Legacy
Lifts® and/or our representation that installed your product before
operating the product.
Legacy Lifts® is fully committed in its design and build for this lift product to
be user-friendly; as, your convenience and personal ease is fully intended
in our product supply. Our representation entities share this intent that
should be evident after this product is made operable. Our instructions for
your convenient operations follow:
1. Engage main power supply electrical breaker.
LEGACY LIFTS®, www.legacylifts.com Page 9

2. Turn “on-off” control key switch further described to its “on” position.
3. Close all doors and/or gates with safety interlocks engaged.
4. Some units are installed with optional devices for additional safety; and,
these devices must be in proper position.
5. There is a four-option control device mounted at each door and within
the lift. Three minimum locations for this device are normal.
6. After satisfying the above required conditions, the operating procedure is
simple as follows:
A. Hold-in the “Up” button (normally “red”) for the platform lift to
move up.
B. Hold-in the “Down” button (normally “green”) for the platform
lift to move down.
•One must apply button pressure continually for the platform to
move and continue moving in either the “up” or “down” direction.
•The red and green colors correlate to the “up” and “down”
directions, respectively, which is industry standard.
C. Push-in the emergency stop button to remove power. Push this
button only in an emergency. This option is provided for safety.
D. Turn the key switch to “off” and remove key when one desires to
disable the lift’s operation and to prevent unauthorized use. This is
provided for safety.
MAINTENANCE
Lift products are designed and built with electrical, electronic, mechanical,
and structural components that operate within an integrated system design;
therefore, periodic maintenance is appropriate. Maintenance enhances
safe operations and further enhances longevity of the product. Legacy
Lifts® strongly recommends that only qualified persons perform all
maintenance.
LEGACY LIFTS®, www.legacylifts.com Page 10

Legacy Lifts® offers with product owner approval an effective maintenance
agreement for the product addressed by this manual. Contact Legacy
Lifts® for this offering, that can be performed in cooperation with our
authorized representation upon consummating a maintenance agreement.
If the product owner elects to not contract for the above offered
maintenance agreement, and further elects to perform product
maintenance alternatively, the following guidance is provided:
1. An inspection should be performed within the 45-90 days of initial
operations to make routine adjustments that may be required by normal
changes in a product’s installed geometry. This need can be caused by
natural physical changes in product components resulting from normal
product loading and/or local environmental conditions. This need may
also be caused by changes and/or shifts in the adjacent structure.
2. A full inspection should be performed at least twice per year, every
year regardless of the amount of operations.
3. A full operational check of the product’s control system, including the
individual components that comprise the control system, should be
performed within the above recommended semi-annual inspections.
Other instruction for the above recommended maintenance and service
follows:
1. Legacy Lifts® applies stainless steel aircraft quality cable in its lift
design; and, this cable should be inspected at least semi-annually for
damage, misalignment, improper winding and/or wear. If the cable is
damaged or misaligned, it could cause premature wear or cable failure.
The Legacy Lifts® design reduces the potential for common
misalignment cable consequences by using winding design that ensures
better cable alignment, thereby reducing wear.
2. The inclusion and proper operation of limit switches are critically
important components within the electrical-electronic-mechanical
components that control the lift. These switches are set precisely during
the build and installation of a lift; nonetheless, it is recommended that a
LEGACY LIFTS®, www.legacylifts.com Page 11

qualified person inspect the settings and operability of the switches,
(again) at least semi-annually.
3. Roller wheels should be lubricated semi-annually. They should not be
over-lubricated; as, this can result in unintended lubricant on the I-beam
surface where a mechanical brake is designed to engage. Lubricant on
this I-beam surface will make the mechanical brake less effective.
Never operate this product before properly addressing the following
conditions:
1. Evidence of any structural deterioration, of either the product and/or its
adjacent mating structure;
2. Evidence of frayed cables;
3. Evidence of unusual noise and/or vibration; and,
4. Evidence of lubricant on the I-beam surface where the mechanical brake
is designed to engage if and when actuated. Lubricant must be removed
from this surface before further operations regardless of its source or
nature.
5. For lift baskets lined with clear structural material, never spray Windex,
ammonia or alcohol containing fluids on these lining materials. These
prohibited fluids will damage the clear structural lining material including
UV effectiveness. Always use approved cleaning fluid; e.g.,
Kleenmaster™ supplied by Brillianize, Inc. (www.BRILLIANIZE.com).
A qualified service person may perform still other maintenance
recommendations that may enhance aesthetics.
PREPARATIONS FOR HURRICANE
The following preparations should be made for an anticipated hurricane;
and, these preparations should be made substantially before the dangers
of the hurricane occur.
1. Lower the lift to the lowest position in cases of anticipated high wind.
LEGACY LIFTS®, www.legacylifts.com Page 12

