Legacy LSWR-7100 User manual

7.2 ROOFMOUNT TFT-LCD MONITOR
YOU'RE NOWREADY FOR
MORE FUN ON
THE ROAD THANEVER BEFOR
7.2 ROOF MOUNTTFT LCDMONITOR
OWNERS MANUAL
YOU'RE NOWREADY FORMORE FUN ONTHE ROADTHAN EVERBEFORE
WWW.LEGACYCARAUDIO.COM
LSWR-7100

7.2 ROOFMOUNT TFT- LCDMONITOR
OSDADJUSTMENT
1. Press thePOWER ON/OFF buttonon the monitoror remote unitto turn onthe power.
a.Touch power switchon the monitorto select video/audioinputs.
b.Press powerswitch on themonitor 2 secondto turn off the monitor
2. Press MENUbutton on themonitor or remoteunit to activethe OSD functionshow on the
LCD screen andpress again toselect the adjustmentitem as below.
BRIGHTNESS
CONTRAST
COLOR
VOLUME
SATURATION
3. Press UP/DOWNbutton on themonitor or remoteunit to increaseor decrease thevalue of
the adjustment functionsfor optimum viewing.
REMOTE CONTROLUNIT
POWER on/off
FEATURESON SCREEN DISPLAY CONTROL
ON SCREEN DISPLAY CONTROL
WIDE SCREEN LCDPANEL
SUPER BRIGHTLCD PANEL
FM signal outputfor wireless headphone
4. WIRE CONNECTION
Red wire: +ve
Black wire: -ve
Violet wire:none
YellowRCA Jack:Video1 In
White RCAJack: Vudio2 In
5. ACCESSORIES
EXTENSION MINIDIN CABLE1PC
REMOTE CONTROLUNIT 1PC
VIDEO CABLE 1PC
MOUNTING PLATE 1 PC
6.LCD MONITORREMOTE CONTROL
DISPLAY 7.2 WIDE SCREEN TFT-LCD
BACK LIGHT BUILTIN CCFT
DOT FORMAT 1440 x480
VIDEO INPUT LEVEL COMPOSITE 1.0V P-P/75 OHMS
VIDEO INPUT SYSTEMS NTSC AUTO SWITCHING
POWER SOURCE DC 12V+/- 15%
POWER CONSUMPTION 700Ma (max) / 10w (max)
OPERATIONTEMPERATURE -20 Celcius to+ 75 Celcius
STORAGE TEMPERATURE -30 Celcius to+ 85 Celcius
DIMENSIONS 210 (W)x182 (H)x38.5 (D)mm
NET WEIGHT 0.9KGS
SPECIFICATIONS:
Power on /off
Color
Contrast
Volume
Brightness
Select
Mute
Mode
Up/down
Left/right
Video1/video2