Note: If only high water is anticipated (without high wind), the lift may be
raised to the highest position to reduce high water damage.
2. Remove electric power by opening the main electricity supply breaker.
3. If the lift has experienced unusually high winds and/or water exposure
by flooding, the unit shall not be operated until re-qualified for service by
an authorized service person.
TECHNICAL
The Legacy Lifts® Cargo Lift is designed and manufactured to comply with
local codes mutually agreed at each order confirmation by Legacy Lifts®
and its authorized representation. In the absence of other controlling
codes, ASME A18.1-2011 (Revision of ASME A18.1-2008) is followed.
LIMITED WARRANTY with EXTENSION OPTION
For LEGACY LIFTS® LIFT PRODUCTS
When the Legacy Lifts® lift product is installed, adjusted and operated in
accordance with Legacy Lifts® instructions, with normal use and regular
maintenance and service, Legacy Lifts® will, for a period of 365 days from
the date of substantial installation, repair defects in workmanship for the
equipment at no charge. Exceptions include: cable and remote control
transmitters. The gear reducer and motor are warranted for two (2) years.
The structure is warranted to a generous five (5) years. Legacy Lifts®
replacement parts in a warranty case shall perform for the term of the
original warranty period repaired or replaced at the discretion of the dealer.
LEGACY LIFTS®, www.legacylifts.com Page 13

Regarding DIYY warranty, the part in question will be sent back to Legacy –
to be tested, repaired or replaced, then returned.
This Limited Warranty extends to the original product owner and is not
transferable; however, Legacy Lifts® may optionally agree in writing at
order consummation that a builder may hold temporary ownership for an
agreed number of days, prior to granting ownership to its intended product
owner with normal warranty. In the case of temporary builder ownership,
Legacy Lifts® authorized personnel shall physically inspect and certify that
the lift retains original design and manufacture credibility before the builder
transfers ownership with normal warranty. Any issues noted during the
Legacy Lifts® mandatory inspection shall be reconciled before transfer.
The Limited Warranty applies to residential property installations utilized by
the original product owner or family member(s) only, and is not valid on
property used for commercial or rental purposes. Acts of God; misuse and
abuse; operator error; neglect; normal wear and tear; use beyond rated
capacity; unsuitable power source; unfavorable environmental conditions;
and, unauthorized repair, modification and/or alteration are excluded from
Limited Warranty. This Limited Warranty applies to services rendered
during normal business hours of 7:30 am to 5:30 pm in the local time zone
Monday through Friday, excluding national holidays. Services rendered or
extended beyond these normal business hours shall be subject to Legacy
Lifts® service charges and restrictions.
Performance under this Limited Warranty is specifically subject to the
product owner acknowledging in writing to Legacy Lifts® or its authorized
representation that original installation is satisfactory including electrical,
mechanical and structural considerations. This warranty performance is
also subject to the product owner registering for warranty per the enclosed
form for this purpose. Notwithstanding completion of the above acceptance
acknowledgment and registration for warranty, Legacy Lifts® commitment
and responsibility hereto begins upon substantial installation.
Legacy Lifts® does not recommend, and is not responsible for any
modifications, alterations, or installations to its products that are not made
by Legacy Lifts® personnel or their authorized representatives, nor
LEGACY LIFTS®, www.legacylifts.com Page 14

replacement of worn or damaged parts from another manufacturer. This
Limited Warranty specifically excludes products or components installed by
others not authorized by Legacy Lifts®. This Limited Warranty also
excludes installation of products or components by others not in
compliance with applicable codes governed by bodies having jurisdiction
over the installation site. The product owner shall hold Legacy Lifts®
harmless for all claims subject to “Work Done by Others.” In cases where
the Legacy Lifts® product, parts or components are altered in any way by
another entity (non Legacy Lifts®), Legacy Lifts® and its authorized
representation reserve the right to void warranty.
No Legacy Lifts® employee or representative is authorized to change the
foregoing warranties in any way or grant any other warranty on behalf of
Legacy Lifts®.
Legacy Lifts® makes no other express warranties to the purchaser of this
product except as set forth above. This warranty covers a consumer
product. No warranties, expressed or implied, (including, but not limited to,
the warranty of merchantability or fitness for a particular purpose), shall
extend beyond the applicable time period stated above and from the date
the product is substantially installed, in sole opinion of Legacy Lifts®. User
is responsible for determining whether the Legacy Lifts® product, as
installed, is fit for a particular purpose and suitable for the product owner’s
method, use and application. Legacy Lifts® is not responsible for any
incidental, consequential or punitive damages resulting from the use of this
product whether direct, indirect, special, incidental or consequential,
regardless of the legal theory asserted, including warranty, contract,
negligence, strict liability or other. Legacy Lifts® liability for any damages
from use of this product or breach of any implied warranty is limited solely
to repair or replacement of parts in accordance with the terms set forth
above and these are the exclusive remedies available to the purchaser.
In the event this Limited Warranty is subject to any U.S. State
Condominium or other Governmental Act requiring an extension to the
warranty period for an additional charge per unit per year of extension; and/
or, if the product owner so elects, Legacy Lifts® offers an extended
LEGACY LIFTS®, www.legacylifts.com Page 15

warranty at a quoted price that shall be due and payable to Legacy Lifts®
upon commencement of Limited Warranty.
EXTENDED WARRANTY OPTION
FOR LEGACY LIFTS® LIFT PRODUCTS
In addition to the limited warranty, Legacy Lifts® provides an extended
warranty when elected and contracted by the product owner. The extended
warranty provides coverage for the same components as provided in the
limited warranty except that the period of coverage is three years as
opposed to one year. The warranty exceptions remain the same as in the
limited warranty; likewise, the structural warranty provisions in the extended
warranty remain the same as in the limited warranty. In summary, the
extended warranty extends coverage on the drive motor, drive gearbox and
limit switches to three years.
MAINTENANCE AGREEMENT IS AVAILABLE BY CONTACTING
LEGACY LIFTS® AT 903-451-2507.
REGISTRATION FOR WARRANTY
Product Owner shall complete this form and return to address below
within 10 calendar days of install date to register and validate
warranty.
Legacy Lifts®, 6556 State Highway 198, Mabank, Texas 75156
903-451-2507; 800-597-5438; FAX: [phone]; www.legacylifts.com
Product I.D.: _________________________________________________
Date of Purchase: ____________________________________________
Install Date: _________________________________________________
Installer: ____________________________________________________
Building Contractor: ___________________________________________
____________________________________________________________
LEGACY LIFTS®, www.legacylifts.com Page 16

Product Owner Identification with Contact Information
Full Name: __________________________________________________
Physical Address: ____________________________________________
____________________________________________________________
____________________________________________________________
Mailing Address: _____________________________________________
____________________________________________________________
Primary Phone No.: ___________________________________________
Secondary Phone No.: _________________________________________
Primary Email Address: ________________________________________
Secondary Email Address: _____________________________________
Product Owner’s Signature ____________________________________
RECORD of PRODUCT SERVICE
Legacy Lifts®, 6556 State Highway 198, Mabank, Texas 75156
903-451-2507; 800-597-5438; FAX: [phone]; www.legacylifts.com;
Product I.D. _________________________________________________
____________________________________________________________
Install Date: _________________________________________________
Installer: ____________________________________________________
PRODUCT SERVICE RECORD (Page 1)
Date
Service By
Notes
LEGACY LIFTS®, www.legacylifts.com Page 17

PRODUCT SERVICE RECORD CONTINUED (Page 2)
Date
Service By
Notes
LEGACY LIFTS®, www.legacylifts.com Page 18

LEGACY LIFTS®, www.legacylifts.com Page 19

LEGACY LIFTS®, www.legacylifts.com Page 20
